SERVICE MANUAL FM/MW/LW/RDS CD Receiver TILT TO ALPINE Home Page 5 / 04-A 68E36533S01 CDA-9835R...
Page 2
<Cautions for Safe Repair Work> The following cautions will prevent accidents in the workplace and will ensure safe products. *The symbols indicate caution is needed to prevent injuries and damage to property. The symbols and their meanings follow. If you ignore this symbol and handle the product incorrectly or unsafely, Warning serious injury or death may result.
Page 3
CDA-9835R Contents Packing Assembly Parts List Packing Method View Specifications 5 , 6 Extension Cable Adjustment Procedures 8 to 11 Block Diagram Parts Layout on P.W.Boards and Wiring Diagram 13 to 18 Schematic Diagram 19 to 28 Terminal Voltage of IC/ TR...
CDA-9835R Packing Assembly Parts List Symbol Description Symbol Description Part No. Part No. 101-1 03S60820Y16 SCR,MCH 5X8 ZN A 15D00529K02 CASE,INNER 101-2 03S60824Y01 SCR,WEV 1.7X4 ZN A 15D01798K03 CARRYING,CASE 101-3 60T55630W01 BAT,MGN R03(NB)UM-4 01T45518Y04 ASSY,REMOCON RUE4187 101-4 01T04296K01 ISO/JASO ANT ADAPTER...
CDA-9835R Extension Cable * When repairing or measuring the voltage of this unit, connect with the Extension Cable as shown in below. MAIN P.W.Board CB511 DP23S27R 01E36492S01 01E29154S01 CH4001 TO CONTENTS - 7 - - 7 -...
Page 9
CDA-9835R (3) Control Settings Power Switch ..........ON Band Switch ......FM/MW/LW Fader Control ......Center Position T-CORR ........Non Effect Balance Control ....... Center Position ............FLAT Treble Control ......Center Position DEMO ........... OFF Bass Contro ......Center Position Others ...........
Page 10
CDA-9835R Test Point / Step Description Connection Signal Generator Dial Control P .W.Board Adjustment Coordinates TP012 Auto Adjustment : 216kHz , (3-E) After setting up of Signal Genarator, 34dBµ 216kHz TP011 short GND and TP011 (Pull-Down) (Mod. OFF) (3-E) for 2~3 seconds.
Page 11
CDA-9835R Test Point / Step Description Connection Signal Generator Dial Control P .W.Board Adjustment Coordinates Set up of Adjustment Mode : — — — Push SOURCE/POWER + UP at the same time. 98.1MHz, Rotary encoder is turned and noise level...
Page 37
CDA-9835R Description of IC Terminal D78F4216AGC : IC001 Symbol Terminal Description IF MUTE IF MUTE control terminal. (H:IF MUTE ON) No connect terminal. RDS data input prevention control terminal of adjoining station. RDS-CONT (H:RDS OFF) IF MUTE(NC) No connect terminal.
Page 38
CDA-9835R Symbol Terminal Description MARKET1 Area set up terminal. MARKET2 MARKET3 AUTOADJ Auto adjustment start signal terminal of FM/AM TUNER. (L:start) No connect terminal. GND terminal. No connect terminal. Power supply terminal. No connect terminal. PAUSE Audio signal detect terminal. (L:Blank) DAVN Data available input terminal of RDS Decoder.
Page 39
CDA-9835R Symbol Terminal Description BUS-IN Ai-NET BUS signal input terminal. CD RST System RESET output terminal to CD u-COM. CD STBY Active stand-by request signal output terminal to CD u-COM. No connect terminal. BUS IN Ai-NET BUS signal input terminal.
Page 40
CDA-9835R Symbol Terminal Description No connect terminal. CD FIN Frame input terminal. CD FOUT Frame output terminal. REG RESET RESET signal output terminal to system Regulator IC. RDS RST RESET control signal output terminal to RDS u-COM. T-MUTE A-MUTE signal input terminal from RDS u-COM.
Page 41
CDA-9835R Symbol Terminal Description SEG-SEL ROM selection terminal. Vpp terminal at writing program. Outernal ROM address BUS terminal. RESET System RESET input terminal. SUB X-IN(PULL-DOWN) Pull-down connect terminal. SUB X-OUT (PULL-DOWN) REGC Capacitor connect terminal for regulator. MAIN X-OUT Crystal connect terminal. (20MHz) MAIN X-IN GND terminal for clock.
Page 42
CDA-9835R Symbol Terminal Description Outernal ROM address terminal. Avdd Power supply terminal for AD Converter. Avss GND terminal for AD Converter. Avref Standard voltage input terminal for AD Converter. NC(PULL-DOWN) Pull-down connect terminal. Key-IN terminal. MODEL MODEL terminal. ENCODER2 ENC-OUT (self return) terminal.
Page 43
CDA-9835R TMS320DA150PGE160 : IC101 Symbol Terminal Description CVSS GND connect terminal. External program address terminal. CVSS GND connect terminal. DVDD Power supply terminal. (+3.3V) External program address terminal. Load-Motor2 LOAD motor control terminal. External program address terminal. CVDD Power supply terminal. (+1.6V) HAS(PULL-DOWN) Pull-down connect terminal.
Page 44
CDA-9835R Symbol Terminal Description SSEL BCLK output signal terminal. PF-BUS2 communication SCK signal terminal. CVSS GND connect terminal. (+1.6V) HINT(PULL-DOWN) Pull-down connect terminal. CVDD Power supply terminal. (+1.6V) MSEL LRCLK output signal terminal. (LR polarity, SMCK fixation) EPF-BUS2 communication CS signal terminal.
Page 45
CDA-9835R Symbol Terminal Description X1(NC) No connect terminal. Clock connect terminal. DSP RESET EPF-BUS2 communication RESET signal terminal. I/O External program data terminal. External program address terminal. DVSS GND connect terminal. External program address terminal. CVSS GND connect terminal. DVDD Power supply terminal.
Page 46
CDA-9835R Exploded View (Cabinet) (1/2) SW4027 ET200 CH4001 OELD1 ET200 CH350 ANT001 JK202 CB801 DIN501 M802 JK601 SW603 SW602 CH511 NOTE : The place of the connection of (L) as shown in ( ), is mentioned in the "Exploded View (Cabinet) (2/2)."...
Page 47
CDA-9835R Exploded View (Cabinet) (2/2) CH831 117 X2 M831 NOTE : The place of the connection of (L) as shown in ( ), is mentioned in the "Exploded View (Cabinet) (1/2)." ..point of GREASE applied. GREASE,E-PAST ( 11S42419J09 ) GREASE,G-8007 ( 11S41558Y01 )
Page 48
Exploded View (CD Deck Mechanism) CDA-9835R (DP23S27R) TO PARTS LIST TO CONTENTS - 54 - - 54 -...
CDA-9835R Electrical Parts List * Each parts on P.W.Board are described in order of the reference number. =======MAIN P.W.Board BZ601 50T15447Y02 BUZZER,PKM13EPY -R5 C001 08S45677W60 CAP,CER 102J-CH1H-CP C003 08S45677W07 CAP,CER.5R0C-CH1H-CP C004 08S45677W12 CAP,CER.10RD-CH1H-CP C006 08S45676W89 CAP,CER 473K-B1E -CP C007 08S45676W80...
CDA-9835R Cabinet Assembly Parts List NOTE : The part that has not PART NUMBER will not be supplied. 01V74900Y89 ASSY,NOSE UNIT 35RT - - - - - - - - - - - COVER,TOP - - - - - - - - - - -...
Page 78
CDA-9835R CD Deck Mechanism Assembly Parts List NOTE : The part that has not PART NUMBER will not be supplied. 01V31800Y79 ASSY,ARM GUIDE 27C11557Y02 CHASSIS,TOP 45B11564Y02 LEVER,LINK-TOP 45B11595Y02 LEVER DISC(R) 45B11596Y02 LEVER,DISC(L) 41B11613Y16 SPRING,PULL 15D50248Y02 GUIDE,TOP-DPS2 07C50608Y01 BKT,MOTOR LOAD-P 03S40014G07...
