- Page 1 85M Powerline Ethernet Bridge PL-201v2-EU/UK User Manual...
- Page 2 Copyright Copyright (C) 2008 PLANET Technology Corp. All rights reserved. The products and programs described in this User’s Manual are licensed products of PLANET Technology, This User’s Manual contains proprietary information protected by copyright, and this User’s Manual and all accompanying hardware, software, and documentation are copyrighted. No part of this User’s Manual may be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form by any means by electronic or mechanical.
- Page 3 In most, if not all cases, these designations are claimed as trademarks or registered trademarks by their respective companies. Revision User’s Manual for PLANET 85M Powerline Ethernet Bridge Model: PL-201v2-EU/UK Rev: 1.0 (Feb. 2008) Part No.: 2081-AE0130-002...
-
Page 4: Table Of Contents
Table of Content Chapter 1: Introduction ..................5 Overview ......................5 Features ......................5 Specification ....................6 System Requirements ..................6 Application Diagram ..................6 Panel .......................7 LED definition ....................7 Package Contents ...................7 Chapter 2: Installation ..................8 Running the InstallShield Wizard..............8 Chapter 3: Configuration..................12 3.1 Main Screen ....................12 3.2 Privacy.....................14 3.3 Diagnostics ....................16... -
Page 5: Chapter 1: Introduction
Chapter 1: Introduction Overview Thank you for purchasing PLANET 85M Powerline Ethernet Bridge. With Planet Powerline communication products, your power outlets are no longer to be viewed only as power receptacles but also as network connection point. The PL- 201v2 is a Powerline to Ethernet Bridge with a RJ-45 Ethernet interface which directly connecting to your computer’s network card. -
Page 6: Specification
Specification Model PL-201v2-EU/UK Standard HomePlug Powerline Specification 1.0 Turbo compliant IEEE802.3 10 Base-T IEEE802.3u 100 Base-T Ports One RJ-45 port Speed UP to 85Mbps Encryption 56-bits DES encryption Power, Ethernet, Data Powerline Frequency Band 4Mhz to 21Mhz Dimension (W x D x H) -
Page 7: Panel
Panel LED definition Status Description Steady on indicate the Powerline device connect to Power the power outlet Blinking Blinking indicates the data are transferring Steady on indicates the RJ-45 port has correctly Ethernet connected to the network card of your PC or the Ethernet network Blinking Data transferring in bridge mode... -
Page 8: Chapter 2: Installation
Chapter 2: Installation Overview The installation of 85M Ethernet Bridge will only take minutes. No need to set up long wires through out the house, just simply install the utility, and physically plug the unit into the wall outlet, then to connect RJ-45 to the computer. Users can select to adjust its security functions and the platform of the network after the installation. - Page 9 On this screen you will be asked to input the User Name and Organization. It is not crucial to the device itself, so enter it as desired. The ‘Install this application for’ will work under the circumstances which multiple logins are applied.
- Page 10 This section allows you to change the default directory where the program is installed. If you don’t want to change it, click on Next to continue the installation. This section allows a user to go ‘Back’ or ‘Install’ the utility. In case if the user wishes to change the previous options then go ahead, click on ‘Back’...
- Page 11 This screen shows the progress of the installation. This screen shows that the installation was completed successfully. Click on Finish to exit the wizard.
-
Page 12: Chapter 3: Configuration
Chapter 3: Configuration Overview The PL-201v2 uses 56-bit DES encryption to block outside access. The key is set by using the Configuration Utility on the CD. By default, the protection is enabled, however, it is recommended to change the default network password. All your Powerline devices must use the same network password in order to be connected together. - Page 13 **Note** If you do not see ANY unit in the device status but the Powerline device does exist, try to unplug all devices and plug them back. Meanwhile, please make sure the cable is the right type and working correctly. If all seems to be correct, and you still receive nothing in the Device window, try rebooting your computer.
-
Page 14: Privacy
If the problem persists, try to move the unit closer to this current unit (adjacent plugs on the same wall socket is most preferable). If the problem still persists and that unit is still not shown on the network, then the unit might be defective please contact technical support. - Page 15 Setting Up Security on a Network Powerline device The Privacy Tab will allow users to use one primary computer to control the Network Password of all units on the home network. You will have to go back to the Main Tab first then find the DEK (Device Encryption Key) Key located on the bottom of each device.
-
Page 16: Diagnostics
**Note** The DEK is unique for EACH Powerline device. To use this you will need to input the DEK for each unit. 3.3 Diagnostics The Diagnostics screen shows system information and a history of all devices seen. Diagnostics Screen... - Page 17 The upper panel shows technical data concerning software and hardware on the host computer used to communicate over HomePlug. It shall include the following： Operating System Type/Version Host Network Name User Name MAC Address of all NICs (network interface card) Chipset manufacturer name (Turbo Only devices) Firmware Version (Turbo Only devices) The lower panel contains a history of all remote devices.
