Electrolux Washing machine Service Manual

Washing machines with ewm 1000 plus electronic control system and “delta 3” display board
Hide thumbs Also See for Washing machine:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , User Manual

SERVICE MANUAL

WASHING
Washing machines with
EWM 1000 PLUS
electronic control system
 ELECTROLUX HOME PRODUCTS
and
ITALY S.p.A.
"Delta 3" display board
Publication no.
Spares Operations Italy
Corso Lino Zanussi, 30
With sensor
I - 33080 PORCIA /PN
599 37 22-15
Fax +39 0434 394096
EN
Production ZP (Porcia-Italy)
Edition: 2005-07-21

Advertisement

Table of Contents
loading

Related Manuals for Electrolux Washing machine

Summary of Contents for Electrolux Washing machine

  • Page 1: Service Manual

    SERVICE MANUAL WASHING Washing machines with EWM 1000 PLUS electronic control system  ELECTROLUX HOME PRODUCTS ITALY S.p.A. “Delta 3” display board Publication no. Spares Operations Italy Corso Lino Zanussi, 30 With sensor I - 33080 PORCIA /PN 599 37 22-15...
  • Page 2 SOI/DT 2005-07 dmm 2/59 599 37 22 15...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PURPOSE OF THIS MANUAL ........................5 PRECAUTIONS ............................5 GENERAL CHARACTERISTICS........................ 5 CONTROL PANEL............................6 “Fabrics” Button............................ 6 “Temperature” Button ........................... 7 “Spin” Button ............................7 Description of the “options” ........................8 Description of options......................... 10 4.5.1 Night cycle ...........................
  • Page 4 6.15.8 Intermediate spin (cotton/linen) C2 ................... 31 6.15.9 Final spin (cotton/linen) COT_CF ....................31 6.15.10 Intermediate and final spin (synthetics) SYN_CF..............31 6.15.11 Final spin (delicate fabrics) DEL_ CF..................32 6.15.12 Final spin (wool and hand wash) WOOL_CF ................32 6.15.13 Impulse spin for easy-iron programmes ..................

  • Page 5: Purpose Of This Manual

    1 PURPOSE OF THIS MANUAL The purpose of this manual is to provide service engineers who are already familiar with the repair procedures for traditional washing machines with information regarding appliances fitted with the EWM 1000 plus electronic control system and produced in Porcia (Italy). The EWM1000 plus electronic control system consists of a main electronic board and one control/display board, “Delta 3”...

  • Page 6: Control Panel

    4 CONTROL PANEL The configuration of the control panel depends on the following: Type of control/display board Design of the control panel ( max.9 buttons, LEDs) Different configuration of the buttons “FABRICS” Button “TEMPERATURE” Button “SPIN” Button “OPTIONS” Button “OPTIONS” Button “OPTIONS”...

  • Page 7: Temperature" Button

    4.2 “Temperature” Button Pushing this button in sequence the temperature is increased or decreased (if a temperature different from that set by the appliance is desired); the relative LED lights. The maximum temperature is 90°C for Cotton, 60°C for Synthetics, 40°C for Delicates, Wool and Hand wash.

  • Page 8: Description Of The Options

    4.4 Description of the options The number and type of buttons vary according to the configuration of the model. Possible options according the selected programme OPZIONI 90°C 60°C 50°C COTTON 40°C 30°C Cold 60°C 50°C SYNTHETICS 40°C 30°C Cold MINI PROGRAMME 30°C 40°C DELICATES...
  • Page 9 Compatibility with options OPTIONS RINSE HOLD NIGHT CYCLE PREWASH SOAK STAINS INTENSIVE DAILY SHORT ECONOMY SENSITIVE EXTRA RINSE BLEACH HALF-LOAD EASY-IRON REDUCED SPIN SPEED NO SPIN PRESELECTION PREWASH WASH RINSES SPIN The table below shows other limitations in the compatibility of the options according to the type of drawer type and number of solenoid valves.

  • Page 10: Description Of Options

    4.5 Description of options 4.5.1 Night cycle Eliminates all spin phases and adds three rinses in COTTON cycles and two rinses in SYNTHETICS cycles. Stops the appliance with water in the tub before the final rinse. Switches off the buzzer (if configured) To drain the water, select a drain or spin cycle.

  • Page 11: Sensitive

    4.5.10 Sensitive Adds one rinse in the COTTON – SYNTHETIC FABRICS cycles. During the cotton cycles the movements pass from vigorous to normal. Eliminates the intermediate spins except from the last two which are ar reduced speed. 4.5.11 Bleach Ducts water through the bleach compartment at the beginning of the first rinse in COTTON cycles. Pre-wash is possible only if there are three solenoids.

  • Page 12: Temperature Adjustment

    4.5.18 Temperature adjustment Used to select the washing temperature compatibly with the limit temperature for the cycle. Can be used during the cycle selection phase: the temperature can be modified only if the heating phase has not started (in pause mode) 4.5.19 Extra rinse Adds two rinses in the COTTON, SYNTHETICS and DELICATES cycles.

  • Page 13: Start/Reset" Button

    4.8 “START/RESET” Button This button performs two functions: • Cancels the programme: Press the button until the cycle LEDs switch off. The display will show three flashing hyphens. • Selects special programmes: In the programme selection and execution phases, this button can be used to cancel certain phases of the programme so that the appliance effectively performs a special cycle.

  • Page 14: Display (Some Models)

    4.9 Display (some models) The display shows the following information: Three flashing hyphens, when a programme is cancelled by pressing the SKIP/RESET button. The hyphens will also be displayed when the ON/OFF button is pressed to switch the appliance on, but only if the cycle selected previously has been cancelled.

  • Page 15: On/Off Button

    4.11 ON/OFF Button Press the ON/OFF button to switch the appliance ON. The display shows three flashing hyphens or a flashing zero. Press the same button to switch the appliance OFF. The ON/OFF button is an individual pushbutton, and is not part of the display board.

  • Page 16: Washing Programmes

    5 WASHING PROGRAMMES The washing programmes and the functions of each button vary for the different models since they are determined by the configuration of the appliance. 5.1 Possible programmes The washing programmes can be configured: the basic programmes are listed in the table below. Programme Temperature (°C) No.

  • Page 17: Washing Programmes

    6 WASHING PROGRAMMES 6.1 Basic programmes for Cotton / Linen: cold – 30-40-60-90 (without options) for G17/18/19/20/22 Phase Function Time/control Movement Heating°C Notes Delay Delayed start Delay time No movement VAE + 2”+ Drain No movement 6” pause Water fill P1 + QPW1 (*) D55 from full Cold wash...

  • Page 18: Cotton / Linen Cycles: 90 Eco, 60 - 40/50 "Energy Label" (Without Options) For G17

    6.2 Cotton / Linen Cycles: 90 Eco, 60 - 40/50 “energy label” (without options) for G17 Heating °C Phase Function Times/Controls Movement Note Delay Delayed start Delay Time No Movement VAE + 2”+ Drain No Movement 6” pause Water fill P1 + QPW1 (*) D55 from full Cold wash...

  • Page 19: Cotton / Linen Cycles: 90 Eco, 60 - 40/50 "Energy Label" (Without Options) For G18

    6.3 Cotton / Linen Cycles: 90 Eco, 60 - 40/50 “energy label” (without options) for G18 Phase Function Times/Controls Movement Heating °C Note Delay Delayed start Delay Time No movement VAE + 2”+ Drain No movement 6” pause Water fill P1 + QPW1 (*) D55 from full Cold wash...

  • Page 20: Cotton / Linen Cycles: 90 Eco, 60 - 40/50 "Energy Label" (Without Options) For G19

    6.4 Cotton / Linen Cycles: 90 Eco, 60 - 40/50 “energy label” (without options) for G19 Heating °C Phase Function Times/Controls Movement Note Delay Delayed start Delay Time No movement VAE + 2”+ Drain No movement 6” pause Water fill P1 + QPW1 (*) D55 from full Cold wash...

  • Page 21: Cotton / Linen Cycles: 90 Eco, 60 - 40/50 "Energy Label" (Without Options) For G20-5Kg-6Kg

    6.5 Cotton / Linen Cycles: 90 Eco, 60 - 40/50 “energy label” (without options) for G20-5Kg-6KG Phase Function Times/Controls Movement Heating °C Note Delay Delayed start Delay Time No movement VAE + 2”+ Drain No movement 6” pause Water fill P1 + QPW1 (*) D55 from full Cold wash...

  • Page 22: Cotton / Linen Cycles: 90 Eco, 60 - 40/50 "Energy Label" (Without Options) For G22-6Kg-7Kg

    6.6 Cotton / Linen Cycles: 90 Eco, 60 - 40/50 “energy label” (without options) for G22-6KG-7Kg Riscal. °C Phase Function Times/Controls Movement Note Delay Delayed start Delay Time No movement Drain VAE + 2”+ 6” pause No movement Water fill P1 + QPW1 (*) D55 from full Cold wash...

  • Page 23: Basic Programmes For Synthetic Fabrics: Cold - 30°- 40° - 50° - 60° (Without Options)

    6.7 Basic programmes for synthetic fabrics: cold – 30°- 40° – 50° - 60° (without options) Heating °C Phase Function Times/Controls Movement Note Delay Delayed start Delay Time No movement VAE + 2”+ Drain No movement 6” pause Water fill P1 + QPW1 (*) D 55 from full Cold wash...

  • Page 24: Basic Programmes For Delicates: Cold - 30° - 40° (Without Options)

    6.8 Basic programmes for delicates: cold – 30° - 40° (without options) Phase Function Times/Controls Movement Heating °C Note Delay Delayed start Delay Time No movement VAE + 2”+ Drain No movement 6” pause Water fill P1 + QPW1 (*) D55 from full Cold wash 5’...

  • Page 25: Wool Programme: Cold - 30° - 40

    6.9 Wool programme: cold - 30° - 40° Heating °C Phase Function Times/Controls Movement Note Delay Delayed start Delay Time No movement VAE + 2”+ Drain No movement 6” pause Water fill (wool) P1 + Qwo (*) Cold wash 1’ Refill:P1+Qwo1(*) Pwl_1 from full Heating...

  • Page 26: Hand-Wash Programmes: Cold - 30° - 40

    6.10 Hand-wash programmes: cold - 30° - 40° Phase Function Times/Controls Movement Heating °C Note Delay Delayed start Delay Time No movement VAE + 2”+ Drain No movement 6” pause Water fill P1 + Qwh (*) No movement Cold wash 1’...

  • Page 27: Jeans Wash Programmes: 40° - 60

    6.11 JEANS Wash programmes: 40° - 60° Heating °C Phase Function Times/Controls Movement Note Delay Delayed start Delay Time No movement VAE + 2”+ Drain No movement 6” pause Water fill P1 + Qpw (*) No movement Cold wash 5’ Refill:P1(*) Water fill Qpw2(*)

  • Page 28: Duvet Wash Programmes

    6.13 DUVET Wash programmes Heating °C Phase Function Times/Controls Movement Note Delay Delayed start Delay Time No movement Drain VAE + 8” No movement Water fill P1+140” No movement WASH compartment Cold wash 5’ Refill P1(*) Heating Programme T° Maintenance 5’...

  • Page 29: Silk Wash Programmes

    6.14 SILK Wash programmes Heating °C Phase Function Times/Controls Movement Note Delay Delayed start Delay Time No movement Drain VAE + 8” No movement Water fill P1+Qdw1(*) WASH compartment Cold wash 1’ Refill Qdw2(*) Heating Programme T° Maintenance 5’ Programme T° Drain VAE +14”...

  • Page 30: Drum Movements - Low Speeds And Spin

    6.15 Drum movements - low speeds and spin 6.15.1 Delicate movement D55 6.15.2 Normal movement N55 N 55 6.15.3 Vigorous movement E55 E 55 6.15.4 Delicate movement PWL_1 (wool) PWL_1 6.15.5 Delicate movement PWL_4 (hand wash) PWL_4 6.15.6 Spin Pre-wash (cotton/linen, synthetics) - C0 intermediate (synthetics) C0 (Pre-wash) sec.

  • Page 31: Wash Spin (Cotton/Linen) C1

    6.15.7 Wash spin (cotton/linen) C1 C1 (Wash) FUCS FUCS imp FUCS 6.15.8 Intermediate spin (cotton/linen) C2 C2 (intermediate) FUCS FUCS imp FUCS 1000 6.15.9 Final spin (cotton/linen) COT_CF COT_CF (final cotton) FUCS FUCS imp FUCS 1000 1150 1400 6.15.10 Intermediate and final spin (synthetics) SYN_CF SYN_CF (intermediate/final) FUCS...

  • Page 32: Final Spin (Delicate Fabrics) Del_ Cf

    6.15.11 Final spin (delicate fabrics) DEL_ CF CF (final delicates) FUCS FUCS imp FUCS 6.15.12 Final spin (wool and hand wash) WOOL_CF CF (final wool) FUCS FUCS imp FUCS 1000 6.15.13 Impulse spin for easy-iron programmes EASY_IRON_IMP FUCS FUCS FUCS FUCS 6.15.14 Intermediate spin for super-rinse options (cotton/linen) CSR FUCS...

  • Page 33: Control Of Water Level In Tub

    Notes: indicates if antifoam function is active FUCS antiunbalance function before spin phase variable duration • In the diagrams the speed is indicated as rotations per minute and the time in seconds 6.16 Control of water level in tub The water fill is carried out in two phases: •...

  • Page 34: Time Water Fill

    6.16.1 Time water fill G21/2 Type Description of time fill litres litres litres litres Levels for COTTON/LINEN Qpw1 First prewash water fill (all cycles) Qpw2 Prewash water fill after cold wash (all cycles) Normal water fill/half load Qhl2 Half load water fill for “VERY SHORT” cycle Water fill for “energy label”...

  • Page 35: Technical Characteristics

    7 TECHNICAL CHARACTERISTICS 7.1 EWM1000 Plus Electronic control The EWM1000 Plus electronic control consists of a main PCB (1) and a control/display board (2). 7.1.1 Functions of the circuit board DISPLAY BOARD µP Buzzer Display LEDs Buttons ELECTRICAL µP SENSORS LOADS MAIN PCB The circuit board receives signals relative to the cycle settings via the control/display board.

  • Page 36: Power Supply And Programme Selection

    7.2 Power supply and programme selection The main board (3) is powered by the interference suppressor (1) and by the closure of the contacts of the main switch (2). The connectors used are J6-2 (neutral) and J10-1 (line). The control/display board (4) is powered at 5V by the main board: the buttons can therefore be used for selection of the programmes and the options.

  • Page 37: Instantaneous Door Interlock

    7.3.2 Instantaneous door interlock 1. Suppressor 2. Main switch (button or programme selector) 3. Door interlock 4. Main PCB 5. Door locked pilot lamp • Operating principle When the appliance is switched on, the ON/OFF switch closes and the bi-metal PTC (contact 4-2) is powered;...

  • Page 38: Pressure Switch

    7.4 Pressure switch Control of the water level is performed by a two or three-level pressure switch which functions as follows: • contact 11-14: anti-boiling safety level • contact 21-24: first level • contact 31-32: anti-overflow safety level (not all models) 7.4.1 Pressure switch settings Full (mm)

  • Page 39: Water Fill System

    7.6 Water fill system The solenoid valves are powered by the PCB via two or three triacs. The status of the pressure switch (empty/full) is detected by two “sensing” lines”. Anti-boiling level 1st level Pre-wash solenoid 5. Wash solenoid 6. Bleach solenoid (certain models only) 7.

  • Page 40: Drain Pump

    7.7 Drain pump 1. PCB 2. Anti-boiling pressure switch 8. Drain pump AB_S Anti-boiling level sensor The PCB powers the drain pump via a triac as follows: for a pre-determined period. until the anti-boiling pressure switch closes on EMPTY, after which the pump is actioned for a brief period or passes to the subsequent phase 7.8 Anti-flooding device 1.

  • Page 41: Aqua Control (Certain Models Only)

    Aqua Control (certain models only) The Aqua Control system is a sensor located in contact with the base frame. The sensor detects water leaks inside the machine (not only during normal operation, but also when the unit is off and plugged in) and starts the drain pump if a leak occurs.

  • Page 42: Heating

    7.10 Heating Anti-boiling pressure switch 1st level pressure switch Heating element NTC temperature sensor Relay AB_S Anti-boiling level sensor L1_S 1st level sensor The heating element is powered by a relay on the main PCB via the contacts of the pressure switch when closed on FULL.

  • Page 43: Motor

    7.11 Motor 1. PCB 2. Motor 3. Anti-boiling/anti-foam pressure switch M = rotor P = motor safety cut-out S = stator T = tachimetric generator AB_S Anti-boiling/anti- foam level sensor 7.12 Power supply to motor The main PCB powers the motor via a triac. The direction of rotation is reversed by switching of the contacts on the two relays (K2-K3), which modify the connection between the rotor and the stator.

  • Page 44: Fucs" (Fast Unbalance Control System)

    7.14 “FUCS” (Fast Unbalance Control System) ( Fast Unbalance Control System) The control procedure for unbalanced loads is performed dynamically, before each spin cycle, as follows: The phase begins at a speed of 55 rpm; the speed can never fall below this threshold, otherwise the check is repeated.
  • Page 45 • Balancing in the longest available interval Phase Unbalancing index Time-out (sec) • Unbalancing after all phases In this case the spin (or impulse) is not performed. SOI/DT 2005-07 dmm 45/59 599 37 22-15...

  • Page 46: Demo Mode

    8 DEMO Mode A special cycle has been created for demonstration of the operation of these appliances in retail outlets without connecting the appliance to the water supply. In this way, the salesman can select any programme; after starting the cycle by pressing START, the appliance will perform certain phases only, and will skip those which cannot be performed (water fill, drain, heating).

  • Page 47: Diagnostics System

    9 DIAGNOSTICS SYSTEM 9.1 Access to diagnostics system Using a single procedure, it is possible to access to the diagnostics system. After accessing this function, the following operations can be performed: control of the operation of each of the components in the appliance read / cancel the alarms The diagnostics cycles are available only if the communication between the main PCB and the display board is correct;...
  • Page 48 Diagnostics phases Displayed Components actioned Operating conditions Function checked parameters All the LEDs light in sequence. When a button is Operation of the Button pressed, the corresponding Always activated user interface codification LED lights (and the buzzer, if featured, sounds) Door locked Water level below Water ducted...

  • Page 49: Display Board Diagnostics

    9.2.1 Display board diagnostics After entering the diagnostics system, the display board is checked: all LEDs and the display light in sequence (if featured). Pressing the buttons the corresponding LEDs light; the display shows the relative code to the codification of the button and the buzzer sounds. When the “FABRICS”...

  • Page 50: Alarms

    10 ALARMS 10.1 User alarm display Control of the alarm system can be configured; according to the model, therefore, some or all of the alarms may be displayed to the user. Normally all the alarms are displayed to the user except for: E61 (insufficient heating during the washing phase), The alarms are active during the execution of the washing programme;...

  • Page 51: Reading The Alarm Codes

    10.2 Reading the alarm codes In order to read the last alarm code memorized in the EEPROM on the PCB: • Enter diagnostics mode • Press the Fabrics (1) or Temperature (2) button until LED L10 lights 10.2.1 Displaying the alarm The alarm is displayed by a repeated flashing sequence of the two LEDs (0.4 seconds lit, 0.4 seconds off, with an interval of 2.5 seconds between sequences).

  • Page 52: Operation Of Alarms During Diagnostics

    10.2.3 Operation of alarms during diagnostics All alarms are enabled during the components diagnostics phase. Moving the selector to pass from one control phase to the other, the appliance exits the alarm condition and performs the selected phase (if the alarm does not occur again).

  • Page 53: Table Of Alarm Codes

    10.6 Table of alarm codes Alarm Description Possible fault Action/machine status Reset Tap closed or mains pressure insufficient; drain hose incorrectly Difficulties in water fill for washing positioned; water fill solenoid faulty; leaks from the hydraulic circuit of Cycle paused with door closed Start the pressure switch;...
  • Page 54 Cycle blocked, door locked (after 5 Motor relay contacts sticking PCB faulty; current leakage from motor or from wiring OFF/reset attempts) Insufficient heating during washing NTC sensor faulty; heating element faulty; wiring faulty; PCB faulty. The heating phase is skipped Safety drain cycle –...

  • Page 55: Operating Time Counter

    11 Operating time counter It is possible to display, with a specific procedure, the operating time of the appliance, which is counted from the first switching on. This option is available only in models with display. The maximum memorization capacity is 6550 operating hours.

  • Page 56: Basic Circuit Diagram

    12 BASIC CIRCUIT DIAGRAM 12.1 Without Aquacontrol SOI/DT 2005-07 dmm 56/59 599 37 22 15...

  • Page 57: Key To Circuit Diagram

    12.2 Key to circuit diagram Components in the appliance Components of the PCB 1. Electronic board 2. Suppressor BELV_TY Bleach solenoid Triac 3. ON/OFF switch DOOR_TY Door interlock Triac 4. ON/OFF pilot lamp DRAIN_TY Drain pump Triac 5. Door interlock Heating element relay 6.

  • Page 58: With Aquacontrol

    12.3 With Aquacontrol SOI/DT 2005-07 dmm 58/59 599 37 22 15...

  • Page 59: Key To Circuit Diagram

    12.3.1 Key to circuit diagram Components in the appliance Components of the PCB 1. Electronic board 2. Suppressor BELV__TY Bleach solenoid Triac 3. Drain pump DOOR_TY Door interlock Triac 4. Aqua control DRAIN_TY Drain pump Triac 5. Anti-boiling pressure switch Heating element relay 6.
