Model No. NETL19714.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 1D, The Gateway
Fryers Way, Silkwood Park
OSSETT
WF5 9TJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for NordicTrack Elite 1500

Summary of Contents for NordicTrack Elite 1500

  • Page 1 Model No. NETL19714.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 1D, The Gateway Fryers Way, Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. 305284 NORDICTRACK is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 20. Never leave the treadmill unattended while 24. Never insert any object into any opening on it is running. Always remove the key, press the treadmill. the power switch into the off position (see the drawing on page 5 for the location of the 25.

  • Page 5: Before You Begin

    Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK ELITE 1500 treadmill. The ELITE manual. To help us assist you, please note the product ® 1500 treadmill offers an impressive selection of fea- model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing materials until you finish all assembly steps. the included hex key •...
  • Page 8 2. Make sure that the power cord is unplugged. Identify the Right Extension Leg (91). Attach the Right Extension Leg to the right Upright (84) with two 5/16" x 3/4" Screws (1). Start both Screws, and then tighten them. Attach the Left Extension Leg (not shown) to the left Upright (84) in the same way.
  • Page 9 4. Attach the two Handrails (74) to the Uprights (84) with two of the 5/16" x 2" Screws (2) that you removed in step 3 and two 5/16" Star Washers (8). Do not fully tighten the Screws yet. Be careful not to pinch the Upright Wire (83) on the right side.
  • Page 10 6. IMPORTANT: To avoid damaging the Pulse Crossbar (80), do not use power tools, and do not overtighten the #10 x 3/4" Screws (6) or the 5/16" x 2" Screws (2). Orient the Pulse Crossbar (80) as shown. Attach the Pulse Crossbar with two of the 5/16" x 2" Screws (2) that you removed in step 3, two 5/16"...
  • Page 11 8. Attach the console assembly (B) to the Handrails (74) with four 5/16" x 2" Screws (2) and four 5/16" Star Washers (8). Start all four Screws, and then tighten them. Be careful not to pinch the wires. Insert the wires upward into the console assem- bly (B).
  • Page 12 10. Set the Right Handrail Top Cover (81) on the right Handrail (74). Attach the Right Handrail Bottom Cover (82) to the Handrail and to the Right Handrail Top Cover with four #8 x 3/4" Truss Head Screws (110). IMPORTANT: Do not confuse the #8 x 3/4"...
  • Page 13 12. Carefully slide the Upright Crossbar (76) between the Uprights (84). Attach the Upright Crossbar with four 5/16" x 3/4" Screws (1). Start all four Screws, and then tighten them. 13. Attach the Tray (79) to the Upright Crossbar (76) with four #8 x 3/4"...
  • Page 14 14. Raise the Frame (52) to the position shown. Have a second person hold the Frame until step 15 is completed. Orient the Storage Latch (56) so that the decal is facing away from the treadmill as shown. Attach the lower end of the Storage Latch (56) to the bracket on the Upright (84) with a 5/16"...

  • Page 15: The Chest Heart Rate Monitor

    THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°...

  • Page 16: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the incline trainer.
  • Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s sound system while you The treadmill console offers an impressive array of exercise. features designed to make your workouts more effec- To turn on the power, see page 18.

  • Page 18: To Use The Manual Mode

    HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 19 5. Follow your progress with the displays. Press the Home button to return to the default menu (see THE SETTINGS MODE on page 24 As you walk or run on the treadmill, the display can to set the default menu). If necessary, press the show the following workout information: Home button again.
  • Page 20 7. Turn on the fan if desired. When you select an onboard workout, the display will show the duration of the workout and the name The fan features several speed settings and an of the workout. In addition, a profile of the speed auto mode.
  • Page 21 Note: The calorie goal is an estimate of the HOW TO USE A SET-A-GOAL WORKOUT number of calories that you will burn during the workout. The actual number of calories 1. Insert the key into the console. that you burn will depend on various factors such as your weight.
  • Page 22 5. Measure your heart rate if desired. 5. Enter your maximum heart rate. See step 6 on page 19. Use the increase and decrease buttons next to the Enter button to enter your maximum heart rate. 6. Turn on the fan if desired. Note: To determine your maximum heart rate, con- sult your physician or a physician-recommended See step 7 on page 20.
  • Page 23 HOW TO USE AN IFIT WORKOUT previously scheduled. Press the Track button to re- run a recent workout. For more information about Note: To use an iFit workout, you must have an the iFit workouts, please see www.iFit.com. optional iFit module. To purchase an iFit module at Note: If there are no workouts of the selected type any time, go to www.iFit.com or call the telephone in your schedule, the next workout in your schedule...
  • Page 24 THE SETTINGS MODE During a competition workout, the Competition tab will show your progress in the race. As you race, the top line in the matrix will show how much of the The console features a settings mode that keeps track race you have completed.
  • Page 25 CONTRAST—Press the Incline increase and HOW TO ADJUST THE CUSHIONING SYSTEM decrease buttons to adjust the contrast level of the display. The treadmill features a cushioning system that reduces the impact as you walk or run on the treadmill. If a module is connected, you may also select the following screen: Remove the key from the console and unplug the power cord.

  • Page 26: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 27: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regularly clean the treadmill and keep the walking a. Check the power switch (see drawing c at the left). belt clean and dry. First, press the power switch into If the switch has tripped, wait for five minutes and the off position and unplug the power cord.
  • Page 28 Locate the Reed Switch (47) and the Magnet (45) b. If the walking belt is overtightened, treadmill per- on the left side of the Pulley (51). Turn the Pulley formance may decrease and the walking belt may until the Magnet is aligned with the Reed Switch. become damaged.
  • Page 29 SYMPTOM: The walking belt is not centered SYMPTOM: The walking belt slips when walked on between the foot rails a. First, remove the key and UNPLUG THE POWER IMPORTANT: If the walking belt rubs against the CORD. Using the hex key, turn both idler roller foot rails, the walking belt may become damaged.

  • Page 30: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 31 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 32 NOTES...
  • Page 33 NOTES...

  • Page 34: Part List

    PART LIST Model No. NETL19714.0 R0514A Key No. Qty. Description Key No. Qty. Description 5/16" x 3/4" Screw Clip 5/16" x 2" Screw Reed Switch 5/16" x 1 3/4" Bolt Controller 5/16" x 2 1/4" Bolt #8 Star Washer #8 x 3/4" Screw Controller Bracket #10 x 3/4"...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Right Extension Leg Right Speaker Cover Rear Wheel Key/Clip Left Extension Leg Console Frame Cap Left Tray Console Frame Wire Tie Console Pulse Strap Left Speaker Cover Pulse Sensor Left Speaker Grill #8 x 3/4"...

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. NETL19714.0 R0514A...
  • Page 37 EXPLODED DRAWING B Model No. NETL19714.0 R0514A...
  • Page 38 EXPLODED DRAWING C Model No. NETL19714.0 R0514A...
  • Page 39 EXPLODED DRAWING D Model No. NETL19714.0 R0514A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
