INTRODUCTION
This service manual describes the latest service information
for the IC-M32 VHF MARINE TRANSCEIVER at the time of
publication.
To upgrade quality, all electrical or mechanical parts and
internal circuits are subject to change without notice or oblig-
ation.
Model
Version
U.S.A.
IC-M32
S.E. Asia
Australia
DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 10 V. This will ruin the
transceiver.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100mW)
to the antenna connector. This could damage the transceiv-
er's front end.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1110003200 S.IC TA31136FN
8930060730
2691 keyboard
Addresses are provided on the inside back cover for your con-
venience.
1. Make sure a problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 40 dB to 50 dB attenuator between the transceiver and a deviation meter or spectrum analyzer when using
such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.
Symbol
AC adapter
TX high power
[USA]
BC-147A
[SEA]
BC-147E
[AUS]
BM-95V
IC-M32 MAIN UNIT
IC-M32 Chassis
5W
1 piece
5 pieces
REPAIR NOTES
