SYNTH/VOCODER
[Synthesizer, Vocoder]
Switches the currently selected pro-
gram between a Synthesizer pro-
gram and a Vocoder program.
Synthesizer (
):
The program will be a synth pro-
gram. You can use two oscillators
to create the sound.
Vocoder (
):
The program will be a vocoder pro-
gram. You can use sound input
from a connected mic to produce
"talking" instrument effects.
The parameters for editing will
vary depending on whether
Synthesizer or Vocoder is se-
lected here.
16
1. VOICE
— SYNTH/VOCODER
These settings determine the basic character of the program, and how it will sound.
"SYNTH/VOCODER" (knob 1) specifies whether the program will be a synth program or a vocoder program. If you want this to be a synth
program, select Synthesizer (
). "SINGLE/LAYER" (knob 2) specifies whether both timbres will be used (Layer) in the case of a synth
program. Other parameters in this section specify whether the program will sound monophonically/polyphonically/unison, and how the
notes will be triggered.
If you simultaneously press more keys than the specified number of voices, the last-pressed key will take priority.
SINGLE/LAYER
[Single, Layer]
VOICE ASSIGN
Specifies how many timbres the
program will use. This cannot be
Specifies how the timbre will be
selected for a vocoder program.
sounded.
Single (
):
Mono (
Only one timbre will be used.
The timbre will sound monophoni-
cally. The program will play only
Figure 1-1
one note at a time.
Timbre1
Poly (
The program will sound polyphoni-
cally, allowing you to play chords.
Layer (
):
The maximum polyphony is four
voices.
Two timbres will be used. When
you play the keyboard, both tim-
Unison (
bres will sound simultaneously.
All four voices will sound in uni-
You can edit each timbre individually.
son at the same pitch. Use "UNI-
SON DETUNE" to specify the pitch
Figure 1-2
difference in steps of one cent.
Timbre2
Timbre1
The maximum polyphony is four
voices (four notes). In the case of
a Layer program, these four
voices are divided between tim-
bres 1 and 2, so only two keys can
be played in a layered program.
TRIGGER MODE
[Mono, Poly, Unison]
Specifies whether the EG and LFO
will be retriggered when you play
the next key while still holding
down the previous key.
):
You can edit this if "VOICE AS-
SIGN" is Mono or Unison.
Single (
The EG and LFO will not be
):
retriggered by the second or subse-
quent key. Use this setting if you
want to play legato.
Multi (
The EG and LFO will be retriggered
):
each time you press a key.
Figure 1-3
"VOICE ASSIGN" and polyphony for
a Layer program
Single
Timbre 1
Timbre 2
Trigger
VOICE ASSIGN Mono
Poly
Polyphony 1 voice
3 voices
VOICE ASSIGN Poly
Poly
Polyphony 2 voices
2 voices
Multi
Trigger
VOICE ASSIGN Unison
Mono
Polyphony 2 voices
1 voices
[Single, Multi]
UNISON DETUNE
Specifies the amount of detuning
(in steps of one cent) between the
notes sounded by Unison mode.
You can edit this if "VOICE AS-
SIGN" is set to Unison.
The detuning method will depend
on the number of unison voices.
):
Figure 1-4
):
Note on
Note on
EG
EG
[0...99]
2 voice
99
Unison
0
Detune
4 voice
99
Unison
0
Detune
