Grandstream Networks DP750 Configuration Manual

Hide thumbs Also See for DP750:
Table of Contents

Advertisement

Quick Links

Download this manual
Home
PBXware
SERVERware
TELCOware
SIPmon
SIPProt
Desktop & Mobile
BRM
UADs
Appliances
EOL
From Bicom Systems Wiki
Contents
1 Introduction
Introduction

Advertisement

Table of Contents
loading

Related Manuals for Grandstream Networks DP750

Summary of Contents for Grandstream Networks DP750

  • Page 1: Table Of Contents

    Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Video Tutorial 3 Requirements 3.1 Identifying device model 3.2 Device firmware 3.3 DHCP server 3.4 PBXware version 4 Installation 4.1 Power adapter 4.2 Power over Ethernet (PoE) 4.3 Find the device IP address 4.4 Reset to factory settings...

  • Page 2: Video Tutorial

    This Configuration Guide is written as general guide on how to configure the Grandstream device model DP750 to work with PBXware 4.1.3. Video Tutorial Video tutorial explaining Auto Provisioning setup for Grandstream Phone on PBXware 4. Video tutorial explaining Auto Provisioning setup for Grandstream Phone on PBXware 5.

  • Page 3: Dhcp Server

    factory default login details are username: admin and password: admin. DHCP server Fully configured and operational DHCP server. PBXware version PBXware version 4.1.3.0 In order to find out the PBXware version: Login to PBXware Navigate to Settings: About. On the top of About page is a code similar to this one PBXware Edition: Business, Release: 4.1.3.0 (387597b7), Running: 1.8.32.1-gc-b47edc45, PBXware Proxy v4.1.3 (62b7bcd), API: 4.1, libmemcached version: 1.0.14, where Release denotes the exact version of your...

  • Page 4: Find The Device Ip Address

    NOTE: If you are using Power over Ethernet (PoE), you don't need to connect the AC adapter. Make sure the Ethernet cable and router or switch is Power over Ethernet (PoE) compliant. Find the device IP address Find out your Grandstream device IP Address. Press the Menu button on the handset.
  • Page 5 Creating extension Registering device UAD Settings UAD settings Login to PBXware web administration interface Open a new browser window and enter the IP address in order to access the PBXware web administration login screen. Example: http://192.168.1.10. Login to PBXware with your e-mail address and password. UAD settings Navigate to Settings:UAD.
  • Page 6 Click on the Next step button. Extension values Enter values into the required field text boxes. REQUIRED FIELDS: Name Enter a name for the extension being created. Example: John Smith. E-mail Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages.

  • Page 7: Auto Provisioning

    - Example for Hostname: voip.bicomsystems.com - Example for IP Address: 192.168.1.10 Click Save button. Click on Dect in the top menu. Click on SIP Account Settings in the left menu. SIP User ID PBXware extension number, example 1003. Authenticate ID Usually the same number as the SIP User ID.
  • Page 8 UAD settings Login to PBXware web administration interface. Open a new browser window and enter the IP address in order to access the PBXware web administration login screen. Example: http://192.168.1.10. Login to PBXware with your e-mail address and password. UAD settings. Navigate to Settings:UAD.
  • Page 9 E-mail Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages. Example: john.smith@bicomsystems.com Auto Provisioning Set to Yes. MAC Address Enter Grandstream device MAC address. Example: 000B82123456. MAC address can be found at the back of the device. Click on the Save button.
  • Page 10 HTTP/HTTPS Password fields. Choose what server type you intend to use in the Provisioning via field: TFTP, HTTP and HTTPS. NOTE: Our recommendation is to use the HTTP. If the Server Type is HTTP or HTTPS enter Hostname or IP Address, followed then by /prov in the Config Server Path field.
  • Page 11 Example for IP Address: 192.168.1.10 Click on Save and Apply button. Click Reboot button in the top right of the web interface. You'll have to wait couple of seconds for the configuration to be updated. NOTE: Do not power off your device. Auto provisioning process will start during device reboot process, device will pickup appropriate configuration file from PBXware.
