Page 1 A020A01A-AAT RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Hyundai are found in Section 5. As the owner, it is your responsibility to see that all maintenance operations specified by the manufacturer are carried out at the appropriate intervals.
Page 2 Specifications All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment.
Page 3 Your Hyundai should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the U.S. Department of Transportation and other federal or state agencies.
Page 4 A090A01A-AAT SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: WARNING: This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded.
Page 5 To retrieve this information, special equipment is needed and access to the vehicle or the device that stores the data is required. Hyundai will not access information about a crash event or share it with others except:...
Page 6 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car.
Page 7 Hyundai Genuine Parts are the same parts Hyundai Genuine Parts? used by Hyundai Motor Company to manu- facture vehicles. They are designed and Look for the Hyundai Genuine Parts Logo on tested for the optimum safety, performance, the package (see below). and reliability to our customers.
Page 8 TABLE OF CONTENTS FEATURES OF YOUR HYUNDAI DRIVING YOUR HYUNDAI WHAT TO DO IN AN EMERGENCY CORROSION PREVENTION & APPEARANCE CARE VEHICLE MAINTENANCE REQUIREMENTS SECTION DO-IT-YOURSELF MAINTENANCE EMISSION CONTROL SYSTEMS CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS...
Page 9: Instruments And Controls
INSTRUMENTS AND CONTROLS B250A02GK-AAT OGK026002N gkflhma-0.p65 7/20/2006, 2:53 PM...
Page 10 1. Multi-Function Light Switch 11.Fuse Box Relay 2. Horn and Driver's Airbag 12.Hood Release Lever 3. Windshield Wiper/Washer Switch 13.Steering Wheel Tilt Lever (If installed) 4. Ignition Switch 14.Heating and Cooling Controls 5. Front Fog Light switch (If installed) 15.Ashtray 6.
Page 11 YOUR VEHICLE AT A GLANCE B255A02GK-AAT INDICATOR SYMBOLS ON THE INSTRUMENT PANEL SRS (Airbag) Service Reminder Indicator (SRI) Turn Signal Indicator Lights Malfunction Indicator Light ABS Service Reminder Indicator (SRI) (If installed) Seat Belt Reminder Light and Chime High Beam Indicator Light CRUISE Indicator Light (If installed) Low Oil Pressure Warning Light CRUISE SET Indicator Light (If installed)
Page 12 A000A01A-AAT This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. OWNER'S I.D. ORIGINAL OWNER ADDRESS CITY STATE ZIP CODE DELIVERY DATE (Date Sold to Original Retail purchaser) DEALER NAME DEALER NO.
Page 13: Table Of Contents
FEATURES OF YOUR HYUNDAI Fuel Recommendations ..........1-2 Breaking in Your New Hyundai ........1-3 Keys ................1-3 Door (Teft-Alarm System) ........1-4, 1-6 Power Windows ............1-9 Seats ................1-10 Seat Belts..............1-16 Child Restraint System ..........1-21 Supplemental Restraint (AIRBAG) System (SRS) ..1-28 Instrument Cluster and Indicator Lights ......
Page 14: Fuel Recommendations
Gasohol (a mixture of 90% unleaded gasoline Fuels containing methanol (wood alcohol) should and 10% ethanol or grain alcohol) may be used not be used in your Hyundai. This type of fuel UNLEADED in your Hyundai. However, if your engine devel-...
Page 15 Operation in Foreign Countries rpm and 4,000 rpm. o Use moderate acceleration. Don't start B030A01E If you are going to drive your Hyundai in another quickly or depress the accelerator pedal country, be sure to: For greater convenience, the same key oper- fully.
Page 16 A code number is stamped on the key number B030C01E-1 o Before opening the door, always look for plate that came with the keys to your Hyundai. Whenever a door is opened, the ignition switch and avoid oncoming traffic. This key number plate should be kept in a safe...
Page 17 FEATURES OF YOUR HYUNDAI B040B01JM-AAT B040C01S-AAT B040D01S-AAT Locking and unlocking front doors with a Locking From the Outside Locking From the Inside UNLOCK UNLOCK LOCK LOCK HGK2009 HGK2010 The doors can be locked without a key. To lock the doors from the inside, simply close...
Page 18 FEATURES OF YOUR HYUNDAI THEFT-ALARM SYSTEM B040G02GK-GAT o If the door is locked/unlocked multiple B070A01A-AAT Central Door Lock (If Installed) times in rapid succession with either the vehicle key or door lock switch, the sys- This system is designed to provide protection tem may stop operating temporarily in from unauthorized entry into the car.
Page 19 FEATURES OF YOUR HYUNDAI NOTE: B070C01GK-AAT B070D04GK-AAT Alarm Stage Disarmed Stage 1) If any door, tail gate or engine hood remains open, the system will not be The alarm will be activated if any of the following armed. occur while the car is parked and the system is 2) If this happens, rearm the system as armed.
Page 20 If you have a problem with the approved by the party responsible for com- 1. Push the "PANIC" button on the transmitter. transmitter, contact an authorized Hyundai pliance could void the user's authority to 2. At the same time, the siren will sound and the Dealer.
Page 21: Power Windows
FEATURES OF YOUR HYUNDAI POWER WINDOW B070E02GK-GAT B050A01GK-AAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pushes on the button to lock or unlock the doors, and the LED will not light. Replace the battery as soon as possible.
Page 22: Seats
FEATURES OF YOUR HYUNDAI SEATS B080A02A-AAT Auto-Down Window (Driver's Side) ADJUSTABLE FRONT SEATS (If Installed) WARNING: o Never adjust the driver’s seat while the vehicle is moving. Any sudden or unex- pected movement of the seat could cause you to lose control of the vehicle result- ing in an accident.
Page 23 FEATURES OF YOUR HYUNDAI B080B03A-AAT B080C02A-AAT Adjusting Seat Forward and Rearward Adjusting Seatback Angle WARNING: After adjusting the seat, always check that it is securely locked into place by attempt- ing to move the seat forward or reverse without using the lock release lever. Sud-...
Page 24 FEATURES OF YOUR HYUNDAI B080D02JM-AAT Adjustable Headrests WARNING: WARNING: Riding with a reclined seatback increases your chance of serious or fatal injuries in the event of a collision or sudden stop. The protection of your restraint system (seat belts and airbags) is greatly reduced by reclining your seat.
Page 25 FEATURES OF YOUR HYUNDAI B080E01F-AAT B080F01F-AAT B129A01F-AAT Lumbar Support Control Seat Cushion Height Adjustment REAR SEAT POSITIONS (Driver's seat only) (Driver's Seat Only) (If Installed) SOFT FIRM B129A01GK HGK2030 HGK2029 The driver's seat is equipped with adjustable To raise or lower the front part of the seat WARNING: lumbar support.
Page 26 FEATURES OF YOUR HYUNDAI B130A01GK-AAT B099A01F-AAT REAR SEAT ENTRY (Walk in device) BEFORE FOLDING THE REAR SEATS The driver and front passenger's seatbacks should be tilted to enter the rear seat. HGK2036-1 By pulling up the walk in device lever (1) at the...
Page 27 FEATURES OF YOUR HYUNDAI B110A02S-AAT FOLDING REAR SEATBACKS WARNING: The purpose of the fold-down rear B140A01S-AAT seatbacks is to allow you to carry longer REAR SEAT WARNING objects than could otherwise be accommo- dated. Never allow passengers to sit on top...
Page 28: Seat Belts
FEATURES OF YOUR HYUNDAI SEAT BELT B150A02S-AAT B150B04Y-AAT for your child's height and weight. Check SEAT BELT PRECAUTIONS Infant or Small Child the label on the child restraint for this information. See page 1-21. All 50 states have child restraint laws. You...
Page 29 FEATURES OF YOUR HYUNDAI B150G02A-AAT B150D01A-AAT B160A02A-AAT Do Not Lie Down Pregnant Women CARE OF SEAT BELTS To reduce the chance of injuries in the event of The use of a seat belt is recommended for Seat belt systems should never be disassembled...
Page 30 You can adjust the height of the shoulder belt Replace your seat belts after being in an directed to your Hyundai Dealer. anchor to one of the 4 positions for maximum accident as soon as possible.
Page 31 To will be an audible "click" when the tab locks into tems. Hyundai strongly recommends that chil- convert from the automatic locking feature the buckle. dren always be seated in the rear seat. NEVER...
Page 32 FEATURES OF YOUR HYUNDAI B200A01A-AAT B210A01A-AAT Adjusting Your Seat Belt To Release the Seat Belt WARNING: o For maximum restraint system protec- tion, seat belts must always be used whenever the car is moving. o Seat belts are most effective when seatbacks are in the upright position.
Page 33: Child Restraint System
FEATURES OF YOUR HYUNDAI CHILD RESTRAINT SYSTEM B230A04A-AAT Children riding in the car should sit in the rear WARNING: seat and must always be properly restrained to WARNING: minimize the risk of injury in an accident, sudden To reduce the chance or serious or fatal o A child restraint system must be placed stop or sudden maneuver.
Page 34 FEATURES OF YOUR HYUNDAI B230B02GK-GAT B230C05F-AAT Using a Child Restraint System Installing a Child Restraint Seat with the WARNING: "Tether Anchorage" System For small children and babies, the use of a child o Never allow two children, or any two seat or infant seat is required.
Page 35 FEATURES OF YOUR HYUNDAI B230D03GK-AAT Rear luggage compartment floor Securing the child Restraint seat with Blanking covers the "ISOFIX" system WARNING: o A child can be seriously injured or killed in a collision if the child restraint is not properly anchored. Always follow the child seat manufacturer’s instructions...
Page 36 FEATURES OF YOUR HYUNDAI o When using the vehicle’s “ISOFIX” sys- tem to install a child restraint system in WARNING: the rear seat, all unused vehicle rear seat ISOFIX Anchor ISOFIX Anchor o There is no center rear seat position.
Page 37 FEATURES OF YOUR HYUNDAI B230G02O-AAT Child Restraint System Installation on outboard Rear Seats WARNING: A child can be seriously injured or killed in On outboard rear seats a collision if the child restraint is not prop- erly anchored to the car and the child is not properly restrained in the child restraint.
Page 38 After installation of the child restraint system, try to move it in all WARNING: Your Hyundai vehicle is equipped with driver's directions to be sure the child restraint system and front passenger's pre-tensioner seat belts.
Page 39 FEATURES OF YOUR HYUNDAI NOTE: Driver's airbag Passenger's o Both the driver's and front passenger's airbag pre-tensioner seat belts will be activated WARNING: in certain frontal collisions. The pre- To obtain maximum benefit from a pre- tensioner seat belts can be activated...
Page 40 B240A01GK the ignition key is turned to "ON" or if it pre-tensioner seat belts yourself. This Your Hyundai is equipped with a Supplemental remains illuminated after approximately must be done by an authorized Hyundai Restraint (Airbag) System. The indications of 6 seconds, or if it illuminates while the dealer.
Page 41 40) remains illuminated while the vehicle o Never place a child in any child or booster is being driven, have an authorized seat in the front seat (see child restraints Hyundai dealer inspect the airbag sys- 1-21). tem as soon as possible. Side Impact o ABC –...
Page 42 - SRS Control Module (SRSCM) o If the airbags deploy, they must be re- or lean unnecessarily close to the airbag placed by an authorized Hyundai dealer. while the vehicle is in motion. The SRSCM continually monitors all elements Deployed airbags WILL NOT inflate again o The SRS airbag system must deploy very while the ignition is "ON"...
Page 43 FEATURES OF YOUR HYUNDAI The SRS service reminder indicator (SRI) on Passanger's Airbag the instrument panel will illuminate for about 6 seconds after the ignition key is turned to the "ON" position or after the engine is started, after which the SRI should go out.
Page 44 B990B02Y Passanger's Airbag ignition key is in the "ON" position. If the Your Hyundai is equipped with a side impact SRS SRI does not illuminute, or contin- airbag in each front seat. The purpose of the uously remains on after illuminating for...
Page 45 Do not place any objects (an umbrella, diately inspected by your Hyundai dealer. motion. The airbags deploy only in cer- bag, etc.) between the front door and the...
Page 46 Sol- shouldn't try to start the engine; have vents or cleaners could adversely affect the car towed to an authorized Hyundai the airbag covers and proper deploy- dealer. ment of the system.
Page 47 FEATURES OF YOUR HYUNDAI B240D02JM-AAT o Keep occupants away from the airbag Additional Safety Precautions covers. All occupants should sit upright, fully o Never let passengers ride in the cargo back in their seats with their seat belts on and...
Page 48: Instrument Cluster And Indicator Lights
FEATURES OF YOUR HYUNDAI INSTRUMENT CLUSTER AND INDICATOR LIGHTS B260A02GK-AAT B260A02GK-A...
Page 49 FEATURES OF YOUR HYUNDAI 1. Speedometer 13. Seat Belt Warning Light 2. Turn Signal Indicator Light 14. High Beam Indicator Light 3. Odometer 15. Low Oil Pressure Warning Light 4. Automatic Transaxle Position Indicator Light (If installed) 16. Malfunction Indicator Light (MIL) 5.
Page 50: Warning And Indicator Lights
If this occurs, have your vehicle checked by engine should be checked by a Hyundai your Hyundai dealer as soon as possible. The dealer before the car is driven again. normal braking system will still be operational, but without the assistance of the anti-lock brake system.
Page 51 If the light stays on fully driven to a Hyundai dealer for inspection. CAUITON: while the engine is running, there is a malfunc-...
Page 52 6 seconds after the ignition key is driver's side front door is closed. rized Hyundai dealer and have the system turned to the "ON" position or after the engine checked.
Page 53 Excessive rotor damage will result if the worn cruise control main switch is pushed a second They will illuminate when the ignition key is pads are not replaced. See your Hyundai dealer time. turned to the "ON" position, but should go out immediately.
Page 54 Then open the hood and after the engine has cooled, check the coolant level and the water pump drive belt. If you suspect cooling system trouble, have your cooling system checked by a Hyundai dealer as soon as possible. B300A01A-AAT SPEEDOMETER HGK2059...
Page 55 FEATURES OF YOUR HYUNDAI B330A03E-AAT B310B01GK-AAT Type A TACHOMETER Odometer/Trip odometer Type A Type B HGK2061-1 Type B B330A01GK HGK028B The tachometer registers the speed of your Function of digital odometer/trip odom- engine in revolutions per minute (rpm). eter Pushing in the reset switch on the right side of speedometer when the ignition switch is turned "ON"...
Page 56 FEATURES OF YOUR HYUNDAI TRIP COMPUTER B400B02GK-GAT 1. Odometer Reset Switch (If installed) The odometer records the total driving distance o The reset switch is used to zero the multi- in miles, and is useful for keeping a record for functional display mode.
Page 57 FEATURES OF YOUR HYUNDAI NOTE: 1. Distance to Empty 2. AVERAGE SPEED o When the distance to empty is less than 50 km, the symbol will always come on Type A Type A and the distance to empty digits will indicate "---"...
Page 58 FEATURES OF YOUR HYUNDAI MULTI GAUGE B330C01GK-GAT 3. DRIVE TIME (If installed) Type A Multi gauge is consists of torque gauge, instan- taneous fuel consumption gauge and volt gauge. Type B B330C04GK HGK2065 Instantaneous fuel Consumption gauge It shows instantaneous fuel consumption ac- o This mode indicates the drive time travelled cording to the driving condition.
Page 59: Multi-Function Light Switch
Check for a burned- It shows moment volt change and makes for out fuse or bulb or see your Hyundai dealer. To indicate a lane change, move the lever up or diver correspond to low volt situation.
Page 60 FEATURES OF YOUR HYUNDAI B340C04E-AAT B340G01LZ-GAT Parking light auto cut Headlight Switch Auto Light (If installed) o The purpose of this feature is to prevent the battery from being discharged. The system automatically turns off the small light when the driver removes the ignition key and opens the driver- side door.
Page 61 FEATURES OF YOUR HYUNDAI WINDSHIELD WIPER AND WASHER SWITCH B340E01A-AAT B350A01A-AAT Headlight Flasher Auto Light Sensor B340G01GK HGK042A NOTE: The windshield wiper switch has three posi- HGK2077 o Never place anything over sensor lo- tions: To flash the headlights, pull the switch lever cated on the instrument panel, this will toward you, then release it.
Page 62 FEATURES OF YOUR HYUNDAI B350B01O-AAT B350C01S-AAT Mist Wiper Operation Windshield Washer Operation Adjustable Intermittent Wiper Operation HGK045A HGK043A HGK044A If a single wipe is desired in mist, move the To use the windshield washer, pull the wiper/ To use the intermittent wiper feature, place the windshield wiper and washer control lever up.
Page 63 FEATURES OF YOUR HYUNDAI FRONT FOG LIGHT SWITCH B390A01E-AAT Do not operate the washer continuously for B360A04A-AAT Rear Window Wiper And Washer Switch more than 15 seconds or when the fluid reser- voir is empty; this could damage the system. Do not operate the wiper when the window is dry;...
Page 64 FEATURES OF YOUR HYUNDAI HAZARD WARNING SYSTEM REAR WINDOW DEFROSTER SWITCH NOTE: B370A01A-AAT B380A02A-AAT The ignition must be running for the rear Type A window defroster to operate. Type A Type B Type C Type B HGK2090-1 B370A01GK The hazard warning system should be used...
Page 65 If it is necessary to replace the cigarette lighter, correct time. When this is done: use only a genuine Hyundai replacement or its approved equivalent. Pressing "R" between 10 : 30 and 11 : 29 changes the readout to 11 : 00.
Page 66 FEATURES OF YOUR HYUNDAI ASHTRAY DRINK HOLDER B430A01GK-AAT B450A02GK-AAT (If Installed) WARNING: Passenger's Driver's o Use caution when using the drink hold- ers. A spilled beverage that is very hot can injure you or your passengers. Spilled liquids can damage interior trim and electrical components.
Page 67 FEATURES OF YOUR HYUNDAI SUNSHADE SUNROOF B470A01S-AAT B460A01S-AAT (If Installed) (If Installed) WARNING: The sunroof can be operated with the ignition o Do not close a sunroof if anyone’s hands, key in the "ON" position. arms or body are between the sliding glass and the sunroof sash, as this could result in injury.
Page 68 FEATURES OF YOUR HYUNDAI B460C01S-AAT B460D03GK-AAT Tilting the Sunroof System Manual Operation of Sunroof If the sunroof does not electrically operate: HGK2025 2. Insert the hexagonal head wrench provided HGK2023 with the vehicle into the socket. This wrench can be found in the vehicle’s trunk or glove The sunroof can be tilted by pushing the "UP"...
Page 69 FEATURES OF YOUR HYUNDAI SUNGLASS HOLDER INTERIOR LIGHT B460E03GK-GAT B480A01GK-GAT B491A02F-AAT Resetting the Sunroof System MAP LIGHT If the battery has been recharged, discon- nected or is manually with operating the hex- agonal head wrench, you may need to reset the sunroof.
Page 70 FEATURES OF YOUR HYUNDAI GLOVE BOX MIRROR B500A01A-AAT B510B01A-AAT 2. Next, adjust the mirror angle by depressing OUTSIDE REAR VIEW MIRROR the appropriate perimeter switch as illus- trated. Electric Type CAUTION: o Do not operate the switch continuously for an unnecessary length of time.
Page 71 (If Installed) MIRRORS Type A Type B HGK2052 Your Hyundai is equipped with a day/night inside rear view mirror. The "night" position is selected HGK2090-1 HGK2055 by flipping the tab at the bottom of the mirror The outside rearview mirror heater is actuated To fold the outside rear view mirrors, push them toward you.
Page 72 FEATURES OF YOUR HYUNDAI PARKING BRAKE B520B02O-GAT B530A03A-EAT o To release the parking brake, first apply the (Electric type) (If installed) foot brake and pull up the parking brake lever slightly. Secondly, depress the release but- ton and lower the parking brake lever whilst holding the button.
Page 73: Hood Release
FEATURES OF YOUR HYUNDAI HIGH-MOUNTED REAR STOP LIGHT FRONT DOOR EDGE WARNING HOOD RELEASE LIGHT B550A01S-GAT B620A01S-AAT B570A01GK-GAT Type A Type B Type C Hood Release Lever B550A02GK B620A01GK HGK2019 In addition to the lower-mounted rear stoplights A red light comes on when the front door is 1.
Page 74 FEATURES OF YOUR HYUNDAI REMOTE FUEL-FILLER LID RELEASE When closing the hood, slowly close the hood B560A03JM-AAT and make sure it locks into place. WARNING: o Always double check to be sure that the hood is firmly latched before driving away.
Page 75 If the filler cap must be ground while refueling. Static electric- replaced, only use genuine Hyundai re- ity discharge from the container can placement parts. ignite fuel vapors causing a fire. While...
Page 76 FEATURES OF YOUR HYUNDAI B540C01F-AAT B540D01GK-GAT To Unlock Using the Key when you close the tailgate WARNING: The tail gate should always be kept com- pletely closed while the vehicle is in motion. If it is left open or ajar, poisonous exhaust gases may enter the car resulting in serious illness or death to the occupants.
Page 77 Closing the tailgate onto a person's head may cause serious injuries, including death. HGK2119 Your Hyundai is equipped with sun visors to give HGK2049 the driver and front passenger either frontal or To adjust the steering wheel: sideward shade.
Page 78 FEATURES OF YOUR HYUNDAI HORN LUGGAGE NET B610A01S-GAT B540D02HP-GAT (if installed) Working Zone Type A WARNING: Avoid eye injury. Do not overstretch. Al- ways keep face and body out of recoil path. Do not use when strap has visible signs of wear or damage.
Page 79: Cruise Control
FEATURES OF YOUR HYUNDAI CRUISE CONTROL B660A02S-AAT B660B01GK-AAT (If Installed) To Set the Cruise Speed WARNING: o Make sure the floor mat is properly placed on the floor carpet. If the floor mat slips and interferes with the movement of the pedals during driving, it may cause an accident.
Page 80 FEATURES OF YOUR HYUNDAI 5. To momently increase speed, depress the B660C01GK-AAT B660D01E-AAT To Cancel the Cruise Speed To Resume the Preset Speed accelerator pedal enough for the vehicle to exceed the preset speed. When you remove your foot from the accelerator pedal, the vehicle will return to the speed you have set.
Page 81 FEATURES OF YOUR HYUNDAI B660E01E-AAT To Reset at a Faster Speed WARNING: WARNING: 1. Push the control switch upward to "RE- o Keep the cruise control ON/OFF switch SUME (ACCEL)" position and hold it. o During normal cruise control operation, off when not using the cruise control to 2.
Page 82: Audio Remote Control Switch
FEATURES OF YOUR HYUNDAI AUDIO REMOTE CONTROL SWITCH B610A01GK-GAT SEEK (UP / ) Switch (If installed) Press the SEEK UP ( ) switch 1 sec. or more. 1. RADIO mode When the SEEK UP ( ) switch is pressed, the unit will automatically tune to the next higher frequency.
Page 83: Heating And Cooling Control
FEATURES OF YOUR HYUNDAI HEATING AND COOLING CONTROL B710A02GK-GAT B710B02O-AAT CENTER VENTILATOR The center ventilators are located in the middle of the dashboard. To change the direction of the air flow, move the knob in the center of the vent up-and-down and side-to-side.
Page 84 FEATURES OF YOUR HYUNDAI HEATING AND VENTILATION B670A01GK-GAT B670B02A-AAT B670E02A-AAT Rotary Type Fan Speed Control (Blower Control) Temperature Control Cool Warm HGK002-3 HGK2093 HGK2092 1. Air Conditioning switch This is used to turn the blower fan on or off and This control is used to adjust the degree of 2.
Page 85 FEATURES OF YOUR HYUNDAI B670C02GK-AAT With the "Fresh" mode selected, air enters the B670D04GK-AAT Air Intake Control Air Flow Control vehicle from the outside and is heated or cooled according to the function selected. With the "Recirculation" mode selected, air from...
Page 86 FEATURES OF YOUR HYUNDAI HGK2095 HGK2096 HGK2097 Floor-Level Bi-Level Face-Level Air is discharged through the floor vents, wind- Selecting the "Face" mode will cause air to be Air is discharged through the dash vents and the shield defroster nozzle, side defroster nozzle, floor vents.
Page 87 FEATURES OF YOUR HYUNDAI mode except the defrost mode and the floor-defrost mode. Although the A/C switch indicator is turned off, this is normal operation. HGK2098 HGK2099 Defrost-Level Floor-Defrost Level Air is discharged through the windshield defrost Air is discharged through the windshield defrost nozzle, side defroster nozzle, side ventilator.
Page 88 B690A01GK-A B700A01GK-A For normal heating operation, set the air intake ON or OFF * Your Hyundai is equipped with bi-level heating control to the "Fresh" position and the air flow controls. To use this feature: ON or OFF * control to "Floor".
Page 89 FEATURES OF YOUR HYUNDAI AIR CONDITIONING SYSTEM VENTILATION B710A01S-AAT B740A01S-AAT B740B01S-AAT Air Conditioning Switch (If installed) Air Conditioning Operation Cooling B710A01GK-A HGK2089-1 To operate the ventilation system: The air conditioning is turned on or off by HGK002-1 o Set the air intake control to "Fresh" mode...
Page 90 FEATURES OF YOUR HYUNDAI o Set the temperature control to "Cool". ("Cool" B740C01S-AAT B730A01FC-AAT Dehumidified Heating Operation Tips provides maximum cooling. The tempera- ture may be moderated by moving the con- o To keep dust or unpleasant fumes from trol toward "Warm".) entering the car through the ventilation sys- o Adjust the fan control to the desired speed.
Page 91 FEATURES OF YOUR HYUNDAI DEFROSTING/DEFOGGING B720A02FC-GAT A Type B Type A Type B Type B720A01GK-1 B720A02GK-1 Use the heating/ventilation system to defrost or defog the To remove frost or exterior fog on the windshield: windshield: o Set the air flow control to the defrost ( ) position.
Page 92 FEATURES OF YOUR HYUNDAI AUTOMATIC HEATING AND COOLING CONTROL SYSTEM B970A01Y-AAT (If lnstalled) Your Hyundai is equipped with an automatic heating and cooling control system controlled by simply setting the desired temperature. B970B02GK-GAT Heating and Cooling Controls TYPE B (With Air Quality System)
Page 93 FEATURES OF YOUR HYUNDAI NOTE: B970C02E-AAT Automatic Operation If the battery has been discharged or dis- connected, the temperature mode will reset to centigrade degrees. This is a normal condition and you can change the temperature mode from centi- grade to farenheit as follows;...
Page 94 FEATURES OF YOUR HYUNDAI B995A01Y-GAT B980A01Y-AAT B980B01Y-AAT Ambient Temperature Switch MANUAL OPERATION Fan Speed Control Switch The heating and cooling system can be con- trolled manually as well by pushing buttons other than the "AUTO" button. In this state, the system sequentially works according to the order of buttons selected.
Page 95 FEATURES OF YOUR HYUNDAI B670C02GK-AAT With the "Fresh" mode selected, air enters the B980C02GK-GAT Air Intake Control Switch Air Intake Control Switch (With A.Q.S) vehicle from the outside and is heated or cooled according to the function selected. (Without A.Q.S) (If Installed) With the "Recirculation"...
Page 96 FEATURES OF YOUR HYUNDAI B980E01GK-GAT Recirculation mode : Air Flow Control Air from within the passenger compartment will CAUTION: be drawn through the heating system and heated If the windows fog up with the Recircula- or cooled according to the function selected.
Page 97 FEATURES OF YOUR HYUNDAI HGK2096 HGK2097 HGK2095 Face-Level Floor-Level Bi-Level When selecting the "Face" mode, the indicator When selecting the "Floor-Level" mode, the When selecting the "Bi-Level" mode, the indica- light will come on, causing air to be discharged indicator light will come on and the air will be tor light will come on and the air will be dis- through the face level vents.
Page 98 FEATURES OF YOUR HYUNDAI CLIMATE CONTROL AIR FILTER (IN FRONT OF BLOWER UNIT) B980F02E-AAT B760A06GK-AAT Defrost Switch (If Installed) Inside air Outside air Filter Blower fan Inside air Evaporator core HGK2098 Heater core Floor-Defrost Level B760A01E HGK012 When the "Defrost" button is pressed, the "...
Page 99 FEATURES OF YOUR HYUNDAI CAUTION: o Replace the filter every 10,000 miles (15,000 km) or once a year. If the car is being driven in severe conditions such as dusty, rough roads, more frequent climate control air filter inspections and changes are required.
Page 100: Stereo Sound System
FEATURES OF YOUR HYUNDAI STEREO SOUND SYSTEM B750A02A-AAT AM reception FM radio station How Car Audio Works Ionosphere FM reception Mountains Unobstructed Ionosphere area Buildings Iron bridges Obstructed area B750A02L B750A03L AM broadcasts can be received at greater FM broadcasts are transmitted at high frequen- B750A01L distances than FM broadcasts.
Page 101 In such a case, use the cellular phone at a place as far as possible from the audio equipment. WARNING: Hyundai recommends that you never use a B750A04L B750A05L cell phone while driving. This could result...
Page 102: Audio System
FEATURES OF YOUR HYUNDAI AUDIO SYSTEM H240A01O-GAT STEREO RADIO OPERATION (H250) (If Installed) 5. BAND Selector 3. TREBLE/FADER Control Knob (TREB/FAD) 2. BASS/BALANCE Control Knob (BASS/BAL) 6. PRESET Buttons 7. SCAN Button 4. TUNE/SEEK Select Button 1. POWER ON/OFF, VOLUME Control Knob...
Page 103 FEATURES OF YOUR HYUNDAI H240B02A-GAT 3. TREB (Treble Control) Knob 5. BAND Selector 1. POWER ON-OFF Control Press to pop the knob out and turn to the left or Pressing the button changes the AM, FM/AM Knob right for the desired treble tone.
Page 104 FEATURES OF YOUR HYUNDAI o Press the station select button for more than two seconds. A select button indicator will show in the display indicating which select button you have depressed. The frequency display will flash after it has been stored into the memory with a beep sound.
Page 105 FEATURES OF YOUR HYUNDAI H240C01O-GAT CASSETTE TAPE PLAYER OPERATION (H250) (If Installed) 3. TAPE PROGRAM Button 6. TAPE SLOT 2. AUTO MUSIC SELECT Button 4. EJECT Button 1. FF/REW Button 5. DOLBY SELECT Button H240C01GK...
Page 106 FEATURES OF YOUR HYUNDAI NOTE: H240A02O-AAT 1. FF/REW Button When tape operation is abnormal or ER8 fault code is displayed, press the eject CAUTION: o The FF (fast forward tape winding) starts button more than 5 seconds to reset the...
Page 107 FEATURES OF YOUR HYUNDAI H260A01O-AAT STEREO RADIO OPERATION (H260) (If installed) 3. BASS/TREBLE Control Knob 4. SCAN Button 6. BAND Selector 2. FADER Control Knob 7. PRESET Buttons 5. TUNE/SEEK Select Button 1. POWER ON-OFF/VOLUME/BALANCE Control Knob H260A01GK...
Page 108 FEATURES OF YOUR HYUNDAI H260B03E-AAT 2. FAD (Fader Control) Knob 5. TUNE (Manual) Select Button 1. POWER ON-OFF Control Knob Turn the control knob counterclockwise to Press the ( ) side or ( ) side to increase or to The radio unit may be operated when the ignition emphasize front speaker sound (rear speaker decrease the frequency.
Page 109 FEATURES OF YOUR HYUNDAI o Press band selector to set the band for AM, 6. BAND Selector FM1 or FM2. Pressing the FM/AM button changes the AM, o Select the desired station to be stored by CAUTION: FM1 and FM2 bands. The mode selected is seek, scan or manual tuning.
Page 110 FEATURES OF YOUR HYUNDAI H260B01O-AAT COMPACT DISC PLAYER OPERATION (H260) (If installed) 4. SCAN Button 1. Playing CD 3. TRACK UP/DOWN 6. EJECT Button 2. FF/REW Button 5. REPEAT Button H260B01GK...
Page 111 FEATURES OF YOUR HYUNDAI NOTE: B260D03O-AAT 4. SCAN Button 1. Playing CD o If the CD does not operate properly or if o Press the SCAN button to playback the first the ER2 fault code is displayed, use one o Insert the CD with the label facing upward.
Page 112 FEATURES OF YOUR HYUNDAI o This unit is made of precision parts. Do o Do not grip or pull out the disc with your not attempt to disassemble or adjust hand while the disc is being pulled into any parts.
Page 113 FEATURES OF YOUR HYUNDAI B260E01E-AAT CD AUTO CHANGER (H260) (If installed) 6. SCAN Button 1. CD Select Button 3. TRACK UP/DOWN 4. FF/REW Button 5. REPEAT Button 2. DISC Select Button H260E01GK...
Page 114 The o This unit is made of precision parts. Do Hyundai CD changer can hold up to eight discs. not attempt to disassemble or adjust The disc number will be lit, and the track number, any parts.
Page 115 FEATURES OF YOUR HYUNDAI CAUTION: o Do not insert warped or poor quality discs into the CD changer as damage to the unit may occur. o Do not insert anything like coins into the changer slot as damage to the unit may occur.
Page 116 FEATURES OF YOUR HYUNDAI H290A01FC-GAT STEREO RADIO OPERATION (H280) (If installed) 1. POWER ON/OFF VOLUME Control Knob 8. SCAN Button (If installed) 7. EQUALIZER Button 3. TREBLE/FAD Konb 2. BASS/BALANCE Control Knob 5. PRESET Buttons 4. TUNE/SEEK Select Button H290A01GK...
Page 117 FEATURES OF YOUR HYUNDAI H290B03E-GAT BALANCE Control knob SEEK Operation (Automatic Channel 1. POWER ON-OFF Control Knob Selection) Pull the Bass control knob out further. Rotate the The radio unit may be operated when the ignition knob clockwise to emphasize right speaker Press the TUNE select button for 0.5 sec or...
Page 118 FEATURES OF YOUR HYUNDAI o Press band selector to set the band for AM, 7. EQUALIZER Button FM or FM2. Press the EQ button to select the CLASSIC, o Select the desired station to be stored by JAZZ, ROCK and DEFEAT MODE for the seek or manual tuning.
Page 119 FEATURES OF YOUR HYUNDAI H290C01FC-GAT CASSETTE TAPE PLAYER OPERATION (H280) (If installed) 5. EQUALIZER Button 4. TAPE EJECT Button 2. AUTO MUSIC Select Button 1. FF/REW Button 6. DOLBY Button 3. TAPE PROGRAM Button H290A02GK...
Page 120 FEATURES OF YOUR HYUNDAI H290D02O-GAT 3. TAPE PROGRAM Button 1. FF/REW Button This allows you to play the reverse side of the CAUTION: o Fast forward tape winding starts when the tape by merely depressing the program button. o Do not insert anything like coins into the...
Page 121 FEATURES OF YOUR HYUNDAI H290E01FC-GAT COMPACT DISC PLAYER OPERATION (H280) (If installed) 6. CD EJECT Button 7. SCAN Button (If installed) 5. EQUALIZER Button 3. TRACK UP/DOWN 2. FF/REW Button 4. REPEAT 1. CD Select Button H290A03GK...
Page 122 FEATURES OF YOUR HYUNDAI H290F01O-GAT 4. REPEAT 7. SCAN Button (If installed) 1. CD Select Button o To repeat the track you are listening to, o Press the SCAN button to playback the first o Insert the CD with the label facing upward.
Page 123 FEATURES OF YOUR HYUNDAI o When driving your vehicle, be sure to o Do not grip or pull out the disc with your keep the volume of the unit set low hand while the disc is being pulled into enough to allow you to hear sounds the unit by the self loading mechanism.
Page 124 FEATURES OF YOUR HYUNDAI H290G01FC-GAT CD AUTO CHANGER (H280) (If Installed) 6. SCAN Button (If installed) 7. EQ Button 3. TRACK UP/DOWN 4. FF/REW Button 5. REPEAT 2. DISC Select Button 1. CD CHANGER Select Button H290A04GK...
Page 125 The Hyundai CD changer can o This unit is made of precision parts. Do This process will be continued until you push hold up to eight discs.
Page 126 FEATURES OF YOUR HYUNDAI CAUTION: o Do not insert warped or poor quality discs into the changer as damage to the unit may occur. o Do not insert anything like coins into the changer slot as damage to the unit may occur.
Page 127 FEATURES OF YOUR HYUNDAI J290A01JM-GAT STEREO RADIO OPERATION (J290) (If installed) 1. POWER ON/OFF/VOLUME Control Knob 2. BAND Select Button 7. TUNE Select Knob / MODE Select Knob 6. EQ Button 3. SEEK Select Button 5. BEST STATION MEMORY J290A01JM...
Page 128 FEATURES OF YOUR HYUNDAI J290B01JM-GAT o When completed, any preset station may be 4. PRESET STATION Select 1. POWER ON-OFF/VOLUME recalled by selecting AM, FM1 or FM2 band Buttons and the appropriate station button. Control Knob Six (6) stations for AM, FM and FM2 respec-...
Page 129 FEATURES OF YOUR HYUNDAI Mode Select Knob FAD (Fader Control) Pressing the MODE button changes the BASS, Rotate the control knob clockwise to empha- MIDDLE, TREBLE, FADER and BALANCE size rear speaker sound (front speaker sound mode. will be attenuated). When the control knob is The mode selected is shown on the display.
Page 130 FEATURES OF YOUR HYUNDAI J290C01JM-GAT CASSETTE TAPE PLAYER OPERATION (J290) (If installed) 1.TAPE PROGRAM Button 2.EJECT Button 6.FF/REW Button 5.AUTO MUSIC Select Button 4.REPEAT Button J290C01JM 3. DOLBY Button...
Page 131 FEATURES OF YOUR HYUNDAI J290D01JM-GAT 5. AUTO MUSIC Select Button 1. TAPE PROGRAM Button Press the button to find the starting point of each CAUTION: This allows you to play the reverse side of the song in a prerecorded music tape. The quiet o Do not insert anything like coins into the tape by merely pressing the program button.
Page 132 FEATURES OF YOUR HYUNDAI J290E01JM-GAT COMPACT DISC PLAYER / CD AUTO CHANGER OPERATION (J290) (If installed) 1.LOAD Button 2.Playing CD 3.EJECT Button 10.EQ Button 4. DISC Select Button 9.SCAN Button 8.FF/REW Button 7.TRACK UP/DOWN J290E01JM 6.REPEAT Button 5.RANDOM Play Button...
Page 133 FEATURES OF YOUR HYUNDAI J290F02JM-GAT 2. Load a disc while the is blinking. Insert 2. Playing CD 1. LOAD Button a disc partway into the slot, label side up. The o Press the 6CDC to start CD playback, player will pull the disc in.
Page 134 FEATURES OF YOUR HYUNDAI NOTE: 5. RANDOM Button 8. FF/REW Button o To assure proper operation of the unit, With random, you can listen to the tracks in While the disc is playing, if you hold down the FF keep the vehicle interior temperature...
Page 135 FEATURES OF YOUR HYUNDAI CAUTION: o Do not insert warped or poor quality discs into the CD player as damage to the unit may occur. o Do not insert anything like coins into the player slot as damage to the unit may occur.
Page 136 If you see any error indication in the display while using the system in the CD or Tape mode, find the cause in the chart below. If you cannot clear the error indication, take the car to your Hyundai dealer.
Page 137 FEATURES OF YOUR HYUNDAI CARE OF DISCS CARE OF CASSETTE TAPES B850A02F-AAT B860A01A-AAT Storage Proper Handling When not in use, place your discs in their individual case and store them in a cool place away from the sun, heat, and dust.
Page 138 FEATURES OF YOUR HYUNDAI o Never leave a cassette inserted in the player o Store cassettes in a cool, dry place with the o The playback head, capstan and pinch roll- when not being played. This could damage open side facing down to prevent dust from ers will develop a coating of tape residue that the tape player unit and the cassette tape.
Page 139: Antenna
FEATURES OF YOUR HYUNDAI ANTENNA B870A01A-AAT Fixed Rod Antenna CAUTION: o Be sure to remove the antenna before washing the car in an automatic car wash or it may be damaged. o When reinstalling your antenna, it is important that it is fully tightened to ensure proper reception.
Page 140: Driving Your Hyundai
DRIVING YOUR HYUNDAI Engine Exhaust Can Be Dangerous! ......2-2 Before Starting the Engine ..........2-3 Key Positions ..............2-4 Starting ................2-5 Operating the Manual Transaxle ........2-6 Automatic Transaxle ............. 2-8 Anti-Lock Brake System (ABS) ........2-12 Good Braking Practices ..........2-12 Electronic Stability Program (ESP) ......
Page 141 Hyundai dealer. o Do not run the engine in an enclosed area.
Page 142 COMBINATION IGNITION SWITCH Before you start the engine, you should always: WARNING: o If your Hyundai is equipped with a manual 1. Look around the vehicle to be sure there are o All passengers must be properly belted transaxle, place the shift lever in neutral and no flat tires, puddles of oil, water or other whenever the vehicle is moving.
Page 143 DRIVING YOUR HYUNDAI KEY POSITIONS NOTE: C040A02A-AAT C070C03A-AAT To Remove the Ignition Key Do not hold the key in the "START" position for more than 15 seconds. LOCK o "ON" LOCK When the key is in the "ON" position, the ignition is on and all accessories may be turned on.
Page 144 DRIVING YOUR HYUNDAI STARTING C050A01A-AAT C050B02JM-AAT NORMAL CONDITIONS: The Starting Procedure: WARNING: LOCK Always fully depress the brake pedal before and while shifting out of the "P" Park posi- 1. Insert key, and fasten the seat belt. 2. Depress the clutch pedal fully and place the...
Page 145 HGK3023 When shifting into reverse gear, pull the mis- vertently press the gear shift lever sideways Your Hyundai's manual transaxle has a con- shift prevention tab and shift into reverse gear in such a manner that second gear is en- ventional shift pattern.
Page 146 DRIVING YOUR HYUNDAI C070B01A-AAT C070D04A-AAT Using the Clutch Good Driving Practices WARNING: The clutch should be pressed all the way to the o Never take the car out of gear and coast o Always buckle-up! In a collision, an floor before shifting, then released slowly. The down a hill.
Page 147 15 mph (20 km/h) 25 mph (40 km/h) HGK3025 35 mph (55 km/h) The highly efficient Hyundai automatic transaxle 45 mph (75 km/h) has four forward speeds and one reverse speed. The individual speeds are selected au- tomatically, depending on the position of the Type B (6 speed) speed selector lever.
Page 148 DRIVING YOUR HYUNDAI NOTE: C090C01A-AAT C090F02GK-GAT o R(Reverse): Sports Mode Depress the brake pedal and push the button when shifting. Use for backing up the vehicle. Bring the car to a complete stop before shifting the selector Push the button when shifting.
Page 149 DRIVING YOUR HYUNDAI o To maintain the required levels of ve- C090I03L-GAT hicle performance and safety, the sys- tem may not execute certain gearshifts CAUTION: when the selector lever is operated. CAUTION: o In sports mode, the driver must execute o Before driving away from a stop on a o Shift into "R"...
Page 150 DRIVING YOUR HYUNDAI C090N05O-AAT o Optimum vehicle performance and economy Good Driving Practices is obtained by smoothly depressing and releasing the accelerator pedal. WARNING: o Never move the gear selector lever from "P" If your vehicle becomes stuck in snow, or "N"...
Page 151 DRIVING YOUR HYUNDAI ANTI-LOCK BRAKE SYSTEM (ABS) GOOD BRAKING PRACTICES C120A03A-AAT C130A02A-AAT (If installed) WARNING: The Anti-Lock Brake System (ABS) is designed WARNING: ABS will not prevent accidents due to im- to prevent wheel lock-up during sudden braking o Whenever leaving vehicle or parking, proper or dangerous driving maneuvers.
Page 152 ESP installed, always follow all the normal Hyundai dealer for assistance. o Under some conditions your parking brake precautions for driving - including driving o Don’t coast down hills with the car out of gear.
Page 153 DRIVING YOUR HYUNDAI C310B01JM-AAT ESP ON/OFF Mode CAUTION: When the ESP is operating, the ESP indicator in Driving with varying tire or wheel size may the instrument cluster will blink. cause the ESP system to malfunction. When If you turn the system off by pressing the ESP...
Page 154 Keep your car clean. For maximum service, sary braking. This also reduces brake wear. If ESP-OFF indicator illuminates, pull your car your Hyundai should be kept clean and free o Drive at a moderate speed. The faster you to a safe place and stop the engine.
Page 155 DRIVING YOUR HYUNDAI SMOOTH CORNERING WINTER DRIVING o Don't "lug" or "over-rev" the engine. Lugging C150A01A-AAT C160A01A-AAT is driving too slowly in too high a gear result- Avoid braking or gear changing in corners, The more severe weather conditions of winter ing in the engine bucking.
Page 156 Hyundai dealer or a service station. To keep the locks from freezing, squirt an cannot roll. Then release the parking brake.
Page 157 DRIVING YOUR HYUNDAI HIGHER SPEED MOTORING C160J01A-AAT C170A02A-AAT 2. Fuel, engine coolant and engine oil: Don’t Let Ice and Snow Accumulate Pre-Trip Inspections High speed travel consumes more fuel than urban motoring. Do not forget to check both Underneath 1. Tires: engine coolant and engine oil.
Page 158 Ask your sis. Hyundai dealer for further details before towing. The hitch should be bolted securely to the car and installed by a qualified technician. DO NOT USE A HITCH DESIGNED FOR TEMPORARY...
Page 159 DRIVING YOUR HYUNDAI C190E02GK-AAT Trailer Weight Limit CAUTION: o Never connect a trailer brake system directly to the vehicle brake system. o When towing a trailer on steep grades (in excess of 6%) pay close attention to the engine coolant temperature gauge to ensure the engine does not overheat.
Page 160 DRIVING YOUR HYUNDAI C190F01S-AAT (automatic). In addition, place wheel chocks Trailer or Vehicle Towing Tips at each of the trailer's tires. 9. If the trailer has electric brakes, start your CAUTION: 1. Before towing, check hitch and safety chain vehicle and trailer moving, and then apply the...
Page 161 DRIVING YOUR HYUNDAI VEHICLE LOAD LIMIT C190F01GK-AAT Vehicle capacity weight: Tire and Loading Information Label 700 lbs (317 kg) CAUTION: Vehicle capacity weight is the maxi- If overheating should occur when towing, mum combined weight of occupants (the temperature gauge reads near red zone), taking the following action may reduce or and cargo.
Page 162 DRIVING YOUR HYUNDAI Towing capacity: (3)Subtract the combined weight of the Example 1 Towing capacity is the maximum trailer driver and passengers from XXX weight including its cargo weight, your kilograms or XXX pounds. vehicle can tow. See the section "Trailer (4)The resulting figure equals the avail- or Vehicle Towing"...
Page 163 DRIVING YOUR HYUNDAI Refer to your vehicle's tire and loading Example 2 Example 3 information label for specific informa- tion about your vehicle's capacity weight and seating positions. The combined weight of the driver, passengers and cargo should never exceed your vehicle's capacity weight.
Page 164 DRIVING YOUR HYUNDAI C190G03JM-AAT This label also tells you the maximum Compliance Label weights that can be supported by the WARNING: front and rear axles, called Gross Axle o Do not load your vehicle any Weight Rating (GAWR). To find out the...
Page 165 DRIVING YOUR HYUNDAI NOTE: o Overloading your vehicle may WARNING: WARNING: cause damage. Repairs would not o Overloading your vehicle can Items you carry inside your vehicle be covered by your warranty. Do cause heat buildup in your can strike and injure people in a not overload your vehicle.
Page 166 WHAT TO DO IN AN EMERGENCY If the Engine will not Start ..........3-2 Jump Starting ..............3-3 If the Engine Overheats ..........3-4 Spare Tire ..............3-5 If You Have a Flat Tire ..........3-6 Changing a Flat Tire ............3-6 If Your Vehicle Must be Towed ........
Page 167 3. Try to start the engine again. If your vehicle 3. Turn on the interior light. If the light dims or will not start, contact a Hyundai dealer or seek other qualified assistance. goes out when you operate the starter, the battery is discharged.
Page 168 WHAT TO DO IN AN EMERGENCY JUMP STARTING D020A03A-AAT o To jump start a car with a discharged battery, follow this procedure exactly: 2.0L WARNING: 1. If the booster battery is installed in another The gas produced by the battery during the vehicle, be sure the two vehicles are not jump-start operation is highly explosive.
Page 169 (manual transaxle) and set engine coolant is leaking out, stop the engine the parking brake. If the air conditioning is on, immediately and call the nearest Hyundai turn it off. dealer for assistance. 3. If engine coolant is running out under the car or steam is coming out from the hood, stop the engine.
Page 170 1. Check inflation pressure as soon as be used on any other wheels, nor ther signs of overheating. If overheating practical after installing the spare happens again, call a Hyundai dealer for should standard tires, snow tires, assistance. tire, and adjust to the specified pres- wheel covers or trim rings be used sure.
Page 171 WHAT TO DO IN AN EMERGENCY IF YOU HAVE A FLAT TIRE D040B01A-AAT D050A01A-AAT Handling the Spare Tire If a tire goes flat while you are driving: WARNING: 1. Take your foot off the accelerator The temporary spare tire is for emer- gency use only.
Page 172 WHAT TO DO IN AN EMERGENCY CHANGING A FLAT TIRE D060A02A-AAT D060B02GK-AAT 1. Obtain Spare Tire and Tool HGK4009 D060A01GK The jack is located behind the right side The procedure described on the follow- HGK4008 of luggage trim. Remove the jack cover Remove the spare tire and remove the ing pages can be used to rotate tires as by unscrewing the bolts.
Page 173 WHAT TO DO IN AN EMERGENCY D060C01A-AAT D060D02A-AAT D060E01A-AAT 2. Block the Wheel 3. Loosen Wheel Nuts 4. Put the Jack in Place Flat tire HGK4011 HGK4012 HGK4013 The base of the jack should be placed Block the wheel that is diagonally oppo- The wheel nuts should be loosened on firm, level ground.
Page 174 WHAT TO DO IN AN EMERGENCY D060F02E-AAT Raise the car high enough so that the D060G02Y-AAT 5. Raising the Car 6. Changing Wheels fully inflated spare tire can be installed. To do this, you will need more ground clearance than is required to remove the flat tire.
Page 175 WHAT TO DO IN AN EMERGENCY ameter ends directed inward. Jiggle the wheel nuts could come loose and tire to be sure it is completely seated, cause the loss of a wheel. Loss of a then tighten the nuts as much as pos- wheel may result in loss of control of sible with your fingers again.
Page 176 WHAT TO DO IN AN EMERGENCY on the wrench handle or use an exten- D060J01FC-GAT After you have changed wheels, al- After Changing Wheels sion pipe over the wrench handle. ways secure the flat tire in its place in Go around the wheel tightening every the luggage compartment and return other nut until they are all tight.
Page 177 D080B01O-GAT If your vehicle has to be towed, it should be done Towing the Vehicle by your Hyundai dealer or a commercial tow CAUTION: truck service. This will help assure that your o When towing the vehicle, take care not to vehicle is not damaged in towing.
Page 178 WHAT TO DO IN AN EMERGENCY EMERGENCY TOWING 1) If the vehicle is being towed with the rear o Automatic Transaxle: D080D02A-AAT wheels on the ground, be sure the parking Be sure to use a towing dolly under the front Front brake is released.
Page 179 WHAT TO DO IN AN EMERGENCY IF YOU LOSE YOUR KEYS D120A01A-AAT If you lose your keys, many Hyundai dealers CAUTION: can make you a new key if you have your key number. o If the car is being towed with all four...
Page 180 CORROSION PREVENTION & APPEARANCE CARE Corrosion Protection ............. 4-2 To Help Prevent Corrosion ........... 4-2 Washing and Waxing ............ 4-3 Cleaning the Interior ............4-5...
Page 181 By using the most advanced design and con- tection is particularly important. Some of the struction practices to combat corrosion, common causes of accelerated corrosion are Hyundai produces cars of the highest quality, E020B01A-AAT road salts, dust control chemicals, ocean air Keep Your Car Clean However, this is only part of the job.
Page 182 These should be carried only in proper contain- the package. These are available at your ers and any spills or leaks should be cleaned up, Hyundai dealer or auto parts outlet. Don't use flushed with clear water and thoroughly dried. strong household detergents, gasoline, strong solvents or abrasive cleaning powders as these may damage the finish.
Page 183 To protect the paintwork of the car Don’t use gasoline, strong solvents or corro- sponge or soft cloth and water. against corrosion, you must clean your Hyundai sive cleaning agents. These can damage the (at least once a month). Give special attention finish of the car.
Page 184 Then apply In the normal course of use, leather upholstered Hyundai. They are: a solution of mild soap or detergent and water surfaces will, like any material, pick-up dust and using a clean sponge or soft cloth.
Page 185 Cleaning the Carpets Cleaning the Windows If you have any questions about the care of your car, consult your Hyundai dealer. Use a foam-type carpet cleaner. Cleaners of You may use any household window cleaner on this type are available in aerosol cans in liquid the windows.
Page 186 VEHICLE MAINTENANCE REQUIREMENTS Maintenance Intervals ........... 5-2 Scheduled Maintenance ..........5-4 Maintenance under Severe Usage Conditions ..... 5-6 Explanation of Scheduled Maintenance Items ....5-7...
Page 187 These are the regular checks you should per- of miles of satisfying operation from your Hyundai, adjustments and replacements that are listed in form when you drive your Hyundai or you fill the certain maintenance procedures must be per- the maintenance charts starting on page 5-4.
Page 188 If you choose to do your own maintenance ments, see page 5-6 of this section. and repairs, you may find it helpful to have an official Hyundai Shop Manual. A copy of this publication may be purchased at your Hyundai dealer's parts department.
Page 189 VEHICLE MAINTENANCE REQUIREMENTS SCHEDULED MAINTENANCE F030A01A-AAT The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your emission warranty. Where both mileage and time are shown, the frequency of service is determined by whichever occurs first. F030B04GK-AAT R :Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary.
Page 190 VEHICLE MAINTENANCE REQUIREMENTS F030C02GK-AAT R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MILES X 1000 22.5 37.5 52.5 67.5 82.5 97.5 112.5 127.5 142.5 DESCRIPTION KILOMETERS X 1000 MONTHS GENERAL ITEMS DRIVE BELT (WATER PUMP, GENERATOR AND A/CON) COOLANT TIMING BELT MANUAL TRANSAXLE OIL...
Page 191 VEHICLE MAINTENANCE REQUIREMENTS MAINTENANCE UNDER SEVERE USAGE CONDITIONS F040A04GK-AAT The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE DRIVING...
Page 192 Air cleaner filter o Fuel Filter o Crankcase Ventilation Hoses A Genuine Hyundai air cleaner filter is recom- A clogged filter can limit the speed at which the Inspect the surface of hoses for evidence of mended when the filter is replaced.
Page 193 Check the automatic transaxle fluid level with the engine running and the transaxle in neutral, with the F070H01A-AAT parking brake properly applied. Use HYUNDAI F060E01A-AAT o Rear Brake Drums and Linings/ o Timing belt GENUINE ATF SP III, DIAMOND ATF SP III, SK...
Page 194 VEHICLE MAINTENANCE REQUIREMENTS F070J01A-AAT F070M01A-AAT F070Q01A-AAT o Brake Pads, Calipers and Rotors o Steering gear box, linkage & o Air Conditioning Refrigerant boots/lower arm ball joint Check the pads for excessive wear, discs for Check the air conditioning lines and connec- run out and wear, and calipers for fluid leakage.
Page 195 Do-It-Yourself Maintenance Engine Compartment ............ 6-2 General Checks ............6-4 Checking the Engine Oil ..........6-5 Changing the Oil and Filter ..........6-6 Checking and Changing the Engine Coolant ....6-7 Changing the Air Cleaner Filter ........6-10 Checking the Transaxle Oil (manual) ......6-12 Checking the Transaxle Fluid (Automatic) ....
Page 196 DO-IT-YOURSELF MAINTENANCE ENGINE COMPARTMENT G010B01GK-GAT (2.0 DOHC CVVT) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HGK5002 1. Engine oil filler cap 5.
Page 197 DO-IT-YOURSELF MAINTENANCE G010C01GK-GAT (2.7 V6) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HGK5001 1. Power steering fluid reservoir 5. Relay box 10.Engine oil filler cap 2.
Page 198 Seat control condition and operation o Seat belt condition and operation o Sunvisor operation If you notice anything that does not operate correctly or appears to be functioning incor- rectly, inspect it carefully and seek assistance from your Hyundai dealer if service is needed.
Page 199 DO-IT-YOURSELF MAINTENANCE CHECKING THE ENGINE OIL NOTE: G030A01A-AAT G030C02A-AAT To Check the Oil Level o For good fuel economy, SAE 5W-20 (5W- Engine oil is essential to the performance and 30), ILSAC GF-3 engine oil is preferred service of the engine. It is suggested that you 2.0L 2.7L regardless of regional option and en-...
Page 200 DO-IT-YOURSELF MAINTENANCE CHANGING THE OIL AND FILTER G030D01A-AAT G040A04GK-AAT The engine oil and filter should be changed at Adding Oil those intervals specified in the maintenance 2.0L schedule in Section 5. If the car is being driven 2.0L 2.7L in severe conditions, more frequent oil and filter changes are required.
Page 201 DO-IT-YOURSELF MAINTENANCE CHECKING AND CHANGING THE ENGINE COOLANT 4. When the oil has stopped draining, replace G050A01A-AAT the drain plug using a new gasket and re- tighten by turning it clockwise. CAUTION: WARNING: Slowly pour the recommended oil using by Tightening torque is: Do not remove the radiator cap when the a funnel.
Page 202 -31 (-35) level frequently. If the level drops again, visit coolant container, add the appropriate quan- your Hyundai dealer for an inspection and -49 (-45) tity of coolant to the radiator. diagnosis of the reason.
Page 203 DO-IT-YOURSELF MAINTENANCE WARNING: The cooling fan is controlled by engine coolant temperature and may sometimes operate even when the engine is not run- ning. Use extreme caution when working near the blades of the coolant fan so that you are not injured by a rotating fan blade. As the engine coolant temperature de- creases, the fan will automatically shut off.
Page 204 To clean in its place. Genuine Hyundai Replacement the wiper blades and arms, use a clean sponge Parts are recommended.
Page 205 DO-IT-YOURSELF MAINTENANCE G080B01HR-GAT 1. Put a new wiper blade onto the wiper arm and Replacing the Wiper Blades lower the wiper blade at the level of the wiper arm as shown in the drawing. To replace the wiper blades, raise the wiper to the vertical.
Page 206 Recommended Oil more frequent use. reservoir. Damage to the vehicle or its Use only HYUNDAI GENUINE PARTS MTF The capacity of the washer reservoir is 3.2 U.S. occupants could occur. 75W/85 (API GL-4) or equivalents in the manual quarts (3.0 Liters).
Page 207 MOND ATF SP III, SK ATF SP III or other brands meeting the SP III specification ap- proved by Hyundai Motor Co.. If you are having your vehicle serviced at a facility other than a Hyundai dealer, verify ATF is...
Page 208 DO-IT-YOURSELF MAINTENANCE G110C02Y-AAT G110D02Y-AAT 2.0L 2.7L Transaxle Fluid Capacity To Check the Transaxle Fluid Level The fluid capacity of the automatic transaxle is 8.2 U.S. quarts (7.8 liters). WARNING: The transaxle fluid level should be checked when the engine is at normal operating temperature.
Page 209 Use caution when handling brake fluid. It they be checked and inspected by your can damage your vision if it gets into your Hyundai dealer. The brakes should be eyes. It will also damage your vehicle’s checked and inspected for wear at those...
Page 210 "MAX". Do not overfill. is always between the "MAX" and "MIN" level markings on the fluid reservoir. Fill as required. Fluid loss indicates a leak in the clutch system which should be inspected and repaired imme- diately. Consult your Hyundai dealer.
Page 211 Do not allow any other liquids to contami- inspected by your Hyundai dealer. nate the brake fluid. Seal damage will result. CAUTION: WARNING: Running the air conditioning system for Use caution when handling brake fluid.
Page 212 22 lb.(98N), the deflection should be 0.315 inches 0.315 in. (approx 8.0 mm). If the belt is too loose, have it (8mm) adjusted by your Hyundai dealer. Tension pulley Crankshaft pulley HTB219 2.7 L...
Page 213 DO-IT-YOURSELF MAINTENANCE HGK2112 HGK2114 HGK2115 3. Remove the filter cover. 4. Replace the climate control air filter with a 2. Open the glove box and remove the mount- new one. ing screws on the upside of the glove box. 5. Installation is the reverse order of disassem- bly.
Page 214 Hyundai necessary. The free-play should be within the limits speci- dealer and adjusted or repaired if necessary. fied in the illustration. If it is not, have it inspected by your Hyundai dealer and adjusted or re- paired if necessary.
Page 215 If the brake pedal clearance is not within the limits specified in the illustration, have it in- spected by your Hyundai dealer and adjusted Generator or repaired if necessary. Crankshaft pulley G190A02B...
Page 216 If this ever happens, fuse. have a Hyundai dealer determine the cause, If any of your car’s lights or other electrical repair the system and replace the fusible link.
Page 217 HXDFL1026-1 ing precautions to avoid serious injuries. serious and should be referred to a Hyundai 4. Replace the blown fuse by pressing a new dealer for diagnosis and repair. Never re- fuse of the same rating into place. The fuse...
Page 218 DO-IT-YOURSELF MAINTENANCE o If battery fluid is on your skin, flush the G210B03A-AAT Checking the Battery affected areas with water for at least 15 minutes and then seek medical assistance. WARNING: Keep the battery clean. Any evidence of corro- o If battery fluid is in your eyes, rinse out your Always read the following in- sion around the battery posts or terminals eyes with water and get medical assistance...
Page 219 DO-IT-YOURSELF MAINTENANCE CHECKING ELECTRIC COOLING FANS G220A01A-AAT G220B01A-AAT Checking Engine Cooling Fan WARNING: The engine cooling fan should come on auto- WARNING: If electrolyte gets on your skin, matically if the engine coolant temperature is thoroughly wash the contacted The cooling fan is controlled by engine high.
Page 220 DO-IT-YOURSELF MAINTENANCE POWER STEERING FLUID LEVEL HEADLIGHT AIMING ADJUSTMENT G230A03A-AAT Recommended Fluid G290A03GK-AAT Use PSF-3 type fluid Low Beam Vertical aiming NOTE: Do not start the engine when the power steering oil reservoir is empty. G240A01A-AAT POWER STEERING HOSES It is suggested that you check the power steer- ing hose connections for fluid leakage at regular intervals.
Page 221 "P" shown in the illustration. ment of your headlights. Horizontal aiming 2. Dotted lines in the illustration show the center must be adjusted by an authorized Hyundai of headlights. dealer to avoid incorrect alignment that will reduce the effectiveness of your headlights.
Page 222 DO-IT-YOURSELF MAINTENANCE REPLACEMENT OF LIGHT BULBS G260A02A-AAT G270A01GK-AAT Headlight and Front Turn Signal Light Before attempting to replace a light bulb, be sure the switch is turned to the "OFF" position. 1. Allow the bulb to cool. Wear eye protection. The next paragraph shows how to reach the 2.
Page 223 DO-IT-YOURSELF MAINTENANCE HGK5026 HGK5027 HGK5036 7. Push the bulb spring to remove the headlight 11.To replace the front turn signal light bulb, 8. Remove the protective cap from the re- bulb. remove from the bulb holder and install the placement bulb and install the new bulb by new bulb.
Page 224 DO-IT-YOURSELF MAINTENANCE G270B01GK-GAT Rear Combination Light (Without woofer speaker) G270A03O HGK5041 2. To remove the cover of the rear luggage trim, turn the knob by hand to the counterclock- wise. HGK5037 WARNING: 1. Open the tail gate. This halogen bulb contains gas under pres- sure and if impacted could shatter, result- ing in flying fragments.
Page 225 DO-IT-YOURSELF MAINTENANCE HGK5044 HGK5042 5. To replace the rear combination light (stop/ HGK5043-1 3. Remove the nut (8mm) with a spanner. tail light, back-up light, turn signal light, side 4. To detach the rear combination light hit it mark light), take it out from the bulb holder by strongly by hand.
Page 226 DO-IT-YOURSELF MAINTENANCE G275B01GK-GAT Rear Combination Light (With woofer speaker) HGK5038 HGK5039 3. Extract the mounting screws (10mm) around 2. Take off the luggage board. the woofer speaker with a spaner. HGK5037 1. Open the tail gate. HGK5040 4. Disconnect the power cord from the woofer speaker.
Page 227 DO-IT-YOURSELF MAINTENANCE HGK5041 HGK5044 HGK5042 8. To replace the rear combination light (stop/ 5. To remove the cover of the rear luggae trim, 6. Remove the nut (8mm) with a wrench. tail light, back-up light, turn signal light, side turn the knob by hand to the counterclock- mark light), take it out from the bulb holder by wise.
Page 228 DO-IT-YOURSELF MAINTENANCE G270C01GK-AAT G270G01GK-AAT Luggage Compartment Light Map Light HGK5046 3. Disconnect the power cord. HGK5045 HGK5047 1. Remove the cover with a flat-blade screw- 1. Open the tail gate. driver. 2. Remove the cover with a flat-blade screw- driver. HTB284 4.
Page 229 DO-IT-YOURSELF MAINTENANCE G270H01GK-GAT Glove Box Illuminated Light HGK5048 HGK2112 2. Open the glove box and remove the mount- 2. Replace with a new bulb. ing screws on the upside of the glove box. HGK2111 1. Remove the mounting screws on the down- side of the glove box.
Page 230 DO-IT-YOURSELF MAINTENANCE Power Cord Clip HTB284 HGK5052 HGK5053 4. Disconnect the power cord. 6. Replace with a new bulb. 3. Remove the glove box by pulling strongly. 5. Remove the glove box illuminated light by pushing the clip. CAUTION: Be careful not to damage the glove box when pulling the glove box.
Page 231 DO-IT-YOURSELF MAINTENANCE BULB WATTAGE G280A04GK-AAT (High) (Low) HGK5021A Wattage Socket type Part Name Wattage Socket type Part Name Head Light (High/Low) 55/55 Px26d/Px26d High Mounted Rear With spoiler 2.4 (LED) W2.1 X 9.5d 3.5 (LED) Map Light W2.1 X 9.5D Stop Light Without spoiler BA15s...
Page 232 DO-IT-YOURSELF MAINTENANCE FUSE PANEL DESCRIPTION G200C01GK-GAT Engine Compartment If installed HGK4005 NOTE: Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label.
Page 233 DO-IT-YOURSELF MAINTENANCE DESCRIPTION FUSERATING PROTECTED COMPONENTS BATT 120A Generator(2.0L) BCM BOX(Tail lamp relay,Power connector,Fuse(2,7,12,13,19,20,24) BATT COND Condenser fan relay Radiator fan relay Engine control relay, Fuel pump relay, A/T control relay, Generator,ECM(Z2.7L),PCM(2.0L) Ignition switch,Start relay ABS 1 ABS/ESP control module,ESP Air bleeding connector ABS 2 ABS/ESP control module,ESP Air bleeding connector BLOWER...
Page 234 DO-IT-YOURSELF MAINTENANCE G200D02GK-GAT Inner Panel HGK204-E...
Page 235 DO-IT-YOURSELF MAINTENANCE DESCRIPTION FUSERATING PROTECTED COMPONENTS IG COIL Ignition coil(2.7L), Electronic chrome mirror B/UP LAMP Back-up lamp switch,Transaxle range switch,Cruise control module,Stop lamp switch A/BAG IND Instrument cluster (A/BAG IND.) A/BAG SRS control module Mirror defogger HTD MIR HAZARD Hazard relay R/WIPER Rear wiper motor,Rear intermittent wiper relay TAIL-RH...
Page 236 EMISSION CONTROL SYSTEMS Emission Control System ..........7-2 Catalytic Converter ............7-3...
Page 237 PCSV closes so that evaporated fuel is not that you have your car inspected and main- taken into the engine. After the engine warms- tained by an authorized Hyundai dealer in ac- H010C01S-AAT up during ordinary driving, the PCSV opens to 2.
Page 238 Remember that your Hyundai dealer is your best source of assistance. WARNING: o Do not stop your Hyundai over any com- o Use unleaded fuel only. bustible material such as grass, paper, o Maintain the engine in good operating leaves or rags.
Page 239 Tire Balancing ............. 8-11 Tire Traction ..............8-11 When to Replace Tires ..........8-12 Spare Tire and Tools ........... 8-13 Warranties for Your Hyundai Vehicle ......8-13 Consumer Information ..........8-13 Reporting Safety Defects ..........8-16 Binding Arbitration of Warranty Claims ....... 8-16...
Page 240 I020A02A-AAT I010A01A-AAT I010B01A-AAT TIRE INFORMATION 2.0L The tires supplied on your new Hyundai are chosen to provide the best perfor- mance for normal driving. If you ever have questions about your tire warranty and where to obtain ser- vice, see the tire manufacture's booklet included with your vehicle's Owner's Manual Literature Kit.
Page 241 Remember to check the pressure vehicle and vehicle capacity weight. of your spare tire. Hyundai recom- mends that you check the spare every time you check the pressure of the other tires on your vehicle.
Page 242 1 Hyundai Dealer. mile (1.6 km) since starting up.) o Overinflation produces a harsh o Check the pressure of your spare...
Page 243 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I035A01JM-AAT label, no further adjustment is neces- I030B01GK-GAT CHECKING TIRE INFLATION PRES- TIRE SIDEWALL LABELING sary. If the pressure is low, add air until SURE you reach the recommended amount. Check your tires once a month or more.
Page 244: Index
CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS 1. Manufacturer or Brand name o V: Speed Rating. The speed rating o Four numbers represent the week o Manufacturer or Brand name is denotes the speed at which a tire is and year the tire was built.
Page 245 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS 6. Maximum load rating I030D01JM-AAT Cold Tire Pressure: The amount of air TIRE TERMINOLOGY AND DEFINI- This number indicates the maximum pressure in a tire, measured in pounds TIONS load in kilograms and pounds that per square inch (psi) or kilopascals Air Pressure: The amount of air inside...
Page 246 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS Intended Outboard Sidewall: The side Occupant Distribution: Designated Sidewall: The portion of a tire between of an asymmetrical tire, that must al- seating positions. the tread and the bead. ways face outward when mounted on a Outward Facing Sidewall: The side of Speed Rating: An alphanumeric code...
Page 247 ALL SEASON TIRES of designated seating positions multi- If you equip your car with snow tires, Hyundai specifies all season tires on plied by 150 lbs. (68 kg) plus the rated they should be the same size and have some models to provide good perfor-...
Page 248 To minimize tire and chain wear, do not tations, have the car checked by a chain to avoid contact with the continue to use tire chains when they Hyundai dealer so the cause may be vehicle body. are no longer needed. corrected.
Page 249 The tires on your tire for tire rotation. the tires must be mount following Hyundai were balanced before the car o Do not mix bias ply and radial ply the "ROTATION" direction marked was delivered but may need balancing tires under any circumstances.
Page 250 Replace tires that are worn, show o Wheels that do not meet Hyundai's uneven wear, or are damaged. specifications may fit poorly and Worn tires can cause loss of brak-...
Page 251 Spare tire and wheel Wheel nut wrench, Wrench bar Jack I110A01A-AAT SHOP MANUAL A Hyundai Shop Manual is available from your authorized Hyundai dealer. It's written for pro- fessional technicians, but is simple enough for most mechanically-inclined owners to under- stand.
Page 252 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I130B04A-AAT Traction AA, A, B, C - The traction Temperature A, B, C - The tempera- Uniform tire quality grading grades, from highest to lowest, are AA, ture grades are A (the highest), B, and Department of Transportation quality A, B, and C.
Page 253 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I130D04A-AAT South Central Region: Alabama, Arkansas, Hyundai motor vehicles are designed and manu- Colorado, Kansas, Louisiana, Mississippi, Mis- factured to meet or exceed all applicable safety souri, New Mexico, Oklahoma, Tennessee, WARNING: standards.
Page 254 All other arbitration costs shall be borne To contact NHTSA, you may call the fairs, 10550 Talbert Avenue, P.O. Box by Hyundai Motor America. You are not Vehicle Safety Hotline toll-free at 1- 20849, Fountain Valley, CA 92728-0849. responsible to pay any of the costs 888-327-4236 (TTY: 1-800-424-9153);...
Page 255 VEHICLE SPECIFICATIONS Measurement ..............9-2 Engine ................9-3 Lubrication Chart ............9-4...
Page 256 VEHICLE SPECIFICATIONS J010A01GK-AAT J030A01GK-AAT MEASUREMENT TIRE in.(mm) Overall length 173(4395) Option 205/55 R16, 215/45 R17 Overall width 69.3(1760) Overall height (unladen) 52.4(1330) J035A01GK-GAT Wheel base 99.6(2530) SPARE TIRE Front Wheel tread 58.7(1490) Standard T125/70 R16 (Temporary) Rear 58.7(1490) J040A03GK-GET ELECTRICAL J020A01GK-AAT POWER STEERING Item...
Page 257 VEHICLE SPECIFICATIONS ENGINE J070A05GK-AAT SPECIFICATION ITEMS 2.0 L 2.7 L Engine Type 4-Cyl., In-line DOHC CVVT 6-Cyl., V-type DOHC Bore x Stroke (mm) 82 x 93.5 86.7 x 75 Displacement (cc) 1,975 2,656 Firing order 1 - 3 - 4 - 2 1 - 2 - 3 - 4 - 5 - 6 Intake 0.0067 ~ 0.0091 in.(0.17 ~ 0.23 mm)
Page 258 Manual HYUNDAI GENUINE PARTS MTF 75W/85 (API GL-4) 5 speed : 2.27 (2.15, 1.86), 6 speed : 2.32 (2.2, 1.94) HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, Transaxle Auto SK ATF SP III or other brands meeting the SP III specification approved 8.2 (7.8, 6.9)
Page 259 INDEX...
Page 260 Consumer Information ..............8-13 Breaking-In your new Hyundai ............1-3 Cooling Fans ..................6-25 Bulbs Wattage ................... 6-37 Corrosion Protection Cleaning the interior ............... 4-5 Protecting your Hyundai from corrosion ........4-2 Washing and waxing ..............4-3 Cruise Control ................... 1-67...
Page 261 INDEX Defrosting/Defogging ................ 1-79 Floor mat Anchor ................1-66 Door Front Fog Light Switch ..............1-51 Central door lock ................1-6 Front Seats Door locks ..................1-4 Adjustable front seats ..............1-10 Front door edge warning light ............1-61 Adjustable headrests ..............1-12 Locking, unlocking front door with a key ........
Page 262 INDEX Heating and cooling control Rotary Type ................. 1-71 Maintenance Intervals Automatic Type ................1-80 Explanation of scheduled maintenance items ....... 5-7 High-mounted Rear Stop light ............1-61 Maintenance under severe usage conditions ....... 5-6 Hood Release ..................1-61 Scheduled maintenance ..............5-4 Horn ....................
Page 263 INDEX Seat Belts Tachometer ..................1-43 3-Point system ................1-19 Tail Gate .................... 1-63 Adjustable height ................1-18 Rear Window Wiper and Washer Switch ......... 1-51 Adjusting your seat belt ............... 1-20 Theft-alarm System ................1-6 Care of seat belts ................. 1-17 Tires Precautions ..................
Page 264 Vehicle Identification Number (VIN) ........... 8-2 Vehicle Load Limit ................2-22 Vehicle Specification ................9-1 Ventilation Center ventilator ................1-71 Side ventilator ................1-71 Warning Lights .................. 1-38 Warranties for Your Hyundai ............8-12 Windshield Wiper and Washer ............1-49 Windshield Wiper Blades ..............6-10...
Page 265 2006...
Page 266 Original, U.S.gal (Imp.gal., liter) 14.5 (12, 55) through all ranges and return to “N” (Neutral) position. Then check the level of fluid on the dipstick. Use only HYUNDAI GENUINE ATF SP III, TIRE PRESSURE: DIAMOND ATF SP III, SK ATF SP III or other brands meeting the SP See the label on the driver side center pillar outer panel.

Hyundai Tiburon Owner's Manual

Quick Links

Related Manuals for Hyundai Tiburon

Summary of Contents for Hyundai Tiburon

Table of Contents
