1.4 R P
EAR ANEL
PS/2 Mouse Port
S-Video TV-Out Port
Transmit anal og vi deo signals to TV or any other dis play panels equipped with S-Video
input.
HDMI Port
The High-Definition Multimedia Interfac e (HDMI) is an all-digital audio/video interfac e
capable of transmitting unc ompress ed s treams to an AV recei ver or any compatibl e digital
audi o and/or video monitor, suc h as a digital television.
The HDMI audio function is not s upported by Windows 2000 / XP.
D-Sub VGA Port
Transmit anal og vi deo signals to computer monitor or any other dis play panels equipped
with D-Sub VGA input.
USB 2.0 Port x 4
Audio Jack x 6 (for Ver 5.x) / Audio Jack x 3 (for Ver 6.x)
Port 2-Channel
Blue Line-In
Green Line-Out
Pink Mic In
Orange
Black Rear Speaker Out
Grey
NOTE: The HDMI audio is c urrentl y onl y s upported by Wi ndows VISTA.
NOTE: The GeForce 7050PV/NF630a chips et uses the same c hannel to control S-Video and
D-Sub for trans mitting anal og vi deo signals, so these ports c annot work simultaneousl y .
6
C (
ONNECT ORS FOR
PS/2 Keyboard Port
RJ-45 LAN Port
4-Channel
Line-In
Front Speaker Out
Mic In
Rear Speaker Out
TF7050-M2)
6-Channel/8-Channel
Line-In
Front Speaker Out
Mic In
Center/Subwoofer
Rear Speaker Out
Side Speaker Out
