Related Manuals for LG MS-207Y(S)
Summary of Contents for LG MS-207Y(S)
-
Page 1: Microwave Oven
MICROWAVE OVEN OWNER’S MANUAL PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING. MS-207Y(S) MS-267Y(S) -
Page 2: Precautions
These safety interlocks automatically switch off any cooking activity when the door is opened; which in the case of a microwave oven could result in harmful exposure to microwave energy. It is important not to tamper with the safety interlocks. -
Page 3: Table Of Contents
Microwaves do not heat cookware, though cooking vessels will eventually get hot from the heat generated by the food. A very safe appliance Your microwave oven is one of the safest of all home appliances. When the door is opened, the oven automatically stops producing microwaves. Microwave energy is converted completely to heat when it enters food, leaving no “left over”... -
Page 4: Unpacking & Installing
Unpacking & Installing Unpack your oven and place it on a flat level surface. GLASS TRAY ROTATING RING MS-267Y(S) By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. - Page 5 Plug your oven into a standard household socket. Make sure your oven is the only appliance connected to the socket. If your oven does not operate properly, unplug it from the electrical socket and then plug it back in. Fill a microwave safe container with 300 ml (1/2 pint) of water.
-
Page 6: Setting The Clock
Setting the Clock When your oven is plugged in for the first time or when power resumes after a power cut, a 0 will be shown in the display; you will have to reset the clock. If the clock (or display) shows any strange looking symbols, unplug your oven from the electrical socket and plug it back in and reset the clock. -
Page 7: Child Lock
Press STOP/CLEAR. Your oven has a safety feature that Press and hold STOP/CLEAR until “L” appears on the display and BEEP sounds. prevents accidental running of the oven. Once the child lock is set, you will be The CHILD LOCK is now set. unable to use any functions and no cooking can take place. -
Page 8: Micro Power Cooking
Micro Power Cooking Your oven has five microwave Power settings. High power is automatically selected but repeated presses of the MICRO button will select a different power level. Press Power Output Power Output OWER MICRO MS-207Y(S) MS-267Y(S) time 100% 800W 900W EDIUM times... -
Page 9: Micro Power Level
Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over cooking. The table below shows the examples of food and their recommended cooking power levels for use with this microwave oven. POWER LEVEL... -
Page 10: Two Stage Cooking
Two stage Cooking During two stage cooking the oven door can be opened and food checked. Close the oven door and press START and the cooking stage will continue. At the end of stage1, BEEP sounds and stage 2 commences. Should you wish to clear the programme press STOP/CLEAR twice. -
Page 11: Quick Start
In the following example I will show you how to set 2 minutes of cooking on high power. Press STOP/CLEAR . The QUICK START feature allows you to Press START four times to select 2 minutes on HIGH power. set 30 seconds intervals of HIGH power Your oven will start before you have finished the fourth press. -
Page 12: Auto Cook 12
Auto Cook AUTO COOK allows you to cook most of your favorite food easily by selecting the food type and entering the weight of the food. Press Category AUTO COOK time ACKET POTATO times RESH VEGETABLE ROZEN VEGETABLE times In the following example I will show you how to cook 0.6kg of fresh vegetable. Press STOP/CLEAR . - Page 13 FOOD CATEGORY FOOD TEMP. 1. JACKET POTATO Room temp. 2. FRESH VEGETABLE Room temp. 3. FROZEN VEGETABLE Frozen UTENSILS WEIGHT LIMIT Wash, dry and prick potato with a fork several times. Place the potato with three pieces of paper towel in the centre of the glass 0.1 kg ~ 1.0 kg Glass tray tray.
-
Page 14: Auto Defrost 14
Auto Defrost Your oven has four microwave defrost settings:- MEAT, POULTRY, FISH and BREAD; each defrost category has different power settings. Repeated presses of the AUTO DEFROST button will select a different setting. Press Category DEFROST time OULTRY times times READ times The temperature and density of food varies, I would recommend that the food is checked before cooking... - Page 15 AUTO WEIGHT DEFROST SEQUENCE LIST SEQUENCE 1. MEAT Minced beef, Fillet steak, Cubes for stew, Sirloin steak, Pot roast, Rump roast, Beef burger. Beef Chops(2.5 cm thick),Rolled roast. Lamb Veal Cutlets(450 g, 1.2 cm thick) 2. POULTRY Whole(under 2 Kg), Cut up Breasts(boneless), Legs. Chicken Turkey Breasts(under 2.5 Kg)
-
Page 16: Quick Defrost 16
Quick Defrost Your oven has a microwave quick defrost setting (MEAT). Use this function to thaw only 0.5kg of Minced meat very quickly. This will require a standing time to allow the center to thaw. In the following example will show you how to defrost 0.5kg of forzen minced meat. - Page 17 QUICK DEFROST SEQUENCE 1. MEAT Beef Minced meat Lamb Veal * The benefit of this Quick Defrost feature is automatic setting and control of defrosting, but just like conventional defrosting you must check the food during the defrosting time. * For best results, remove fish, shellfish, meat and poultry from its original paper or plastic package(wrapper). Otherwise, the wrap will hold steam and juice close to the food which can cause the outer surface of the food to cook.
-
Page 18: Favorite Cook
Favorite Cook The cooking programme is stored permanently in the memory of your microwave oven. If you wish to change your FAVORITE COOK, simply enter a new cooking programme. This feature allows you to set and execute a frequently used single stage programme. Once the cooking programme is set, you can use it by pressing the favorite cook key. -
Page 19: Timer
This pad performs two function; 1) It operate as an independent timer. 2) It can be set to delay cooking. 1. Timer Press TIMER. To enter amount of time you want to count down. Turn DIAL knob until display shows “15:00”. Your oven also has a Timer that can be used for noncooking functions. -
Page 20: More/Less
More or Less Cooking If you find that your food is over or undercooked when using the AUTO COOK programme, you can increase or decrease cooking time by pressing the button. When cooking without Auto function you can extend the cooking time at any point by pressing the button. -
Page 21: Heating Or Reheating Guide
To heat or reheat successfully in the microwave,it is important to follow several guidelines.Measure the amount of food in order to determine the time needed to reheat.Arrange the food in a circular pattern for best results.Room temperature food will heat faster than refrigerated food.Canned foods should be taken out of the can and placed in a microwavable container.The food will be heated more evenly if covered with a microwavable lid or vented plastic wrap.Remove cover carefully to prevent steam burns.Use the following chart as a guide for reheating cooked food. -
Page 22: Safety Precautions
The water will safely absorb all microwave energy, if the oven is accidentally started. 3 Do not dry clothes in the microwave oven, which may become carbonized or burned if heated too long. 4 Do not cook food wrapped in paper towels, unless your cook book contains instructions, for the food you are cooking. -
Page 23: Microwave - Safe Utensils
You probably have many items on hand in your kitchen right now that can be used as cooking equipment in your microwave oven. -
Page 24: Food Characteristics & Microwave Cooking 24
Always watch your food while it cooks. Your microwave oven is equipped with a light that turns on automatically when the oven is in operation so that you can see inside and check the progress of your food. - Page 25 Testing if cooked Food cooks so quickly in a microwave oven, it is necessary to test it frequently. Some foods are left in the microwave until completely cooked, but most foods, including meats and poultry, are removed from the oven while still slightly undercooked and allowed to finish cooking during standing time.
-
Page 26: Questions & Answers
A The beep tone sounds to assure that the setting is being properly entered. Q Will the microwave oven be damaged if it operates empty? A Yes Never run it empty or without the glass tray. Q Why do eggs sometimes pop? A When baking, frying, or poaching eggs, the yolk may pop due to steam build up inside the yolk membrane. -
Page 27: Plug Wiring Information/Technical Specifications
To obtain a replacement fuse cover contact your supplying dealer or LG Electronics U.K. LTD. If the mains sockets in your home differ, or are not suitable for the type of plug supplied then the plug should be removed and a suitable type fitted. -
Page 28: Maff Reheating Cooked Chilled Foods
MAFF working in partnership with the food companies and microwave oven manufacturers such as ‘LG electronics’ have overcome this problem by the introduction of heating categories. Because you may not yet be familiar with this system, we have used the following explanation as an example. -
Page 29: Guarantee
2. The dealer (or his Service Agent) who sold the product will be reimbursed for any labor provided in the repair of this LG electronics equipment, for a period of 12 months from the original date of purchase. These claims must be made in accordance with the published scale of service charges and relevant claims procedure. - Page 30 P/No: 3828W5A2114 Printed in Korea...
