Do not use the appliance if the plug, the mains cord or other components are damaged. If the mains cord is damaged, you must have it replaced by Philips, a service centre authorised by Philips or similarly qualified persons in order to avoid a hazard.
Place the juice collector onto the appliance and put the filter in the juice collector. Make sure the filter is fitted securely onto the driving shaft (Fig. 3). Always check the filter before use. If you detect any cracks or damage, do not use the appliance. Contact the nearest Philips service centre or take the appliance to your dealer. Push the pulp container against the appliance (‘click’) and put the lid on the appliance. (Fig. 4) Snap the two clamps onto the lid (‘click’). Slide the pusher into the feeding tube. (Fig. 5) Make sure the clamps on either side of the lid are locked into position.
EnglisH If the pulp container becomes full during use, switch off the appliance, carefully remove the pulp container and empty it. Note: Reassemble the empty pulp container before you continue juicing. After you have processed all ingredients and the juice flow has stopped, pour the juice from the jug into the glass. If the foam separator is in the juice jug, the foam is removed from the juice (Fig. 7). Tips Use fresh fruit and vegetables, as they contain more juice. Pineapples, beetroots, celery stalks, apples, cucumbers, carrots, spinach, melons, tomatoes and grapes are particularly suitable for processing in the juice extractor.
Page 9
EnglisH Peel the horseradish with a knife. Juice the horseradish. Note: This appliance can process 3.6kg of horseradish in approx. 2 minutes (not including the time required to remove the pulp). When you juice horseradish, switch off and unplug the appliance and remove the pulp from the pulp container, the lid and the sieve after you have processed 1.2kg.
EnglisH Guarantee & service If you need service or information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Consumer Care Centre in your country (you find its phone number in the worldwide guarantee leaflet). If there is no Consumer Care Centre in your country, go to your local Philips dealer.
