- Page 21 NAVIGATION USER’S MANUAL POWERED by...
- Page 22 Table of contents...
-
Page 23: Main Map Screen
Welcome! Dear Customer, Thank you for selecting NDrive as your navigation software. This guide is created so that you can find quick and simple answers to your questions, considering both basic and advanced features, so that you can get more of this application. The new clean and elegant user interface of our latest version, will allow you to easily use the application, improving your user experience. - Page 24 Navigation (*) – Time, speed and distance controls show different information, by toggling among the alternative modes: - Estimated time left to destination - Estimated time of arrival - Speed limit on the current street - Distance left to destination - Current speed - Current time USERGUIDE_V11.3_ENG...
-
Page 25: Basic Commands
Context If you click on any point on the map, the context bar shows up on the bottom and these four actions can be performed. Basic Commands Exploring menu screens All menu screens show, on top, two buttons which allow for the following actions: Go back to previous screen Return to main map screen Using keyboards... - Page 26 USERGUIDE_V11.3_ENG...
- Page 27 USERGUIDE_V11.3_ENG...
-
Page 28: Performing A Search
Performing a search When a search is being performed, this type of screen allows you to enter search details, to filter your results. Go screen After performing a search or selecting a POI on the map, the Go Screen will be shown. This screen allows you to perform several actions, based on the location you just selected: USERGUIDE_V11.3_ENG... -
Page 29: Navigate To An Address
How to Navigate… Navigate to an address From the main menu select Go To and then Address After inputting the address click Input an address Select Country, State (when available), City. Afterwards type in the Street name and house number. Navigate to a Point of Interest (POI) From the main menu select Go To and then Places... -
Page 30: Use Coordinates To Navigate To A Location
Navigate to a Postcode From the main menu select Go To and then Places . Select Postcode and after selecting the country, use the keyboard to filter your search. After completing your selection, click Use coordinates to navigate to a location From the main menu select Go To and then Places . - Page 31 Navigate to my favorite locations From the main menu select Go To and then Favourites . Use the scroll bar or the keyboard to filter your search. After selecting the desired location from the list, click You may type in either the name or the tag of the favourite you have previously defined. NDrive will filter your search according to both fields.
-
Page 32: Delete Recent Locations
Delete recent locations From the main menu select Go To and then Recent Location . Click clear all recent locations. Use itineraries From the main menu select Go To and then Itineraries . You can then create a new itinerary, or select an itinerary from the list, if you have already created or imported any. Create an itinerary To create an itinerary, click Add New Itinerary . -
Page 33: Manage Alternative Routes
You can also see the whole itinerary on the map, by clicking View On Map The first waypoint is represented by a green flag and the last one by a checkered flag (black and white). The waypoints in between are marked with orange flags. Manage alternative routes From the main menu select My Route and then Alternatives... - Page 34 Customizing Your NDrive The speaker volume From the main menu select Settings and then . Use +/- to adjust the volume according to your preference. It’s also possible to quickly adjust the volume from the Main Map Screen, simply by clicking on the lower bar placed near the Menu button at the bottom of the screen and sliding your finger across it.
- Page 35 Lane Assistance Displays information about the lanes on junctions and turns. In Intersections, it will display the signposts allowing you to pick the right lane. You may choose between simplified and detailed view. Map North Up This option is only applicable to Pedestrian and Adventure modes. When enabled, the map will be displayed with North orientation and the locator will rotate according to your movements.
-
Page 36: Safety Options
Safety options From the main menu select Settings and then to customize the following options: Speed Limit Alarm: an alarm will ring when you exceed the speed limit configured by you (50 kph-160 kph); you may choose to turn off this option Road Speed Alert: you can adjust the way the speed limit of each road is displayed, among visual (an icon will appear on screen), visual and sound (icon on screen and voice indication), or turned off. -
Page 37: Export Data From Ndrive
Export data from NDrive From the main menu select My NDrive and then Data Import/Export . Then, according to what you wish to export, select Export Itineraries or Export Favourites . After you perform this action, a new .kml file will be created in the correspondent NDrive folder: “itineraries” or “favourites”. - Page 38 Getting More of your NDrive How to get new maps, voices or other features NDrive’s store offers you additional free or purchasable features, such as voices or new maps, which will enhance your software and user experience. Since your device does not have network connectivity, when you select Store , the following message will be displayed.
- Page 39 What is… Go To - This button allows you to enter a destination such as an address or a Point of Interest. You can then display it on the map, navigate there or set it as your current location. Address - Select this button to search for a location by its address. –...
- Page 40 Around Me - A POI located around your location, according to GPS signal, or a previously selected location. In a City - A POI in a specific or remote location. Coordinates - Using the special keyboard, you may search for coordinates using the Lat/Lon format.
- Page 41 Stop Navigation - Stops the current turn-by-turn & voice guidance. Start Demo - Starts a demonstration route of the previously selected navigation. Stop Demo - Stops the current demonstration route Alternatives - This button gives you the option to calculate an alternative route; place a Roadblock (if for any reason a part of the route is blocked);...
- Page 42 Settings - Customize the way NDrive is displayed, navigates, uses the GPS and others. For further details see the “How to” section. Store - Here you may download easily and securely additional content to your NDrive such as additional Worldwide Maps and Map Updates, Voices, Real Navigation city photos, Premium Weather and more.
- Page 43 Support Visit our Support section at http://www.ndrive.com to learn more on how to use NDrive. Additional contents such as video tutorials give you a more intuitive view on how to take advantage of your application. If any questions should remain, consult our FAQs or alternatively contact our technical support.
- Page 44 BOSS Audio Systems 3451 Lunar Court, Oxnard, CA 93030 www.bossaudio.com | 800.999.1236 Tech Support: www.bossaudio.com/support PRINTED IN CHINA V1.0...
- Page 50 Boss Audio Systems Free Extended Warranty Program When you purchase directly from BossAudio.com, one of our “Authorized Platinum Online Dealers” or have your product installed at an authorized Boss Audio dealer at the time of purchase, you qualify a free extended warranty on the product you purchased as shown below. Mobile Video & CD and DVD Receivers: 3 Years Total Boss Audio will extend the warranty for an additional two years, 3 years total, directly to the original consumer. Woofers, Speakers, ATV/UTV and Motorcycle Sound Systems: 3 Years Total Boss Audio will extend the warranty for an additional two years, 3 years total, directly to the original consumer. Amplifiers: 6 Years Total Boss Audio will extend the warranty for an additional five years, 6 years total, directly to the original consumer. Other Electronics and Accessories: There is No extended warranty available. Terms and Conditions: Purchases made online from dealers other than Bossaudio.com or an Authorized Platinum Online Dealer listed on this site do not qualify for the free extended warranty program. The online extended warranty program cannot be combined with the Installation Extended Warranty program. The extended warranty is valid only on purchases made and shipped within the US and covers parts and labor to repair only. This program is effective as of 3/1/2015. Any purchase made prior to this date will not qualify for this program. All other conditions of original warranty apply. To see a list of Authorized Platinum online Dealers, please click here. To get service on any product that falls under the Extended Warranty (800)999‐1236 ext. 2239 or email to: http://bossaudio.com/support/, an original or copy of dated purchase receipt is required to validate the warranty and a statement of the problem with the product is needed. ...
