Summary of Contents for LevelOne WAP-6150

  • Page 1 LevelOne User Manual WAP-6150 300Mbps Wireless Gigabit PoE Access Point...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1 INTRODUCTION ..........................5 ............................. 5 ONTENTS ..........................6 ARDWARE NSTALLATION 1.2.1 WARNING ..........................6 1.2.2 SYSTEM REQUIREMENTS.......................6 1.2.3 Hardware Configuration ......................8 1.2.4 LED Indicators ..........................9 1.2.5 Button Indicators ........................10 CHAPTER 2 GETTING STARTED .......................... 11 UI ......................
  • Page 3 3.3.2.3 Email Alert ............................. 35 3.3.3 System Tools ........................... 36 3.3.3.1 Change Password ......................... 36 3.3.3.2 FW Upgrade ..........................37 3.3.3.3 System Time ..........................38 3.3.3.4 Others ............................39 3.3.4 MMI ............................40 3.3.4.1 Web UI ............................40 CHAPTOR 4 TROUBLESHOOTING ........................41 APPENDIX A.
  • Page 4 Copyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written permission.

  • Page 5: Chapter 1 Introduction

    Before you install and use this product, please read this manual carefully for fully exploiting the functions of this product. Contents List Items Description Contents Quantity 1pce WAP-6150 2.4G WiFi Antenna 2pce 1pce Power Adapter RJ45 Cable 1pce 1pce...

  • Page 6: Hardware Installation

    1.2 Hardware Installation 1.2.1 WARNING  Do not use the product in high humidity or high temperatures.  Do not use the same power source for the Product as other equipment. Only use the power adapter that comes with the package. Using a different voltage rating power adaptor may damage the router.
  • Page 7  ® ® CD Installation Wizard Requirements  ...

  • Page 8: Hardware Configuration

    1.2.3 Hardware Configuration Rear View: WEC Button Reset Button LAN Port LAN(PoE) Port Power Jack...

  • Page 9: Led Indicators

    1.2.4 LED Indicators Description Color: Amber / Green Soild Amber: Device druing power-on process Soild Amber: Device druing power-on process Soild Green: Completion of power on Status Blinking Amber: Device is crashed and under recovery mode Blinking Green: The system is detective, such firmware upgrades fail Blink Amber led while pinging IP address of the device.

  • Page 10: Button Indicators

    1.2.5 Button Indicators Button Description The device has to take about 36 sec to change Mode completely. Step1:Press WEC Button about 9~10 seconds (Watch Status LED to flash about 9~10 times) Step2: WiFi LED Dark then release button Step3: Wait for about 25~26 seconds to change Wi-Fi LED WEC(Wireless Easy Color: Connection)

  • Page 11: Chapter 2 Getting Started

    Chapter 2 Getting Started Please use windows EZ setup utility or Web UI wizard to enter the setup process. Easy Setup by Configuring Web UI You can also browse web UI to configure the device. Firstly you need to launch the Setup Wizard browser first and then the Setup Wizard will guide you step-by-step to finish the basic setup process.
  • Page 12 Select “Wizard” for basic settings in a simple way. Or, you can go to Basic Network / Advanced Network / Applications / System to setup the configuration by your own selection. Press “Next” to start the Setup Wizard. Configure with the Setup Wizard Step 1 You can change the password of administrator here.
  • Page 13 Step 2 Entry LAN IP Address. Step 3-1 Wireless setting. Step 3-2 Wireless authentication and encryption. Step 4 Check the information again.
  • Page 14 Step 5 System is applying the setting. Step 6 Click finish to complete it.

  • Page 15: Use Wec Button To Setup Wireless Profiles

    Use WEC Button to Setup Wireless Profiles WEC Button is Wireless Easy Connection. There are 2 purposes for this Button. One is to switch AP into Master or Slave Mode. However, Main purpose of Slave AP is to get Wireless profile of Master AP to extend connective distance w/o login configured Web.
  • Page 16 Configure Slave AP via WEC Button Step 1 Check 2.4GHz LED of Access Point which acts as Master Mode. It should be Green. If not, please use WEC button to switch into Master Mode. Step 2 Check 2.4GHz LED of Access Point which acts as Slave Mode. It should be Amber. If not, please use WEC button to switch into Slave Mode.

  • Page 17: Chapter 3 Making Configurations

    Chapter 3 Making Configurations Whenever you want to configure your network or this device, you can access the Configuration Menu by opening the web-browser and typing in the IP Address of the device. The default IP Address is: 192.168.1.1. In the configuration section you may want to check the connection status of the router, to do Basic or Advanced Network setup or to check the system status.
  • Page 18 Afterwards, you can go Wizard, Basic Network, Advanced Network, Application or System respectively on left hand side of web page. Note: You can see the Connection Status screen below after you logged in. You can see all the status of this device in the ‘Status’ main menu section. Note :...

  • Page 19: Basic Network

    Basic Network You can enter Basic Network for Ethernet LAN and Wireless settings as the icon here shown 3.1.1 Ethernet LAN This device supports two types as Follows: Static IP: Allow a device to act as a Static host. If you need Static host and please entry IP Address.

  • Page 20: Wireless

    3.1.2 Wireless Wireless settings allow you to set the WLAN (WiFi) configuration items. When the wireless configuration is done your WiFi LAN is ready to support your local WiFi devices such as your laptop PC, wireless printer and some portable wireless devices.
  • Page 21 Wireless Module: Enable the wireless function. Wireless Operation Mode: Choose “AP Only Mode” from the list. Green AP: Enable the Green AP function to reduce the power consumption when there is no wireless traffics. AP Number: This device supports up to 8 SSIDs for you to manage your wireless network.

  • Page 22: Wds Hybrid Mode

    VLAN ID: Supports mapping of SSIDs to VLANs to separate workgroups across wireless and wired domains. Max Supported Stations: Support Max Stations to associated related SSID. Channel: The radio channel number. The permissible channels depend on the Regulatory Domain. The factory default setting is auto channel selection. 10.
  • Page 23 Lazy Mode: This device support the Lazy Mode to automatically learn the MAC address of WDS peers, you don’t have to input other peer AP's MAC address. However, not all the APs can be set to enable the Lazy mode simultaneously; at least there must be one AP with all the WDS peers’...

  • Page 24: Wds Only Mode

    default setting is “A/N mixed”. 10. Authentication & Encryption: You may select one of the following authentications to secure your wireless network: Open, Shared, Auto, WPA-PSK, WPA, WPA2-PSK, WPA2, WPA-PSK/WPA2-PSK,WPA /WPA2, or 802.1x. 11. Remote AP MAC 1 ~ Remote AP MAC 4: If you do not enable the Lazy mode, you have to enter the wireless MAC address for each WDS peer one by one.

  • Page 25: Universal Repeater Mode

    However, not all the APs can be set to enable the Lazy mode simultaneously; at least there must be one AP with all the WDS peers’ MAC address filled. Green AP: Enable the Green AP function to reduce the power consumption when there is no wireless traffics.

  • Page 26: Advanced Wireless Setup

    Green AP: Enable the Green AP function to reduce the power consumption when there is no wireless traffics. Network ID (SSID): Network ID is used for identifying the Wireless LAN (WLAN). Client stations can roam freely over this device and other Access Points that have the same Network ID.

  • Page 27: Advanced Rf Module2 Settings

    Beacon interval: Beacons are packets sent by a wireless router to synchronize wireless devices. Transmit Power: Normally the wireless transmission power operates at 100% out power specification of this device. You can lower down the power ratio to prevent transmissions from reaching beyond your corporate/home office or designated wireless area.
  • Page 28 Beacon interval: Beacons are packets sent by a wireless router to synchronize wireless devices. Transmit Power: Normally the wireless transmission power operates at 100% out power specification of this device. You can lower down the power ratio to prevent transmissions from reaching beyond your corporate/home office or designated wireless area.

  • Page 29: Ipv6

    3.1.3 IPv6 The growth of the Internet has created a need for more addresses than are possible with IPv4. IPv6 (Internet Protocol version 6) is a version of the Internet Protocol (IP) intended to succeed IPv4, which is the protocol currently used to direct almost all Internet traffic.

  • Page 30: Advanced Network

    Advanced Network This router also supports many advanced network features, such as Firewall, and Management. You can finish those configurations in this section. 3.2.1 Firewall The firewall includes MAC Address Control. 3.2.1.1 MAC Address Control MAC Address Control allows you to assign different access right for different users and to assign a specific IP address to a certain MAC address.

  • Page 31: Management

    Afterwards, click on “Save” to store your settings or click “Undo” to give up the changes. 3.2.2 Management 3.2.2.1 UPNP UPnP Internet Gateway Device (IGD) Standardized Device Control Protocol is a NAT port mapping protocol and is supported by some NAT routers. It is a common communication protocol of automatically configuring port forwarding.
  • Page 32 Enable SNMP: Enable this Function. SNMP Version: Supports SNMP V1, V2c, and V3. Get Community: The community of GetRequest that this device will respond. This is a text password mechanism that is used to weakly authenticate queries to agents of managed network devices. Set Community: The community of SetRequest that this device will accept.
  • Page 33 “authPriv” for both authentication and private key required. Username 1/2: Use this field to identify the user name for the specified level of access. Password 1/2: Use this field to set the password for the specified level of access. 10. User 1/2 Priv Key: Use this field to define the encryption key for the specified level of access.

  • Page 34: System

    System In this section you can see system information, system logs, use system tools for system update and do service scheduling and system administration setting. 3.3.1 System Information You can view the System Information in this page. 3.3.2 System Status 3.3.2.1 Web Log...

  • Page 35: Syslog

    Log Types: You can select the log types to be collected in the web log area. There are “System”, “Attacks”, “Drop”, and “Debug” types for you to select. Web Log: You can browse, refresh, download, and clear the log messages. 3.3.2.2 Syslog This device can also export system logs to specific destination by means of syslog (UDP) and SMTP(TCP).

  • Page 36: System Tools

    This device can also export system logs via sending emails to specific recipients. The items you have to setup include: Setting of Email alert: Check if you want to enable Email alert (send syslog via email). SMTP Server: Port: Input the SMTP server IP and port, which are connected with ':'.

  • Page 37: Fw Upgrade

    click “Undo” to give up the changes. 3.3.3.2 FW Upgrade If new firmware is available, you can upgrade router firmware through the WEB GUI here Press “browse” button to indicate the file name of new firmware, and then press Upgrade button to start to upgrade new firmware on this device. If you want to upgrade a firmware which is from GPL policy, please check “Accept unofficial firmware”.

  • Page 38: System Time

    3.3.3.3 System Time If new firmware is available, you can upgrade router firmware through the WEB GUI here Time Zone: Select a time zone where this device locates. Auto-Synchronization: Check the “Enable” checkbox to enable this function. Besides, you can select a NTP time server to consult UTC time. Sync with Time Server: Click on the button if you want to set Date and Time by NTP Protocol.

  • Page 39: Others

    3.3.3.4 Others In this section you can do system backup, reset to default, system reboot settings and ping test. Backup Setting: You can backup your settings by clicking the “Backup” button and save it as a bin file. Once you want to restore these settings, please click Firmware Upgrade button and use the bin file you saved.

  • Page 40: Mmi

    3.3.4 MMI 3.3.4.1 Web UI You can set UI administration time-out duration give remote administration host port in this page. When the host port is given please remember to check the enable box and save your settings.

  • Page 41: Chaptor 4 Troubleshooting

    CHAPTOR 4 Troubleshooting This Chapter provides solutions to problems for the installation and operation of the WiFi Concurrent N600 Business AP. You can refer to the following if you are having problems. 1 Why can’t I configure the router even the cable is plugged and the LED is lit? Do a Ping test to make sure that the WiFi Note: It is recommended that you...
  • Page 42 properly. Network adapter names will vary depending on your specific adapter. The installation steps listed below are applicable for all network adapters. Go to Start > Right click on “My Computer” > Properties. Select the Hardware Tab. Click Device Manager. Double-click on “Network Adapters”.
  • Page 43 III. Disable all security settings such as WEP, and MAC Address Control. IV. Turn off the WiFi Concurrent N600 Business AP and the client, then restart it and then turn on the client again. Ensure that the LEDs are indicating normally. If not, make sure that the power and Ethernet cables are firmly connected.
  • Page 44 Try changing the channel on the WiFi Concurrent N600 Business AP, and your Access Point and Wireless adapter to a different channel to avoid interference. III. Keep your product away from electrical devices that generate RF noise, like microwaves, monitors, electric motors, etc. 4 What to do if I forgot my encryption key? 1.

  • Page 45: Appendix A. Licensing Information

    Appendix A. Licensing information This product includes copyrighted third-party software licensed under the terms of the GNU General Public License. Please refer to the GNU General Public License below to check the detailed terms of this license. The following parts of this product are subject to the GNU GPL, and those software packages are copyright by their respective authors.
  • Page 46 GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 59 Temple Place, Suite 330, Boston, MA 02111-1307 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The licenses for most software are designed to take away your freedom to share and change it.
  • Page 47 1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty;...
  • Page 48 offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code. 4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License.
  • Page 49 NO WARRANTY 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
