Installation and Maintenance
Instructions
Logano G234X
gas-fired boiler
Gas-fired boiler
WARNING
!
Before commissioning the boiler, heed the safety
instructions for mounting and maintenance.
DANGER!
If installation, adjustment, modification, operation
or maintenance of the heating system is carried
out by an unqualified person, this may result in
danger to life and limb or property damage. The
installation and servicing instructions must be
followed precisely. If you require assistance or
further information, contact a qualified installer or
an appropriate service provider.
CAUTION!
The operating instructions are part of the techni-
cal documents that must be handed over to the
operator of the heating system. Discuss the in-
struction in this manual with the owner or opera-
tor of the heating system to ensure that they are
familiar with all information required for operation
of the heating system.
For heating contractors
Please read carefully before
installing and servicing.
