Operation & Installation Manual
Rinnai Instantaneous Water Heater
Model - IHF10
This appliance shall be installed in accordance with:
• Manufacturer's Installation Instructions
• Current AS/NZS 3500 & AS/NZS 5601
• Local Regulations and Municipal Building Codes including local OH&S requirements
This appliance must be installed, maintained and removed by an Authorised Person.
For continued safety of this appliance it must be installed operated and maintained in
This Appliance complies
All Rinnai gas products
with AS 3498:2009
accordance with the manufacturers instructions.
are A.G.A. certified.
AGA LIC. 60089
This appliance is not suitable for use as a pool heater.

Advertisement

Table of Contents
loading

Summary of Contents for Rinnai IHF10

  • Page 1 Operation & Installation Manual Rinnai Instantaneous Water Heater Model - IHF10 This appliance shall be installed in accordance with: • Manufacturer’s Installation Instructions • Current AS/NZS 3500 & AS/NZS 5601 • Local Regulations and Municipal Building Codes including local OH&S requirements This appliance must be installed, maintained and removed by an Authorised Person.
  • Page 2 This page is intentionally blank. Rinnai Australia Operation Manual...
  • Page 3: Table Of Contents

    WARNING ABOUT HOT WATER....................1 FEATURES AND BENEFITS....................... 2 IMPORTANT INFORMATION ...................... 3 OPERATION ..........................4 DELIVERY TEMPERATURE........................4 WATER FLOW AND TEMPERATURE ADJUSTMENT ................5 TROUBLESHOOTING ......................... 6 MAINTENANCE............................6 INSTALLATION ........................... 8 CONTACT INFORMATION ....................... 17 Rinnai Australia Operation Manual...
  • Page 4: Regulatory Information

    REGULATORY INFORMATION Your Rinnai Instantaneous water heater has been certified for water, plumbing and gas safety. Certification details are shown on the appliance. This Appliance must be installed correctly by an authorised person. The installation of gas and water must conform to local regulations.
  • Page 5: Features And Benefits

    FEATURES AND BENEFITS Congratulations on purchasing the Rinnai Instantaneous water heating system. • The appliance NEVER RUNS OUT of hot water. Whilst water and gas supplies are connected and available and battery power is available, hot water is delivered whenever hot water taps are open.
  • Page 6: Important Information

    IMPORTANT INFORMATION The range of Rinnai Instantaneous water heaters referred to in this manual are incompatible with solar water heating systems. A dedicated range of solar compatible continuous flow water NOTE heaters is available from Rinnai. At low water flows, the hot water unit may extinguish without Always check water temperature carefully before use.
  • Page 7: Operation

    The delivery temperature set point programmed into the electronic ignition and control module is 60°C. The actual delivery temperature may be lower depending on the prevailing operating conditions, for example, low incoming cold water temperatures and high water flow rates. Rinnai Australia Operation Manual...
  • Page 8: Water Flow And Temperature Adjustment

    For appliances installed in locations where the temperature falls below 0°C for short periods, the installation of an Anti Freezing Relief Valve will minimise the possibility of damage to the appliance. Rinnai Australia Operation Manual...
  • Page 9: Troubleshooting

    MAINTENANCE Rinnai has a Service and Spare Parts network with personnel who are fully trained and equipped to give the best service on your appliance. If your appliance requires service, please call our National Help Line. Rinnai recommend that the appliance be serviced by an authorised person every 2 years.
  • Page 10 This page is intentionally blank. Rinnai Australia Operation Manual...
  • Page 11: Installation

    SERVICE CONNECTION POINTS ........................10 SPECIFICATIONS ........................11 HORIZONTAL FLUE TERMINAL CLEARANCES ..............12 APPLIANCE DIMENSIONS ...................... 13 WIRING DIAGRAM ........................14 COMMISSIONING ........................15 TESTING ................................15 COMMISSIONING CHECK LIST ......................... 15 CONTACT INFORMATION ....................... 17 Rinnai Australia Installation Manual...
  • Page 12: General Installation Instructions

    3. Demonstrating the operation of the appliance to the customer, including water flow rate adjustment. 4. Demonstrating the location of the battery compartment and how to replace the battery. 5. Advising the customer of the need for regular servicing (Rinnai recommends servicing every 2 years). 6. Handing these instructions to the customer.
  • Page 13: Hot Water Delivery Temperature

    Purge gas and cold water supply lines to remove air and swarf before final connection of the appliance. Swarf in either the gas or water supplies may cause damage or malfuntion. These are not covered by warranty. Rinnai Australia Installation Manual...
  • Page 14: Specifications

    Water Pressure Hot & Cold Water Natural Gas Propane Gas Water Pressure For 10L/min. For Operation R 1/2” BSP R 1/2” BSP R 1/2” BSP IHF10 1000 Male Female Male Nominate Gas Inlet Gas Pressure Burner TPP Heating Capacity Model...
  • Page 15: Horizontal Flue Terminal Clearances

    A flue terminal is considered to be a source of ignition. For appliance s not addressed above acceptance should be obtained from the Technical Regulator. FIGURE 6.2 (in-part) MINIMUM CLEARANCES REQUIRED FOR BALANCED FLUE TERMINALS Figure 1. Extract from AS/NZS 5601 Rinnai Australia Installation Manual...
  • Page 16: Appliance Dimensions

    APPLIANCE DIMENSIONS Location of upper rear mounting holes Location of lower rear mounting hole Figure 2. Rinnai Australia Installation Manual...
  • Page 17: Wiring Diagram

    WIRING DIAGRAM MAIN MICROPROCESSOR TEMPERATURE CONTROL MICROPROCESSOR Solenoid Valve 1 Solenoid Valve 2 High Voltage Lead (Ignition) Flame Rod Temperature Overheat Switch (Self-resetting) Modulation Motor Thermistor (Heated water outlet temperature) Micro-switch Figure 3. Rinnai Australia Installation Manual...
  • Page 18: Commissioning

    COMMISSIONING CHECK LIST A commissioning check list is provided on the appliance front cover to enable the installer to step through the correct commissioning procedure when installing a Rinnai Strainer Cap water heater. The check list can also assist the installer to identify potential installation errors that may prevent the appliance from operating correctly.
  • Page 19 INSTALLER NOTES Rinnai Australia Installation Manual...
  • Page 20: Contact Information

    Tel: (03) 9271 6625 Fax: (03) 9271 6622 Rinnai has a Service and Spare Parts network with personnel who are fully trained and equipped to give the best service on your Rinnai appliance. If your appliance requires service, please call our National Help Line. Rinnai recommends that this appliance be serviced every 2 years.
