VACUUM CLEANER
SERVICE MANUAL
MODEL: V-CQ302HT
CAUTION
BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS"
IN THIS MANUAL.
P/No.: 3828FI3864U
Nov.2008
Printed in China
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Related Manuals for LG V-CQ302HT
Vacuum Cleaner LG V-CQ3 H Series Quick Start Manual
(9 pages)
Vacuum Cleaner LG V-CQ443N Series Manual
(17 pages)
Vacuum Cleaner LG V-CQ453ST Manual
(11 pages)
Vacuum Cleaner LG V-CQ3-H Series Manual
(17 pages)
Vacuum Cleaner LG V-CQ243 Series Quick Start Manual
(8 pages)
Vacuum Cleaner LG V-CQ382S Series Manual
(15 pages)
Vacuum Cleaner LG V-CQ7 S Series Quick Start Manual
(7 pages)
Vacuum Cleaner LG V-CP943N Series Quick Manual
(41 pages)
Vacuum Cleaner LG V-CR403STU Manual
(44 pages)
Vacuum Cleaner LG V-CR3S Quick Manual
(16 pages)
Vacuum Cleaner LG VC5404PF Service Manual
(18 pages)
Vacuum Cleaner LG VC4914N Series Owner's Manual
Cyclone vacuum cleaner (27 pages)
Vacuum Cleaner LG V-CA241HT series Owner's Manual
(36 pages)
Vacuum Cleaner LG VC671*S series Owner's Manual
(21 pages)
Vacuum Cleaner LG VC6120NHT Owner's Manual
New type (53 pages)
Vacuum Cleaner LG VC3016NRTV Manual
(31 pages)
Summary of Contents for LG V-CQ302HT
Page 1
VACUUM CLEANER SERVICE MANUAL MODEL: V-CQ302HT CAUTION BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS" IN THIS MANUAL. Nov.2008 Printed in China P/No.: 3828FI3864U...
Page 2: Table Of Contents
SPECIFICATIONS .........................4 DISASSEMBLY ...........................5-6 TROUBLE SHOOTING ......................7-9 SCHEMATIC DIAGRAM .......................10 PRINTED CIRCUIT BOARD ....................10-11 EXPLODED VIEW .........................12-14 REPLACEMENT PARTS LIST .....................15 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 3: Safety Precautions
2) After disconnecting the lead wires, replace the old motor with a new one. 2. In case of exchanging other parts, refer LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 4: Description
10. PACKING DIMENSION : 330 570 330 (W D H)mm TURBINE NOZZLE ASS'Y ......... 1EA • This specifications are subject to change according to the buyer's request. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 5: Disassembly
• Lift the PWB ASS'Y in the direction of the arrow. 2) Open the filter cover and remove the five screws fastening the body base in the direction of arrow. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 6
1) Lift the cordreel assembly from the body base in the direction of the arrow. 2) Strip off the lead wires. Cordreel ASS'Y Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 7: Trouble Shooting
Motor armature cut Exchange the motor Ball bearing defacement Exchange the motor Impeller hindrance Remove the foreign (Caused by foreign matters) matters LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 8
The slide knob on the Close the slide knob by handle is opened sliding it Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 9
7. IMPROPER HOSE OR NOZZLE CONNECTION Bent connection parts Exchange the parts Poor connection Remove the foreign matters (Caused by foreign matters) and reconnect LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 10: Circuit Diagram
CIRCUIT DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only -10- Only for training and service purposes...
Page 11: Exploded View
MCQCA1 MDSBA1 EBRBM1 ADQBP1 MDJBM1 MEGBB1 MFGBF1 MHYBC1 MBDBB8 MAMBB1 MAVBT1 MBDBB9 MDSCF1 MFCBR1 MCQBO1 AJWBA1 MHYBA1 AHJBA1 MCKCA2 Copyright © 200 7 LG Electronics. Inc. All right reserved. LGE Internal Use Only -11- Only for training and service purposes...
Page 12
MEBBC1 MBGBR1 MHYCA1 MCKCD1 MCKCF1 MCKCC1 MFGTA1 EBRCM1 ACVBA1 AESCA1 MHYCC1 MFCCR1 MCKCX1 MCKBE1 ADQCE1 MCKCB1 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only -12- Only for training and service purposes...
Page 13
AEMAF1 AGRPT1 AGBN41 ADQBH1 NZ-41 MFVAC1 ABCAD1 AGBNU1 LGE Internal Use Only Copyright © 200 7 LG Electronics. Inc. All right reserved. Only for training and service purposes -13-...
Page 14: Replacement Parts List
3521FI3700B 3550FI1906B 335501 COVER, FILTER 3550FI1906C 3550FI1906D 335503 COVER ACCESSORY 3550FI2617B 335506 INDICATOR COVER 3550FI3803B 4026FI3699F 340261 LATCH 4026FI3699C 4026FI3699B Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only -14- Only for training and service purposes...
Page 15
BRUSH ASS'Y, DUST 5203FI2068A B TYPE 652031 BRUSH ASS'Y, DUST 5203FI2072F A TYPE 652491 NOZZLE ASM,UPHOLSTERY 5249FI2456C 552495 NOZZLE ASM, TURBINE 5249FI1431B LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. -15- Only for training and service purposes...
Page 16
MEMO Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only -16- Only for training and service purposes...
Page 17
MEMO LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. -17- Only for training and service purposes...
