Klipsch Reference Series RB-10 Specifications

4'' Two-Way Bookshelf Loudspeaker
The Reference Series RB -10 bookshelf
loudspeaker is part of Klipsch's new entry-
level Reference 10 family that offers the same
advanced technology and world-class materials
as the Reference III models but from smaller
enclosures and at lower price points.
As the smallest bookshelf loudspeaker Klipsch
has ever made, the RB-10 employs a 4-inch
woofer and a 1-inch titanium-dome
compression driver loaded with a 4-inch
square Tractrix Horn for maximum clarity
®
and efficiency.
The woofer on the RB -10 still features
Klipsch's distinctive,
Cerametallic™ material. Made with an
anodized aluminum, this cone is strong with
low mass. The anodizing process converts its
inner and out surface to ceramic. The
outcome is a rigid cone with superb damping
characteristics that will not flex or resonate at
frequencies within the woofer's operating
range.
As in all Reference Series speakers, the RB-10
crossover network is constructed using
extremely high-quality components including
top-of-the-line internal wiring, polyester film-
type capacitors and an air-core inductor to
ensure signal purity and proper driver
integration.
The RB-10 has both a back-panel keyhole for
on-wall mounting and a threaded insert for
attachment to popular adjustable wall and
ceiling brackets. Available in a black vinyl finish,
the RB-10 features a low-diffraction sculpted
baffle and magnetically attached grille for an
elegant fit and finish.
RB-10
Magnetically shielded to prevent video interference
I
Back-panel keyhole and threaded insert for popular wall and
I
ceiling brackets
Tractrix Horn titanium dome compression driver tweeter for clean,
I
detailed highs
Cerametallic cone woofer
I
High sensitivity and power handling
I
S P E C I F I C A T I O N S
BANDWIDTH
SENSITIVITY
NOMINAL IMPEDANCE
copper-colored
CROSSOVER FREQUENCY
POWER HANDLING
ENCLOSURE TYPE
DRIVE COMPONENTS
WEIGHT
HEIGHT
WIDTH
DEPTH
FINISH
MOUNTING
*All dimensions include grille and binding posts
90Hz-20kHz ± 3dB
90dB @ 2.83 volts/1 meter
8 ohms compatible
2800Hz
50 watts (200 watts peak)
Bass-reflex via rear-firing port
Two way system using one 1'' (2.5cm)
magnetically shielded, titanium dome
compression driver with an integral
4'' (10.2cm) square 90˚x 60˚ Tractrix Horn
and one 4'' (10.2cm) magnetically shielded,
Cerametallic cone woofer
6 lbs. (2.7kg)
8.7" (22.1cm)
5.6" (14.1cm)
7.8" (19.8cm)
Black Ash woodgrain vinyl
Keyhole mount with threaded insert
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2004
