- Page 1 The Ultimate Sound Experience ™ Professional Cinema Loudspeaker Systems...
- Page 2 The best performers Once movie-goers experience the unbridled dynamics and intense realism of a Klipsch Cinema and Stage System, they will have a new favorite theater for life. Audiences have never heard dialogue so precise or soundtracks so stunningly detailed and immersive. Only Klipsch delivers...
- Page 3 American-made for over 60 years, Klipsch cinema speakers offer years of reliable and trouble-free performance. From the grandest auditoriums to the coziest cinemas, our technical experts will ensure that your customers have the richest auditory experience possible.
- Page 4 KPT-745-N. KPT-445-N Klipsch designed the new, four-way KPT-445 N to deliver the digital soundtracks found on today’s latest films for the small to medium sized auditoriums. This system is designed to be used in a tri-amp configuration. It utilizes the KPT-904 LF double 15”...
- Page 5 As the first complete three-way passive behind-the-screen system on the market, the KPT-435-N affords the ultimate in audio performance for small-and medium-sized venues. Less than 20 inches in depth, it is also one of the most space saving speakers in its performance category. Based on the proven KPT-904-LF dual 15-inch bass unit, the KPT-435-N delivers powerful bass from a shallow cabinet that is just 17.75 inches deep.
- Page 6 KPT-1201 The KPT-1201 is a THX-Certified cinema surround speaker system that delivers extended bass response, controlled coverage and standard SMPTE/ISO 2696 X-curve de-emphasis from an enclosure designed not to appear bulky. Its 12-inch woofer and 1.75-inch titanium high-frequency compression driver coupled to a 100˚...
- Page 7 Capable of delivering an earth-shaking low frequency of 18Hz, the KPT-884 is a high-output, bass-reflex cinema subwoofer that features an advanced low-frequency four-inch voice coil driver design. Less than 23 inches in depth, this system utilizes a single 18-inch driver that gains its high efficiency through the use of large, geometrically optimized structures and lightweight cones.
-
Page 8: Specifications
S P E C I F I C A T I O N S B E H I N D – T H E – S C R E E N S Y S T E M S KPT-MCM-4-T Grand Frequency Response* 40Hz-19kHz ±... - Page 9 KPT-535-4-T KPT-535-T 43Hz-19kHz ± 3dB,-10dB @ 26Hz 45Hz-19kHz ± 3dB,-10dB @ 32Hz 500Hz, 5kHz 500Hz, 5kHz LF – 0ms LF – 0ms MF – .29ms MF – .12ms HF – .83ms HF – .66ms 24dB/Octave 24dB/Octave 107dB 104dB Horizontal 90° ± 30° 200Hz-16kHz Horizontal 90°...
- Page 10 S U B WO O F E R S KPT-884 27Hz-240Hz ± 3dB Frequency Response 18Hz–1.2kHz -10dB 1200 watts (92V) 20-200Hz Power Handling 128dB Calc. Max. Cont. Output Sensitivity 98dB Coverage 8 ohms (7.2 min. @ 23Hz) Nominal Impedance One K-472 18" woofer Transducers Barrier strip Input Connectors...
- Page 11 KPT-KHJ-LF KPT-904-LF 45Hz-800Hz ± 4dB 45Hz-1.5kHz ± 3dB 34Hz-1kHz -10dB 32Hz-2kHz -10dB 200 watts (40.5V) per woofer 40Hz-800Hz 400 watts (58V) per woofer 40Hz-800Hz 128dB 130dB 105dB 104dB Horizontal 90° ± 20° 200Hz-1kHz Horizontal 90° ± 20° 250Hz-1.5kHz Vertical 90° ± 20° 200Hz-600Hz Vertical 60°...
- Page 12 High efficiency, low distortion, controlled directivity, flat frequency response. It’s all here. Klipsch Audio Technologies 3502 Woodview Trace Indianapolis, IN 46268 klipsch.com 193171 (Rev. 2) ©2006 Klipsch Audio Technologies. Specifications are subject to change without notice. 3M207...
