White Mountain Hearth VFP24FP3 Series Installation Instructions And Owner's Manual

The vail vent-free gas fireplaces
Hide thumbs Also See for VFP24FP3 Series:

Advertisement

The Vail Vent-Free Gas Fireplaces
This appliance may be installed in an aftermarket,
permanently located, manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas in-
dicated on the rating plate. This appliance is not con-
vertible for use with other gases.
WARNING: If the information in these instructions
are not followed exactly, a fire or explosion may
result causing property damage, personal injury or
loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use
any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.

INSTALLATION INSTRUCTIONS

OWNER'S MANUAL
AND
UNVENTED GAS FIREPLACE
HYDRAULIC THERMOSTAT
MODELS:
VFP24FP2(0,1,2,3)L(N,P)-1
MILLIVOLT MODELS:
VFP24FP3(0,1,2,3)L(N,P)-1
VFP24FP3(0,1,2,3)L10(N,P)-1 (10,000 BTU UNIT)
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
This is an unvented gas-fired heater. It uses air (oxy-
gen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be
provided. Refer to page 6.
WARNING: If not installed, operated and maintained
in accordance with the manufacturer's instructions,
this product could expose you to substances in fuel
or from fuel combustion which can cause death or
serious illness.
WATER VAPOR: A BY-PRODUCT OF UNVENTED
ROOM HEATERS
Water vapor is a by-product of gas combustion.
An unvented room heater produces approximately
one (1) ounce (30ml) of water for every 1,000 BTU's
(.3KW's) of gas input per hour. Refer to page 6.
Page 1

Advertisement

Table of Contents
loading

Summary of Contents for White Mountain Hearth VFP24FP3 Series

  • Page 1: Installation Instructions

    INSTALLATION INSTRUCTIONS OWNER'S MANUAL UNVENTED GAS FIREPLACE The Vail Vent-Free Gas Fireplaces HYDRAULIC THERMOSTAT MODELS: VFP24FP2(0,1,2,3)L(N,P)-1 MILLIVOLT MODELS: VFP24FP3(0,1,2,3)L(N,P)-1 VFP24FP3(0,1,2,3)L10(N,P)-1 (10,000 BTU UNIT) This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited by local codes. This appliance is only for use with the type of gas in- dicated on the rating plate.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE Important Safety Information ....................3 Safety Information for Users of LP Gas ..................4 Introduction ..........................5 Specifications ..........................6 Water Vapor: A By-Product of Unvented Room Heaters ............6 Provisions for Adequate Combustion and Ventilation Air ............6-7 Gas Supply ..........................
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION THIS IS A HEATING APPLIANCE • You must operate fireplace with fireplace screen closed in DANGER: Indicates a hazardous situation which, if not place. Do not close glass doors while operating heater. avoided, will result in death or serious injury. • Do not place trash, logs or other articles on the log set WARNING: Indicates a hazardous situation which, if not during operation.
  • Page 4: Safety Information For Users Of Lp Gas

    SAFETY INFORMATION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires with the members of your household. Someday when there and explosions. In its natural state, propane is odorless and may not be a minute to lose, everyone's safety will depend colorless. You may not know all the following safety precautions on knowing exactly what to do.
  • Page 5: Introduction

    INTRODUCTION Instructions to Installer instructions. 1. Installer must leave instruction manual with owner after Any alteration of the original design, installed other than as installation. shown in these instructions or use with a type of gas not 2. Installer must have owner fill out and mail warranty card supplied shown on the rating plate is the responsibility of the person with unvented room heater.
  • Page 6: Specifications

    SPECIFICATIONS Accessories Model VFP24FP3*L VFP24FP2*L VFP24FP3*L10 FBB6 Automatic Blower Input Max. 20,000 20,000 10,000 VPP1A-22 Aged Brick Liner Min. 14,000 10,000 10,000 VFF24BR-1 Brass Trim Kit Fireplace Dimensions VFF24SS-1 Stainless Steel Trim Kit Height 26 3/8" 26 3/8" 26 3/8" VFF24HP-1 Hammered Pewter Trim Kit Depth...
  • Page 7 3. Add the BTU/Hr of all fuel burning appliances in the space. Vent-free heater BTU/Hr Gas water heater BTU/Hr Gas furnace BTU/Hr Vented gas heater BTU/Hr Gas fireplace logs BTU/Hr Other gas appliances* + BTU/Hr Total BTU/Hr Example: Vented gas heater 20,000 BTU/Hr Vent-free heater...
  • Page 8: Gas Supply

    GAS SUPPLY The appliance must be isolated from the gas supply piping Check all local codes for requirements, especially for the size and system by closing its individual manual shutoff valve during type of gas supply line required. any pressure testing of the gas supply piping system at test Recommended Gas Pipe Diameter pressures equal to or less than 1/2 psig (3.5 kPa).
  • Page 9: Clearances

    CLEARANCES Mantel Clearances for Built-in Installation Minimum Wall and Ceiling Clearances 30” (762mm) Figure 4 This fireplace can be installed with zero (0") clearance to combustible material. When facing the front of the appliance the minimum clearances to combustible construction (material) are the following: Clearances from the right side or left side of the fireplace opening to any combustible wall or material should not be less than 4 inches.
  • Page 10: Installation Of Fireplace Into Mantel

    INSTALLATION OF FIREPLACE INTO MANTEL Position base approximately 5" from wall surface. Installing Fireplace in Mantel Attach nailing flange to fireplace top with two (2) 10 x 1/2" screws. Place fireplace on top of base. Gas line connections must be made at this time. When facing the fireplace the gas supply will enter on right-hand side.
  • Page 11: Built-In Fireplace Installation

    BUILT-IN FIREPLACE INSTALLATION Built-In Fireplace Installation Rough Opening for Installing in Corner Built-in installation of this fireplace involves installing fireplace into a framed-in enclosure. This makes the front of fireplace flush with wall. If installing a mantel above the fireplace, you must follow the clearances shown in Figure 5, page 9.
  • Page 12: Placement Of Glowing Embers (Rock Wool)

    PLACEMENT OF GLOWING EMBERS (ROCK WOOL) Provided with the log set is a small bag of glowing embers (rock Replacement of loose material (glowing embers) must be purchased wool) to be placed between logs on the flat metal surface of the from Empire Comfort Systems, Inc.
  • Page 13: For Your Safety Read Before Lighting

    MILLIVOLT CONTROLS LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by C. Use only your hand to push in or turn the gas control hand.
  • Page 14: Hydraulic Thermostat Lighting Instructions

    HYDRAULIC THERMOSTAT MODELS LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by C. Use only your hand to push in or turn the gas control hand.
  • Page 15: Pilot Flame Characteristics

    PILOT FLAME CHARACTERISTICS Figures 13 and 15 show a correct pilot flame pattern. The correct flame will be blue and will extend beyond the thermocouple. The flame will surround the thermocouple just below the tip. A slight yellow flame may occur where the pilot flame and main burner flame meet. Figures 14 and 16 show an incorrect pilot flame pattern.
  • Page 16: Main Burner And Thermostat Operation

    Have heater inspected yearly by a qualified (LO setting) to a maximum input of 20,000 BTU/HR (HI setting). service person. Heater may need more frequent cleaning due to excessive lint from carpeting, bedding materials, etc. VFP24FP3 Series (with 10,000 BTU burner) Fixed 10,000 BTU/HR Logs Be careful cleaning and handling logs so as not to damage them.
  • Page 17: Wiring

    WIRING Label all wires prior to disconnection when servicing controls. Wiring Remote Receiver errors can cause improper and dangerous operation. Verify proper Use the following steps to place the remote receiver adjacent to operation after servicing. the gas valve. Attention: The remote receiver bracket is not used in this Millivolt thermopile is self powered, gas valve does not require 110 installation.
  • Page 18: Troubleshooting

    TROUBLESHOOTING SYMPTOMS, POSSIBLE CAUSES AND CORRECTIONS Turn appliance OFF and allow to cool before servicing. Only a qualified service person should service and repair the heater. When ignitor button is pressed, there is no spark at ODS/ pilot lights, keep control knob pressed in 30 seconds. pilot.
  • Page 19: Parts List

    PARTS LIST ATTENTION: When ordering parts, it is very important that part number and description of part coincide. INDEX PART INDEX PART DESCRIPTION DESCRIPTION COMMON VFP24FP30L and VFP24FP30L10 25897 TRIM - TOP R3623 PILOT ASSEMBLY - LPG 25895 TRIM - LEFT R3624 PILOT ASSEMBLY - NAT 25896...
  • Page 20: Parts View

    PARTS VIEW 34 33 VFP24FP3 Series VFP24FP2 Series Page 20 25783-5-1011...
  • Page 21: Optional Brick Liner Installation Instructions

    OPTIONAL BRICK LINER INSTALLATION INSTRUCTIONS VPP1A-22 For Unvented Gas Fireplace INSTALLING OPTIONAL BRICK LINER Remove screen assembly from fireplace. Remove logs from burner assembly. Insert rear brick liner and (2) side brick liners onto bottom of the inner casing. Align grout lines on rear brick liner with grout lines on side brick liners.
  • Page 22: Optional Blower Installation Instructions

    OPTIONAL BLOWER INSTALLATION INSTRUCTIONS FBB6 for Unvented Gas Fireplace Models VFP24FP2 Series & VFP24FP3 Series INSTALLING OPTIONAL BLOWER Insert blower assembly in left side of outer casing. Motor with wiring will be to the inside of the outer casing, blower chute Remove bottom louver.
  • Page 23 OPTIONAL BLOWER INSTALLATION INSTRUCTIONS 25. Position blower shield beneath left flange on burner assembly. 12. Route wires from fan control behind inner casing to bottom of Align clearance hole on left flange of burner assembly with outer casing. screw hole on blower side shield. 13.
  • Page 24 OPTIONAL BLOWER INSTALLATION INSTRUCTIONS (cont.) 30. Attach rear log support to inner casing with three (3) Wiring 10 x 1/2" screws from step 4. The appliance, when installed, must be electrically grounded in 31. Place and align blower diverter on top of inner casing. Attach accordance with local codes or, in the absence of local codes, deflector to top of inner casing with two (2) 10 x 1/2"...
  • Page 25 OPTIONAL BLOWER INSTALLATION INSTRUCTIONS (cont.) FBB6 PARTS LIST Index Part Description Number 11508 FAN CONTROL BRACKET R2503 FAN CONTROL 11301 BLOWER DIVERTER R2099 CORD SET R1410 STRAIN RELIEF BUSHING 25794 BLOWER BASE ASSEMBLY R2804A BLOWER ASSEMBLY R5804 WIRE HARNESS R1404 SNAP BUSHING 11507 BLOWER SHIELD - SIDE...
  • Page 26: Parts List And Parts View For Optional Trim Kits

    PARTS LIST AND PARTS VIEW FOR OPTIONAL TRIM KITS Attention: When ordering parts, it is very important that the part number and description coincide. Index Number Part Number Description VFF24BR Brass Trim Kit 25974 Trim Top 25972 Trim Left 25973 Trim Right VFF24SS Stainless Steel Trim Kit 25982...
  • Page 27: Master Parts Distributor List

    MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort. com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit.
  • Page 28 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 28 25783-5-1011...
