- Page 1 START Click the button and follow the instructions. CC-GL51 Quick Start...
- Page 2 Thank you for purchasing our cyclocomputer CATEYE STEALTH evo+. This Quick Start Manual explains how to set up the STEALTH evo+ and how to install the unit on your bicycle. Please set up the unit according to the specified procedure, then it will be ready for use as a cyclocomputer.
- Page 3 This PDF contains a movie file. When you click on the movie screen, a message regarding security appears. Click the “Trust in the text” or “Play” button to close the message. Click the screen again to play the movie. Next...
- Page 4 Return to a Cover Quick Start Manual Contents Click on the item to view. Setting up the STEALTH evo+ How to install the bracket (movie format) Optional: How to install the speed sensor (movie format) Optional: How to wear the heart rate sensor (movie format) Perform measurement Set up the STEALTH evo+ from a PC...
- Page 5 Operation of buttons Set up the STEALTH evo+ by operating the buttons as follows. Check the button position before you start setting up. (Power) MENU MODE Next...
- Page 6 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Power ON Power ON Power ON Pressing and holding the button on the back of the STEALTH evo+ for 2 seconds turns on the power, and the Formatting operation screen lights up.
- Page 7 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Formatting operation Power ON Press the MENU button on the back of the STEALTH evo+ and the AC button simultaneously. Formatting operation After all screen items light up, the display will be changed to the speed unit setting screen, and setup will start.
- Page 8 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the speed unit Power ON When the MODE button is pressed, either “km/h” or “m/h (mile)” is selected for the speed unit display. Formatting operation Select the display of your choice. Press the MENU button to go to the next step “Selecting Setting the speed unit the time zone”.
- Page 9 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Pairing (Searching the sensor ID) Power ON When using the ANT+ sensor, it is necessary to perform pairing with the STEALTH evo+. When not using, pairing Formatting operation is not required. Click on either button and follow the steps below.
- Page 10 Return to Contents Quick Start Manual Setting up the STEALTH evo+ I do not have an ANT+ sensor Power ON Pairing is not required. Press the MENU button 5 times to jump to the next step “Setting the time zone”. Formatting operation Setting the speed unit Pairing...
- Page 11 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the time zone Power ON Power ON Select the code for the city nearest from your current location, while viewing the “Time zone list”. Formatting operation Formatting operation When the MODE button is pressed, the city code chang- es.
- Page 12 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the daylight saving time Power ON Power ON Change ON/OFF according to the period of daylight sav- ing time, when you are on Daylight Saving Time. Formatting operation Formatting operation Press and hold the MODE button to go to the next step “Setting the clock display format”.
- Page 13 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the clock display format Power ON Power ON When the MODE button is pressed, either “12h” or “24h” is selected for the clock display format. Select the display Formatting operation Formatting operation format of your choice.
- Page 14 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Now, setup of the STEALTH evo+ is completed. Power ON Power ON When the bracket is not attached to your bicycle, return Formatting operation Formatting operation to Contents, click on “How to install the bracket (movie formant)”, and then attach it according to the instruc- Setting the speed unit Setting the speed unit...
- Page 15 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the time zone City Time dif- -11:00 -10:00 -09:00 +08:00 -07:00 -06:00 -05:00 -04:00 -03:00 -02:00 -01:00 -00:00 +01:00 +02:00 +03:00 +04:00 +05:00 +06:00 +07:00 +08:00 +09:00 +10:00 +11:00 +12:00 City name...
- Page 16 Return to Contents Quick Start Manual Setting up the STEALTH evo+ I have an ANT+ sensor Power ON Power ON This unit has 2 different methods for pairing. Formatting operation Formatting operation • Automatic search: The STEALTH evo+ completes pairing by receiving the signal sent from the Setting the speed unit Setting the speed unit ANT+ sensor.
- Page 17 When you perform pairing with “ ISC:1” (Speed/cadence sensor), the dis- play of “CD:1” (Cadence sensor) is skipped. Setting the clock display format Select “ ISC” to pair the CATEYE speed/cadence sensor (ISC-11). GPS search screen Return Next (Setup completed)
- Page 18 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Pairing: Automatic search (2/4) Power ON Power ON Pressing and holding the MODE button changes the value in the lower display, and then automatic search is Formatting operation Formatting operation started.
- Page 19 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Pairing: Automatic search (3/4) Power ON Power ON When the STEALTH evo+ receives the ID signal from the sensor successfully, the ID number is displayed. Formatting operation Formatting operation Press the MENU button to register the setting, and then perform paring for the next sensor.
- Page 20 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Pairing: Automatic search (4/4) Power ON Power ON When you use other sensors, perform pairing in the same procedure. Formatting operation Formatting operation Selecting the sensor To the Setting the speed unit Setting the speed unit next step Pairing...
- Page 21 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Entering the tire circumference Power ON Power ON Enter the tire circumference (mm) of your bicycle with 4 digits in reference to the Tire circumference reference table. Formatting operation Formatting operation Pressing the MODE button increases the value flashing, and pressing and holding the MODE button moves to the...
- Page 22 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the time zone Power ON Power ON Select the code for the city nearest from your current location, while viewing the “Time zone list”. Formatting operation Formatting operation When the MODE button is pressed, the city code display changes.
- Page 23 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the daylight saving time Power ON Power ON Change ON/OFF according to the period of daylight sav- ing time, when you are on Daylight Saving Time. Formatting operation Formatting operation After selecting, press and hold the MODE button to go to the next step “Setting the clock display format”.
- Page 24 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the clock display format Power ON Power ON When the MODE button is pressed, either “12h” or “24h” is selected for the clock display format. Select the display Formatting operation Formatting operation format of your choice.
- Page 25 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Now, setup of the STEALTH evo+ is completed. Power ON Power ON When the bracket is not attached to your bicycle, return Formatting operation Formatting operation to Contents, click on “How to install the bracket (movie formant)”, and then attach it according to the instruc- Setting the speed unit Setting the speed unit...
- Page 26 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Tire circumference reference table Generally, ETRTO or the tire size is indicated on the side of the tire. ETRTO Tire size L (mm) ETRTO Tire size L (mm) ETRTO Tire size L (mm) ETRTO Tire size L (mm)
- Page 27 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the time zone City Time dif- -11:00 -10:00 -09:00 +08:00 -07:00 -06:00 -05:00 -04:00 -03:00 -02:00 -01:00 -00:00 +01:00 +02:00 +03:00 +04:00 +05:00 +06:00 +07:00 +08:00 +09:00 +10:00 +11:00 +12:00 City name...
- Page 28 When you perform pairing with “ ISC:1” (Speed/cadence sensor), the dis- play of “CD:1” (Cadence sensor) is skipped. Setting the clock display format Select “ ISC” to pair the CATEYE speed/cadence sensor (ISC-11). GPS search screen Return Next (Setup completed)
- Page 29 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Pairing: manual ID number entry (2/4) Power ON Power ON Press and hold the MODE button, and then press the MODE button within 3 seconds after the value in the low- Formatting operation Formatting operation er display starts changing.
- Page 30 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Pairing: manual ID number entry (3/4) Power ON Power ON Pressing the MODE button increases the value flashing, and pressing and holding the MODE button moves to the Formatting operation Formatting operation next digit.
- Page 31 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Pairing: manual ID number entry (4/4) Power ON Power ON When you use other sensors, perform pairing in the same procedure. Formatting operation Formatting operation Selecting the sensor To the Setting the speed unit Setting the speed unit next step...
- Page 32 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Entering the tire circumference Power ON Enter the tire circumference (mm) of your bicycle with 4 digits in reference to the Tire circumference reference table. Formatting operation Pressing the MODE button increases the value flashing, and pressing and holding the MODE button moves to the Setting the speed unit next digit.
- Page 33 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the time zone Power ON Select the code for the city nearest from your current location, while viewing the “Time zone list”. Formatting operation When the MODE button is pressed, the city code display changes.
- Page 34 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the daylight saving time Power ON Change ON/OFF according to the period of daylight sav- ing time, when you are on Daylight Saving Time. Formatting operation After selecting, press and hold the MODE button to go to the next step “Setting the clock display format”.
- Page 35 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the clock display format Power ON When the MODE button is pressed, either “12h” or “24h” is selected for the clock display format. Select the display Formatting operation format of your choice.
- Page 36 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Now, setup of the STEALTH evo+ is completed. Power ON When the bracket is not attached to your bicycle, return Formatting operation to Contents, click on “How to install the bracket (movie formant)”, and then attach it according to the instruc- Setting the speed unit tions.
- Page 37 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Tire circumference reference table Generally, ETRTO or the tire size is indicated on the side of the tire. ETRTO Tire size L (mm) ETRTO Tire size L (mm) ETRTO Tire size L (mm) ETRTO Tire size L (mm)
- Page 38 Return to Contents Quick Start Manual Setting up the STEALTH evo+ Setting the time zone City Time dif- -11:00 -10:00 -09:00 +08:00 -07:00 -06:00 -05:00 -04:00 -03:00 -02:00 -01:00 -00:00 +01:00 +02:00 +03:00 +04:00 +05:00 +06:00 +07:00 +08:00 +09:00 +10:00 +11:00 +12:00 City name...
- Page 39 Return to Contents Quick Start Manual How to install the bracket...
- Page 40 Return to Contents Quick Start Manual How to install the speed sensor...
- Page 41 Return to Contents Quick Start Manual How to wear the heart rate sensor...
- Page 42 Return to Contents Quick Start Manual Perform measurement Start measurement Start measurement Pause measurement Stop measurement Important: The following measurements cannot be made in locations where a GPS signal can- not be received: • Displaying altitude and recording route information •...
- Page 43 Return to Contents Quick Start Manual Perform measurement Start measurement Pause measurement Pause measurement Stop measurement If the button is pressed during measurement, STOP is displayed on the screen and measurement is paused. To resume measurement press the button again. Press &...
- Page 44 Return to Contents Quick Start Manual Perform measurement Start measurement Pause measurement Stop measurement Stop measurement To stop measurement, reset measurement Resetting operation data by pressing and holding MODE. All data measured up to the current point in time is created as trip data. For information about uploading trip data, return to the Contents page and watch the MODE...
- Page 45 CATEYE Atlas™ is a website where you can view trips recorded with a STEALTH evo+ or INOU. • The trip (measurement data) loaded using CATEYE Sync™ can be viewed on a map and a graph. • By storing trips, you can use CATEYE Atlas™ as a database of your cycling life.
- Page 46 Return to Contents Quick Start Manual CATEYE Sync™ / CATEYE Atlas™ Click on the item to view. Before use : Setting up your PC Uploading the trip (movie format) View and edit the trip (movie format) Changing settings of the STEALTH evo+ (movie format)
- Page 47 When you have an account: Membership registration is not required. Go to the next step “Installing CATEYE Sync™”. You can use the same account when using CATEYE INOU and having registered membership. When you do not have an account: Return...
- Page 48 Return to Contents Quick Start Manual Setup of your PC Membership registration to CATEYE Atlas™ (2/3) Membership Membership Installing Setting registration to registration to CATEYE Sync™ CATEYE Sync™ Confirm the Terms of Service, and then click on CATEYE Atlas™(2/3) CATEYE Atlas™...
- Page 49 Be sure to enter the required items. Entering the registration form Confirm the registration, and then click on Now, your membership registration is completed. After your membership registration is completed, go to the next step “Installing CATEYE Sync™”. Confirming the registration Return Next...
- Page 50 Membership Installing Installing Setting registration to registration to CATEYE Sync™ CATEYE Sync™ CATEYE Sync™ Click on the banner of CATEYE Sync™ from the top CATEYE Atlas™ CATEYE Atlas™ (1/2) page of CATEYE Atlas™. The download page will open. Return Next...
- Page 51 CATEYE Sync™ will start being downloaded. Double-click on the execution file downloaded. Install CATEYE Sync™ according to the instruction displayed on the screen. After CATEYE Sync™ is installed, go to the next step “Setting CATEYE Sync™”. Download for Windows version...
- Page 52 CATEYE Sync™ CATEYE Sync™ CATEYE Sync™ Start CATEYE Sync™. CATEYE Atlas™ CATEYE Atlas™ (1/2) Double-click the shortcut [CATEYE Sync™] to start CATEYE Sync™. CATEYE Sync™ icon Click on [Q Series / STEALTH] The menu screen appears. Starting CATEYE Sync™ Return...
- Page 53 Login setting of CATEYE Sync™ is completed. Now, setup of your PC is completed. Enter your e-mail address and password Return to the contents of CATEYE Sync™/Atlas™ and see “Uploading, editing and sharing the trip” and “Changing settings of the STEALTH evo+”.
- Page 54 Return to Contents Quick Start Manual Uploading the trip...
- Page 55 Return to Contents Quick Start Manual View and edit the trip...
- Page 56 Return to Contents Quick Start Manual Changing settings of the STEALTH evo+...
