MULTIQUIP GA6HR Operating Manual page 49

NO. pART NO.
1 A3214000403
2 0601850102
3 0601823204
4 Y0021003012
5 0601823853
6 0021004010
7 OEMAA8
8 A3224000703
9 0601806819
10 0601814065
11 0601811092
12 0601811031
13 0601812529
14 0021004010
15 OEMAA8
16 0601830737
17 0601831620
18 0601831620
19 A3262800004
20 011106015
21 0017105010
22 0601872301
23 0021003005
24 0601829301
25 Y0601815779
26 0021004020
27 OEMAA8
28 Y0027004025
29 OEMAA8
30 58042
31 0040004000
32 Y0601800699
33 Y0021003012
34 0207003000
ga6HR/6HRS 60 hz gENERATOR • OpERATiON ANd pARTs mANuAl — REv. #0 (08/12/14) — pAgE 49
pART NAmE
CONTROL BOX
GROMMET
RECTIFIER
MACHINE SCREW
SLOW DOWN UNIT
MACHINE SCREW
HEX. NUT .........................................................2................REPLACES P/N 0207004000
CONTROL PANEL
AC VOLTMETER 0~120/240V
RECEPTACLE
RECEPTACLE ..................................................1................REPLACES P/N 0601812592
RECEPTACLE ..................................................1................REPLACES P/N 0601811035
RECEPTACLE
MACHINE SCREW
HEX. NUT ........................................................10...............REPLACES P/N 0207004000
FULL POWER SWITCH
IDLE CONTROL SWITCH
OPERATION SWITCH
CONDENSER ASSY.
HEX. HEAD BOLT .............................................4................REPLACES P/N 0017106015
HEX. HEAD BOLT
CIRCUIT BREAKER, 120V 23A 2P
MACHINE SCREW
EARTH LEAKAGE RELAY
TERMINAL BOARD
MACHINE SCREW
HEX. NUT .........................................................2................REPLACES P/N 0207004000
MACHINE SCREW
HEX. NUT .........................................................3................REPLACES P/N 0030004000
WASHER, FLAT ................................................5................REPLACES P/N 0041204000
WASHER, LOCK
HOUR METER
MACHINE SCREW
HEX. NUT
GA6HRS — CONTROl bOX ASSy.
QTY.
1
1
2
2
1
2
1
1
2
1
10
1
1
1
1
4
1
4
1
1
2
1
3
1
2
2
REmARks
