Using the ProConnect
Switch
Hot Plugging
The 8-Station KVM Switch supports hot plugging - cables can be connected or
unplugged without turning off the switches power. In order for hot plugging to
work properly, however, these procedures must be followed:
•
Hot Plugging CPU Ports
CPU port cables can be unplugged if necessary without powering down the
switch. If you reconnect the Cabling Kit (available from your nearest Linksys
dealer) to the same port on the switch, the switch will immediately recognize
the PC. If you connect it to a different CPU port, the switch will need to rede-
tect and initialize the connection.
•
Hot Plugging Console Ports
The switch supports limited hot plugging of the keyboard, monitor, and mouse.
Keyboards and monitors can be hot plugged on the Console ports. When hot
plugging the mouse from the Console's mouse port, however, the follow should
be considered:
1. You may unplug the mouse and plug it back in again (to reset the mouse,
for example), as long as you use the exact same mouse.
2. If you plug in a different mouse, all of the switches and all the PCs con-
nected to the switches must be shut down and restarted. (Refer to the
Powering Off and Restarting section the follows.)
NOTE: If there is no response to mouse and/or keyboard
input, simultaneously press and hold Port Selection buttons
1 and 2 on the Primary 8-Station KVM Switch for several
seconds to reset the keyboard and mouse connection.
10
ProConnect
Series
®
®
8-Station KVM
ProConnect
®
8-Station KVM Switch
Powering Off and Restarting
If it becomes necessary to power down an 8-Station KVM Switch, you must
perform the following prior to starting it back up:
1. Shut down all the PCs that are attached to the 8-Station KVM Switch, along
with all other switches and PCs daisy chained.
2. Unplug the switch's AC power cord.
3. After a minute, reconnect the power along with any PCs and daisy chained
switches, starting with the last connection in the chain and working back to
the Primary switch.
4. After all of the connections have been made, power on the Primary switch
and then any switches daisy chained. Next, power on the PCs connected.
Port Selection
The 8-Station KVM Switch provides three methods for obtaining instant access
any computer connected: Manual, Hotkey, and OSD (On Screen Display).
•
Manual
Simply press the appropriate Port Selection switch on the switch's front panel
to select the computer connected to the corresponding port. After you press the
switch, the Selected LED lights to indicate that the port is currently selected.
When using the OSD function (as shown in Using the OSD Function), you
can initiate a Quick View Scan to cycle amongst the active ports.
•
HotKey Navigation
HotKey navigation allows you to conveniently access any computer directly
from the keyboard, instead of having to manually select it with a Port Selection
switch. Use the following method for HotKey navigation:
1) Press [CTRL] + [ALT] + [SHIFT] in sequence (not at the same time) to
invoke the HotKey function.
2) Key in the Port ID number (as shown in the following section), then press
the Enter key. The Port ID number must be typed within one second of
invoking HotKey navigation and should be typed from the keyboard, not the
number pad.
