Kyocera Mita FS-C8008N Installation Manual

FS-C8008N/DN

Installation Guide

Unpacking
1
Unpacking the Printer
To avoid injury,
the printer must
be lifted and
carried by four
persons or more.
Unpacking
the Paper Feeder
PF-30A for FS-C8008N
PD-800 for FS-C8008DN
The following setup assumes three paper feeders to be installed with the printer (including the one supplied as a standard accessory), which requires a CA-31B caster kit to
be installed on the bottom of the bottom paper feeder. If the extra paper feeders are not installed, the CA-31 casters may be used. See the Operation Guide for more details.
Placing the Printer
Attaching the Caster kit (purchased
3
separately): Stand the paper feeder on its
back side. Remove each one screw to
remove four feet.
Using another topple-resistant bracket,
7
stack and joint the middle and top paper
feeder.
Installing the Fuser Unit, Secondary Transfer Unit, and Waste Toner Box
Remove the tape and then open the
11
front cover.
Tape
Install the caster kit onto the bottom of the
4
paper feeder.
Be sure to face
the longer end
towards the front
of the feeder.
Place the printer over the paper feeders (by
8
at least four persons).
Pull out thoroughly the paper transfer unit.
12
Important!
Installation should be performed only by a qualified service personnel. Kyocera Mita
assumes no liability for any damage caused by an improper installation of the printer.
Checking Parts and Components
2
1 Documents
Installation Guide (This sheet)
Quick Reference Guide
CD-ROMs
2 Cyan Developer
3 Magenta Developer
4 Yellow Developer
5 Black Developer
6 Cyan Toner Container
7 Magenta Toner Container
8 Yellow Toner Container
9 Black Toner Container
Place the paper feeder in a proper location.
5
Lock the stopper for each caster. Turn the
bolts to adjust height.
Join the printer and topmost paper feeder
9
with the jig provided by using one screw.
Unscrew the screw. Remove the lock pin
13
and release the (green-colored) lock lever.
Pull out the primary transfer unit until it
stops.
Screw
Lock Pin
Continued on
the Reverse Page
10 Secondary Transfer Unit
11 Fuser Unit
12 Waste Toner Boxes
13 Power Cord
14 Exhaust Duct
15 Quick Reference Guide Holder
16 Jig (Used in step 9)
17 Secondary Transfer Unit Anchor Jig
(Used in step 20)
18 Screw M4 (Used in step 9)
19 Screw M3 (Used in step 16)
20 Screws M3 (Used in step 20)
Using a topple-resistant bracket (supplied
6
with the CA-31B caster kit), stack and joint
the bottom and middle paper feeder.
Install the exhaust duct and the quick
10
reference guide holder. Peel the protective
tape off when attaching the holder.
Quick Reference
Guide Holder
Exhaust Duct
While pushing the gray lever, pull out
14
the primary transfer unit. Make sure
not to scratch the roller.
Gray Lever
