- Page 1 Service Handbook...
-
Page 2: Table Of Contents
Annual Service Record ..........2-4 Warranty ............... 5-7 Specification ..............8-9 Wiring Diagrams ............10-12 Fuse/MCB Specification ..........13 Bulb, Tube & Fuse Specification ........14 Awning Sizes ..............15 Moisture Test ..............16 MY2012/Bailey Unicorn Thermal Insulation ............16... -
Page 3: Annual Service Record
ANNUAL SERVICE RECORD CARAVAN MODEL YEAR CHASSIS NUMBER 2000 MILES OR 1 YEAR AFTER DELIVERY 4000 MILES OR 2 YEARS AFTER DELIVERY STANDARD CARAVAN SERVICE INCLUDING MOISTURE SURVEY STANDARD CARAVAN SERVICE INCLUDING MOISTURE SURVEY DEALER STAMP DEALER STAMP DATE DATE VIN No. - Page 4 ANNUAL SERVICE RECORD 10000 MILES OR 5 YEARS AFTER DELIVERY 12000 MILES OR 6YEARS AFTER DELIVERY STANDARD CARAVAN SERVICE INCLUDING MOISTURE SURVEY STANDARD CARAVAN SERVICE INCLUDING MOISTURE SURVEY DEALER STAMP DEALER STAMP DATE DATE VIN No. VIN No. 14000 MILES OR 7 YEARS AFTER DELIVERY 16000 MILES OR 8 YEARS AFTER DELIVERY STANDARD CARAVAN SERVICE INCLUDING MOISTURE SURVEY STANDARD CARAVAN SERVICE INCLUDING MOISTURE SURVEY...
- Page 5 ANNUAL SERVICE RECORD YEAR CARAVAN MODEL CHASSIS NUMBER 18000 MILES OR 9 YEARS AFTER DELIVERY 20000 MILES OR 10 YEARS AFTER DELIVERY STANDARD CARAVAN SERVICE INCLUDING MOISTURE SURVEY STANDARD CARAVAN SERVICE INCLUDING MOISTURE SURVEY DEALER STAMP DEALER STAMP DATE DATE VIN No.
-
Page 6: Warranty
3 Year Manufacturers Warranty For a period of twenty-four (24) months from the initial date of purchase Bailey of Bristol offer a comprehensive warranty on all parts and components as well as full coverage for any manufacturing faults forming part of the original specification of the vehicle. The manufacturer’s warranty then extends to an additional twelve (12) - Page 7 The unexpired term of the Warranty Cover on your vehicle may only be assigned, transferred or novated to subsequent owners with Bailey’s consent (not to be unreasonably withheld) and on payment to Bailey of a transfer fee of £35. Transfer can only be made within the first three months (3) of subsequent ownership and full documentary evidence that the vehicle has been serviced annually must be provided at the time of assignment in accordance with the terms and conditions detailed above.
-
Page 8: Warranty
(d) transport costs to and from point of repair. 14 Bailey will only be liable for costs which are incurred as a direct consequence of the event, defect or fault leading to the claim being made under this warranty. No liability will be accepted for any other loss or damage (such as loss of income or revenue, or loss of business or profits), costs, expenses or other claims for compensation howsoever arising which was not reasonably foreseeable by both parties when the caravan was originally purchased. -
Page 9: Specification
SPECIFICATIONS MODEL BERTHS INTERNAL SHIPPING OVERALL OVERALL MAXIMUM TYRE BODY LENGTH BODY HEIGHT HEADROOM SIZES LENGTH WIDTH SEVILLE 4.902m (16' 1") 6.475m (21' 3") 2.28m (7' 6") 2.63m (8' 8") 1.96m (6' 5") 195/70 R15 LI 104S MADRID 5.678m (18' 8") 7.251m (23' 9") 2.28m (7' 6") 2.63m (8' 8") -
Page 10: Specification
SPECIFICATIONS MODEL TYRE MAXIMUM TECHNICAL M.R.O. PAYLOAD ALLOWANCE TOTAL PRESSURE PERMISSIBLE USER (P.S.I/BAR) ** LADEN MASS OPTIONAL EQUIPMENT PAYLOAD SEVILLE 58 / 4.0 1433kg (28.2 cwt) 1304kg (25.7 cwt) 3kg (0.1 cwt) 129kg (2.5 cwt) MADRID 62 / 4.3 1596kg (31.4 cwt) 1440kg (28.3 cwt) 3kg (0.1 cwt) 156kg (3.1 cwt) -
Page 11: Wiring Diagrams
WIRING DIAGRAMS ROADLIGHT WIRING - UNICORN... - Page 12 WIRING DIAGRAMS 230 VOLT & 12 VOLT PRIMARY CIRCUIT DIAGRAM - UNICORN...
- Page 13 WIRING DIAGRAMS UNICORN CONTROL PANEL DIAGRAM...
-
Page 14: Fuse/Mcb Specification
TECHNICAL INFORMATION FUSE/MCB SPECIFICATION - UNICORN FUSES Alarm ............................5 amp (yellow) Fridge Ign ..........................5 amp (yellow) Caravan battery ........................15 amp (blue) Fridge ............................. 15 amp (blue) Car ............................15 amp (blue) Lights 1 ........................... 15 amp (blue) Lights 2 ........................... -
Page 15: Bulb, Tube & Fuse Specification
TECHNICAL INFORMATION BULB, TUBE & FUSE SPECIFICATION - UNICORN ROAD LIGHTS Front and rear grab handles 12 volt < 1 watt Front marker light 12 volt < 1 watt Jokon Side marker light 12 volt 5 watt Bayonet Clear Brake lights (low level) 12 volt 21 watt Bayonet... -
Page 16: Awning Sizes
TECHNICAL INFORMATION AWNING SIZES The following are the ground to ground dimensions through the awning channel. These dimensions are issued as a guideline only, please refer to your dealer for the correct awning size to suit your particular caravan. UNICORN Seville ...... -
Page 17: Moisture Test
NCC recommended service schedule. Service Centre. A full listing of the current Approved Bailey Centres can be found on Readings should be taken on the floor section of the caravan in the Retailer Network pages of our web site @ www.bailey- positions where the holes created by the meter's probe are not caravans.co.uk. - Page 18 There is a fee charged for this service of £35 + VAT. WARRANTY TRANSFER FORM Failure to request this transfer within 14 days of acquisition by the new owner will invalidate the remaining warranty. Model Chassis number Bailey Production Number Purchase Date Previous Owner New Owner's Address Telephone Number...
- Page 19 INTENTIONALLY LEFT BLANK...
- Page 20 There is a fee charged for this service of £35 + VAT. WARRANTY TRANSFER FORM Failure to request this transfer within 14 days of acquisition by the new owner will invalidate the remaining warranty. Model Chassis number Bailey Production Number Purchase Date Previous Owner New Owner's Address Telephone Number...
- Page 21 INTENTIONALLY LEFT BLANK...
- Page 22 There is a fee charged for this service of £35 + VAT. WARRANTY TRANSFER FORM Failure to request this transfer within 14 days of acquisition by the new owner will invalidate the remaining warranty. Model Chassis number Bailey Production Number Purchase Date Previous Owner New Owner's Address Telephone Number...
- Page 23 INTENTIONALLY LEFT BLANK...
- Page 24 There is a fee charged for this service of £35 + VAT. WARRANTY TRANSFER FORM Failure to request this transfer within 14 days of acquisition by the new owner will invalidate the remaining warranty. Model Chassis number Bailey Production Number Purchase Date Previous Owner New Owner's Address Telephone Number...
- Page 25 NOTES © Designed & Printed by Preset Graphics (Ref: 21266UNI MY12). Tel: 01332 549278...
