_____________________________________________________________________
OPERATING MANUAL
Before attempting to connect or operate this product,
please read these instructions completely
ON-SCREEN-DISPLAY
Optical Low Pass Filter (OLPF) Switching Mechanism
CCD ZOOM CAMERA
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
AND DO NOT REMOVE COVER OR BACK.
CAUTION:
1. CONNECT 12V DC UL LISTED POWER SUPPLY.
2. INSTALL CAMERA UNDER UNSTABLE LIGHT SOURCE MAY CAUSE
ABNORMAL FUNCTION.
3. ONLY USE CAMERA UNDER CONDITIONS WHERE TEMPERATURES
ARE BETWEEN -10°C to 50°C.
FILES INSTALLATION MARKING:
INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE PERSON
AND SHOULD CONFORM TO ALL LOCAL CODES
SZX23-1480
NTSC
SZX23-1480P PAL
12V DC

Advertisement

loading

Related Manuals for Oki SZX23-1480 NTSC

Summary of Contents for Oki SZX23-1480 NTSC

  • Page 1 _____________________________________________________________________ OPERATING MANUAL Before attempting to connect or operate this product, please read these instructions completely ON-SCREEN-DISPLAY Optical Low Pass Filter (OLPF) Switching Mechanism CCD ZOOM CAMERA SZX23-1480 NTSC SZX23-1480P PAL 12V DC WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE AND DO NOT REMOVE COVER OR BACK.
  • Page 2 ______________________________________________________________________ General………………………… ……………………… ……… This camera features a new Ultra Super high sensitive Near Infra-red CCD sensor and the combination of special optical and digital electronic processing circuit, deliver a high resolution, sharp, crisp image at daytime, and a clear monochrome picture under low light or minimal IR projection.
  • Page 3 ______________________________________________________________________ 3. Major Control And Their Function-- ----------------------- 123.5 109.5 230X COLOR CCD CAMERA DIGITAL ZOOM DC12V WIDE NEAR PROTOCOL TELE RS485 D0 V IDEO OUT 36.4 A. Holder screw hole The mounting hole is a standard photographic pan-head screw size (1/4”...
  • Page 4 ______________________________________________________________________ 4. User OSD Setting Menu And Functions----- --------------- ： UP & RIGHT MOVE KEY [UP] ： DOWN & LEFT MOVE KEY [DOWN] ： ENTER KEY [ENTER] ： ESC KEY [ESC] Push [ENTER] key 3 sec. to get into the OSD menu. Push [ESC] key to leave menu.
  • Page 5 ______________________________________________________________________ 4.1 Camera Identification Setting (CAMERA ID) Move cursor to CAMERA ID, press ENTER key to enter SETUP MENU [1/5] ID FUNCTION SELECTING menu, then Press UP or →ON. CAMERA ID DOWN key to select ON. SENSE UP Press ENTER key to enter CAMERA ID EDIT menu. AISHUT AUTO.
  • Page 6 ______________________________________________________________________ 4.2 SENSE UP Move cursor to SENSE UP, press ENTER key to enter SETUP MENU [1/5] SENSE UP FUNCTION SELECTING menu, then Press UP CAMERA ID or DOWN key to select OFF, x2, x4, x6, x8, x12, x16, x32 →x4 SENSE UP or x64 (0 Frame, 2 Frames, 4 Frames, 6 Frames, 8...
  • Page 7 ______________________________________________________________________ 4.3.2AISHUT FIX MODE Move cursor to AISHUT, press ENTER key to enter SETUP MENU [1/5] AISHUT FUNCTION SELECTING menu, then Press UP or DOWN key to select FIX. CAMERA ID SENSE UP →FIX. AISHUT Press ENTER key to enter FIX LEVEL ADJUSTMENT FIX.
  • Page 8 ______________________________________________________________________ 4.4.2 AES AUTO MODE Move cursor to AES, press ENTER key to enter AES SETUP MENU [1/5] FUNCTION SELECTING menu, then Press UP or CAMERA ID DOWN key to select AUTO. SENSE UP AISHUT AUTO. Press ENTER key to enter AUTO LEVEL →AUTO.
  • Page 9 ______________________________________________________________________ Press ENTER key to set BLC AREA BLOCK. Press UP or DOWN key to select BLC AREA BLOCK. OPD WINDOW This method is suited for cases where the main subject is fixed within the screen. The important object in a scene is usually placed in the center of the monitor’s screen. In this mode more photometric weight is given to the center of the screen than to the edge of the picture, this function will eliminate the interference by strong background light, which makes the camera picture dark.

  • Page 10: White Balance

    ______________________________________________________________________ 4.7 WHITE BALANCE 4.7.1 ATW (Auto Trace White Balance) Move cursor to WHITE BAL, press ENTER key to enter SETUP MENU [2/5] WHITE BAL FUNCTION SELECTING menu, then Press →ATW. WHITE BAL UP or DOWN key to select ATW. SYNC ZOOM Press ENTER key to enter ATW LEVEL ADJUSTMENT...
  • Page 11 ______________________________________________________________________ 4.7.2 AWB (Auto White Balance) SETUP MENU [2/5] Move cursor to WHITE BAL, press ENTER key to enter WHITE BAL FUNCTION SELECTING menu, then →AWB. WHITE BAL SYNC Press UP or DOWN key to select AWB. ZOOM DIGITAL ZOOM Press ENTER key to enter AWB LEVEL ADJUSTMENT FOCUS menu.

  • Page 12: Digital Zoom

    ______________________________________________________________________ 4.8 SYNC This function is used to adjust phase of external sync. SETUP MENU [2/5] When input external sync, we can press ENTER key WHITE BAL AWB. to set SYNC ON, then press UP or DOWN key to →OFF SYNC adjust phase.

  • Page 13: Auto Focus

    ______________________________________________________________________ 4.11 FOCUS Move cursor to FOCUS, press ENTER key to enter FOCUS ADJUSTMENT menu. SETUP MENU [2/5] WHITE BAL AWB. SYNC ZOOM DIGITAL ZOOM →FOCUS AUTO FOCUS Page 2 MAIN MENU Press UP or DOWN key to select FOCUS FAR to FOCUS NEAR.
  • Page 14 ______________________________________________________________________ There have 64 steps (position with zoom & focus) can POSITION SAVE be programmed. →1 After adjusting position with zoom & focus, Press POSITION SAVE ENTER key to enter POSITION SAVE SELECTNG menu. Press UP or DOWN key to select position (1 to 64 position that you want to save), then press ENTER key that will be saved.
  • Page 15 ______________________________________________________________________ 4.14 H-GAIN This is used to enhance the compensation of the picture quality. H-GAIN: Horizontal Compensation SETUP MENU [3/5] Move cursor to H-GAIN, press ENTER key to enter H-GAIN ADJUSTMENT menu. POSITION LOAD. →+6 H-GAIN V-GAIN Press UP or DOWN key to select MIN, +1, +2, +3, +4, MOTION +5, +6, +7, +8, +9, +11, MAX, 13 steps adjustable.
  • Page 16 ______________________________________________________________________ Press ENTER key to enter MOTION FUNCTION menu. MOTION Press UP or DOWN key to select motion detection →AREA AREA, LEVEL (Sensitivity), TIME, OSD. LEVEL TIME 30sec When detecting motion, it will output alarm signal. MOTION MENU 4.17 IR IR FILTER REMOVABLE FUNTION (DAY &...
  • Page 17 ______________________________________________________________________ x 12 x 16 x 32 x 64 BASE IR INT LEVEL TABLE NOTE1: *1: AGC LEVEL *2: IR INT LEVEL (ACT UP THE LEVEL) *3: SENSE UP NOTE2: IR INT LEVEL (MAX) Approach 15Lux (illumination) IR INT LEVEL (MIN) Approach 0.02Lux (illumination) Press ENTER key to enter IR SW FUNCTION menu.
  • Page 18 ______________________________________________________________________ 4.18 INITIAL FOCUS RESET FUNCTION Move cursor to INITIAL, press ENTER key to enter SETUP MENU [3/5] INITIAL ON/OFF menu. POSITION LOAD. H-GAIN Press UP or DOWN key to select ON/OFF. V-GAIN MOTION →ON INITIAL Page 3 MAIN MENU 4.19 DEFAULT RESTART THE CAMERA AND RESET PARAMETERS TO FACTORY’S DEFAULT.

  • Page 19: Freeze Mode

    ______________________________________________________________________ 4.21 FREEZE MODE FREEZE FIELD (or FRAME) OF PICTURE FUNCTION Move cursor to FREEZE MODE, press ENTER key to SETUP MENU [4/5] select FREEZE MODE menu. DEFAULT CANCEL FREEZE Press UP or DOWN key to select FIELD/FRAME. →FIELD FREEZE MODE ZOOM SPEED FOCUS SPEED GAMMA...
  • Page 20 ______________________________________________________________________ 4.24 GAMMA GAMMA SELECTION SETUP MENU [4/5] Move cursor to set GAMMA menu, press ENTER key DEFAULT CANCEL to select GAMMA mode , then Press UP or DOWN FREEZE key to select GAMMA1 or GAMMA2. FREEZE MODE FIELD GAMMA1 = 0.45 ZOOM SPEED GAMMA2 = 1.0 FOCUS SPEED...
  • Page 21 ______________________________________________________________________ 4.27 SCALE ZOOM SCALE DISPLAY Move cursor to SCALE, press ENTER key to enter SETUP MENU [5/5] SCALE ON/OFF menu. ZOOM+AF Press UP or DOWN key to select ON/OFF. AF SLEEP The zoom scale will be display on right-down of the →SCALE screen in SCALE ON mode.
  • Page 22 ______________________________________________________________________ 4.30 MISC Move cursor to MISC, press ENTER key to enter SETUP MENU [5/5] MISC menu. ZOOM+AF AF SLEEP SCALE LANGUAGE ENGLISH WINKER →MISC Page 5 MAIN MENU 4.30.1 H-REVERS Horizontal Reverse (Mirror) Function Move cursor to H-REVERS, press ENTER key to enter MISC FREEZE ON/OFF menu.
  • Page 23 ______________________________________________________________________ 4.30.3 POSI/NEGA Positive or Negative Picture Function Move cursor to POSI/NEGA, press ENTER key to MISC enter POSI/NEGA menu. H-REVERS V-REVERS Press UP or DOWN key to select POSI/NEGA. →POSI POSI/NEGA PRIORITY MASK A MASK B MISC MENU 4.30.4 PRIORITY Selecting IR SW INT Detecting Signal Move cursor to PRIORITY, press ENTER key to enter MISC...
  • Page 24 ______________________________________________________________________ Move cursor to H-POSITION, V-POSITION, H-SIZE or MASK A / B V-SIZE press ENTER key to enter NUMBER SETTING menu. →032 H-POSITION V-POSITION Press UP or DOWN key to adjust number (Adjusting H-SIZE H-POSITION, V-POSITION, H-SIZE or V-SIZE). V-SIZE CONNECTED set OFF, MASK will be fixed.
  • Page 25 ______________________________________________________________________ 5.2 Controller The keyboard controller can control most of the camera functions. (reference circuit). Screwless type Terminal (REMOTE) Pin Assignment Iris + RS485 + Z RS485 DO Iris - RS485 - Focus + Motion out Focus - Zoom + Alarm in Zoom - OPEN...
  • Page 26 ______________________________________________________________________ 6. RS-485 Control------------------ ------------------ ** For using RS-485 serial control, camera address ID must be set before connecting to the chain system, please refer to 4.31 Camera Address ID Setting (p.23). 6.1 Protocol Select PELCO-P 9600 PELCO-P 4800 PELCO-P 2400 PELCO-D 9600 PELCO-D 4800 PELCO-D 2400...
  • Page 27 ______________________________________________________________________ [70]+Preset Camera OSD Key ON. * [71]+Preset Camera ID ON [72]+Preset Position OSD ON [73]+Preset Zoom Scale ON [74]+Preset Sense UP ON (+4) [75]+Preset AIS (Auto IRIS ON) [76]+Preset BLC ON [77]+Preset AGC Super (MAX) [78]+Preset Day/Night (IR) Auto ON [79]+Preset Manual Night Mode (B/W) [80]+Preset...
  • Page 28 ______________________________________________________________________ [1~64]+Set Set (Save) Preset Point [70]+Set Camera OSD Key OFF [71]+Set Camera ID OFF [72]+Set Position OSD OFF [73]+Set Zoom Scale OFF [74]+Set Sense Up OFF [75]+Set AES (Auto Iris OFF) [76]+Set BLC OFF [77]+Set AGC Normal (+4) [78]+Set Day/Night (IR) Auto OFF [79]+Set Manual Day Mode (Color)
  • Page 29 ______________________________________________________________________ ** For keyboard not containing “CLEAR” key, following commands cannot be executed. [1~64]+Clear Clear Preset Point [69]+Clear One Push Auto focus [90]+Clear Zoom Speed MIN [91]+Clear Zoom Speed +1 [92]+Clear Zoom Speed +2 [93]+Clear Zoom Speed +3 [94]+Clear Zoom Speed MAX [95]+Clear Focus Speed MIN [96]+Clear...

  • Page 30: Specifications

    ______________________________________________________________________ 9.Specifications-------------------- ---------------------------------------- MODEL NO. SZX23-1480 SZX23-1480P TV System NTSC Image Sensor 1/4-inch SUPER HAD CCD Image sensor Picture Elements 811(H) x 508(v) 795(H) x 596(V) Scanning System 525 lines, 2:1 Interlace 625 lines, 2:1 Interlace Sync System Internal 0.5 Lux Color, IR-cut on Minimum Illumination 0.1 Lux B/W, IR-cut off (Super HAD) 0 Lux under IR illumination...
