- Page 1 TECHNICAL INFORMATION, ASSEMBLING INSTRUCTIONS, USE AND MAINTENANCE Vertical warm air heaters BI SERIES All Parts available from www.sparesgiant.com 01772 329 565...
-
Page 2: Range
This is particularly the case if the heater is put in the hands of DESA ITALIA Technical Assistance Department which is specially trained end equipped to keep it working at maximum efficiency with low running costs and has a large number of original spare parts in stock. -
Page 3: Table Of Contents
INDEX GENERAL RANGE ....................................2 GUARANTEE ..................................2 GENERAL WARNINGS ..............................4 BASIC SAFETY RULES..............................5 DESCRIPTION OF THE EQUIPMENT ..........................6 IDENTIFICATION ................................7 STRUCTURE ..................................7 COMBUSTION CHAMBER DIMENSIONS ......................... 8 ... -
Page 4: General Warnings
01772 329 565 exchanger during storage: this is normal and will disappear after a short period. It is advisable to DESA ITALIA shall not be held liable for any keep rooms ventilated. failures to observe the instructions contained in this booklet, for the consequences of any... -
Page 5: Basic Safety Rules
Close the fuel shut-off; It is forbidden to put objects on top of the Call the DESA ITALIA Technical Assistance equipment or push them inside the boy shell grill Dept. other professionally qualified and exhaust discharge dust. -
Page 6: Description Of The Equipment
DESCRIPTION OF THE EQUIPMENT The BI equipment is designed to heat the air in the room using heat energy produces by combustion. Essentially the equipment consists of heat exchanger assemblies exchanging heat from the combustion by-products from a forced gas or heating fuel oil burner by a high performance fan assembly. -
Page 7: Identification
The Technical Plate bearing their main technical and performance details. The plate is located on the front of the equipment. If the Plate gets lost or damaged, ask for a duplicate from DESA ITALIA Technical Department. MANUFACTURER IDENTIFICATION AIR HEATER... -
Page 8: Combustion Chamber Dimensions
COMBUSTION CHAMBER DIMENSIONS The three fume-cycle heat exchanger and combustion chamber have the following dimensions. All Parts available from TYPE www.sparesgiant.com Measurements in millimetres; 01772 329 565... -
Page 9: Dimensions
DIMENSIONS Type 14 Type 510 Type 1115 All Parts available from www.sparesgiant.com 01772 329 565 Type chimney 1580 1305 1800 1475 1060 1926 1667 1060 1926 1667 1300 2120 1182 1240 1905 1300 2120 1182 1240 1905 1500 1000 2120 1382 1440... -
Page 10: Technical Data
TECHNICAL DATA TYPE Heating capacity 60,0 94,0 103,2 122,3 161,2 190,0 225,8 258,8 322,6 391,0 460,6 590,0 645,3 769,0 1000 Kcal/h 51600 80850 88790 105150 138600 163400 194225 222600 277470 336250 396160 507300 554940 661500 860000 Heating power 54,0 82,2 93,0 107,0 145,3... -
Page 11: Handling And Transportation
HANDLING AND TRANSPORTATION Moving the equipment must be carried out by properly equipped personnel with equipment which is suitable for the weight of the heater. If a fork lift is used, the equipment should be taken up at the bottom using the guides in the supporting base. -
Page 12: Location
LOCATION The place of installation must be established by the plant project engineer or competent person and must take account of the technical requirements and current legislation and regulations which demand the obtaining of an authorisation (e.g. building, architectural and fire regulations, environmental legislation and so on). Before installing the equipment it is therefore advisable to apply for and obtain all the necessary authorisations. -
Page 13: Air Inlet Connection
AIR INLET CONNECTION Connect any eventual channelling to the hot air distribution circuit to the equipment upper delivery flange, interposing a vibration damper joint to prevent vibrations being transmitted to the pipes. WARNING! The dimensioning of eventual air inlet and outlet channels has to be previewed by qualified personnel in compliance with the maximal performances of the heater as indicated in the “TECHNICAL DATA”. - Page 14 MOUNTING INSTRUCTIONS Free the diffusion plenum from its packaging; Remove the delivery air outlets and the closing panel from the plenum; Place the plenum on the top of the equipment; Fix the plenum to the equipment using the screws provided, entering through the delivery outlet openings and the closing panel;...
-
Page 15: Air Inlet Filter
AIR INLET FILTER Type 1300 1300 1500 1500 1700 1700 2090 2090 2500 2500 3500 1000 1000 1000 1000 1000 Cells N° P (Pa) All Parts available from MOUNTING INSTRUCTIONS Type 14 Type 515 www.sparesgiant.com 01772 329 565 Type 14 Type 515 ... -
Page 16: Mounting The Burner
MOUNTING THE BURNER To proceed with the installation of the oil burner, respect and follow the instructions contained in the specifically manual of the burner in detail. ELECTRICAL CONNECTION The equipment is supplied with the electrical panel mounted as standard and with the motor/s and the FAN-LIMIT thermostat/s connected. -
Page 17: Type 1 Wiring Diagram
TYPE 1 WIRING DIAGRAM 230V ~ 50 Hz All Parts available from SWITCHBOARD CONNECTING TERMINAL www.sparesgiant.com 01772 329 565 ELECTRICITY SUPPLY 230 V ~ 50 Hz Contents: - FAN Thermostat (25-35°C) - LIMIT Thermostat (100°C) - Safety fuses - Motor internal protection - Fan motor - Fan motor condense - Burner... -
Page 18: Type 2 To 10 Wiring Diagram
TYPE 2 TO 10 WIRING DIAGRAM 400V~ 3+N 50 Hz All Parts available from www.sparesgiant.com SWITCHBOARD CONNECTING TERMINAL 01772 329 565 MONOPHASIC BURNER ELECTRIC SUPPLY VARIANT GROUND ELECTRICITY SUPPLY BURNER SUPPLY BURNER SUPPLY 400 V ~ 3+N 50 HZ 400 V ~ 3+N 50 HZ 230 V ~ 50 HZ Contents FAN thermostat (25-35°C) -
Page 19: Types 11 To 14 Wiring Diagram
TYPES 11 TO 14 WIRING DIAGRAM 400V~ 3+N 50 Hz SWITCHBOARD CONNECTING TERMINAL All Parts available from Earth www.sparesgiant.com GROUND connection 01772 329 565 BURNER SUPPLY 400 V ~ 3+N 50 HZ ELECTRICITY SUPPLY 400 V ~ 3+N 50 HZ Contents FAN thermostat (25-35°C) Safety burner stop flag... -
Page 20: Type 15 Wiring Diagram
TYPE 15 WIRING DIAGRAM CAPACITY: 400V~ 3+N 50 Hz RTV1 RTV2 All Parts available from www.sparesgiant.com CONTROL: 01772 329 565 RTV1 RTV2 For contents and switchboard connecting terminal, see next page. - Page 21 SWITCHBOARD CONNECTING TERMINAL Earth connection Burner supply Electrical supply 400V ~ 3+N 50 Hz 400V ~ 3+N 50 Hz THERMOSTAT LINE Contents FAN thermostat (25-35°C) Auxiliary charges fuses LIMIT thermostat (100°C) Burner fuses All Parts available from FV1-2 Safety thermostat (preset 80°C) Fan motor fuses Fan start timer Fan flow switch control 1...
-
Page 22: Fan-Limit Dual Thermostat
FAN-LIMIT DUAL THERMOSTAT This thermostat sensor is positioned at the hot air delivery outlet and has the double function of controlling the start up and the stopping of the fan (FAN function), as well as the safety shutting off of the equipment in case of overheating. ... - Page 23 The equipments typ 11 to 15 , will be delivered, due theirs possibility to be handled, in 2 separated sections. For this reason the thermostats will be connected to the electric boards but not positioned: they need to be positioned during the installation.
-
Page 24: Fan-Limit-Safety Thermostats Setting
FAN-LIMIT-SAFETY THERMOSTATS SETTING The thermostats will be supplied with the setting pointed out in the table here under: FAN thermostat: 25 – 35°C LIMIT (1) thermostat 100°C SAFETY (2) thermostat Pre-setting 80°C The LIMIT thermostat have a permanent setting and do not have to be touched; The SAFETY Thermostat (Typ 515) need to be set as specified in the manual during the installation. -
Page 25: Fan Start Timer
FAN START TIMER POSITIONING Housed inside the electrical panel in the models typ 11 to typ 14. FUNCTION This is connected in parallel with the FAN (FA) thermostat and controlled by the RTZ relay with the function of ensuring the start up of the fan assembly after a maximum time of 1 minute from the ignition of the burner flame. -
Page 26: Oil-Fired Burner Setting
230V 50Hz RL 28/1 tc 230V 50Hz RL 34/1 MZ tc 230V 50Hz RL 38 tc 230V 50Hz RL 34/1 MZ tc 400V 50Hz 3N RL 50 tc 400V 50Hz 3N RL 44 MZ tc 400V 50Hz 3N ... -
Page 27: Fan Speed Set-Up
FAN SPEED SET-UP The equipment is supplied as standard with the transmission ratio adjusted in such a way that the nominal air flow can be obtained with plenum diffusion through three or four of its sides and with air intake from one or two sides through the intake grills. -
Page 28: Checks
CHECKS To ensure the proper working of the equipment it is necessary certain basic parameters must be checked. Switch the equipment on and carry out the following: Check that the fan assembly starts up about 1 minute after the burner runs. When the generator is up to temperature and working normally (after about 20 minutes of continuous working), carry out the following operations:... -
Page 29: Indicators
INDICATORS VOLTAGE ON INDICATOR types 1115 Located on the electrical panels of the models. It is an orange light which comes on when there is voltage. BURNER LOCKED INDICATOR This red button is located on the burner and lights up when the burner is locked. It is also the reset button. -
Page 30: Start Up And Stop
START UP AND STOP START UP Follow the instructions in the chapter WORKING CYCLE. STOP To stop the equipment it is necessary follow the procedure below: Set the room thermostat at ‘no frost’ or set the switch at “STOP”; ... -
Page 31: Burner Cleaning
BURNER CLEANING The cleaning of the burner must be carried out by authorised people strictly following the burner own instructions manual. HEAT EXCHANGER CLEANING The cleaning of the heat exchanger must be carried out by authorised people and is subject to specific regulations. Generally speaking, the operation should be carried out annually at the start of each winter. -
Page 32: Fan Maintenance
FAN MAINTENANCE The bearings on type 110 fans are also hermetic pre- Periodically check the tightness of the transmission belts and the alignment between the motor pulley and the fan loaded. pulley. The belts must not be more taut than necessary to The type 11 - 12 - 13 - 1 4 - 15 (the last only on the side stop them slipping;... -
Page 33: Faults And Solutions
FAULTS AND SOLUTIONS FAULT CAUSE SOLUTIONS No voltage THE GENERATOR Check electrical connections DOESN’T WORK NEITHER Check line fuses and auxiliaty charges wholeness IN VENTILATION NOR IN HEATING MODE THE GENERATOR No electricity supply to tha fan Check electrical connections motor DOESN’T WORK IN... - Page 34 FAULT CAUSE SOLUTIONS THE BURNER STOPS LIMIT thermostat cut-in Check the opening of the flow directing fins ANOMALOUSLY AND CASUALLY Check for the absence of obstructions on air inlet grids Check fan motor Burner flame detached Check the burner setting Check that the generator doesn’t work in a depressed room...
- Page 35 FAULT CAUSE SOLUTIONS THE FAN DOESN’T STOP Too high room temperature Check the air inlet temperature WITHIN ABOUT 4 MINUTES Check for an eventual solar FROM THE STOPPING OF irradiation THE BURNER To be verified or out of order Check FAN index setting FAN-LIMIT dual thermostat Verify that the white button Is on the...
- Page 36 PRODUCT DISPOSAL This product was designed and made with high qualità material and components which can be recycled and reused. When finding the symbol of a wheeled crossed bin on a product, be aware of the fact that the component is covered by the European Directive 2002/96/EC. Get informed about your local waste separation system as far as electric and electronic products are concerned.
- Page 37 - Încălzitoare portabile de aer: - Преносими отоплители под налягане: - Uređaj za upuh toploga zraka: - Портативні повітрянагрівачі: BI 60 - BI 95 - BI 105 - BI 120 - BI 160 - BI 190 - BI 225 - BI 260 01772 329 565 BI 320 - BI 390 - BI 590 - BI 645 - BI 770 - BI 1000 - BI 1100 It is declared that these models conform to: - Ces modèles ont été...
