WS-9730U-IT Instruction Manual

Table of Contents

Topic
Inventory of Contents
Features
Setting Up
Battery Installation
Function keys
LCD Screen and Settings
Manual Settings
Weather Forecast and Tendency
Display of Indoor Temperature and Humidity Reading
Display of Outdoor Temperature Reading
Display of Indoor Maximum and Minimum records
Display of Outdoor Maximum and Minimum records
915 MHz Reception
Mounting
Care and Maintenance
Specifications
Warranty Information
This product offers:
INSTANT TRANSMISSION is the state-of-the-art new
wireless transmission technology, exclusively designed and
developed by LA CROSSE TECHNOLOGY. INSTANT
TRANSMISSION offers you an immediate update (every 4
seconds!) of all your outdoor data measured from the
sensors: follow your climatic variations in real-time!

INVENTORY OF CONTENTS

1. Wireless Weather Station
2. Wireless Outdoor Temperature Sensor (TX29U-IT) and mounting bracket.
3. Instruction Manual and Warranty Card.

FEATURES:

The Weather station
LCD
Display
Function

Manual time setting Keys

12/24 hour display

Hour and minute display

Wireless transmission at 915 MHz

Signal reception intervals at 4-second

Display indoor and outdoor temperature and indoor humidity (% RH)

Temperature displayed in degrees Fahrenheit (°F) or Celsius (°C) selectable

Weather forecasting with 15 easy-to-read weather forecast signs featured by Weather girl

Indoor comfort level indicator

Indoor and Outdoor temperature display with MIN/MAX recording

All MIN/MAX recordings can be reset

Low battery indicator

Table standing/ Wall mounting
The Outdoor Temperature Sensor
Page
1
1
1
1-2
2
2
2-3
2

SETTING UP:

3
Note:
4
This weather station receives only one outdoor sensor.
4
1. First, insert the batteries into the Temperature sensor. (see "Install and replace batteries in
4
the Temperature sensor").
4
2. Immediately after and within 30 seconds, insert the batteries into Weather station (see "Install
4
and replace batteries in the Weather station"). Once the batteries are in place, all segments
5
of the LCD will light up briefly. Following the time as 12:00 and the "Weather girl" icon will be
5
displayed. If these are not displayed after 60 seconds, remove the batteries and wait for at
5
least 10 seconds before reinserting them.
3. After inserting the batteries, the Weather station will start receiving data from the sensor. The
outdoor temperature and the signal reception icon should then be displayed on the Weather
station. If this does not happen after 3 minutes, the batteries will need to be removed from both
units and reset from step 1.
4. In order to ensure sufficient 915 MHz transmission however, this should under good conditions
be a distance no more than 100 meters between the final position of the Weather Station and
the sensor (see notes on "Mounting" and "915 MHz Reception").
Note:

If the signal reception is not successful on the first frequency (915MHz) for 45 seconds, the
frequency is changed to 920MHz and the learning is tried another 45 seconds. If still not
successful the reception is tried for 45 seconds on 910MHz. This will also be done for re-
synchronization.

BATTERY INSTALLATION

INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION
The Weather station uses 2 x AA, IEC LR6, 1.5V batteries. To install and replace the batteries, please
follow the steps below:
Hanging hole
Battery
compartment
cover
INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE SENSOR
Foldout
Stand
Note:
In the event of changing batteries in any of the units, all units need to be reset by following the setting
up procedures. This is because a random security code is assigned by the sensor at start-up and this
code must be received and stored by the Weather station in the first 3 minutes of power being supplied
to it.

Remote transmission of outdoor temperature to Weather Station by
915 MHz

Shower proof casing

Wall mounting case (Mounting at a sheltered place. Avoid direct rain
and sunshine)
1. Remove the cover at the back of the Weather station.
2. Insert batteries observing the correct polarity (see marking).
3. Replace compartment cover.
The Temperature Sensor uses 2 x AA, IEC LR6, 1.5V battery. To install and
replace the batteries, please follow the steps below:
1. Remove the battery compartment cover at the back of the sensor.
2. Insert the batteries, observing the correct polarity (see marking).
3. Replace the battery compartment cover on the unit.
