Service Manual
Microwave Oven
Model: KOG-37250S
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : G37250S001
KOG-39250S
Advertisement
Table of Contents
Related Manuals for Daewoo KOG-37250S
Summary of Contents for Daewoo KOG-37250S
- Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD.
-
Page 2: Table Of Contents
PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated w ith the door open. (b) M ake the following safety checks on all ovens to be serviced before activating the m agnetron or other m icrowave source, and m ake repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) S eal and sealing surfaces (arcing, wear, and other dam age), (4) Dam age to or loosening of hinges and latches, (5) Evidence of dropping or abuse. -
Page 3: Safety And Precautions
SAFETY AND PRECAUTIONS 1. FOR SAFE OPERATION Damage that allows the microwave energy (that cooks or heats the food) to escape will result in poor cooking and may cause serious bodily injury to the operator. IF ANY OF THE FOLLOWING CONDITIONS EXIST, OPERATOR MUST NOT USE THE APPLIANCE. (Only a trained service personnel should make repairs.) 1) A broken door hinge. -
Page 4: Specifications
SPECIFICATIONS M O D E L K O G -37250S K O G -39250S P O W E R S U P P LY 230V ~50H z, SIN G LE P H A SE W ITH E A RT HIN G P O W E R C O N SU M PT IO N M IC RO W AVE 1200W... -
Page 5: External View
EXTERNAL VIEW 1. OUTER DIMENSION (KOG-3725 / KOG-3925) 465/495 360/388 Fig2. Side view Fig1. Front view... -
Page 6: Feature Diagram
EXTERNAL VIEW 2. FEATURE DIAGRAM 1) Door seal - Door seal maintains the microwave energy within the oven cavity and prevents microwave leakage. 2) Reflector (Insulator Heater) 3) Heating Element 4) Oven cavity 5) Safety interlock system 6) Knob V.P.C - Used to select a microwave power level. 7) Knob timer - Used in setting cooking time for all functions. -
Page 7: Installation
• This appliance is supplied with cable of special type, which, if damaged, must be repaired with cable of same type. Such a cable can be purchased from DAEWOO and must be installed by a Qualified Person. 6. Examine the oven after unpacking for any damage such as: A misaligned door, broken door or a dent in cavity. -
Page 8: Operations And Functions
OPERATIONS AND FUNCTIONS 1. Connect the main lead to an electrical outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray must always be in place during cooking. 3. -
Page 9: Disassembly And Assembly
DISASSEMBLY AND ASSEMBLY Cautions to be observed when trouble shooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safety during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully. - Page 10 DISASSEMBLY AND ASSEMBLY 1. To remove cabinet (1) Remove three screws on cabinet back. (2) Push the cabinet backward. 2. To remove door assembly (1) Remove a screw which secure the stopper hinge top. (2) Remove the door assembly from top plate of cavity. (3) Reverse the above steps for reassembly.
- Page 11 DISASSEMBLY AND ASSEMBLY 3. To remove door parts. D O OR A ssem bly: 3711710350(K O G -37250S ) 3511710750(K O G -39250S ) KOG-37250S R EF. N O PA R T C O D E PA R T NA M E...
- Page 12 DISASSEMBLY AND ASSEMBLY 4. Method to reduce the gap between the door seal and the oven front surface. (1) To reduce gap located on part ‘A’. Loosen a screw on stopper hinge top, and then push the door to contact the door seal to oven front surface. Tighten a screw.
- Page 13 Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) DISASSEMBLY AND ASSEMBLY 5.
- Page 14 DISASSEMBLY AND ASSEMBLY 6. To remove high voltage capacitor. (1) Remove a screw which secure the grounding ring terminal of the H.V.diode and the capacitor holder. (2) Remove the H.V. diode from the capacitor holder. (3) Reverse the above steps for reassembly. High voltage circuit wiring 7.
- Page 15 DISASSEMBLY AND ASSEMBLY 8. To remove wind guide assembly. (1) Remove a screw for earthing. (2) Remove the noise filter from the wind guide. (3) Remove a screw which secure the wind guide assembly. (4) Draw forward the wind guide assembly. (5) Pull the fan from the motor shaft.
- Page 16 DISASSEMBLY AND ASSEMBLY 10. To remove tray motor. (1) Remove the coupler in the cavity. (2) Turn the set upside down. (3) Cut the tray motor cover part from the base plate. (4) Remove the tray motor cover. (5) Remove a screw which secure the tray motor. (6) Remove the tray motor.
- Page 17 Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) DISASSEMBLY AND ASSEMBLY 12.
-
Page 18: Interlock Mechanism And Adjustment
INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. 1. -
Page 19: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE Following the procedures below to check if the oven is defective or not. 1. Check grounding before checking trouble. 2. Be careful of the high voltage circuit. 3. Discharge the high voltage capacitor. 4. When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and then check continuity with the AC plug removed. - Page 20 TROUBLE SHOOTING GUIDE D oes the fan m oto r w ork w hen yo u shut the doo r and turn the tim e r? Y E S D oes the ove n lam p light? R epla ce or repa ir oven la m p, D oes the turntab le turn? turntable m otor.
-
Page 21: Measurement And Test
MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 1000 ±... -
Page 22: Microwave Radiation Test
MEASUREMENT AND TEST 2. MICROWAVE RADIATION TEST WARNING M ake sure to check the m icrow ave leakage before and after repair of adjustm ent. A lw ays start m easuring of an unknow n field to assure safety for operating personnel from m icrow ave energy. D o not place your hands into any suspected m icrow ave radiation field unless the safe density level is know n. -
Page 23: Component Test Procedure
MEASUREMENT AND TEST 3. COMPONENT TEST PROCEDURE High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. It is neither necessary nor advisable to attempt measurement of the high voltage. Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor. 1. -
Page 24: Wiring Diagram
WIRING DIAGRAM... -
Page 25: Exploded View And Parts List
EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly 3. TOTAL ASSEMBLY... - Page 26 Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) EXPLODED VIEW AND PARTS LIST PART CODE PART NAM E DESC RIPTION...
- Page 27 Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) EXPLODED VIEW AND PARTS LIST PART CODE PART NAM E DESC RIPTION...
- Page 28 DAEWOO ELECTRONICS CO., LTD 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX : DWELEC K28177-8 CABLE : “DAEWOOELEC” E-mail : G7F00E@web.dwe.co.kr FAX : 02) 360-8184 TEL: 02) 360-8179~8180 PRINTED DATE : JUN. 1999...
