- Page 1 Modular 8-Port Mid-span Power over Ethernet Injector KPOE-800-1P KPOE-800-2P Installation Guide DOC.090201...
- Page 2 (C) 2008 KTI Networks Inc. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any directive work (such as translation or transformation) without permission from KTI Networks Inc.
- Page 3 The information contained in this document is subject to change without prior notice. Copyright (C) All Rights Reserved. TRADEMARKS Ethernet is a registered trademark of Xerox Corp. FCC NOTICE This device complies with Class A Part 15 the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received including the interference that may cause.
-
Page 4: Table Of Contents
2.3 Mounting the Injector ...10 2.4 Installing Power Module...12 2.5 Applying AC Power...13 3. Making LAN Connections...14 3.1 Making Switch Port Connections ...14 3.2 Making Powered Device Connections ...15 3.3 LED Indication ...16 4. Applications...17 4.1 Application with Low Power Requirements...17 4.2 Application with High Power Requirements...17... -
Page 5: Introduction
The Power over Ethernet (PoE) injector is a mid-span power injector designed and tested for use with all IEEE802.3af compatible PoE Powered Devices (PDs). The PoE injector sits between a switch port and the PoE powered device, providing inline power capability to an un-powered switch port. -
Page 6: Product Panels
1.3 Mid-span Injector Function The PoE mid-span power injector is designed and tested for use with all IEEE802.3af compatible PoE PDs. The PoE injector sits between a switch port and the PoE powered device, providing inline power capability to an un-powered switch port. -
Page 7: Model Definition
1.4 Model Definition KPOE-800-1P 1 Power Model KPOE-800-2P 2 Power Model KPOE-800P60W Power Module KPOE-800BSET1 BRACKET SET1 KPOE-800BSET2 BRACKET SET2 1.5 Specifications Network Ports 8 connections to 8 non-PoE switched ports 8 connections to 8 PoE powered devices Compatible Std. - Page 8 - Disconnection, - Overload, - Over-current - Short-circuit, - Under voltage Power Module Slots LED Indicators Power module status x 2 , Port PoE status x 8 Power Input Voltage: 100 ~ 240VAC, Frequency: 50/60Hz Power Consumption 1 Power Model: 68W max. (60W for remote PoE PDs) 2 Power Model: 136W max.
-
Page 9: Installation
2. Installation 2.1 Unpacking Check that the following components have been included: Information CD The device unit An AC power cord If any item is found missing or damaged, please contact your local reseller for replacement. The following are available optional accessories: 19”... -
Page 10: Mounting The Injector
2.3 Mounting the Injector Desktop Mounting The injector can be mounted on a desktop or shelf. Make sure there is proper heat dissipation from and adequate ventilation around the device. Do not place heavy objects on the device. Rack Mounting The following brackets are designed for use to mount the devices in a 19”... - Page 11 2. Install the long bracket to the other side of the device. 3. Mount the device in a 19” rack. Mounting two units in a rack Use the bracket set 2 and follow the steps shown below: Short bracket x 4 Joint bracket x 1 1.
-
Page 12: Installing Power Module
3. Mount two device units as one in a 19” rack. 2.4 Installing Power Module If you purchased 2 Power Model, you may skip this section. 1 Power Model can deliver total up to 60W for consuming by all eight ports. Calculate the total power budget required for your PD connections before making any connections. -
Page 13: Applying Ac Power
3. Install the power module into the slot until it is seated properly. 4. Screw the module in the injector securely. 2.5 Applying AC Power One AC power cord, which meets the specification of your country of origin was supplied with the device unit. -
Page 14: Making Lan Connections
3. Making LAN Connections 3.1 Making Switch Port Connections The mid-span injector is designed to support the following PoE incapable switch port types and the PoE function is transparent and independent to the following port configuration: IEEE 802.3 std. 10BASE-T... -
Page 15: Making Powered Device Connections
3.2 Making Powered Device Connections The mid-span injector supports connection to IEEE 802.3af compliant PoE PD (Powered Device). The Ethernet port of the PD can be Ethernet, Fast Ethernet or Gigabit Ethernet. The injector’s PoE OUT port delivers power together with network signal to a connected powered device via Cat.5 cable or better. -
Page 16: Led Indication
Short-circuit A short-circuit situation is detected on the port. Under voltage An under-voltage situation is detected on the port. 3.3 LED Indication Function Power 1 status Power 2 status 1 ~ 8 Port 1 ~ Port 8 PoE status State Interpretation Power 1 is ON. -
Page 17: Applications
4. Applications 4.1 Application with Low Power Requirements 1 Power model may be used if the total power budget of the connected PDs is less than 60Watts. One empty slot can be upgraded with one more power if total power budget increased and is more than 60W in future.
