Asus Crossblade Ranger User Manual

Hide thumbs Also See for Crossblade Ranger:
Table of Contents

Advertisement

Quick Links

CROSSBLADE
RANGER

Advertisement

Table of Contents
loading

Related Manuals for Asus Crossblade Ranger

Summary of Contents for Asus Crossblade Ranger

  • Page 1 CROSSBLADE RANGER...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... vi About this guide ......................vii CROSSBLADE RANGER specifications summary ..........ix Package contents ..................... xiii Installation tools and components ................. xiv Chapter 1: Product Introduction Special features..................1-1 1.1.1 Product highlights................ 1-1 1.1.2 ROG Gaming Features ............... 1-2 1.1.3...
  • Page 4 3.6.8 ROG Effects ................3-26 Monitor menu ................... 3-27 Boot menu ....................3-30 Tool menu ....................3-36 3.9.1 ASUS EZ Flash 2 Utility ............3-36 3.9.2 Secure Erase ................3-36 3.9.3 Setup Animator [Disabled] ............3-37 3.9.4 Graphics Card Information ............3-37 3.9.5...
  • Page 5 GameFirst III ..................... 4-30 KeyBot....................... 4-33 4.10 ASUS Media Streamer ................4-35 4.11 ASUS Disk Unlocker ................4-37 4.12 RAMDisk ....................4-38 4.13 MemTweakIt ....................4-41 4.14 ROG CPU-Z ....................4-43 Chapter 5: RAID support RAID configurations .................. 5-1 5.1.1 RAID definitions ................

  • Page 6: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 7: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 8: Conventions Used In This Guide

    Conventions used in this guide To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task IMPORTANT: Instructions that you MUST follow to complete a task.

  • Page 9: Crossblade Ranger Specifications Summary

    * The max. 64GB memory capacity can be supported with DIMMs of Memory 16GB (or above). ASUS will update the QVL once the DIMMs are available on the market. ** Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  • Page 10 CROSSBLADE RANGER specifications summary ROG SupremeFX Audio 8-Channel High Definition Audio - SupremeFX Shielding Technology - ELNA Premium Audio Capacitors ® - Content Protection for Full Rate lossless DVD Audio, Blu-ray DVD, and HD-DVD audio content playback - Jack-detection, Multi-streaming, and Front Panel Jack-...
  • Page 11 - ASUS Fanless Design: Stylish Heatpipe & MOS Heatsink Solution - ASUS Fan Xpert3 ASUS EZ DIY - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 ASUS Q-Design...
  • Page 12 1 x KeyBot button 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, BIOS Features...

  • Page 13: Package Contents

    Package contents Check your motherboard package for the following items. ROG CROSSBLADE RANGER Motherboard 2 x 2-in-1 SATA 6 Gb/s cables Cables 1 x I/O Shield 1 x 12-in-1 ROG cable label 1 x 2-in-1 Q-Connector kit Accessories 1 x ROG Door Hanger...

  • Page 14: Installation Tools And Components

    Installation tools and components 1 bag of screws Philips (cross) screwdriver PC chassis Power supply unit AMD FM2+ CPU AMD FM2+ compatible CPU Fan DDR3 DIMM SATA hard disk drive SATA optical disc drive (optional) Graphics card (optional) The tools and components in the table above are not included in the motherboard package.

  • Page 15: Chapter 1: Product Introduction

    This motherboard offers you the strategic USB 3.0 accessibility for both the front and rear panels, allowing you to experience the convenience of the latest plug and play connectivity solution at speed up to ten times faster than USB 2.0. ASUS CROSSBLADE RANGER...

  • Page 16: Rog Gaming Features

    GameFirst III ASUS GameFirst III is a network management software that features four preset packet prioritized profiles (Optimization, Game, Media Streaming and File Sharing) facilitating user’s need. Users can also manually allocate bandwidth and adjust priority settings of each application to run faster and smoother.

  • Page 17: Rog Exclusive Features

    ASUS Special Features AI Suite 3 With its user-friendly interface, ASUS AI Suite 3 consolidates all the exclusive ASUS features into one simple-to-use software package. It allows you to supervise fan speed control, voltage and sensor readings. This all-in-one software offers diverse and ease to use functions, with no need to switch back and forth between different utilities.

  • Page 18: Rog Rich Bundled Software

    1.1.5 ROG rich bundled software KeyBot KeyBot is a built-in microprocessor that provides instant upgrade to your keyboard. You can configure and assign macros to specific keys on your keyboard to perform specific or several task at the same time. You can also configure your PC to wake up in CPU Level UP, XMP, or directly to BIOS mode.

  • Page 19: Motherboard Overview

    Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. ASUS CROSSBLADE RANGER...

  • Page 20: Motherboard Layout

    1.2.2 Motherboard layout CPU_OPT CPU_FAN KBMS_USB12 Q_CODE RESET EATX12V MemOK! BIOS_FLBK USB3_12 LAN_USB3_E12 Intel I211 AUDIO CHA_FAN1 PCIEX1_1 BATTERY 1042A CHA_FAN3 PCIEX16/X8_1 PCIEX1_2 ® PCI1 A88X FCH Super PCIEX8_2 PCI2 BIOS HD_LED FLBK_LED PCIEX4_3 DRCT USB56 USB34 ROG_EXT KEYBOT_LED CHA_FAN2 PANEL CLR_CMOS SOUNDSTAGE...

  • Page 21: Layout Contents

    1-37 21. Clear CMOS button (CLR_CMOS) 1-25 22. ROG Extension connector (18-1 pin ROG_EXT) 1-42 23. TPM connector (20-1 pin TPM) 1-42 24. Sonic SoundStage button (SOUNDSTAGE) 1-26 25. Front panel audio connector (10-1 pin AAFP) 1-38 ASUS CROSSBLADE RANGER...

  • Page 22: Central Processing Unit (Cpu)

    ® Athlon™ Series processors. CROSSBLADE RANGER CPU socket FM2+ Ensure that you use a APU designed for the FM2+ socket. The APU fits in only one correct orientation. DO NOT force the APU into the socket to prevent bending the pins and...

  • Page 23: System Memory

    The motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory Modules (DIMM) slots. A DDR3 module is notched differently from a DDR or DDR2 module. DO NOT install a DDR or DDR2 memory module to the DDR3 slot. CROSSBLADE RANGER 240-pin DDR3 DIMM sockets Recommended memory configurations ASUS CROSSBLADE RANGER...

  • Page 24: Memory Configurations

    Memory configurations You may install 1 GB, 2 GB, 4 GB and 8 GB unbuffered and non-ECC DDR3 DIMMs into the DIMM sockets. • You may install varying memory sizes in Channel A and Channel B. The system maps the total size of the lower-sized channel for the dual-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation.
  • Page 25 CROSSBLADE RANGER Motherboard Qualified Vendors Lists (QVL) DDR3 2666 (O.C.) MHz capability DIMM socket support (optional) Chip Chip Vendors Part No. Size Timing Voltage Brand 1DIMM 2DIMMs 4DIMMs CORSAIR CMD16GX3M4A2666C10 (Ver4.13) 4GB 10-12-12-31 1.65V G.SKILL F3-2666C11Q-16GTXD(XMP) 16GB (4x4GB) DS 11-13-13-35 1.65V DDR3 2400 (O.C.) MHz capability...
  • Page 26 DDR3 2133 MHz capability DIMM socket support (optional) Vendors Part No. Size Chip Brand Chip NO. Timing Voltage 1DIMM 2DIMMs 4DIMMs AX3U2133GC2G9B-DG2 1.55~ A-DATA 9-11-9-27 (XMP) 1.75V CMT16GX3M4X2133C9 16GB CORSAIR 9-11-10-27 1.50V (XMP1.3) (4GBx4 ) CMT4GX3M2A2133C9 CORSAIR 9-10-9-24 1.65V (XMP) (2x2GB) CMT4GX3M2B2133C9 CORSAIR...
  • Page 27 AX3U1866XW8G10 DS - 10-11-10-30 1.5V (2x8GB ) PATRIOT PV138G186C9KPD000326 DS - 1.5V Team TLD34G1866H9KBK DS - 9-11-9-27 1.5V Team TLD38G1866HC10SBK DS - 10-11-10-30 1.5V BLT4G3D1869DT1TX0.13FKD CRUCIAL DS - 9-9-9-27 1.5V (XMP) KINGSTON KHX18C10T3K4/32X DS - 1.5V ASUS CROSSBLADE RANGER 1-13...
  • Page 28 DDR3 1600 MHz capability DIMM socket support Chip (optional) Vendor Part No. Size Chip NO. Timing Voltage Brand 1DIMM 2DIMMs 4DIMMs A-DATA AM2U16BC2P1 A-DATA 3CCD-1509A EL1126T - AX3U1600XB2G79-2X A-DATA 7-9-7-21 1.55V-1.75V (XMP) (2x2GB) A-DATA AM2U16BC4P2 A-DATA 3CCD-1509A EL1126T - AX3U1600GC4G9-2G A-DATA 9-9-9-24 1.55V-1.75V...
  • Page 29 M2P2G64CB8HC9N-DG Elixir (XMP) M2X8G64CB8HB5N-DG Elixir Elixir1213 N2CB4G8BOBN-DG (XMP) Mushkin 998659 (XMP) 9-9-9-24 (3x2GB) Mushkin 998659 (XMP) 9-9-9-24 (3x2GB) ~1.6V 32GB PATRIOT PGD316G1600ELK (XMP) 9-9-9-24 1.65V (8GBx4) PATRIOT PGS34G1600LLKA 7-7-7-20 1.7V (2x2GB) (continued on the next page) ASUS CROSSBLADE RANGER 1-15...
  • Page 30 DDR3 1600 MHz capability DIMM socket support (optional) Vendor Part No. Size Chip Brand Chip NO. Timing Voltage 1DIMM 2DIMMs 4DIMMs Silicon SP002GBLTU160V02 SS S-POWER 20YT5NG-1201 Power (XMP) Silicon SP004GBLTU160V02 DS S-POWER 20YT5NG-1201 Power (XMP) Apacer 78.B1GE3.9L10C DS Apacer KZZC AM5D5908DEQSCK 16GB KINGSTON KHX16C9K2/16...
  • Page 31 Kingmax KKB8FNWBFGNX-27A Kingmax FLFE85F-C8KF9 CAES Kingmax KFC8FMFXF-DXX-15A Kingmax FLFE85F-C8KL9 NAES Kingmax KFC8FNLXF-DXX-15A Kingmax FLFE85F-C8KM9 NAES Kingmax KFC8FNMXF-BXX-15A Kingmax FLFE85F-B8KL9 NEES Kingmax KKB8FNWBFGNX-26A Kingmax FLFF65F-C8KL9 NEES Kingmax KFC8FNLXF-DXX-15A Kingmax FLFF65F-C8KM9 NEES Kingmax KFC8FNMXF-BXX-15A (continued on the next page) ASUS CROSSBLADE RANGER 1-17...
  • Page 32 DDR3 1333 MHz capability DIMM socket support (optional) Vendor Part No. Size Chip Brand Chip NO. Timing Voltage 1DIMM 2DIMMs 4DIMMs KVR1333D3N9/1G KINGSTON ELPIDA J1108BDBG-DJ-F 1.5V (Low Profile) KVR1333D3N9/2G KINGSTON Hynix H5TQ2G83AFRH9C (Low Profile) KINGSTON KVR1333D3S8N9/2G Micron IID77 D9LGK 1.5V KVR1333D3S8N9/2G-SP KINGSTON ELPIDA...
  • Page 33 Transcend 8G DDR3 1333 DIMM CL9 HMDD302GU648S1B9C-MEX 2GB ERTH 256X8DDR3 WT 1.5V HMDD304GU648S1B9C-MEX 4GB UUJK 512X8DDR3 WT 1.5V HMDD308GU648D1B9C-MEX 8GB FFCT 512X8DDR3 WT 1.5V TEAM TED34G1333HC9BK 9-9-9-24 TEAM TED38G1333HC9BK 9-9-9-24 1.5V Asint SLA304G08-EDJ1B Asint 304G08-DJ1B1301 - ASUS CROSSBLADE RANGER 1-19...
  • Page 34 A2 and B2 for better compatibility. • 4 DIMMs: Supports four (4) modules inserted into both the red and black slots as two pairs of Dual-channel memory configuration. Visit the ASUS website for the latest QVL. Chapter 1: Product introduction 1-20...

  • Page 35: Expansion Slots

    PCIEX16/X8_1 PCIEX1_2 PCI1 PCIEX8_2 PCI2 PCIEX4_3 Slot No. Slot Description PCIe 2.0 x1_1 slot PCIe 3.0/2.0 x16/x8_1 slot PCIe 2.0 x1_2 slot PCI slot 1 PCIe 3.0/2.0 x8_2 slot PCI slot 2 PCIe 2.0 x4_3 slot ASUS CROSSBLADE RANGER 1-21...
  • Page 36 PCIe operating mode VGA Configuration Single VGA CrossFireX™ 3-WAY CrossFireX™ PCIEX16/X8_1 PCIEX8_2 PCIEX4_3 • We recommend that you provide sufficient power when running CrossFireX™ mode. • Connect a chassis fan to the motherboard connector labeled CHA_FAN1-3 when using multiple graphics cards for better thermal environment. •...

  • Page 37: Onboard Buttons And Switches

    The button also lights up when the system is plugged to a power source indicating that you should shut down the system and unplug the power cable before removing or installing any motherboard component. CROSSBLADE RANGER Power-on button RESET button (RESET) Press the reset button to reboot the system.
  • Page 38 If the installed DIMMs still fail to boot after the whole tuning process, replace the DIMMs with ones recommended in the Memory QVL (Qualified Vendors Lists) in this user manual or on the ASUS website at www.asus.com. •...
  • Page 39 Clear CMOS button (CLR_CMOS) Press this button to clear the BIOS setup information only when the systems hangs due to overclocking. CROSSBLADE RANGER Clear CMOS button KeyBot button (KeyBot) Press this button to activate the KeyBot feature. KEYBOT CROSSBLADE RANGER KeyBot button •...
  • Page 40 Sonic SoundStage button (SOUNDSTAGE) Press this button to activate the Sonic SoundStage feature. SOUNDSTAGE CROSSBLADE RANGER Sonic SoundStage button • The debug code on the Q-Code LED shows the current Sonic SoundStage profile when you press the Sonic SoundStage button.

  • Page 41: Jumpers

    When enabled, the LN2 Mode jumper allows your system to eliminate the cold bugs in the processor during POST. It allows the processor to run at an extremely low temperature and helps the system boot fast. LN2_MODE CROSSBLADE RANGER LN2 mode setting 1.2.8 Onboard LEDs Hard Disk LED (HD_LED) The Hard Disk LED is designed to indicate the hard disk activity.
  • Page 42 BOOT_DEVICE_LED VGA_LED DRAM_LED CPU_LED CROSSBLADE RANGER CPU/DRAM/ BOOT_DEVICE/VGA/HD LED KeyBot LED (KEYBOT_LED) This LED lights up when the KeyBot button is pressed. KEYBOT_LED CROSSBLADE RANGER KeyBot LED Chapter 1: Product introduction 1-28...
  • Page 43 USB BIOS Flashback LED (FLBK_LED) This LED flashes when you press the BIOS Flashback button for BIOS update. FLBK_LED CROSSBLADE RANGER BIOS Flashback LED Q-Code LED (Q_CODE) The Q-Code LED design provides you with a 2-digit error code that displays the system status.
  • Page 44 Q-Code table Code Description Not used Power on. Reset type detection (soft/hard). AP initialization before microcode loading System Agent initialization before microcode loading PCH initialization before microcode loading Microcode loading AP initialization after microcode loading System Agent initialization after microcode loading PCH initialization after microcode loading Cache initialization 0C –...
  • Page 45 Reserved for future AMI progress codes S3 Resume Failed S3 Resume PPI not Found S3 Resume Boot Script Error S3 OS Wake Error Reserved for future AMI error codes EC – EF (continued on the next page) ASUS CROSSBLADE RANGER 1-31...
  • Page 46 Q-Code table Code Description Recovery condition triggered by firmware (Auto recovery) Recovery condition triggered by user (Forced recovery) Recovery process started Recovery firmware image is found Recovery firmware image is loaded F5 – F7 Reserved for future AMI progress codes Recovery PPI is not available Recovery capsule is not found Invalid recovery capsule...
  • Page 47 Legacy Boot event Exit Boot Services event Runtime Set Virtual Address MAP Begin Runtime Set Virtual Address MAP End Legacy Option ROM Initialization System Reset USB hot plug PCI bus hot plug (continued on the next page) ASUS CROSSBLADE RANGER 1-33...
  • Page 48 Q-Code table Code Description Clean-up of NVRAM Configuration Reset (reset of NVRAM settings) Reserved for future AMI codes B8– BF CPU initialization error System Agent initialization error PCH initialization error Some of the Architectural Protocols are not available PCI resource allocation error. Out of Resources No Space for Legacy Option ROM No Console Output Devices are found No Console Input Devices are found...

  • Page 49: Internal Connectors

    RSATA_RXN2 RSATA_RXP1 RSATA_RXP2 CROSSBLADE RANGER SATA 6.0Gb/s connectors • These connectors are set to [AHCI] by default. If you intend to create a Serial ATA RAID set using these connectors, set the SATA Mode item in the BIOS to [RAID].
  • Page 50 IntA_P2_D+ CROSSBLADE RANGER USB3.0 front panel connector The USB 3.0 module is purchased separately. You can connect the ASUS front panel USB 3.0 bracket to this connector to obtain the front panel USB 3.0 solution. Chapter 1: Product introduction 1-36...
  • Page 51 Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! You can connect the front panel USB cable to the ASUS Q-Connector (USB) first, and then install the Q-Connector (USB) to the USB connector onboard if your chassis supports front panel USB ports.
  • Page 52 PIN 1 HD-audio-compliant Legacy AC’97 pin definition compliant definition CROSSBLADE RANGER Front panel audio connector • We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. • If you want to connect a high-definition or an AC’97 front panel audio module to this connector, set the Front Panel Type item in the BIOS setup to [HD] or [AC97].
  • Page 53 CPU_FAN CHA_FAN1 CHA_FAN3 CHA_FAN2 CROSSBLADE RANGER Fan connectors • DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan connectors! •...
  • Page 54 • If you are uncertain about the minimum power supply requirement for your system, refer to the Recommended Power Supply Wattage Calculator at http://support.asus. com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-us for details. Chapter 1: Product introduction 1-40...

  • Page 55: System Panel Connector

    PANEL PIN 1 +HDD_LED- PWR_SW RESET CROSSBLADE RANGER System panel connector • System power LED (2-pin PWR_LED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.
  • Page 56 • The Front Base is purchased separately. • Visit www.asus.com for more information about the Front Base. TPM connector (20-1 pin TPM) This connector supports a Trusted Platform Module (TPM) system, which securely store keys, digital certificates, passwords and data. A TPM system also helps enhance the network security, protects digital identities, and ensures platform integrity.

  • Page 57: Chapter 2: Basic Installation

    The diagrams in this section are for reference only. The motherboard layout may vary with models, but the installation steps are the same for all models. Install the ASUS Q-Shield to the chassis rear I/O panel. Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to the chassis’...
  • Page 58 Place nine screws into the holes indicated by circles to secure the motherboard to the chassis. DO NOT over tighten the screws! Doing so can damage the motherboard. Chapter 2: Basic Installation...

  • Page 59: Apu Installation

    APU installation Ensure that you use a APU designed for the FM2+ socket. The APU fits in only one correct orientation. DO NOT force the APU into the socket to prevent bending the pins and damaging the APU! ASUS CROSSBLADE RANGER...

  • Page 60: Apu Heatsink And Fan Assembly Installation

    2.1.3 APU heatsink and fan assembly installation Apply the Thermal Interface Material to the APU heatsink and APU before you install the heatsink and fan if necessary. To install the APU heatsink and fan assembly Chapter 2: Basic Installation...
  • Page 61 To uninstall the APU heatsink and fan assembly ASUS CROSSBLADE RANGER...

  • Page 62: Dimm Installation

    2.1.4 DIMM installation To remove a DIMM Chapter 2: Basic Installation...

  • Page 63: Atx Power Connection

    2.1.5 ATX Power connection ASUS CROSSBLADE RANGER...

  • Page 64: Sata Device Connection

    2.1.6 SATA device connection Chapter 2: Basic Installation...

  • Page 65: Front I/O Connector

    2.1.7 Front I/O Connector To install ASUS Q-Connector To install USB 2.0 connector To install front panel audio connector AAFP USB 2.0 To install USB 3.0 connector USB 3.0 ASUS CROSSBLADE RANGER...

  • Page 66: Expansion Card Installation

    2.1.8 Expansion Card installation To install PCIe x16 cards To install PCIe x1 cards To install PCI cards Chapter 2: Basic Installation 2-10...

  • Page 67: Bios Update Utility

    Connect your USB keyboard on the KeyBot port if you want to use the KeyBot feature. Updating BIOS may have risks. If the BIOS program is damaged during the process and results to the system’s failure to boot up, please contact your local ASUS Service Center. ASUS CROSSBLADE RANGER...

  • Page 68: Motherboard Rear And Audio Connections

    Motherboard rear and audio connections 2.3.1 Rear I/O connection Rear panel connectors 1. PS/2 Keyboard/Mouse combo port 2. Optical S/PDIF OUT port 3. VGA port 4. Intel USB 3.0 ports 1 and 2. Lower port supports the USB BIOS Flasback feature. ®...

  • Page 69: Audio I/O Connections

    Mic In Mic In Center/Sub Center/Sub Orange – – woofer woofer Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out Gray – – – Side Speaker Out 2.3.2 Audio I/O connections Audio I/O ports ASUS CROSSBLADE RANGER 2-13...
  • Page 70 Connect to Headphone and Mic Connect to Stereo Speakers Connect to 2.1 channel Speakers Chapter 2: Basic Installation 2-14...
  • Page 71 Connect to 4.1 channel Speakers Connect to 5.1 channel Speakers ASUS CROSSBLADE RANGER 2-15...
  • Page 72 Connect to 7.1 channel Speakers Chapter 2: Basic Installation 2-16...

  • Page 73: Starting Up For The First Time

    While the system is ON, press the power button for less than four seconds to put the system on sleep mode or soft-off mode, depending on the BIOS setting. Press the power button for more than four seconds to let the system enter the soft-off mode regardless of the BIOS setting. ASUS CROSSBLADE RANGER 2-17...
  • Page 74 Chapter 2: Basic Installation 2-18...

  • Page 75: Chapter 3: Bios Setup

    BIOS setup Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 76: Bios Setup Program

    BIOS setup program Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screen include navigation keys and brief onscreen help to guide you in using the BIOS Setup program. Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST).

  • Page 77: Ez Mode

    Loads optimized default settings Click to go to Advanced mode Click to display boot devices Selects the boot device priority The boot device options vary depending on the devices you installed to the system. ASUS CROSSBLADE RANGER...

  • Page 78: Advanced Mode

    3.2.2 Advanced Mode The Advanced Mode provides advanced options for experienced end-users to configure the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. To switch from EZ Mode to Advanced Mode, click Advanced Mode(F7) or press F7 hotkey.

  • Page 79: Menu Bar

    EZ Tuning Wizard(F11) This button above the menu bar allows you to view and tweak the overclocking settings of your system. It also allows you to change the motherboard’s SATA mode from AHCI to RAID mode. ASUS CROSSBLADE RANGER...

  • Page 80: Hot Keys

    Quick Note (F9) This button above the menu bar allows you to key in notes of the activities that you have done in BIOS. • The quick Note function does not support the following keyboard functions: delete, cut, copy and paste. •...

  • Page 81: My Favorites

    Favorites screen then click the plus sign (“+”) to save it in My Favorites screen. You cannot add the following items to My Favorite items: • Items with submenu options • User-managed items such as language and boot order • Configuration items such as Memory SPD Information, system time and date. ASUS CROSSBLADE RANGER...

  • Page 82: Extreme Tweaker Menu

    Extreme Tweaker menu The Extreme Tweaker menu items allow you to configure overclocking-related items. Be cautious when changing the settings of the Extreme Tweaker menu items. Incorrect field values can cause the system to malfunction. The configuration options for this section vary depending on the CPU and DIMM model you installed on the motherboard.

  • Page 83: Dram Timing Control

    The subitems in this menu allow you to set the DRAM timing control features. Use the <+> and <-> keys to adjust the value. To restore the default setting, type [auto] using the keyboard and press the <Enter> key. ASUS CROSSBLADE RANGER...
  • Page 84 Primary Timings DRAM CAS# Latency [Auto] Configuration options: [Auto] [5] – [16] DRAM RAS# to CAS# Delay [Auto] Configuration options: [Auto] [2] – [19] DRAM RAS# PRE Time [Auto] Configuration options: [Auto] [5] – [19] DRAM RAS# ACT Time [Auto] Configuration options: [Auto] [8] –...
  • Page 85 0% (Regular), 20% (Medium), 40% (High) and 100% (Extreme). Configuration options: [Auto] [Regular] [Medium] [High] [Extreme] The actual performance boost may vary depending on your CPU specification. DO NOT remove the thermal module. The thermal conditions should be monitored. ASUS CROSSBLADE RANGER 3-11...
  • Page 86 Reduce the phase number under light system loading to increase VRM efficiency. [Standard] Proceeds to phase control depending on the CPU loading. [Optimized] Loads the ASUS optimized phase tuning profile. [Extreme] Proceeds to the full phase mode. [Manual Adjustment] Allows manual adjustment.
  • Page 87 DRAM Power Phase Control [Optimized] [Optimized] Loads the ASUS optimized phase tuning profile. [Extreme] Proceeds to the full phase mode. CPU Voltage [Offset Mode] [Manual Mode] Allows you to set a fixed CPU voltage. [Offset Mode] Allows you to set the Offset voltage.
  • Page 88 SB 1.1V Voltage [Auto] Allows you to set the Southbridge 1.1V voltage. The values range from 1.1V to 1.4V with a 0.01V interval. 1.1VSB Voltage [Auto] Allows you to set the 1.1Vsb voltage. The values range from 1.1000V to 1.4000V with a 0.1V interval.

  • Page 89: Main Menu

    The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup program. The Main menu provides you an overview of the basic system information, and allows you to set the system language and security settings. ASUS CROSSBLADE RANGER 3-15...
  • Page 90 Security The Security menu items allow you to change the system security settings. • If you have forgotten your BIOS password, erase the CMOS Real Time Clock (RTC) RAM to clear the BIOS password. See section 1.2.6 Onboard buttons and switches for information on how to erase the RTC RAM via the Clear CMOS button.

  • Page 91: Administrator Password

    To clear the user password, follow the same steps as in changing a user password, but press <Enter> when prompted to create/confirm the password. After you clear the password, the User Password item on top of the screen shows Not Installed. ASUS CROSSBLADE RANGER 3-17...

  • Page 92: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. Chapter 3: BIOS setup 3-18...

  • Page 93: Cpu Configuration

    Disables the CPB (Core Performance Boost) mode or set it to [Auto] for automatic configuration. Configuration options: [Disabled] [Auto] APM Master enable [Auto] Allows you to enable or disable Application Power Management (APM) function. Configuration options: [Auto] [Enabled] [Disabled] ASUS CROSSBLADE RANGER 3-19...

  • Page 94: Sata Configuration

    C6 Mode [Enabled] Enables or disables C6 mode. Configuration options: [Enabled] [Disabled] IOMMU [Disabled] Set this item to [Enabled] to show IOMMU Mode. Configuration options: [Enabled] [Disabled] Bank Interleaving [Enabled] Enables or disables the bank memory interleaving. Configuration options: [Enabled] [Disabled] Channel Interleaving [Enabled] Enables or disables the channel memory interleaving.
  • Page 95 POST (Power-on Self Test) when an error occurs in the hard disks. Configuration options: [Disabled] [Enabled] SATA ESP on Port1~8 [Disabled] Enable this item to support ESATA. Configuration options: [Enabled] [Disabled] SATA6G_1 (Red) - SATA6G_8 (Red) Press <Enter> to rename the AMD SATA ports. ASUS CROSSBLADE RANGER 3-21...

  • Page 96: Usb Configuration

    3.6.3 USB Configuration The items in this menu allow you to change the USB-related features. The USB Devices item shows the auto-detected values. If no USB device is detected, the item shows None. USB Device Enable [Enabled] Allows you to enable or disable all USB ports. Configuration options: [Disabled] [Enabled] Legacy USB Support [Enabled] [Disabled] The USB devices can be used only for the BIOS setup program.

  • Page 97: Nb Configuration

    Enables the integrated graphics controller. Configuration options: [Auto] [Force] PCIEX16/X8_1 [Auto] Sets the speed mode for the PCIex16_1 slot. When [Force X16] is selected, the PCIEX8_2 slot will be disabled. Configuration options: [Auto] [Force X16] [Force X8] ASUS CROSSBLADE RANGER 3-23...

  • Page 98: Onboard Devices Configuration

    3.6.5 Onboard Devices Configuration Scroll down to view the other BIOS items. HD Audio Device [Enabled] [Enabled] Enables the High Definition Audio Controller. [Disabled] Disables the controller. The following items appear only when you set the HD Audio Controller to [Enabled]. Front Panel Type [HD] [HD] Sets the front panel audio connector (AAFP) mode to high definition audio.

  • Page 99: Apm Configuration

    This feature requires an ATX power supply that provides at least 1A on the +5VSB lead. Power On By RTC [Disabled] [Disabled] Disables RTC to generate a wake event. [Enabled] Generates a wake event and configure the real-time clock (RTC) alarm date. ASUS CROSSBLADE RANGER 3-25...

  • Page 100: Network Stack

    3.6.7 Network Stack Network Stack [Disabled] This item allows you to disable or enable the UEFI network stack. Configuration options: [Disabled] [Enabled] 3.6.8 ROG Effects Onboard LED [Enabled] This item allows you to enable all the onboard LEDs. Configuration options: [Enabled] [Disabled] SupremeFX Lighting LED [Enabled] This item allows both Red line LED and SupremeFX logo LED turn on or off at the same time...

  • Page 101: Monitor Menu

    (RPM). If any of the fans is not connected to the motherboard, the field shows [N/A]. These items are not user-configurable. Press <Enter> and select [Ignore] if you do not wish to display the detected temperatures. ASUS CROSSBLADE RANGER 3-27...

  • Page 102: Fan Speed Control

    Fan Speed Control CPU Q-Fan Control [Auto] [Auto] Detects the type of CPU fan installed and automatically switches the mode control. [Disabled] Disables the Q-Fan control. [DC Mode] Enables the CPU Q-Fan control feature in DC mode for 3-pin CPU fan. [PWM Mode] Enables the CPU Q-Fan control feature in PWM mode for 4-pin CPU fan.
  • Page 103 60% to 100%. When the CPU temperature reaches the upper limit, the CPU fan will operate at the maximum duty cycle. Chassis Fan 1/2/3 Lower Temperature [40] Displays the lower limit of the CPU temperature. ASUS CROSSBLADE RANGER 3-29...

  • Page 104: Boot Menu

    Chassis Fan 1/2/3 Min. Duty Cycle(%) [60] Use the <+> or <-> keys to adjust the minimum CPU fan duty cycle. The values range from 60% to 100%. When the CPU temperature is under 40ºC, the CPU fan will operate at the minimum duty cycle. Allow Fan Stop [Disabled] When this item is set to [Enabled], the selected fan is controlled based on the temperature source.
  • Page 105 Set the power-on state of the NumLock to [Off]. Wait For ‘F1’ If Error [Enabled] Enable this item for the system to pause until the F1 key is pressed when any error occurs. Configuration options: [Disabled] [Enabled] ASUS CROSSBLADE RANGER 3-31...
  • Page 106 The Option ROM Messages will be shown during the POST. [Keep Current] Only the ASUS logo will be shown during the POST. Interrupt 19 Capture [Enabled] Enable this item to allow the option ROMs to trap the interrupt 19. Configuration options:...

  • Page 107: Secure Boot

    The PK file must be formatted as a UEFI variable structure with time-based authenticated variable. KEK Management Key-exchange Key (KEK) refers to Microsoft Secure Boot Key-Enrollment Key (KEK). ® Delete the KEK Allows you to delete the KEK from your system. Configuration options: [Yes] [No] ASUS CROSSBLADE RANGER 3-33...
  • Page 108 Load KEK from File Allows you to load the downloaded KEK from a USB storage device. Append KEK from File Allows you to load the additional KEK from a storage device for an additional db and dbx loaded management. The KEK file must be formatted as a UEFI variable structure with time-based authenticated variable.

  • Page 109: Boot Option Priorities

    OS in Safe Mode, press <F8 > after POST (Windows 8 not supported). • To select the boot device during system startup, press <F8> when ASUS Logo appears. Boot Override These items displays the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system.

  • Page 110: Tool Menu

    To launch ROG SSD Secure Erase, click Tool > Secure Erase on the Advanced mode menu. Check the ASUS support site for a full list of SSDs tested with Secure Erase. The drive may become unstable if you run Secure Erase on an incompatible SSD.

  • Page 111: Setup Animator [Disabled]

    Locked. SSDs might be locked if the Secure Erase process is either incomplete or was stopped. This may be due to a third party software that uses a different password defined by ASUS. You have to unlock the SSD in the software before proceeding with Secure Erase.

  • Page 112: Asus Overclocking Profile

    3.9.5 ASUS Overclocking Profile This item allows you to store or load multiple BIOS settings. The Overclocking Profile items show Not assigned if no profile is created. Load from Profile Allows you to load the previous BIOS settings saved in the BIOS Flash. Key in the profile number that saved your CMOS settings, press <Enter>, and then select Yes.

  • Page 113: Asus Spd Information

    Allows you to view the DRAM SPD information. DIMM slot number [DIMM_A2] Allows you to select the DIMM slot number to show the plugged DRAM Serial Presence Detect (SPD) information. Configuration options: [DIMM_A1] [DIMM_A2] [DIMM_B1] [DIMM_ Some DRAM manufacturers may not be recognized. ASUS CROSSBLADE RANGER 3-39...

  • Page 114: Exit Menu

    3.10 Exit menu The Exit menu items allow you to load the optimal default values for the BIOS items, and save or discard your changes to the BIOS items. You can access the EZ Mode from the Exit menu. Load Optimized Defaults This option allows you to load the default values for each of the parameters on the Setup menus.

  • Page 115: Updating Bios

    ® ASUS EZ Flash 2: Updates the BIOS using a USB flash drive. ASUS CrashFree BIOS 3: Restores the BIOS using the motherboard support DVD or a USB flash drive when the BIOS file fails or gets corrupted. ASUS BIOS Updater: Updates the BIOS in DOS environment using the motherboard support DVD and a USB flash disk drive.

  • Page 116: Asus Ez Flash

    3.11.2 ASUS EZ Flash 2 ASUS EZ Flash 2 allows you to update the BIOS without having to use a bootable floppy disk or an OS-based utility. Before you start using this utility, download the latest BIOS from the ASUS website at www.asus.com.

  • Page 117: Asus Crashfree Bios

    The BIOS file in the motherboard support DVD may be older than the BIOS file published on the ASUS official website. If you want to use the newer BIOS file, download the file at http://support.asus.com and save it to a USB flash drive.

  • Page 118: Asus Bios Updater

    3.11.4 ASUS BIOS Updater ASUS BIOS Updater allows you to update the BIOS in DOS environment. The screen captures used in this section are for reference only and may not be exactly the same as actually shown on your computer screen.
  • Page 119 [Enter] Select or Load [Tab] Switch [V] Drive Info [Up/Down/Home/End] Move [Esc] Exit Press <Tab> to switch from Drives panel to Files panel then press <Up/Down or Home/ End> keys to select the BIOS file and press <Enter>. ASUS CROSSBLADE RANGER 3-45...
  • Page 120 After the BIOS Updater checks the selected BIOS file, select Yes to confirm the BIOS update. Are you sure you want to update the BIOS? The BIOS Backup feature is not supported due to security regulations. Select Yes then press <Enter>. When BIOS update is done, press <ESC> to exit BIOS Updater.
  • Page 121 ASUS CROSSBLADE RANGER 3-47...

  • Page 122: Chapter 4: Software Support

    • Motherboard settings and hardware options vary. Use the setup procedures presented in this chapter for reference only. Refer to your OS documentation for detailed information. Support DVD information The contents of the support DVD are subject to change at any time without notice. Visit www.asus.com for updates. 4.2.1 Running the support DVD Ensure that you have an Administrator account before running the support DVD in Windows 7, Windows 8, or Windows 8.1 OS. ® ® ® To run the support DVD Place the Support DVD into the optical drive. 2. In the AutoPlay dialog box, click Run ASSETUP.exe. If the AutoPlay dialog box does not appear, browse the contents of the support DVD and ASUS motherboard support double-click or tap \\bin\ASSETUP.EXE to launch the DVD main menu ASUS CROSSBLADE RANGER...

  • Page 123: Obtaining The Software Manuals

    Contains ROG related videos. Shows the available device drivers if the system detects installed devices. Click to display the ASUS contact information. Install the necessary drivers to use Click to display product the devices.

  • Page 124: Software Information

    Most of the applications in the support DVD have wizards that will conveniently guide you through the installation. View the online help or readme file that came with the software application for more information. AI Suite 3 AI Suite 3 is an all-in-one interface that integrates several ASUS utilities and allows you to launch and operate these utilities simultaneously. Installing AI Suite 3 Ensure that you have an Administrator account before installing AI Suite 3 in Windows 7, ® Windows 8, or Windows 8.1 OS. ® ® To install AI Suite 3 on your computer: Windows 7 OS ® Place the Support DVD into the optical drive. 2. In the AutoPlay dialog box, click Run ASSETUP.exe then select the Utilities tab 3. From the Utilities tab, click ASUS AI Suite 3 then follow the succeeding onscreen instructions. ASUS CROSSBLADE RANGER...
  • Page 125 If the ASUS motherboard support DVD main menu did not appear, try the following steps: Go to the Start Screen then click or tap the Desktop app. On the lower left corner of the Desktop, click or tap File Explorer then select your DVD drive and tap or double-click the Setup application. Launching AI Suite 3 Windows 7 OS ® From the Desktop, click Start > All Programs > ASUS > AI Suite 3 > AI Suite 3. You can also launch AI Suite 3 in Windows 7 by clicking on the Notification area. ® Windows 8 / Windows 8.1 OS ® ®...
  • Page 126 Click to launch AI Suite 3 menu bar AI Suite 3 main menu bar USB BIOS Push Notice 5-Way Optimization Ai Charger+ EZ Update Flashback USB 3.0 Boost System USB Charger+ Version Information • Some functions in the AI Suite 3 main menu in this user guide may vary depending on the motherboard model. • Refer to the software manual in the support DVD or visit the ASUS website at www.asus.com for detailed software configuration. ASUS CROSSBLADE RANGER...

  • Page 127: Way Optimization

    Dual Intelligent Processors 5 ASUS Dual Intelligent Processors 5 combines TPU, EPU, DIGI+ Power Control, Fan Xpert 3, and Turbo App functions to push the system’s performance to its optimal potential. It automatically balances the system’s performance, power saving, levels, and fan settings via the user-friendly AI Suite 3 utility. 5-Way Optimization The 5-Way Optimization function dynamically optimizes your PC based on real-time usage to provide the best system status. It covers the essential areas such as CPU performance, energy saving, stable digital power, cool and quiet fan control, and includes tailored settings for your apps to ensure your PC is ready for gaming, entertainment, productivity, or just about anything. Click or tap this 5-Way Optimization button to auto-detect and tune the best settings for your system DO NOT remove your fan during the tuning process. Chapter 4: Software support...
  • Page 128 Click or tap adjust the voltages Click or tap to load Click or tap to apply the the saved profile adjustments Click or tap to save the adjustment into a profile Click or tap to undo the adjustments ASUS CROSSBLADE RANGER...

  • Page 129: Fan Xpert 3

    Fan Xpert 3 ASUS Fan Xpert 3 provides customizable settings of your fans for a cooler and more quiet computing environment. With its fan Auto Tuning feature, ASUS Fan Xpert 3 automatically tweaks the settings of CPU and chassis fans to achieve their best cooling performance. ASUS Fan Xpert 3 also supports hardware level PWM/DC combo mode for the CPU and chassis fans. You can also reduce the CPU fan speed below the default minimum for a noiseless operation during light loads. Click a screen to select the type of fan that you want to customize Click to Click to set the maximize the fan’s speed to fan speed silent mode Click to set the balanced Click to increase the fan’s...

  • Page 130: Digi+ Power Control

    CPU Power Phase Control Increase the phase number under a heavy system load to get more transient and better thermal performance. Reduce the phase number under a light system load to increase the VRM efficiency. CPU Voltage Frequency Enables spread spectrum to enhance system stability. CPU Power Thermal Control A higher temperature brings a wider CPU power thermal range and extends the overclocking tolerance to enlarge the overclocking potential. CPU/NB Current Capability CPU Current Capability provides a wider total power range for overclocking. A higher value brings a wider total power range and extends the overclocking frequency range simultaneously. CPU/NB Load-line Calibration CPU/NB Load-line controls the behavior of the DRAM controller. Adjust to a high value for better system performance or to a low value for a better power efficiency. CPU Current Capability A higher value brings a wider total power range and extends the overclocking frequency range simultaneously. ASUS CROSSBLADE RANGER...

  • Page 131: Turbo App

    Turbo App Turbo App allows you customize the system performance, network priority, and audio setting of an application. When an application is on the Turbo App List, you can allocate the CPU frequency, assign a network priority, and define the audio setting of the selected application. Click to refresh the list of running applications Click to assign a specific application(.exe) into Turbo App list Click to scroll up/down Click to apply the changes Click to undo the changes Applications list pane Displays all the running applications on your system.

  • Page 132: Energy Processing Unit (Epu)

    Away Mode Click to set the power plan Click to select a fan profile Select a setting for Click to enable the Click to undo Click to apply the Vcore Downgrade default settings the adjustments adjustments ASUS CROSSBLADE RANGER 4-11...

  • Page 133: Usb 3.0 Boost

    Click to enable UASP or Turbo Mode to the USB Click to select a USB device device for a faster data transfer rate Ensure to connect your USB 3.0 device to the USB 3.0 ports that support USB 3.0 Boost. Refer to the Rear I/O connection section of your user guide for more details. • USB 3.0 Boost automatically detects the USB 3.0 devices that support UASP. For a list of UASP-supported USB 3.0 devices, visit the ASUS website at www.asus.com. • The data transfer speed varies with USB devices. For a higher data transfer performance, use a USB 3.0 device. Chapter 4: Software support 4-12...
  • Page 134 Ai Charger+ This utility allows you to fast-charge your portable BC 1.1* mobile devices on your computer’s USB port three times faster than the standard USB devices**. • * Check your manufacturer if your USB device is a Battery Charging Specification 1.1 (BC 1.1) compliant or compatible device. • ** Actual charging speeds may vary depending on the charging rate and specifications of your USB device. • To ensure normal charging function, disconnect and reconnect your USB device every time you enable or disable Ai Charger+. ASUS CROSSBLADE RANGER 4-13...
  • Page 135 EZ Update EZ Update is a utility that allows you to automatically update your motherboard’s software, drivers, or BIOS. With this utility, you can also manually update the BIOS and select the boot logo that will display during POST. Launching EZ Update To launch EZ Update, click or tap on the top-right corner of the AI Suite 3 main menu, then click EZ Update on the AI Suite 3 main menu bar. EZ Update screen Click to automatically update your motherboard’s driver, software and firmware Click to select a Click to update Click to search and boot logo the BIOS select the BIOS file Chapter 4: Software support...

  • Page 136: System Information

    System Information This utility displays the detailed information and settings of the installed motherboard, CPU, and memory. Launching the System Information To launch System Information, click or tap on the top-right corner of the AI Suite 3 main menu, then select System Information. Viewing the motherboard information Click or tap the MB tab to view the motherboard’s information. Viewing the CPU information Click or tap the CPU tab to view the processor’s information. ASUS CROSSBLADE RANGER 4-15...
  • Page 137 Viewing the SPD information Click or tap the SPD tab to view the memory’s information. Chapter 4: Software support 4-16...

  • Page 138: Usb Bios Flashback

    Click to check for a new BIOS Click or tap update available to cancel the for download download schedule setting Click or tap to apply the download schedule setting Scheduling the BIOS download In the Download Setting field, tick Schedule (days) then select the number of days for the BIOS download schedule. Click or tap Apply to save the BIOS download schedule. Click or tap Cancel to cancel the download schedule. ASUS CROSSBLADE RANGER 4-17...

  • Page 139: Usb Charger

    Click or tap to discard the settings Click or tap to select the type of USB device that you wish to charge when the system is off Ensure to connect your USB device into the USB port that supports this utility. Refer to section 2.3.1 Rear I/O connection of your user manual for more details. • USB Charger+ does not support USB hubs, USB extension cables, and generic USB cables. • USB Charger+ may not recognize some ASUS devices due to varying design. Chapter 4: Software support 4-18...

  • Page 140: Push Notice

    Click or tap to Click or tap to apply the settings discard the settings You can also enable the Push Notice via the Push Notice shortcut on the lower-right corner of your screen. To do this, click or tap << then click or tap then select Pairing your computer and smart device To pair your computer and smart device: On your smart device, tap to launch Push Notice. Push Notice Tap Push Scan then tap the name of your computer that you want to pair with. To pair your computer and smart device, ensure that both are connected to the same wireless network. ASUS CROSSBLADE RANGER 4-19...
  • Page 141 Setting up PC Mode alerts of your computer This feature allows you to restart, shut down, or put your computer to sleep mode and sends an alert to your smart device. Tick these to enable mode alerts Tick to select the smart device Set the day and time to enable the PC modes Set the minutes to send the alert before the PC mode/s activation Key in your messages for more information...

  • Page 142: Sending Messages To Your Smart Device

    Viewing your computer status on your smart device Tap on your smart device to launch Push Notice. Push Notice Tap to delete PC Tap to view PC alerts mode alerts Tap to view PC status alerts Tap to view PC sent messages Tap to scan more host computers ASUS CROSSBLADE RANGER 4-21...

  • Page 143: Rog Audio Features

    ROG audio features Installing the Software Follow the installation wizard to install the Realtek Audio Manager driver from the support ® DVD that is bundled with the motherboard. If the Realtek audio software is correctly installed, you will find the Realtek HD Audio ® ® Manager icon on the taskbar. Double-click or tap on the icon to display the Realtek HD ® Audio Manager. Realtek ® HD Audio Manager Sonic Studio Sonic Studio is an audio suite that offers six audio controls: Reverb, Bass Boost, Equalizer, Voice Clarity, Smart EQ, and Virtual Surround. Virtual Surround is dedicated for 2-channel headset and offers one of the best virtual surround technology for gaming. Chapter 4: Software support 4-22...
  • Page 144 Bass Boost switch Click to boosts the bass effects. Use the slider to adjust the sound of the bass effect. Voice Clarity switch Click to enable this item. Voice clarity extracts human voice for better dialog/audio communication or to hear vocals more clearly when listening to a music. Smart EQ switch Dynamically adjust the EQ so you can hear more details. Virtual Surround switch This item lets you experience 7.1 CH virtual surround from your headset when enabled. Reverb switch The Reverb effect is part of the Virtual Sound Stage effects that lets you choose other reverb presets. Reverb presets Click to choice and select a reverb effect from the different environmental spaces for reverb effects. This item is only available when the Reverb switch is enabled. Test tone Click this button to start the test for the selected preset profile. Preset profiles Click any of the preset profiles. Choose from Gaming, music, movie, or communication. Profile import/export Allows you to Import, export, or revert to the default setting of a profile. ASUS CROSSBLADE RANGER 4-23...

  • Page 145: Sonic Senseamp

    Sonic SenseAmp Sonic SenseAmp is an exclusive ROG invention that is a built-in headphone AMP on onboard audio with three AMP levels adjustment. It detects your headphone’s impedance and adjusts the built-in AMP accordingly. Sonic SenseAmp only works on front panel. When you plug a headphone into the front headphone jack, Sonic SenseAmp displays a pop- up window that displays “Detecting headphone impedance”. After detecting the headphone’s impedance, Sonic SenseAmp displays another pop-up window similar to the one shown below. Refer to the table below on the behavior of Sonic SenseAmp when adjusting the impedance of the detected headphone: 32 ohm Amplify Level is automatically set at Performance 150 ohms Amplify Level is automatically set at Powerful > 150 ohms Amplify Level is automatically set at Extreme Other device The device plugged in detected as other device Chapter 4: Software support 4-24...
  • Page 146 After you close the pop-window, Sonic SenseAmp enters speaker configuration and displays the adjusted headphone impedance. Click to manually adjust the amplify level Displays the impedance of your headphone ASUS CROSSBLADE RANGER 4-25...

  • Page 147: Sonic Soundstage

    Sonic SoundStage Sonic SoundStage is a hardware based sound solution for virtual Sound Stage that offers four preset gaming profiles: FPS, Racing, Combat and Sport. • This feature is only available for front panel Headphone output. • You can enable this feature by enabling the dedicated SoundStage button on your motherboard. Refer to the section of your motherboard’s user guide for the location of the SoundStage button. Click any of the four preset gaming profiles Use the slider to manually adjust the setting of an item Crossing Move the slider to adjust the amount of cross channel mixing. Revert Move the slider to revert the main audio source. Space Move the slider to adjust and virtualize the space sound. Crossing gain This item only works when Crossing and Revert is enabled. Move the slider to adjust the hardness of the wall. Chapter 4: Software support 4-26...

  • Page 148: Dts Connect

    DTS Connect DTS Connect delivers excellent audio entertainment across all formats and works with 4, 5.1 and 7.1 channels of incredible surround sound . It also allows you to connect your PC to a home theatre system. Control settings panel ASUS CROSSBLADE RANGER 4-27...

  • Page 149: Sonic Radar Ii

    Sonic Radar II Sonic Radar II is designed for First Person Shooting (FPS) games and shows the precise direction and intensity of where a sound is coming from. It features a simple and friendly user-interface and also features sound enhancers to amplify desired sound effects. Display Menu Customize the settings for each game including Transparency, Signal, Size, and Remanency. Displays the options available. Click a tab to select an option. Each option has its own settings and menus. Click to reset to the default settings Click to start the test tone Use the sliders to adjust the settings Displays the list of games...
  • Page 150 Audio Mode/Radar Selection menu Allows you to configure the sound enhancers. Tick to choose the desired sound enhancer Audio Mode/Radar Selection are enabled with shortcut keys in the game. Refer to the Controls tab for more information about the shortcut key settings. ASUS CROSSBLADE RANGER 4-29...

  • Page 151: Gamefirst Iii

    GameFirst III GameFirst III is a network management software that features four preset packet prioritized profiles (Optimization, Game, Media Streaming and File Sharing) facilitating different user scenarios. Users can also manually allocate bandwidth and adjust priority settings of each application to run faster and smoother. To use GameFirst III, double-click on the desktop. Click any item for quick view Click to open the tabs for different functions Use the bar to adjust the bandwidth Click to load a preset speed settings or priority profile and key in the value of configure its settings the input field...
  • Page 152 Network Monitor Top 5 application Displays the top 5 bandwidth consuming applications currently used. Application usage Displays the individual downloading and uploading bandwidth of currently used applications. Total usage Displays the total downloading and uploading bandwidth of the currently used applications. ASUS CROSSBLADE RANGER 4-31...
  • Page 153 Bandwidth Test You can use this feature to test the Internet Service Provider (ISP) speed or manually key in the desired uploading/downloading speed and apply the speed if needed. Key in the upload/ download speed Click to begin the speed test Click to apply the speed after manually keying in the desired speed or after you performing the speed test Using the Network Information Displays information about the physical network card such as speed, physical address, IP address, subnet mask, and default gateway.

  • Page 154: Keybot

    Click to configure Macro keys, Smart login, Tick to toggle the KeyBot Function keys, and Shortcut settings function on/off Click any of the items to perform a specific tasks, or click their corresponding keys on the keyboard Smart Input ASUS CROSSBLADE RANGER 4-33...
  • Page 155 Function Keys Shortcut Chapter 4: Software support 4-34...

  • Page 156: Asus Media Streamer

    Click or tap to edit media files Click or tap to select media type Select the device you Log in ASUS account to stream Click or tap a media file to play want to stream to play in different networks...
  • Page 157 Adding and deleting media files Drag and drop or tick files to add or delete. Click to add or create a new folder Click to add the selected files Click to delete selected files Click to proceed with the deletion or Click to cancel changes addition of files The following media formats are supported: .3gp, .mp4, .m4a, .aac, .ts, .flac, .mp3, .mid,...

  • Page 158: Asus Disk Unlocker

    4.11 ASUS Disk Unlocker This ASUS exclusive utility provides an easy-to-use interface to identify and utilize all drive space in hard disk drives (HDD). ASUS Disk Unlocker is supported only on Windows 7 and Windows ® ® To launch ASUS Disk Unlocker, click Click to open the help file that shows the detailed information on how to use ASUS Disk Unlocker ASUS Disk Unlocker Help file ASUS CROSSBLADE RANGER 4-37...

  • Page 159: Ramdisk

    4.12 RAMDisk RAMDisk is a data-storage software that reserves a part of your system’s memory and turns it into a high-speed virtual drive where you can store cache files and game apps for instant access. The Dynamic Memory Allocation function can release the unused memory of RAMDisk back to the system when needed and helps extend the lifespan of your SSD or HDD. The following folders are not suitable for RAMDisk optimization. Moving them into the RAMDisk might negatively affect the performance of your system. • Swap file/Page file: The swap file is a permanent storage space used as the virtual memory expansion of the system memory. Moving the swap file into the RAM Disk simply defects the whole purpose of having it and may affect your system’s performance. • Startup folders: Since RAMDisk loads during boot up together with the contents of the Junction folders, changing the location of the startup folders may cause system error and disable loading your RAMDisk. To launch RAMDisk, click Creating/Deleting a RAMDisk drive Your RAMDisk drive allows you to place your favorite applications and files into RAM so you can utilize your RAM speed for better read/write performance. The files that are stored inside the RAMDisk are automatically backed up every time your PC is turned off. The startup time may take a while, depending on the size of your RAMDisk drive. To create RAMDisk drives: Click to create RAMDisk drives Move the slider to the Click the drop-down right to set the size arrow to choose a drive...

  • Page 160: Creating/Deleting A Junction Point

    Click the drop-down arrow to select your Click to select where to RAMDisk drive and its create a junction point. available storage space. Click to finish adding the new junction point. Click to delete the existing junction point. ASUS CROSSBLADE RANGER 4-39...
  • Page 161 Synchronizing backup files After creating a junction point, RAMDisk automatically creates a backup folder in the file’s original location. Use RAMDisk to manually synchronize updates with these backup files. Click Synchronize to update your files Chapter 4: Software support 4-40...

  • Page 162: Memtweakit

    Click a tab to configure the memory timing Click About tab then click REPUBLIC OF GAMERS to access the official ROG website Click to exit MemTweakIt Click to apply your settings Click to validate your settings. ASUS CROSSBLADE RANGER 4-41...
  • Page 163 Validating and saving your MemTweakIt settings To validate and save your configuration online: Launch MemTweakIt and click Validate. In Online Mode, key in your ASUS account ID and password, and click Submit. Your configuration will be displayed in MemTweakIt webpage. To validate and save your configuration manually: Launch MemTweakIt and click Validate. In Manual Mode, click Save Validation File. Key in a file name for your configuration file and click Submit. Click validation webpage. In MemTweakIt - Validation File Upload window, key in your ASUS account ID and password. Click Browse, locate the saved .cvf file, and click Open. Click Submit. Your configuration will be displayed in MemTweakIt webpage. Chapter 4: Software support 4-42...

  • Page 164: Rog Cpu-Z

    4.14 ROG CPU-Z This utility gathers information about the main devices installed in your system and displays it in an ROG custom layout. ROG CPU-Z provides you information and status of your CPU, motherboard, memory, graphics card, and other components installed in your system. You can generate a report about your system info and send or post it on the CPU-Z website. To use ROG CPU-Z, double-click on the desktop. ASUS CROSSBLADE RANGER 4-43...
  • Page 165 Chapter 4: Software support 4-44...

  • Page 166: Chapter 5: Raid Support

    With the RAID 10 configuration you get all the benefits of both RAID 0 and RAID 1 configurations. Use four new hard disk drives or use an existing drive and three new drives for this setup. ASUS CROSSBLADE RANGER...

  • Page 167: Installing Serial Ata Hard Disks

    5.1.2 Installing Serial ATA hard disks The motherboard supports Serial ATA hard disk drives. For optimal performance, install identical drives of the same model and capacity when creating a disk array. To install the SATA hard disks for a RAID configuration: Install the SATA hard disks into the drive bays.
  • Page 168 The RAID BIOS setup screens shown in this section are for reference only, and may not exactly match the items on your screen. To create a RAID volume using more than four hard disk drives, ensure that the SATA connectors 5/6 are set to [RAID] mode. ASUS CROSSBLADE RANGER...

  • Page 169: Creating A Raid Volume

    Creating a RAID volume To create a RAID volume: In the Main Menu, press <2> to enter the LD View / LD Define Menu function. Press <Ctrl> + <C>, and the following screen appears. Option ROM Utility (c) 2009 Advanced Micro Devices, Inc. [ LD Define Menu ] LD No LD Name...

  • Page 170: Deleting A Raid Configuration

    LD Name RAID Mode Capacity(GB) xxxxx RAID 0 157.99 Strip Block 64 KB Cache Mode WriteThru [ Drives Assignments ] Port:ID Drive Model Capabilities Capacity(GB) 01:00 xxxxxxxxx xxxxxxx xxxxxx 02:00 xxxxxxxxx xxxxxxx xxxxxx Any Key To Continue..ASUS CROSSBLADE RANGER...

  • Page 171: Install The Raid Driver During Windows ® Os Installation
