Page 1: Installation Manual
INSTALLATION MANUAL Split System air conditioners FCQ35C7VEB FCQ50C7VEB FCQ60C7VEB FCQ71C7VEB FCQ100C7VEB FCQ125C7VEB FCQ140C7VEB FCQH71C7VEB FCQH100C7VEB FCQH125C7VEB FCQH140C7VEB Downloaded from AC-Manual.com Manuals... - Page 2 ≥1500 ≥1500 ≤ 35 ≤ 35 ≤300 mm 1~1.5 m 6+10 Downloaded from AC-Manual.com Manuals...
- Page 3 3PW33501-2 Downloaded from AC-Manual.com Manuals...
-
Page 4: Table Of Contents
EQUIPMENT OR ACCESSORIES COULD RESULT IN ELECTRIC SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR OTHER DAMAGE TO THE EQUIPMENT. BE SURE ONLY TO USE ACCESSORIES MADE BY DAIKIN WHICH ARE SPECIFICALLY DESIGNED FOR USE WITH THE EQUIPMENT AND HAVE THEM INSTALLED BY A PROFESSIONAL. -
Page 5: Selecting Installation Site
For the following items, take special care during Ceiling height construction and check after installation is finished This indoor unit may be installed on ceilings up to 3.5 m in height (for FCQH100~140 units: 4.2 m). However, it becomes necessary to make field settings using the remote controller Tick when installing the unit at a height over 2.7 m (for when... -
Page 6: Indoor Unit Installation
Use the installation guide (delivered with the unit) for exact NDOOR UNIT INSTALLATION vertical positioning of the unit. When installing optional accessories (except for the decoration Apply the short side Apply the long side panel), read also the installation manual of the optional accessories. of the installation guide in case of of the installation guide in case of normal installation... -
Page 7: Refrigerant Piping Work
Finally, insulate as shown in the figure below (use the supplied EFRIGERANT PIPING WORK accessory parts) For refrigerant piping of outdoor unit, refer to the installation manual Liquid pipe supplied with the outdoor unit. Gas pipe Execute heat insulation work completely on both sides of the gas Insulation for fitting for liquid piping and liquid piping. -
Page 8: Drain Piping Work
How to perform piping (See figure 7) RAIN PIPING WORK Ceiling slab Installation of drain piping Hanger bracket Adjustable range Install the drain piping as shown in the figure and take measures against condensation. Improperly rigged piping could lead to leaks Drain raising pipe (nominal diameter of vinyl pipe = 25 mm) and eventually wet furniture and belongings. -
Page 9: Electric Wiring Work
Specifications for field wire Control box lid Inter unit wiring Wire Length Size (mm Earth cable Between (1),(2) H05VV-U4G — indoor units Inter unit wiring terminal block Unit-Remote Sheathed wire ≤500 m Clamp 0.75-1.25 controller (2 wire) Transmission wiring (1) Shows only in case of protected pipes. Use H07RN-F in case of no protection. (2) Run transmission wiring between the indoor and outdoor units through a conduit Terminal board for transmission wiring to protect against external forces, and feed the conduit through the wall together... -
Page 10: Wiring Example
When connecting wires of the same gauge, connect them Group control (See figure 15) according to the figure. 2 remote controller control (See figure 16) Main power supply Main switch Use the specified electric wire. Connect the wire securely to the terminal. -
Page 11: Field Setting
When using wireless remote controllers IELD SETTING When using wireless remote controllers, wireless remote controller Field setting must be made from the remote controller in accordance address setting is necessary. Refer to the installation manual with the installation condition. attached to the wireless remote controller for setting instructions. Setting can be made by changing the "Mode No.", "First code No."... - Page 12 Press Inspection/Test Operation button 4 times /TEST OTES (2 times for wireless remote controller) and operate at Test Operation mode for 3 minutes. Push air flow direction adjust button to make sure SWING the unit is in operation. Press Inspection/Test Operation button /TEST and operate normally.
-
Page 13: Wiring Diagram
IRING DIAGRAM Indoor unit Receiver/display unit (attached to wireless remote controller) A1P......Printed circuit board A3P,A4P ....Printed circuit board A2P......Printed circuit board (humidity sensor unit) BS1 ..... ON/OFF button F1U......Fuse (T, 5 A, 250 V) (only for FCQ35~60) H1P ..... Light emmiting diode (On - Red) HAP .....Light emitting diode (service monitor - green) H2P ..... - Page 14 NOTES NOTES Downloaded from AC-Manual.com Manuals...
- Page 15 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3...
- Page 16 4PW31577-1B Zandvoordestraat 300, B-8400 Oostende, Belgium Downloaded from AC-Manual.com Manuals...
