- Page 1 OWNER’S MANUAL LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. 47LM8600 47LM8650 55LM8600 55LM8650 www.lg.com P/NO : MFL67468152 (1207-REV03)
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product. Read these instructions. Keep these instructions. WARNING/CAUTION Heed all warnings. Follow all instructions. RISK OF ELECTRIC SHOCK DO NOT OPEN Do not use this apparatus near water. - Page 3 IMPORTANT SAFETY INSTRUCTIONS Protect the power cord from being walked on Keep the packing anti-moisture material or or pinched particularly at plugs, convenience vinyl packing out of the reach of children. receptacles, and the point where they exit Anti-moisture material is harmful if from the apparatus.
- Page 4 Do not attempt to modify this product in any as gasoline or candles, or expose the TV to way without written authorization from LG direct air conditioning. Electronics. Unauthorized modification could void the user’s authority to operate this product.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS Cleaning Dot Defect When cleaning, unplug the power cord and The Plasma or LCD panel is a high wipe gently with a soft cloth to prevent technology product with resolution of two scratching. Do not spray water or other million to six million pixels.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS DISPOSAL (Hg lamp only used in LCD TVs) The fluorescent lamp used in this product contains a small amount of mercury. Do not dispose of this product with general household waste. Disposal of this product must be carried out in accordance to the regulations of your local authority.
-
Page 7: Viewing 3D Imaging
IMPORTANT SAFETY INSTRUCTIONS Viewing 3D Imaging WARNING Viewing Environment Viewing Time - When watching 3D contents, take 5 - 15 minute breaks every hour. Viewing 3D contents for a long period of time may cause headache, dizziness, fatigue or eye strain. Those that have a photosensitive seizure or chronic illness Some users may experience a seizure or other abnormal symptoms when they are exposed to a flashing light or particular pattern from 3D contents. - Page 8 Cautions when using the 3D glasses Make sure to use LG 3D glasses. Otherwise, you may not be able to view 3D videos properly. Do not use 3D glasses instead of your normal glasses, sunglasses or protective goggles.
-
Page 9: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 10: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS REMOTE CONTROL Viewing 3D Imaging Magic Remote Control Functions - Registering Magic Remote Control LICENSES - How to use Magic Remote Control - Precautions to Take when Using the Magic Remote Control OPEN SOURCE SOFTWARE NOTICE WATCHING TV TABLE OF CONTENTS... -
Page 11: Installation Procedure
ASSEMBLING AND PREPARING INSTALLATION PROCEdURE Open the package and make sure all the accessories are included. Attach the stand to the TV set. Connect an external device to the TV set. Make sure the network connection is available. You can use the TV network functions only when the network connection is made. ASSEMBLING ANd PREPARING Unpacking Check your product box for the following items. - Page 12 ASSEMBLING AND PREPARING Magic remote control, Owner’s manual Cinema 3D glasses Batteries (AA) The number of 3D glasses may differ depending on the (See p.31) model or country. Stand body Stand base Stand screws (See p.16) (See p.16) 8 EA, M4 x 20 (See p.16) Cable holder Component video cable...
-
Page 13: Optional Extras
ASSEMBLING AND PREPARING Optional Extras Optional extras can be changed or modified for quality improvement without any notification. Contact your dealer for buying these items. These devices only work with certain models. AN-MR300 AG-F2**, AG-F3** Magic remote control Cinema 3D glasses The model name or design may be changed manufacturer’s circumstances or policies. -
Page 14: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Screen Buttons Speakers Remote control and LG Logo Light intelligent sensors Power indicator Button Description (^ / v) Scrolls through the saved channels. (+ / -) Adjusts the volume level. (OK ⊙ ) Selects the highlighted menu option or confirms an input. -
Page 15: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and moving the TV When moving or lifting the TV, read the following When transporting a large TV, there should to prevent the TV from being scratched or be at least 2 people. damaged and for safe transportation regardless of When transporting the TV by hand, hold the its type and size. -
Page 16: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV Put your TV on a pedestal stand and mount the TV on a table or wall. Attaching the stand If you are not mounting the TV to a wall, use the following instructions to attach the stand. 4 EA M4 x 20 Stand Body... - Page 17 ASSEMBLING AND PREPARING 4 EA M4 x 20 Protection pad CAUTION Remove protection pads after installing NOTE Remove the stand before installing the TV on a wall mount by performing the stand attachment in reverse. CAUTION Make sure that the screws are fastened completely.
-
Page 18: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table Adjusting the angle of the TV to suit view Swivel 10 degrees to the left or right and adjust Lift and tilt the TV into its upright position on a the angle of the TV to suit your view. table. -
Page 19: Tidying Cables
ASSEMBLING AND PREPARING Tidying cables Securing the TV to a wall (optional) Gather and bind the cables with the cable management clip. Insert and tighten the eye-bolts, or TV brackets and bolts on the back of the TV. Cable management clip - If there are bolts inserted at the eye-bolts Gather and bind the cables with the cable position, remove the bolts first. -
Page 20: Mounting On A Wall
Use an authorized LG wall mount and We recommend that you use an LG brand wall contact the local dealer or qualified mount when mounting the TV to a wall. -
Page 21: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Connect various external devices to the TV and switch input modes to select an external device. For more information of external device’s connection, refer to the manual provided with each device. Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. -
Page 22: Connecting To A Hd Receiver, Dvd, Or Vcr Player
MAKING CONNECTIONS Connecting to a HD receiver, DVD, or VCR player Connect a HD receiver, DVD, or VCR player to the TV and select an appropriate input mode. HDMI Connection HDMI is the best way to connect a device. Transmits the digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown in the following illustration. -
Page 23: Dvi To Hdmi Connection
MAKING CONNECTIONS DVI to HDMI Connection Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an audio cable. -
Page 24: Connecting To A Mobile Phone
MAKING CONNECTIONS Connecting to a mobile phone Mobile High-definition Link (MHL) is an interface for transmitting digital audiovisual signals from mobile phones to television sets. NOTE Connect the mobile phone to the HDMI/DVI IN 4 (MHL) port to view the phone screen on the TV. This only works for the MHL-enabled phone. -
Page 25: Component Connection
MAKING CONNECTIONS Component Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with a component cable as shown in the following illustration. NOTE If cables are installed incorrectly, it could case the image to display in black and white or with distorted color. -
Page 26: Composite Connection
MAKING CONNECTIONS Composite Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown in the following illustration. NOTE If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the Check to ensure the cables are matched with the corresponding color connection. -
Page 27: Connecting To A Pc
MAKING CONNECTIONS Connecting to a PC NOTE It is recommended to use the HDMI connection for the best image quality. Depending on the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use. In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness. - Page 28 MAKING CONNECTIONS Method B: dVI to HdMI Connection DVI OUT (*Not Provided) (*Not Provided) AUDIO OUT (RGB/HDMI-PC) (RGB/DVI) AUDIO AUDIO Method C: RGB Connection (PC) (RGB/HDMI-PC) (RGB/DVI) (PC) AUDIO AUDIO RGB OUT (PC) AUDIO OUT...
-
Page 29: Connecting To An Audio System
MAKING CONNECTIONS Connecting to an Audio System You may use an optional external audio system instead of the built-in speaker. NOTE If you use an optional external audio device instead of the built-in speaker, set the TV speaker feature to off. Digital Optical Audio Connection Transmits a digital audio signal from the TV to an external device. -
Page 30: Connecting To A Usb
MAKING CONNECTIONS Connecting to a USB Connect a USB storage device such as a USB flash memory, external hard drive, or a USB memory card reader to the TV and access the Smart Share menu to use various multimedia files. NOTE To use a HDD device, make sure that it is connected to the USB IN 1 HDD IN port. -
Page 31: Remote Control
REMOTE CONTROL REMOTE CONTROL Magic Remote Control Functions When the message “Magic remote control battery is low. Change the battery.” is displayed, replace the battery. To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching ends to the label inside the compartment, and close the battery cover. -
Page 32: Registering Magic Remote Control
REMOTE CONTROL Registering Magic Remote Control The Magic Remote Control operates by pairing with your TV. Once you purchased the TV, please register the Magic remote control as follows; How to register the Magic Remote Control To register automatically, turn the TV on and press the Wheel (OK). -
Page 33: Watching Tv
WATCHING TV WATCHING TV Turning the TV on for the first NOTE time Select Home when prompted. Store mode puts the TV in demo mode. If you select Store, the any customized When you turn the TV on for the first time, the settings will switch back to the default Initial setting screen appears. -
Page 34: Using The User Guide
Select the language to make voice search. Voice Search ✎ Only the voice search adopted model can support this OPTION Language setting. LG SMART Function Advabced Function Information Try Now Zoom In Close HOME Settings OPTION Language Selects Menu Language and Audio Language displayed on the screen. -
Page 35: Specifications
Storage Temperature -20 - 60 °C Storage Humidity Less than 85 % 47LM8600 55LM8600 (47LM8600-UC) (55LM8600-UC) MODELS 47LM8650 55LM8650 (47LM8650-UC) (55LM8650-UC) Dimensions With stand 1063.0 x 701.0 x 263.0 mm 1232.0 x 795.0 x 331.0 mm (W x H x D) (41.8 x 27.5 x 10.3 inch) - Page 36 SPECIFICATIONS 3D supported formats Video, which is input as below media contents is switched into the 3D screen automatically. 3D supported formats automatically Horizontal Vertical Input Signal Frequency Frequency Playable 3D video format (kHz) (Hz) 31.469 59.94 Top & Bottom, Side by Side (Half), Side by Side (Full) 31.5 640 x 480 62.938...
- Page 37 SPECIFICATIONS For models supporting WiDi, you can set the 3D mode in the same way as in RGB (PC) mode. 3D supported formats manually Horizontal Vertical Input Signal Frequency Frequency Playable 3D video format (kHz) (Hz) 2D to 3D, Side by Side (Half), Top & Bottom, 720p 45.00 Single Frame Sequential...
- Page 38 SPECIFICATIONS HDMI (DTV) supported mode Wireless LAN module(TWFM-B003D) specification Horizontal Vertical Resolution Frequency (kHz) Frequency (Hz) Standard IEEE802.11a/b/g/n 31.47 59.94 2400 to 2483.5 MHz 720x480p 31.50 60.00 Frequency Range 5150 to 5250 MHz 5725 to 5850 MHz 44.96 59.94 1280x720p Modulation CCK / OFDM / MIMO 45.00...
-
Page 39: Maintenance
MAINTENANCE & TROUBLESHOOTING MAINTENANCE Cleaning Your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended or unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. - Page 40 LG Customer Information Center For inquires or comments, visit www.lg.com or call; 1-888-542-2623 CANADA 1-800-243-0000 USA, Commercial User 1-888-865-3026 USA, Consumer User Register your product Online! www.lg.com The model and serial number of the TV is located This product qualifies for ENERGY STAR in the “factory default (Home Use)”...
