Lindy 25004 Product Manual

8 Port Gigabit Smart Switch
1. Default IP Address:
Default IP mask:
Default gateway:
Default Password:
2. Terminal mode:
Baud rate:
Attribute:
Default Password:
Press "?" for the first page, then choose a command by typing lower case
Press "?" after each command to get a command description
Type "up" or "/" to go back to the previous page
3. Firmware update:
When a new firmware version is released for added functions or bug fixes, you can go
to the web interface and select the "Firmware Update" command. Follow the on
screen instructions to upload the new code. Once the new code has uploaded, you
must activate it by pressing the "Reset" button on the front panel. NOTE: a new
default setting may also be updated as different versions sometimes have different
default settings. Please log back in to the web interface to see the changes.
Part No.25004
192.168.223.100
255.255.255.0
192.168.223.254
"admin" (for F/W Version V3.7 or later)
115,200
n, 8, 1, none
"admin" (for F/W Version V3.7 or later)
