CABINET LINER AND DOOR PARTS
Illus.
Part
No.
No.
DESCRIPTION
1
Literature Parts
2313820 Use & Care Guide
2324311 Service &
Wiring Sheet
2
3400886 Screw 8−18 x 1 1/4
3
2208354 Bin, Door
4
2185678 Spacer
5
2217394 Cover, Wiring
6
489442 Screw
7
2208352B Panel, Exterior
8
2217298 Panel, Interior
10
2208377 Insulation
11
2217227 Ballast−Back, I.M.
12
941839 Hole Plug
13
Bracket, Door
2217466 (Left Side)
2217465 (Right Side)
14
489503 Clamp
15
2217295 Gasket, Door
16
2208535 Clip
17 W10046610 Nameplate
18
Hinge
2208425 (Left Side)
2208426 (Right Side)
19
2208401 Shim, Hinge
For Models: KUIC18PNTS1
(Stainless Steel)
Illus.
Part
No.
No.
DESCRIPTION
20
2208452B Handle, Icemaker
21
9872207S Handle, Bar
22 W10136200 Assembly,
Unit Cover
23
8281186 Screw, Handle
24
2208595B Grommet, Edge
Guard(2)
25
2217225 Pad, Foam
26
2185691 Channel, Wiring
27
2208350B Endcap, Door
28
2208459 Tube, Drain
29
2208386 Scoop
30
3400884 Screw 8−18 x 5/8
31
692400 Nut, Push−In
32
2208382B Panel, Wrap Lower
33
2208487 Bracket, Spring
34
2208417 Pin, Hinge
35
489048 Screw, Ground
36
2208570 Spring, Hinge
37
2208383B Endcap, Panel
38
2208530 Dampener, Spring
39
489423 Screw
40
2208449 Holder, Scoop
41
2208596B Grommet, Edge
guard(2)
2
Illus.
Part
No.
No.
DESCRIPTION
42
3374849 Leg, Leveler (4)
43
2208384 Insulation
44
2929701B Top
45
2185690 Shield, Electrical
46
2217296 Gasket, Top Panel
47
2217206B Grill, Front
48
489474 Screw 8−18 x 1
49
Cabinet & Liner
(NOT SERVICED)
50
2313817 Panel, Wrap
51
2208594S Panel, Lower
52
3400240 Nut,
Leg Leveler
53
2208434 Strike, Magnet
54
3400916 Washer
55
8281191 Screw
56
3400237 Screw
(Handle Bar)
57
8281184 Screw
58
488208 Screw
59
2217467 Tube−Vent
60
2208367 Clamp−Half
61
8281265 Screw
62
489505 Clamp
W10165874
