projectiondesign as
addendum
This addendum contains a decription of the special features
which are different from a standard type projector. Please
refer to the main user guide of the product for important in-
formation about safety precautions and the set-up and use of
the projector. Make sure to read both the standard user guide
and this addendum carefully before you operate the projector.
Dieser Anhang enthält eine Beschreibung der besonderen
Merkmale, die sich von denen eines normalen Projektors
unterscheiden. Für wichtige Informationen in Bezug auf die
Sicherheitsvorkehrungen und den Aufbau und die Benutzung
des Projektors schauen Sie bitte in die Gebrauchsanweisung
für das Produkt. Lesen Sie bitte die Gebrauchsanweisung und
diesen Anhang aufmerksam durch, bevor Sie den Projektor in
Benutzung nehmen.
Le présent addenda présente les caractéristiques particulières
qui diffèrent de celles d'un projecteur de série. Pour les con-
signes de sécurité importantes et les indications concernant
la configuration et le maniement de l'appareil, reportez-vous
au guide d'utilisation principal. Lisez soigneusement le guide
standard ainsi que cet addenda avant de mette le projecteur
en service.
Esta adenda contiene una descripción de las funciones
especiales que se diferencian de las de un proyector de tipo
estándar. Por favor, remitirse a la guía del usuario principal del
producto, para información importante sobre las precau-
ciones de seguridad y la configuración y el uso del proyector.
Procurar leer detenidamente tanto la guía del usuario estándar
como esta adenda antes de poner en marcha el proyector.
Il presente allegato illustra le caratteristiche speciali differenti
rispetto a un proiettore standard. Fare riferimento alla Guida
dell'utente principale del prodotto per informazioni importanti
sulle precauzioni di sicurezza, la configurazione e l'uso del
proiettore. Leggere attentamente sia la Guida dell'utente
standard che questo allegato prima di utilizzare il proiettore.
Dette addendumet inneholder en beskrivelse av de egen-
skapene som avviker fra en standard projektor. Sjekk med
produktes komplette brukerveiledning for viktig informasjon
om sikkerhets-tiltak, oppsett og bruk av projektoren. Les både
den komplette brukerveiledningen og addendumet nøye før
projektoren tas i bruk.
FS35
IR PROJECTORS
WUXGA / WQXGA
w ww . pr oj ec t i o ndesi g n. co m
Advertisement
Related Manuals for Barco FS35
Summary of Contents for Barco FS35
- Page 1 FS35 IR PROJECTORS addendum WUXGA / WQXGA This addendum contains a decription of the special features which are different from a standard type projector. Please refer to the main user guide of the product for important in- formation about safety precautions and the set-up and use of the projector.
-
Page 3: Table Of Contents
Contents Introduction Features Menus Product Use Compatibility... -
Page 4: Introduction
1 Introduction The FS35 is a state of the art NVG (Night Vision Goggle) stimulation LED projector which include a fourth LED light chip that emits infrared light beyond the range visible to the human eye. The product is capable of visualizing night-time and limited-visibility scenario simulation as well as visible day-time or pitch black scenarios from the common display engine in order to have a true-to-life simulation. - Page 5 2.5 Dual Channel Input FS35 WUXGA allows dual input so the user can have separate content on IR LED and RGB LEDs simultaneously. In this mode the IR LED will display the source connected to DVI 1/HDMI 1, while RGB LEDs are used to display source connected to DVI 2/HDMI 2. The RGB LEDs are turned off when the IR source is displayed to allow best possible night-time or limited-visibility simulation.
-
Page 6: Menus
3 Menus 3.1 BrilliantColor Sequences There are 5 sequences to choose in the REALCOLOR menu. These displays differently when it comes to sequence modes for color points versus lumens output. • Vizsim • Graphics • HighBrightness • SRP 6ms (smear reduction) •... - Page 7 Dim mode custom: Dimming scheme for limited visibility scenarios, enabling the user to sepa- rately adjust the values of the R, G and B intensity in order to tune in the low light visibility match- ing the projected content. 3.3 IR menu WUXGA A separate IR menu which works with each BrilliantColor sequence listed above, controls the infrared and visual RGB performance.
- Page 8 RGB LEDs: Turns visible RGB LED’s on/off. Dim mode standard: Dimming options from full to minimum with color processing turned on so the white point is kept constant throughout the range. Appropriate use for daytime and evening scenarios. Dim mode custom: Dimming scheme for limited visibility scenarios, enabling the user to separately adjust the values of the R, G and B intensity in order to tune in the low light visibility matching the projected content.
-
Page 9: Product Use
For basic operations, set-up and safety precautions, please refer to the main user guide included with the product. The FS35 is capable of displaying both daytime images, as well as night vision stimulated content using the fourth infrared chip in the display engine. By operating and adjusting the dedicated IR Menu options described in the MENU section, the projector is able to display the full spectrum of the simulation scenarios (see examples below). -
Page 10: Compatibility
5 Compatibility Examples of supported Night Vision-goggles: (not a complete list, a selection of the most common in the market today) • Gen 1 • Gen 2 • Gen 2+ Russian • Gen 2+ • Gen 2 SuperGen • Gen 2 XD-4 •... - Page 12 ©2010 projectiondesign AS. All rights reserved. All brands and trade names are the property of their respective owners. Specifications subject to All brands and trade names are the property of their respective owners. Specifications subject to change without prior notice. change without prior notice.
