- Page 1 ™ POWER WAVE WELDING SYSTEMS ™ WITH POWER FEED 10 AND 10 DUAL Premium MIG Welding Systems...
- Page 2 POWER WAVE WELDING SYSTEMS Simple. Innovative. Technologically Advanced. These are all words that describe the Power Wave welding systems. These next generation systems utilize Waveform Control Technology™ for the finest welding arc in the industry. POWER SOURCE The Power Wave 455 is a high efficiency inverter designed for unprecedented ease of use and performance.
-
Page 3: Technical Specifications
TECHNICAL SPECIFICATIONS POWER SOURCE Product Ordering Input AC Name Information Voltage Power K1517-5 208/230/460 Wave 3 Phase 50/60 Hz K1517-2 460/575 3 Phase 60 Hz K1517-3 380-415 CE 3 Phase 50 Hz WIRE FEEDER Ordering Power Feed 10 Information BENCH MODEL K1541-2 BOOM READY MODELS: 16-18 ft. -
Page 4: A Closer Look
A CLOSER LOOK Large, Easy To Read Digital Meter Large, Easy To Use Wire Feed Speed/ Control Amperage Dual Head Select Panel (Standard on Power Feed 10 Dual Models) Weld Mode Selector Switch (Standard on Power Feed 10 and 10 Dual) SYSTEM SELECTION Typical MIG welding systems. - Page 5 OPTIONAL CONTROL PANELS PROCEDURE CONTROL PANELS POWER FEED 10 POWER FEED 10 DUAL DUAL PROCEDURE PANEL This panel stores two procedures in memory. The user may select procedure “A” or “B” at the switch with a separate gun mounted switch, or while welding with any welding gun. Order K1542-5.
- Page 6 OPTIONAL CONTROL PANELS PROCESS CONTROL PANELS POWER FEED 10 & 10 DUAL M PANEL This optional control panel allows the user to select the type of output desired: CV-MIG/CV Gas-Shielded, Flux-Cored (Outershield,Metal-Cored), Flux-Cored (Innershield), or CC- Stick (Soft)/Gouge. The “Arc Control “ varies inductance in the CV modes and arc force in the CC-Stick mode.
- Page 7 NEW WIRE DRIVE ADVANTAGES • Four gear driven rolls. No tools needed to snap rolls on or off. Each roll has two grooves of the same size to double feed life. • Revolutionary Split Wire Guide precisely aligns and supports wire through the entire system.
- Page 8 FEED PLATE GUN RECEIVER BUSHINGS One of the following Gun Receiver Bushings is required for connecting gun and cable assemblies to the feed plate. K1500-1 Gun Receiver K1500-2 Gun Receiver Bushing (Optional) Bushing • Magnum 200 and 400 fully • Magnum 200, 300 and 400 assembled guns (K497-2X gun and cable assemblies and K471-2X).
- Page 9 DRIVE ROLLS AND SPLIT WIRE GUIDE KITS 4 Roll, and Split Wire Guide Solid Steel Wire, Smooth V Groove .023-.030 (0.6-0.8mm) Solid .035 (0.9mm) Solid .040-.045 (1.0-1.2mm) Solid .052 (1.4mm) Solid 1/16” (1.6mm) Solid Cored Steel Wire, Knurled V Groove .030-.035 (0.8-0.9mm) Cored .040-.045 (1.0-1.2mm) Cored .052 (1.4mm) Cored...
-
Page 10: Control Cables
LINC-NET CONTROL CABLES These come standard with both bench and boom versions of the Power Feed 10 and Power Feed 10 Dual wire feeders. The Linc-Net con- trol cable has several advantages over existing control cables: • Common cable for all parts - The same cable can be used between the power source and wire feeder in a bench system and between the... - Page 11 RECOMMENDED OPTIONS Caster Kit - Light Duty Mounts to the wire reel stand on the Power Feed 10 and Power Feed 10 Dual. Allows for easy movement of wire feeder. Order K1556-1. K1556-1 Insulated Lift Bail Allows the entire wire feeder to be hung from a crane or hook.
- Page 12 We respond to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such information or advice. We expressly disclaim any warranty of any kind, including any warranty of fitness for any customer’s particular purpose, with respect to such informa-...
