Grandstream Networks, Inc.
DP715/DP710
DECT Cordless IPPhone

Advertisement

Table of Contents
loading

Related Manuals for Grandstream Networks DP715

Summary of Contents for Grandstream Networks DP715

  • Page 1 Grandstream Networks, Inc. DP715/DP710 DECT Cordless IPPhone...
  • Page 2 This page is intentionally left bank...

  • Page 3: Table Of Contents

    SAFETY COMPLIANCES .......................... 7 WARRANTY ............................... 7 CONNECT YOUR DP715/710 ..............9 EQUIPMENT PACKAGING ........................9 CONNECTING THE DP715 BASE STATION .................... 9 CONNECTING THEDP710 CHARGER UNIT ..................11 SETTING UP THE DP715/710 HANDSET ....................11 PRODUCT OVERVIEW ................13 SOFTWARE FEATURES OVERVIEW.....................
  • Page 4 ADVANCED USER CONFIGURATION ....................41 SAVING THE CONFIGURATION CHANGES ..................50 REBOOTING THE DP715 BASE STATION FROM REMOTE ..............50 CONFIGURING THE DP715 BASE STATION THROUGH A CENTRAL SERVER ......... 50 SOFTWARE UPGRADE ................51 FIRMWARE UPGRADE THROUGH TFTP/HTTP/HTTPS ............... 51 INSTRUCTIONS FOR UPLOAD FROM LOCAL DIRECTORY ..............
  • Page 5 Table 1: EQUIPMENT PACKAGING ....................9 Table 2: DEFINITIONS OF THE DP715 CONNECTORS ............. 10 Table 3: BASIC DEFINITIONS OF THE DP715 LEDS PATTERN ..........10 Table 4: ADVANCED DEFINITIONS OF THE DP715 LEDS PATTERN........10 Table 5: DP715/DP710TECHNICAL SPECIFICATIONS .............. 13 Table 6:DP715/710 HARDWARE SPECIFICATIONS ..............

  • Page 6: Gnu Gpl Information

    GNU GPL INFORMATION The DP715/710 firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license.

  • Page 7: Change Log

    Added option [ ] under Profiles. Authenticate incoming INVITE • Updated new LED pattern table: Table 4: ADVANCED DEFINITIONS OF THE DP715 LEDS PATTERN CHANGES FROM 1.0.0.5 USER MANUAL • Added option [Update Handset Time] under Advanced Setting. Firmware version 1.0.0.31...
  • Page 8 This page is intentionally left bank Firmware version 1.0.0.31 DP715/DP710 User Manual Page 6 of 56...

  • Page 9: Welcome

    Their compact size, superb voice quality, rich feature set, market leading price-performance and wide range radio coverage enable consumers to maximize the power of IP voice application and mobility for a minimum investment. The DP715/710 is SIP and DECT compliant and field proven for flexible deployment.
  • Page 10 User Manual, could void your manufacturer warranty. Please do not use a different power adaptor with the DP715 as it may cause damage to the products and void the manufacturer warranty.

  • Page 11: Connect Your Dp715/710

    CONNECTING THE DP715 BASE STATION To setup the DP715 Base Station, follow the steps below: 1. Connect the Network port of the DP715 to the RJ-45 socket of a hub/switch or a router (LAN side of the router) using the Ethernet cable provided.

  • Page 12: Table 2: Definitions Of The Dp715 Connectors

    10/100Mbps RJ-45 port toconnect to the network. (RJ-45) RESET Factory Reset button: Press for 7 seconds to reset factory default settings. Table 3: BASIC DEFINITIONS OF THE DP715 LEDS PATTERN LEDs POWER LED Indicates Power. Remains green when power is connected, and orange when handset is connected for charging.

  • Page 13: Connecting Thedp710 Charger Unit

    1 Underside of the charger unit 2 Powersupply plug Figure 2: CONNECTING THE DP710 CHARGER UNIT SETTING UP THE DP715/710 HANDSET To setup the handset, follow the steps below: 1. Open the battery compartment (see below). 2. Insert the batteries in the correct polarity (+ and -).
  • Page 14 This page is intentionally left bank Firmware version 1.0.0.31 DP715/DP710 User Manual Page 12 of 56...

  • Page 15: Product Overview

    PRODUCT OVERVIEW The DP715/710 is the next generation of powerful, affordable, high quality and simple to configure DECT Cordless IP Phone for small business and residential users. Their compact size, superb voice quality, rich feature set, market leading price-performance and wide range radio coverage enable consumers to maximize the power of IP voice application and mobility for a minimum investment.

  • Page 16: Hardware Specifications

    18 different ringer melodies are available to indicate an incoming call (internal intercom Polyphonic Ringtones or external VoIP) HARDWARE SPECIFICATIONS The table below lists the hardware specifications of the DP715/710. Table 6:DP715/710 HARDWARE SPECIFICATIONS Input: 100–240 VAC, 50-60 Hz, 0.15A; Output: 6VDC, 500mA (for Base Station)

  • Page 17: Using The Dp715/710 Handset

    USING THE DP715/710 HANDSET GETTING FAMILIAR WITH THE HANDSET The DP715/710 Handset has a dynamic screen. The screen displays differently depending on whether the handset is idle or in use (active screen). HANDSET KEYS DESCRIPTION 1. Display 2. Right display button (display functions) 3.
  • Page 18 Decrease the volume during the call. Internal Call key : Allows you to make an internal call to any Handset registered to the same DP715 Base Station Standard telephone keypad. The # key can act as a send key. In the input mode, if an English alphabet needs to be entered, press the corresponding numerical key multiple times.

  • Page 19: Handset Display Structure (Lcd)

    Table 8: LCD ICONS Icon LCD Icon Definitions On Hook. Off Hook. Ringing. Handsfree Speaker ON. Missed Calls Notification. Upper Case. Lower Case. Navigate Through Menu Items. Handset Ringer Off. Alarm Set. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 17 of 56...

  • Page 20: Handset Menu Structure

    You can press the key at any time to cancel and return to standby mode. If you do not press any key, the handset automatically reverts to standby mode after 20 seconds. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 18 of 56...

  • Page 21: Handset Menu Overview

     Every Day: Same Alarm will be triggered everyday at the same time. Time  Mon to Fri: Same Alarm will be triggered from Monday to Friday  Off: Turn Off the Alarm. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 19 of 56...

  • Page 22: Handset Menu Description

    – New: Unread or unanswered call. – Old: Read or answered call. – Repeat: Multiple calls of the same number. Only the last call is shown. 3. Press to display further entries in the list. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 20 of 56...

  • Page 23: The Phonebook

    2. Enter the initial letter of the name using the alphanumeric keys. 3. The first name in the list with this letter appears in the display. 4. Press repeatedly to scroll through the other numbers in the phonebook. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 21 of 56...
  • Page 24 Show Details and press 5. The name, phone number and ringer melody you have assigned to the entry appears in the display. 6. Press to return to the list of entries. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 22 of 56...

  • Page 25: Selecting The Menu Language

    You can now talk freely without the other party hearing you. Press Off again to switch the microphone back on. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 23 of 56...

  • Page 26: Setting The Ringer Volume On The Handset

    7. The current melody is displayed and can be heard. 8. Press repeatedly, to select the desired melody. 9. Press Saveto confirm your selection, or press to quit the menu without saving the setting. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 24 of 56...

  • Page 27: Setting The Key Lock

    6. Press repeatedly to select the desired contrast level (8 contrast levels). 7. Press Saveto confirm your selection or press to quit the menu without saving the setting. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 25 of 56...

  • Page 28: Edit Handset Name

    9. Select Off to turn off the alarm function. Confirm with Switching the Alarm Off 1. Switch the alarm off when it sounds by pressing Stop. 2. Press Snooze to repeat the alarm function 5 minutes later. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 26 of 56...

  • Page 29: Appointments

    5. Press Stop, to stop the watch. 6. Press Start again to allow the stop watch to continue to run. 7. Press Reset to reset the stop watch to 00:00. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 27 of 56...
  • Page 30 This page is intentionally left bank Firmware version 1.0.0.31 DP715/DP710 User Manual Page 28 of 56...

  • Page 31: Basic Operations

    UNDERSTANDING DP715/710 VOICE PROMPT DP715 Base Station has a built-in voice prompt menu for simple device configuration. The IVR menu work with any Handset registered to the base. Pick up the handset and dial “***” to use the IVR menu.

  • Page 32: Registering A Handset To The Dp715 Base Station

    REGISTERING A HANDSET TO THE DP715 BASE STATION You can register up to 5 handsets to one DP715 base station. Each handset can, for its part, be registered to up to four base units and the user can choose which base unit he wishes to use. In the default setting as supplied, each handset is registered as Handset 1 to Base unit 1.

  • Page 33: Completing Calls

    ANSWERING CALLS The handset starts ringing during an incoming call; you have the following options to answer: a. Press to pick up the call. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 31 of 56...

  • Page 34: Internal Calls

    INTERNAL CALLS In some cases a user may want to make phone calls between the handsets registered to the same DP715 Base Station when it is used as a standalone unit, without the use of a SIP server. This feature will also be applicable when the DP715 Base Station is used with Hunting Groups and is registered to SIP server only with one master number.

  • Page 35: Call Hold

    A quick confirmation tone (similar to call waiting tone) followed by a dial-tone: This indicates the transfer is successful (transferee has received a 200 OK from transfer target). At this point, Caller A can either hang up or make another call. Firmware version 1.0.0.31 DP715/DP710 User Manual Page 33 of 56...

  • Page 36: 3-Way Conferencing

    “flash” to resume call with Caller B. Note:When Attended Transfer fails and A hangs up, the DP715 will ring back user A to remind A that B is still on the call. A can pick up the phone to resume conversation with B.

  • Page 37: Call Features

    CALL FEATURES The DP715/710 supports all the traditional and advanced telephony features. Table 10: DP715/710 CALL FEATURE DEFINITIONS Call Features Forcing a Codec (per call) *027110 (PCMU), *027111 (PCMA), *02723 (G723), *02729 (G729), *0272632 (G726-r32),*027201 (iLBC) Enable SRTP Disable SRTP...
  • Page 38 This page is intentionally left bank Firmware version 1.0.0.31 DP715/DP710 User Manual Page 36 of 56...

  • Page 39: Dp715 Base Station - Configuration Guide

    Select voice menu option 01 to enable DP715 to use DHCP. STATIC IP M Select voice menu option 01 to enable DP715 to use STATIC IP mode, then use option 02, 03, 04, 05 to set up IP address, Subnet Mask, Gateway and DNS server respectively.

  • Page 40: Important Settings

    Note:Most settings on the web configuration pages are set to the default values. NAT Settings If you plan to keep the DP715 Base Station within a private network behind a firewall, we recommend using STUN Server. The following three (3) settings are useful in the STUN Server scenario: 1.

  • Page 41: Table 11: Basic Settings

    DHCPmode: all the field values for the Static IP mode are not used (even though they are still saved in the Flash memory.) The DP715 acquires its IP address from the first DHCP server it discovers from the LAN it is connected. Using the PPPoE feature: set the PPPoE account settings.

  • Page 42: Dp715/Dp710 User Manual

    Shows system up time since the last reboot. PPPoE Link Status Indicates whether the PPPoE connection is up if the DP715 is connected to DSL modem. This filed indicates the type of NAT connection used by the DP715. Base Status Displays relevant information regarding the Handset subscription status.

  • Page 43: Advanced User Configuration

    TCP port where the HTTP or HTTPS server is listening; it can be omitted if using default port 80. Note: If Auto Upgrade is set to No, DP715 will only do HTTP/HTTPS download once at boot up. Firmware Server Path IP address or domain name of firmware server.
  • Page 44 23. If select “Yes, weekly on day” make sure you input the day of the week (in format 0-6, 0 is Sunday) you want it to check for update. When set to No, DP715 will only do the following option you select; “Always check for New Firmware at Boot up” will check for new firmware every time the device reboots.
  • Page 45 Default No. Enables the DHCP server to handle the NTP Server via Option 42 to override NTP server Syslog Server The IP address or URL of System log server. This feature is especially useful for the ITSP (Internet Telephone Service Provider) Firmware version 1.0.0.31 DP715/DP710 User Manual Page 43 of 56...

  • Page 46: Table 14: Profile Settings

    Syslog Level Select the DP715 to report the log level. Default is NONE. The level is one of DEBUG, INFO, WARNING or ERROR. Syslog messages are sent based on the following events: product model/version on boot up (INFO level) NAT related info (INFO level)
  • Page 47 Retry registration if the process failed. Default is 20 seconds. Retry Wait Time Local SIP port Defines the local SIP port the DP715 will listen and transmit. Default is 5060 for profile 1 & 6060 for profile 2. Local RTP port Defines the local RTP port the DP715 will listen and transmit.
  • Page 48 Sets the payload type for DTMF using RFC2833. Default is 101. Preferred DTMF method The DP715 supports up to 3 different DTMF methods including in-audio, via RTP (RFC2833) and via Sip Info using SIP INFO messages. The user can configure DTMF method in a priority list.
  • Page 49 Note: In some cases where the user wishes to dial strings such as *123 to activate voice mail or other applications provided by their service provider, the * should be predefined Firmware version 1.0.0.31 DP715/DP710 User Manual Page 47 of 56...
  • Page 50 Codec Configuration Preferred Vocoder The DP715 supports up to 6 different Vocoder types including G.711 A-/U-law, G.726-32 , G.723.1, G.729A/B and iLBC. The user can configure Vocoders in a preference list that will be included with the same preference order in SDP message. The first Vocoder is entered by choosing the appropriate option in “Choice 1”.

  • Page 51: Table 15: Handsets Settings

    This button is used to de-register all the handset previously registered with the DP715 Handsets Base Station Enable Subscription This button will allow you to set the DP715 into subscription mode in order to register a Mode new Handset. Note: Subscription mode is automatically exited after 120 seconds.

  • Page 52: Saving The Configuration Changes

    Select the corresponding Profile ID between Profile 1 and Profile 2. SAVING THE CONFIGURATION CHANGES Click the “Update” button in the Configuration page to save the changes to the DP715 configuration. The following screen confirms that the changes are saved. Reboot or power cycle the DP715 to make the changes take effect.

  • Page 53: Software Upgrade

    Once a “Firmware Server Path” is set, user needs to update the settings and reboot the device. If the configured firmware server is found and a new code image is available, the DP715 will attempt to retrieve the new image files by downloading them into the DP715’s SRAM. During this stage, the DP715’s LEDs will blink until the checking/downloading process is completed.

  • Page 54: Instructions For Upload From Local Directory

    1. Unzip the file and put all of them under the root directory of the TFTP server. 2. Put the PC running the TFTP server and the DP715 device in the same LAN segment. 3. Please go to File -> Configure -> Security to change the TFTP server's default setting from "Receive Only"...

  • Page 55: Managing Firmware And Configuration File Download

    Firmware or Provisioning Server load at any given time. Automatic Upgrade: 10080 Yes, every minutes(60-5256000). Yes, daily at hour (0-23). Yes, weekly on day (0-6). Firmware version 1.0.0.31 DP715/DP710 User Manual Page 53 of 56...

  • Page 56: Firmware Version 1.0.0.31

    This page is intentionally left bank Firmware version 1.0.0.31 DP715/DP710 User Manual Page 54 of 56...

  • Page 57: Restore Factory Default Setting

    1. From the Advanced Settings Page user can select three types: • Full Reset: This will make a full reset • ISP Data:This will reset only the basic settings, like IP mode, PPPoE and Web port Firmware version 1.0.0.31 DP715/DP710 User Manual Page 55 of 56...

  • Page 58: Firmware Version 1.0.0.31 Dp715/Dp710 User Manual

    1. Factory Reset will be disabled if the “Lock keypad update” is set to “Yes”. 2. If the DP715 was previously locked by your local service provider, pressing the RESET button will only restart the unit. The device will not return to factory default settings.
