United States Stove Company WONDERCOAL 2847 Owner's Manual

Automatic coal burning circulator heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version

HOW TO ORDER REPAIR PARTS

This manual will help you to obtain efficient, dependable service
from the heater, and enable you to order repair parts correctly.
Keep this manual in a safe place for future reference.
When writing, always give the full model number which is on the
nameplate attached to the inside of the cabinet door of the
heater.
When ordering repair parts or options, always
give the following information as shown in the list:
1. The PART NUMBER
2. The PART DESCRIPTION
3. The MODEL NUMBER: 2847
4. The SERIAL NUMBER:________________
Before installing your heater, fill in the serial number of your
heater in the space provided above.
United States Stove Company
227 Industrial Park Rd.
P.O.Box 151
South Pittsburg, TN 37380
(423) 837-2100

Owners Manual

Model 2847
WONDERCOAL
AUTOMATIC COAL BURNING CIRCULATOR HEATER
*ASSEMBLY
*INSTALLATION
*OPERATION
*REPAIR PARTS
SAFETY NOTICE:
If this heater is not properly installed, a house fire may result.
For your safety, follow the installation directions.
Contact local building or fire officials about restrictions and
inspection requirements in your area.
CAUTION:
Read all instructions carefully before starting the installation
or operation of this heater.
Improper installation may void your warranty.
DO NOT USE THIS HEATER IN A MOBILE HOME OR TRAILER
United States Stove Company
227 Industrial Park Rd.
P.O.Box 151
S
C
U
S
South Pittsburg, TN 37380
(423) 837-2100
WARNOCK HERSEY
R
851171A 3/96

Advertisement

Table of Contents
loading

Related Manuals for United States Stove Company WONDERCOAL 2847

Summary of Contents for United States Stove Company WONDERCOAL 2847

  • Page 1: Owners Manual

    1. The PART NUMBER 2. The PART DESCRIPTION 3. The MODEL NUMBER: 2847 4. The SERIAL NUMBER:________________ Before installing your heater, fill in the serial number of your heater in the space provided above.

  • Page 2: Tools And Material Needed

    TOOLS AND MATERIAL NEEDED TOOLS Pencil Chimney Connection- 6" Dia. Black 6 Foot Folding rule or tape Steel (24 Ga. minimum): Straight or Tin Snips Corrugated Elbow (as required)* Drill, hand or electric 1/2" Sheet Metal Screws Drill bit, 1/8" dia. 6"...
  • Page 3 F36 BLOWER KIT An Optional Blower Kit is available for the 2847 Wondercoal automatic coal burning circulator heater. If this kit is not available where you have purchased this Wondercoal heater, you can purchase the F36 Blower Kit directly from the factory.

  • Page 4: Locating The Heater

    CAUTION: Keep furnishings and other combustible materials away from the heater. 21" Fig. 3 20" TROUBLE SHOOTING TIPS FOR MODEL 2847 LIST OF PROBLEMS POSSIBLE CAUSE 1. Smoking when feed A) Insufficient Draft. door is open. B) Clogged chimney or chimney connector.

  • Page 5: Chimney Connection

    As of April 1, 1987, all heaters Do not expect your stove or furnace to and furnaces manufactured by United create draft. Draft is not a function of the States Stove Company should be appliance.
  • Page 6 FLOOR PROTECTOR 3 FT. 11 FT. MIN. MIN. APPROVED COWL 3 FT. MIN. REPAIR PARTS LIST - MODEL 2847 (SEE PAGE 20) AUTOMATIC COAL BURNING CIRCULATOR Key No. Description Shaker Handle Second Heat Shield Heat Shield Draft Damper Hinge Pin...
  • Page 7 VENTING INTO A FIREPLACE Many people may wish to convert an Many prefabricated fireplaces fall into existing fireplace to heater use. Usually, the "zero-clearance fireplace" category. safe connection of stovepipe to a ma- This is a factory metal fireplace with sonry chimney requires more effort than multilayered construction.

  • Page 8: Repair Parts

    They do not meet code and are not recom- mended. quite durable, most REPAIR PARTS AUTOMATIC COAL BURNING CIRCULATOR HEATER MODEL NUMBER 2847 (SEE PAGE 18) REPAIR PARTS LIST KEY NO. PART NO. DESCRIPTION 89062 Door Knob 83005 10-24x1/2"...
  • Page 9 5. To close and latch the door, reverse steps 2 thru 4. NOTE: THIS NEW LATCHING MECHANISM MEETS CODES AND PROVIDES MORE SAFETY FOR THE USER OF THIS STOVE. Fig. 11 NOTE: DURING OPENING AND CLOSING OF THE FEED AND ASH DOORS OF THIS HEATER, IT MAY SEEM THAT THE FIT OF THE DOOR IS "TOO TIGHT".

  • Page 10: Service Hints

    SERVICE HINTS 4. If the flue is too cool, water will condense in the chimney and run back into the stove. Creosote formation will be rapid and may block the chimney. Operate the heater at a high enough fire to keep the chimney warm preventing this condensation.
  • Page 11 MULATE AND EXPLODE. NEVER A WAX-TYPE BINDER. SMOTHER A FIRE WHEN ADDING WARNING: THE USE OF WOOD IN FRESH COAL. THIS STOVE EXCEPT FOR COAL IG- NITION PURPOSES, IS A VIOLATION CAUTION: NEVER USE GASOLINE, GASOLINE-TYPE LANTERN FUEL, OF FEDERAL LAW.
  • Page 12 2-5/16" and 4-3/8". Note tures which can cause warpage or burnout. that it is important to the life of your stove to buy coal which has been sized and cleaned. For overnight operation (long duration burn...
