Page 1: User Guide
VN247 Series LCD Monitor User Guide... -
Page 2: Table Of Contents
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. -
Page 4: Safety Information
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. -
Page 5: Care & Cleaning
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. •... - Page 6 Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com Optional documentation Your product package may include optional documentation that may have been added by your dealer.
-
Page 7: Welcome
® Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a crisper, broader, and brighter display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual... -
Page 8: Assembling The Monitor Base
Assembling the monitor base Attach the base to the arm. Beware to align the latch to the notch on the base. The end of the arm will slightly protrude from the base. No need to push it in. Screw the base to the arm tightly. •... -
Page 9: Monitor Introduction
Exit the OSD menu or go back to the previous menu as the OSD menu is active. Button: • Press this button to decrease the value of the function selected or move to the next function. • This is also a hotkey for Volume adjustment. ASUS LCD Monitor VN247 Series... - Page 10 MENU Button: • Press this button to enter the OSD menu. • Press this button to enter/select the icon (function) highlighted while the OSD is activated. • Press this button over five seconds to enable or disable the key lock function.
-
Page 11: Rear Of The Lcd Monitor
1.5.2 Rear of the LCD monitor AC-IN port HDMI port VGA port Audio - in Port Earphone - out Port Kensington Lock Screw Holes for VESA Wall Mount Control buttons ASUS LCD Monitor VN247 Series... -
Page 12: Quickfit Function
1.5.3 QuickFit Function The QuickFit function contains three patterns: (1) Grid (2) Paper size (3) Photo size. Grid pattern: Facilitates designers and users to organize content and layout on one page and achieve a consistent look and feel. Alignment Grid Paper size: Provides users to view their documents in real size on the screen. -
Page 13: Detaching The Arm/Stand (For Vesa Wall Mount)
Hold the stand while removing the screws. • The VESA wall mount kit ( 100 x 100 mm) is purchased separately. • Use only the UL Listed Wall Mount Bracket with minimum weight/load 22.7kg (Screw size: M4 x 10 mm). ASUS LCD Monitor VN247 Series... -
Page 14: Adjusting The Monitor
Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling while changing its angle. -
Page 15: Osd (On-Screen Display) Menu
VN247 Splendid Scenery Mode Color Standard Mode Image Theater Mode Input Select Game Mode System Setup Night View Mode sRGB Reading Mode Darkroom Mode Move Menu Exit ASUS LCD Monitor VN247 Series... - Page 16 • Scenery Mode: This is the best choice for scenery photo displaying with SplendidPlus Video Intelligence Technology. • Standard Mode: This is the best choice for document editing with SplendidPlus Video Intelligence Technology. • Theater Mode: This is the best choice for movie watching with SplendidPlus Video Intelligence Technology.
- Page 17 0 to faster 100. • Aspect Control: Adjusts the aspect ratio to “Full”, “4:3”,“Overscan”. • Vividpixel: ASUS Exclusive Technology that brings lifelike visuals for crystal-clear and detail-oriented enjoyment. The adjusting range is from 0 to 100.
-
Page 18: Input Select
• 4:3 is only available when input source is in 4:3 format. OverScan is only available for the HDMI input source. • Phase adjusts the phase of the pixel clock signal. With a wrong phase adjustment, the screen shows horizontal disturbances. •... - Page 19 • Key Lock: To disable all function keys. Press the MENU button over five seconds to cancel the key lock function. • Information: Displays the monitor information. • All Reset: Selects “Yes” to revert all settings to the factory default mode. ASUS LCD Monitor VN247 Series...
-
Page 20: Specifications
3.2 Specifications Model VN247HA Panel Size 23.6”W (59.9cm) Max. Resolution 1920 x 1080 Brightness (Typ.) 250cd/m Intrisinc Contrast Ratio (Typ.) 1000:1 Viewing Angle (CR≤10) 178°(V) ; 178°(H) Display Colors 16.7 M Response Time (Typ.) 5 ms (Gray to Gray) D-Sub input... -
Page 21: Troubleshooting (Faq)
• Make sure the audio cable is properly connected to the monitor. • Adjust the volume settings of both your monitor and computer. • Make sure the computer sound card driver is properly installed and activated. ASUS LCD Monitor VN247 Series... -
Page 22: Supported Timing List
Supported Timing List VESA / IBM Modes Support Timing Resolution Refresh Rate Horizontal Frequency 640 x 350 70Hz 31.469KHz 640 x 480 60Hz 31.469KHz 640 x 480 67Hz 35KHz 640 x 480 75Hz 37.5KHz 720 x 400 70Hz 31.469KHz 800 x 600 56Hz 35.156KHz 800 x 600...
