SERVICE MANUAL
Ver 1.1 2003. 06
• The tuner and CD sections have no adjustments.
AUDIO POWER SPECIFICATIONS (US Model)
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more
than 5% total harmonic distortion.
CD player section
Signal-to-noise ratio
90 dB
Frequency response
10 – 20,000 Hz
Wow and flutter
Below measurable limit
Tuner section
FM
Tuning range
87.5 – 107.9 MHz
Antenna terminal
External antenna connector
Intermediate frequency 10.7 MHz
Usable sensitivity
11 dBf
Selectivity
75 dB at 400 kHz
Signal-to-noise ratio
65 dB (stereo),
68 dB (mono)
Harmonic distortion at 1 kHz
0.7% (stereo),
0.5% (mono)
Separation
33 dB at 1 kHz
Frequency response
30 – 15,000 Hz
AM
Tuning range
530 – 1,710 kHz
Antenna terminal
External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity
AM: 30 µV
Power amplifier section
Outputs
Speaker outputs
(sure seal connectors)
Speaker impedance
4 – 8 ohms
Maximum power output 50 W × 4 (at 4 ohms)
Sony Corporation
9-874-231-02
2003F04-1
e Vehicle Company
© 2003. 06
Published by Sony Engineering Corporation
CDX-L510X
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
SPECIFICATIONS
General
Outputs
Inputs
Tone controls
Power requirements
Dimensions
Mounting dimensions
Mass
Supplied accessories
Note
This unit cannot be connected to a digital preamplifier or an equalizer.
Design and specifications are subject to change without
notice.
FM/AM COMPACT DISC PLAYER
US Model
Canadian Model
CDX-L280
MG-393XC-121//K
KSS-721A
Audio outputs (rear)
Power antenna relay control terminal
Power amplifier control terminal
Remote controller input terminal
Antenna input terminal
Low: ±10 dB at 60 Hz (XPLOD)
Mid: ±10 dB at 1 kHz (XPLOD)
High: ±10 dB at 10 kHz (XPLOD)
12 V DC car battery
(negative ground)
Approx. 178 × 50 × 180 mm
× 2 × 7
(7
in.) (w/h/d)
1/8
1/8
Approx. 182 × 53 × 161 mm
× 2
× 6
(7
in.) (w/h/d)
1/4
1/8
3/8
Approx. 1.2 kg
(2 lb. 10 oz.)
Parts for installation and connections
Front panel case (1)
Card remote commander
RM-X115
1
