- Page 1 S9i Stairclimber A S S E M B L Y I N S T R U C T I O N S...
- Page 2 Congratulations... Life Fitness and welcome to the world of and the Life Fitness S9i Stairclimber. The following Parts Identification Listing and the step by step assembly procedures have been assembled to make the set-up of the Stairclimber as quick and easy as possible.
-
Page 3: Important Safety Instructions
Parts Listing prior to setting the cartons and shipping material aside. If any parts are missing, contact Life Fitness Customer Support Services at the number listed in the Operation Manual. Save the shipping cartons in case of return. -
Page 4: Parts Description
OOLS EQUIRED FOR Hex Head Bolt 3/8 – 16 x 3 0017-00101-1048 Hex Head Bolt 5/16 – 18 x 1 0017-00101-0933 Phillips Pan Head Screw #8 – 18 x .625 0017-00101-1243 Phillips Pan Head Screw #8 – 18 x .75 0017-00101-1242 Display Console Assembly Accessory Tray... - Page 5 1. Before proceeding, familiarize yourself with the parts of the Stairclimber and make sure that you have received all the items described in the Parts List. 2. Locate the MONOCOLUMN (#10). Position the MONOCOLUMN SHROUD (#18) onto the MONOCOLUMN as shown. Position the MONOCOLUMN near the MONOCOLUMN MOUNTING BRACKET (B) as shown.
- Page 6 4. Locate the TELEMETRY CABLE (#15). Feed the 3-PIN CONNECTOR (3P) end of the cable through the front of the HANDLEBAR ASSEMBLY (#13). The cable must be routed down the HANDLEBAR BRACKET TUBE (F) and back up the top of the MONOCOLUMN (#10).
- Page 7 7. Locate one of the VERTICAL HANDRAILS (#12). Carefully insert the top of the VERTICAL HANDRAIL into the user right end of the HANDLEBAR ASSEMBLY (#13). Align the mounting holes. Secure the VERTICAL HANDRAIL to the HANDLEBAR ASSEMBLY using two MOUNTING SCREWS (#4). Position the bottom of the VERTICAL HANDRAIL over the mounting hole in the top of the right FRAME LEG (K).
-
Page 8: Pre-Operation Checklist
Operation Manual. If your Stairclimber does not respond as described in the OPERATION MANUAL, contact the nearest Life Fitness service center as listed in the Operation Manual. © 2002 Brunswick Corporation. All rights reserved. Life Fitness is a trademark of Brunswick Corporation. Polar is a registered trademark of Polar Electro, Inc. - Page 9 M051-00K20-A315 4/02...
