Icom IC-F5062 Instruction Manual page 9

RX SPEAKER KEY
Push to turn the RX speaker function ON or OFF.
When the RX speaker function is turned ON, the received
audio can be heard via the external speaker.
• This function is available when the external speaker is additionally
connected.
• This function is useful when you are out of the vehicle.
• The audio output level is linked to the transceiver's volume control.
LIGHT KEY
Push to turn ON the transceiver's backlight for about 5 sec-
onds when the backlight function is turned OFF in user set
mode.
LOCK KEY
Hold down to electronically lock all programmable keys except
the following:
[Moni(Audi)], [Light], [Lock], [Call] (incl. Call A and Call B),
[Emergency Single], [Surveillance], [Lone Worker] and [OPT 1/2/3].
LONE WORKER KEY
Push to turn the Lone Worker function ON or OFF.
• If the Lone Worker function is activated, the Emergency function is
automatically turned ON after the specified time period has passed
with no operation is performed.
HIGH/LOW KEY
Push to select the transmit output power temporarily or per-
manently, depending on the presetting.
• Ask your dealer for the output power level for each selection.
PANEL DESCRIPTION
TONE/RAN CH SELECT KEY
➥ While in analog mode operation, push to enter the con-
tinuous tone channel selection mode. Then select the
desired tone frequency/code setting with [CH Up] or
[CH Down]. After the selection, push this key again to set.
➥ While in digital mode operation*, push to enter the RAN
channel selection mode. Then select the desired RAN set-
ting with [CH Up] or [CH Down]. After the selection, push
this key again to set.
➥ While in mixed (digital and analog) mode operation*, push
to enter the continuous tone channel selection mode.
Then select the desired tone frequency/code setting with
[CH Up] or [CH Down]. After the selection, push this key
to set. After that, the RAN channel selection screen ap-
pears. Select the desired RAN setting with [CH Up] or
[CH Down]. After the selection, push this key again to set.
* Depending on version, digital and mixed (digital and analog) mode
operations are available only when the optional UT-126H
modulator demodulator unit
/
tails.
C.TONE CH ENT KEY
Push to enter the continuous tone channel selection mode.
Then select the desired tone frequency/code setting with
[CH Up] or [CH Down]. The selected channel remains set as
the continuous tone channel until another channel is desig-
nated as such.
digital
is installed. Ask your dealer for de-
