TURN OFF WATER SUPPLY
1. Close the main water supply valve, near the well
pump or water meter.
2. Open all faucets to drain water from the house
pipes.
NOTE: Be sure not to drain water from the water
heater, as damage to the water heater ele-
ments could result.
MOVE THE CENTRAL WATER FILTRATION
SYSTEM INTO PLACE
Excessive Weight Hazard
Use two or more people to move and install
Central Water Filtration System.
Failure to do so can result in back or other
injury.
1. Move the Central Water Filtration System into instal-
lation position. Set it on a level surface. If needed,
place the unit on a section of plywood, a minimum
of 5/8" thick. Then place shims under the plywood
to level the Central Water Filtration System (see
Figure 8).
2. Remove top cover.
3. Hang cover from post on front of rim, as shown in
Figure 9. Avoid allowing cover to hang from wires.

Installation Instructions

LEVEL IF NECESSARY
Shim(s)
REMOVE TOP COVER AND HANG IT
FROM POST ON FRONT OF RIM
Post
Top Cover
9
Plywood
FIG. 8
FIG. 9
