Oki SZX23-1480 Operating Manual

Hide thumbs Also See for SZX23-1480:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
_____________________________________________________________________________________________
OPERATING MANUAL
Before attempting to connect or operate this product, please read these
instructions completely
Optical Low Pass Filter (OLPF) Switching Mechanism
CCD ZOOM CAMERA
WARNING
TO REDUCETHE RISK OF FIRE OR ELECTRONIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
CAUTION
:
1. CONNECT 24VAC UL LISTED CLASS 2 POWER SUPPLY.
2. INSTALL CAMERA UNDER UNSTABLE LIGHT SOURCE MAY
CAUSE ABNORMAL FUNCTION.
3. ONLY USE CAMERA UNDER CONDITIONS WHERE
TWMPERATURES ARE BETWEEN
FIELS INSTALLATION MARKING:
INSTALLATION SHOULD BE MADE BY A QUALIFIED
SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL
CODES
ON-SCREEN-DISPLAY
SZX23-1480 NTSC
SZX23-1480P PAL
12V DC
:
AND DO NOT REMOVE COVER OR BACK.
-10°C to 50°C.

Advertisement

Table of Contents
loading

Related Manuals for Oki SZX23-1480

Summary of Contents for Oki SZX23-1480

  • Page 1 Before attempting to connect or operate this product, please read these instructions completely ON-SCREEN-DISPLAY Optical Low Pass Filter (OLPF) Switching Mechanism CCD ZOOM CAMERA SZX23-1480 NTSC SZX23-1480P PAL 12V DC WARNING TO REDUCETHE RISK OF FIRE OR ELECTRONIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE AND DO NOT REMOVE COVER OR BACK.
  • Page 2 ______________________________________________________________________ 1. General This camera features a new Ultra Super high sensitive Near Infra-red CCD sensor and the combination of special optical and digital electronic processing circuit, deliver a high resolution, sharp, crisp image at daytime, and a clear monochrome picture under low light or minimal IR projection.
  • Page 3 ______________________________________________________________________ 3. Major Control And Their Function-- 123.5 109.5 230X COLOR CCD CAMERA DIGITAL ZOOM DC12V WIDE NEAR PROTOCOL TELE Z RS485 D0 VIDEO OUT 36.4 A. Holder screw hole The mounting hole is a standard photographic pan-head screw size (1/4”...
  • Page 4 ______________________________________________________________________ SETUP MENU [1/5] SETUP MENU [2/5] CAMERA ID WHITE BAL ATW. SENSE UP SYNC AISHUT AUTO. ZOOM FIX. DIGITAL ZOOM FOCUS AUTO FOCUS Page1 MAIN MENU Page2 MAIN MENU SETUP MENU [3/5] SETUP MENU [4/5] POSITION LOAD. DEFAULT CANCEL H-GAIN FREEZE V-GAIN...
  • Page 5 ______________________________________________________________________ ID CHARACTER MENU Move cursor to POSITION, press ENTER key to enter ID POSITION SELECTING CAMERA ID menu, then Press UP or DOWN key to select ID POSTION L-U, R-D, L-D or R-U. EDIT →POSITION - - - - - - - - - - - - - - - - - - - - CAMERA ID EDIT MENU 4.2 SENSE UP Move cursor to SENSE UP, press ENTER key to enter SENSE UP FUNCTION...
  • Page 6 ______________________________________________________________________ AISHUT →+4 FIX LEVEL Press ENTER key to enter FIX LEVEL SELECTING menu, then Press UP or DOWN key to select MIN, +1, +2, +3, +4, +5, +6, +7, MAX. FIX LEVEL ADJUSTMENT MENU 4.4 AES (Auto Exposure Mode) 4.4.1 AES FIX MODE SETUP MENU [1/5]...

  • Page 7: White Balance

    ______________________________________________________________________ →BLC AREA BLC LEVEL Press ENTER key to enter BLC AREA ADJUSTMENT menu. AREA AND LEVEL ADJUSTMENT MENU Press ENTER key to set BLC AREA BLOCK. Press UP or DOWN key to select BLC AREA BLOCK. OPD WINDOW This method is suited for cases where the main subject is fixed within the screen. The important object in a scene is usually placed in the center of the monitor’s screen.
  • Page 8 ______________________________________________________________________ Page 2 MAIN MENU Press ENTER key to enter ATW LEVEL ADJUSTMENT menu, then Press UP or DOWN ATW LEVEL key to select RED, RED+, RED++, RED+++, MIDDLE, BLUE, BLUE+, →MIDDLE ATW LEVEL BLUE++,BLUE+++, 9 steps adjustable. R-Y GAIN B-Y GAIN ATW LEVEL ADJUSTMENT MENU Move cursor to R-Y GAIN, press ENTER key to enter R-Y GAIN ADJUSTMENT menu,...

  • Page 9: Digital Zoom

    ______________________________________________________________________ R-Y GAIN ADJUSTMENT MENU Move cursor to B-Y GAIN, press ENTER key to enter B-Y GAIN ADJUSTMENT menu, AWB LEVEL then Press UP or DOWN key to select MIN, +1, +2, +3, +4, +5, +6, +7, MAX, 9 steps adjustable.

  • Page 10: Auto Focus

    ______________________________________________________________________ 4.11 FOCUS Move cursor to FOCUS, press ENTER key to enter FOCUS ADJUSTMENT menu. SETUP MENU [2/5] WHITE BAL AWB. SYNC ZOOM DIGITAL ZOOM →FOCUS AUTO FOCUS Page 2 MAIN MENU Press UP or DOWN key to select FOCUS FAR to NEAR. FOCUS FAR - - - - - - - - - - - NEAR FOCUS ADJUSTMENT MENU...
  • Page 11 ______________________________________________________________________ Press ENTER key to enter POSITION LOAD SELECTNG menu. Press UP or DOWN POSITION LOAD key to select position (1 to 64 position that you want to LOAD), then press ENTER →1 key that will be loaded. POSITION LOAD POSITION LOAD MENU ALARM POSITION Press ENTER key to enter ALARM POSITION SELECTNG menu.
  • Page 12 ______________________________________________________________________ Page 3 MAIN MENU 4.16 MOTION MOTION DETECTION FUNCTION Move cursor to MOTION, press ENTER key to enter MOTION ON/OFF menu. SETUP MENU [3/5] POSITION LOAD. Press UP or DOWN key to select ON. H-GAIN V-GAIN →ON. MOTION INITIAL Page 3 MAIN MENU Press ENTER key to enter MOTION FUNCTION menu.
  • Page 13 ______________________________________________________________________ x 12 x 16 x 32 x 64 BASE IR INT LEVEL TABLE NOTE1: *1: AGC LEVEL *2:IR INT LEVEL (ACT UP THE LEVEL) *3:SENSE UP NOTE2: IR INT LEVEL (MAX) Approach 15Lux (illumination) IR INT LEVEL (MIN) Approach 0.02Lux (illumination) Press ENTER key to enter IR SW FUNCTION menu.

  • Page 14: Freeze Mode

    ______________________________________________________________________ 4.19 DEFAULT RESTART THE CAMERA AND RESET PARAMETERS TO FACTORY’S DEFAULT. SETUP MENU [4/5] Move cursor to DEFAULT, press ENTER key to enter DEFAULT CANCEL/OK menu. →CANCEL DEFAULT FREEZE Press UP or DOWN key to select OK, and then press ENTER key. FREEZE MODE FIELD ZOOM SPEED...

  • Page 15: Focus Speed

    ______________________________________________________________________ 4.23 FOCUS SPEED FOCUS SPEED ADJUSTMENT SETUP MENU [4/5] Move cursor to set FOCUS SPEED, press ENTER key to FOCUS SPEED DEFAULT CANCEL SELECTING menu, then Press UP or DOWN key to select MIN, +1, +2, +3, MAX (5 FREEZE steps adjustable).
  • Page 16 ______________________________________________________________________ 4.27 SCALE ZOOM SCALE DISPLAY Move cursor to SCALE, press ENTER key to enter SCALE ON/OFF menu. SETUP MENU [5/5] Press UP or DOWN key to select ON/OFF. ZOOM+AF The zoom scale will be display on right-down of the screen in SCALE ON mode. AF SLEEP Note: The zoom scale is non-linear approximate value.
  • Page 17 ______________________________________________________________________ 4.30.1 H-REVERS Horizontal Reverse (Mirror) Function Move cursor to H-REVERS, press ENTER key to enter FREEZE ON/OFF menu. MISC →OFF H-REVERS Press UP or DOWN key to select ON/OFF. V-REVERS POSI/NEGA POSI PRIORITY MASK A MASK B MISC MENU 4.30.2 V-REVERS Vertical Reverse (Up-side Down) Function Move cursor to V-REVERS, press ENTER key to enter FREEZE ON/OFF menu.

  • Page 18: Control Methods

    ______________________________________________________________________ 4.30.5 MASK A / B MASKING AREA SETTING Move cursor to MASK A/B, press ENTER key to enter MASK A/B menu. MISC H-REVERS Press UP or DOWN key to select ON/OFF. V-REVERS Then press ENTER key to enter MASK A/B SETTING menu. POSI/NEGA POSI PRIORITY...
  • Page 19 ______________________________________________________________________ Z RS485 DO Iris + RS485 + Iris - RS485 - Focus + Motion out Focus - Zoom + Alarm in Zoom - OPEN +12V IRIS IRIS+ IRIS- CLOSE +12V +12V ALARM MDET-H MOTION-H OUTPUT ALARM ZOOM+ ZOOM- FOCUS+ FOCUS- NEAR WIDE...
  • Page 20 ______________________________________________________________________ 6. RS-485 Control ** For using RS-485 serial control, camera address ID must be set before connecting to the chain system, please refer to 4.31 Camera Address ID Setting (p.23). 6.1 Protocol Select PELCO-P 9600 PELCO-P 4800 PELCO-P 2400 PELCO-D 9600 PELCO-D 4800 PELCO-D 2400...
  • Page 21 ______________________________________________________________________ [80]+Preset [81]+Preset Digital Zoom ON [82]+Preset Auto Focus ON [83]+Preset Zoom +AF ON [84]+Preset Lens Initial ON [85]+Preset Motion ON [86]+Preset Freeze ON [87]+Preset Mirror ON [88]+Preset Up/Down ON [89]+Preset Mask 1 ON [90]+Preset Mask 2 ON [99]+Preset Camera Address ID Display ON * For OSD display, the commands are as follow ==>...
  • Page 22 ______________________________________________________________________ [87]+Set Mirror OFF [88]+Set Up/Down OFF [89]+Set Mask 1 OFF [90]+Set Mask 2 OFF [99]+Set Camera Address ID Display OFF ** For keyboard not containing “CLEAR” key, following commands cannot be executed. [1~64]+Clear Clear Preset Point [69]+Clear One Push Auto focus [90]+Clear Zoom Speed MIN [91]+Clear...

  • Page 23: Specifications

    ______________________________________________________________________ 9. Specifications MODEL NO. SZX23-1480 SZX23-1480P Signal System NTSC Image Sensor 1/4-inch SUPER HAD CCD Image sensor Picture Elements 795(H) x 596(V) / 811(H) x 508(v) Scanning System 625lines, 2:1 Interlace / 525lines, 2:1 Interlace Sync System Internal / External 0.5Lux Color, IR-cut on/0.1Lux B/W, IR-cut off (Super had)

This manual is also suitable for:

Szx23-1480p
