LED LCD TV

SERVICE MANUAL

CHASSIS : LB23E
MODEL : 55LM8600
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL67365301 (1203-REV00)
North/Latin America
Europe/Africa
Asia/Oceania
55LM860Y
Internal Use Only
http://aic.lgservice.com
http://eic.lgservice.com
http://biz.lgservice.com
55LM8600-TA
55LM860Y-TA
Printed in Korea
