- Page 1 FS-FL40 MKII series User Manual ENABLING BRIGHT OUTCOMES...
- Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
- Page 3 Barco. Changes Barco provides this manual 'as is' without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
- Page 4 This software and the accompanying files are sold “as is” and without warranties as to performance or merchantability or any other warranties whether expressed or implied. In no event shall Barco be liable for damage of any kind, loss of data, loss of profits, business interruption or other pecuniary loss arising directly or indirectly.
-
Page 5: Table Of Contents
Remote control, battery installation ........................26 3.6.2 Remote control, protocol setup ...........................27 3.6.3 Functionality overview..............................28 3.6.4 Remote control, on/off button..........................28 3.6.5 Function of the RGB filter button ........................29 3.6.6 Enable / Disable Remote Control........................29 3.6.7 Wired RC connection..............................30 R5913251 /00 FS-FL40 MKII series... - Page 6 Profiles setup parameters ................................48 Create new profile ..................................49 7 3D ............................................53 Setup 3D mode....................................54 8 Upgrade projector firmware.................................57 Upgrade procedure..................................58 9 User maintenance — Cleaning the projector ......................59 Projector lenses ....................................60 Projector cabinet .....................................60 Filters ........................................60 Index ..........................................61 R5913251 /00 FS-FL40 MKII series...
-
Page 7: Safety And Environmental Information
Use in this document of the term, FL40 , means that the content is applicable for the following products: • FL40 - WU • FL40 - 4K • FS40 - WU • FS40 - 4K Defining the FL40 platform The FL40 series products in general, are all products within the Barco GP5 platform R5913251 /00 FS-FL40 MKII series... -
Page 8: General Considerations
HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to themselves or other persons. Only Barco authorized SERVICE PERSONNEL, knowledgeable of such risks, are allowed to perform service functions inside the product enclosure. The term USER and OPERATOR refers to any person other than SERVICE PERSONNEL. - Page 9 To prevent fire hazard • Barco projection products are designed and manufactured to meet the most stringent safety regulations. This projector radiates heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe. Exposing flammable or combustible materials into close proximity of this projector could result in the spontaneous ignition of that material, resulting in a fire.
- Page 10 • Unplug this product from the wall outlet and refer servicing to Barco authorized service personnel or technicians under the following conditions: If liquid has been spilled into the equipment.
-
Page 11: Safety Symbols Fl40 / Fs40
• Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards. Unauthorized substitutions may void warranty. •... -
Page 12: Location Of Labels
For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/AboutBarco/weee WEEE Information This product conforms to all requirements of the EU Directive on waste electrical and electronic equipment (WEEE). -
Page 13: China Rohs Compliance
Electronic Products” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”. -
Page 14: Taiwan Rohs Compliance
Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products”... -
Page 15: Contact Information
傳真 (Fax)：02-7715 0298 電話 (Tel)：02-7715 0299 E-mail：service.taiwan@barco.com Importers contact information To find your local importer, contact Barco directly or one of Barco's regional offices via the contact information given on Barco's web site, www.barco.com. Contact information Norway factory Barco Fredrikstad as... - Page 16 Class A ITE (Information Technology Equipment) Warning : This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. 警告使用者: 此為甲類資訊技術設備，於居住環境中使用時，可能會造成射頻擾動，在此種情況下，使用者會 被要求採取某些適當的對策。 R5913251 /00 FS-FL40 MKII series...
-
Page 17: Important Notice
Important notice R5913251 /00 FS-FL40 MKII series... -
Page 18: Grinding Sound During Startup
This sound will appear every time the dimming disk needs to be calibrated during start up. Mechanical sound from the dimming disk can also be heard every time you adjust the LED power below 50% output. R5913251 /00 FS-FL40 MKII series... -
Page 19: Getting To Know The Projector
Getting to know the projector. Location of the main exterior components..................20 Service and maintenance ......................21 Power on / Standby button backlight indications ................21 LCD Panel ...........................21 Local keypad..........................25 Remote control..........................26 Projector Address .........................30 Connector panel ...........................31 R5913251 /00 FS-FL40 MKII series... -
Page 20: Location Of The Main Exterior Components
Main Components Image 3–2 Main exterior components matrix Component Component Item Number Item Number IR Receiver top Projector feet (x4) IR Receiver front LCD Panel Lens Key Pad Lens release handle Back Panel / Connectors R5913251 /00 FS-FL40 MKII series... -
Page 21: Service And Maintenance
General The FL40 / FS 40 projectors does not have any user serviceable parts. All service tasks must only be carried out by the manufacturer, or a Barco authorized service personnel or Barco technicians. 3.3 Power on / Standby button backlight... -
Page 22: Lcd Touch Panel
The GUI images in this manual are example illustrations and should be treated as such. While the name of the projector displayed in the illustrations may be different from the projector model you are currently using, the menu lay-out and functionality is identical. R5913251 /00 FS-FL40 MKII series... - Page 23 Notifications: The error and/or warning messages that are currently active. If no messages are active, this list will be empty. • Preview: A preview pane of the projected image. If no image is being projected, a test image is displayed instead. Image 3–5 Dashboard page Image 3–6 About page R5913251 /00 FS-FL40 MKII series...
-
Page 24: Osd Menu Mode
Ready mode is enabled either when the power cable is connected (after the startup sequence), or when pressing the Power Off for 4 seconds when the projector is in On mode. See chapter 5.4 Power Mode Transitions for a graphic presentation of the ready mode. R5913251 /00 FS-FL40 MKII series... -
Page 25: Local Keypad
Shortcut to input source menu on LCD. Use navigation keys to select and enable input. Shutter Enable and disable the lens shutter function. This is not a mechanical shutter, but it toggles the light source on and off. Backlight is red when the shutter are enabled. R5913251 /00 FS-FL40 MKII series... -
Page 26: Remote Control
Tip: Use alkaline batteries for optimum range and life time. Image 3–11 Insert (1) both lower tabs of the battery cover in the gaps at the bottom of the remote control, and press (2) the cover until it clicks in place. R5913251 /00 FS-FL40 MKII series... -
Page 27: Remote Control, Protocol Setup
Depending on the projector to control, the remote control can be switched between these protocols. Which protocol to use • The NEC protocol have to be used for Barco projectors based on the Pulse platform: Loki, Balder, F40. F70, F80, F90, HDX 4K, UDX, UDM and more.. •... -
Page 28: Functionality Overview
RCU off will extend the battery life time of the remote control. To activate the remote control press the on/off button. To deactivate the remote control press the on/off button again. Default when (re)placing batteries, is “ON”. R5913251 /00 FS-FL40 MKII series... -
Page 29: Function Of The Rgb Filter Button
Image 3–15 When all sensors are turned off, the projector will not receive any signals from the remote control. To enable the sensors again, use the keypad on the projector. Select which sensors to be disabled. R5913251 /00 FS-FL40 MKII series... -
Page 30: Wired Rc Connection
When the address is set, the projector can be controlled now: • with the RCU: only for addresses between 1 and 31. Broadcast Address Every projector has a broadcast (common) address '0' or '1'. The default address is '0'. R5913251 /00 FS-FL40 MKII series... -
Page 31: Connector Panel
HDCP compliant for sources up 165 Mhz HDMI Standard HDMI 2.0 For Projector Input HDBaseT Standard RJ45 8P8C For Projector Input Connector R5913251 /00 FS-FL40 MKII series... - Page 32 Getting to know the projector. R5913251 /00 FS-FL40 MKII series...
-
Page 33: Lenses
Lenses Approved lenses...........................34 Replace a lens ..........................34 Locking the lens position .......................36 R5913251 /00 FS-FL40 MKII series... -
Page 34: Approved Lenses
The keypad button will illuminate red when the shutter is activated. Press the shutter button again, or shutter Open on the remote, to deactivate the shutter and resume normal operation. The keypad button will illuminate white when the shutter is deactivated. R5913251 /00 FS-FL40 MKII series... - Page 35 Position the lens bayonet into the projector lens mount and support in place with one hand. Slide the lens lever to the far right. Verify that the lens is firmly in place before removing your hand from the lens. Image 4–2 Remove a lens Support the lens with one hand. R5913251 /00 FS-FL40 MKII series...
-
Page 36: Locking The Lens Position
Disable the lens shift function by entering the menu Home / System Settings / Service / Lens features Select the function to disable by the arrow keys, and disable the function by pressing the OK button. R5913251 /00 FS-FL40 MKII series... - Page 37 Image 4–6 Image 4–7 Tighten the screws indicated below. Tighten the screws indicated by the red circles for locking the vertical movement Tighten the screws indicated by the blue circles for locking the horizontal movement R5913251 /00 FS-FL40 MKII series...
- Page 38 Lenses Image 4–8 Reassemble the front cover. R5913251 /00 FS-FL40 MKII series...
-
Page 39: Getting The Projector Started
Getting the projector started Projector source and control connections ..................40 Power up the projector ........................43 Power down the projector......................43 Power mode transitions.........................43 Power modes ..........................45 Customize projector settings ......................45 User interface..........................46 R5913251 /00 FS-FL40 MKII series... -
Page 40: Projector Source And Control Connections
Connector Standard Display port Signal characteristics DP 1.2 Functionality Mandatory Max. cable length 2 m (24 AWG) - RBR; 2 m (24 AWG) – HBR1, HBR2 Supported Link Rate RBR, HBR1, HBR2 Scan format Progressive R5913251 /00 FS-FL40 MKII series... -
Page 41: Hdmi 2.0
100 m (Cat6a/7), Pixel Clock >225HHz, Video Datarate >5.3Gbps Max TMDS Clock Frequency 270 MHz Max video resolution supported 4096x2160 @30Hz HDCP Pass-Through Yes, from Source to Projector IR Extension Not Supported RS-232 Extension Not Supported R5913251 /00 FS-FL40 MKII series... -
Page 42: Control Interfaces
1 RJ45 Connector for projector control (not content) Protocols DHCP, TCP/IP, UDP/P Speed 10/100 Mbit/1000Mbit 5.1.3.3 USB-A port Specifications Parameter Value USB connector Type A Function Firmware upgrade using USB sticks Power Power 5V, max 1,5A (out) Standard USB 2.0 R5913251 /00 FS-FL40 MKII series... -
Page 43: Power Up The Projector
5.4 Power mode transitions 5.4.1 General Transition Diagram This diagram shows all modes available on the projector (unplug, ON, READY, ECO), and the actions necessary to change mode. R5913251 /00 FS-FL40 MKII series... -
Page 44: Power On Projector
The projector will power down through a cool down phase. The Power on/off button will BLINK WHITE during the transition from ON to READY. Once the projector is in READY, thePower on/off button will be lit WHITE. R5913251 /00 FS-FL40 MKII series... -
Page 45: Going From Ready To Eco Standby
Light source is switched off and projector electronics are powered down 5.6 Customize projector settings About The projector display, behavior and user interface can be adjusted to meet individual requirements. Options include:Menu/Settings/Themes • Adjust the OSD menu color R5913251 /00 FS-FL40 MKII series... -
Page 46: User Interface
ENTER 79 ENTER. Changes to values are implemented dynamically. Menu memory The OSD menu remembers the last selected sub–item as long as the projector is running. The menu memory is reset when restarting the projector from standby. R5913251 /00 FS-FL40 MKII series... -
Page 47: Gui - Profiles
GUI – Profiles Profiles introduction ........................48 Profiles setup parameters......................48 Create new profile ........................49 R5913251 /00 FS-FL40 MKII series... -
Page 48: Profiles Introduction
Realcolor • Brilliant Color mode • P7 desired values • P7 measured values Installation • Lens parameters, if available (only valid if recalled with same lens) Iris Focus Zoom • Lens shift (Vertical / Horizontal) R5913251 /00 FS-FL40 MKII series... -
Page 49: Create New Profile
Sync Delay value Sync Delay Invert On/Off 6.3 Create new profile Adjust the necessary projector set up values for the actual user case as described in the specific topics in this manual. Enter the menu Profiles R5913251 /00 FS-FL40 MKII series... - Page 50 GUI – Profiles Image 6–2 Select the Edit button Image 6–3 The Profile edit menu shows up. Image 6–4 Select New profile R5913251 /00 FS-FL40 MKII series...
- Page 51 The profile “video” are now created and saved. Repeat step 1 to 6 for creating of more profiles. Recall a profile. Enter the Menu/ Profile The stored profiles will be visible in the menu. Select the actual profile. R5913251 /00 FS-FL40 MKII series...
- Page 52 Set, or change the “Assign to preset slot” number, or delete the actual profile. It is not possible to add or remove selected features in an stored profile. Must then be deleted, and a new profile must be created. Image 6–8 R5913251 /00 FS-FL40 MKII series...
- Page 53 Passive stereo input. Use two channel input (two cables), one for each eye. Update frequency limited to 60 Hz for each channel. Dual Sequential input source (DVI or Displayport) must be used. No external sync signal required. R5913251 /00 FS-FL40 MKII series...
-
Page 54: Setup 3D Mode
Why change the 3D setup? While Barco can provide a 3D emitter and active shutter glasses as options to this projector, you are also free to use a 3D emitter and active shutter glasses of your own choice. Since glasses and emitter can have various specifications compared to the ones Barco can provide, the 3D setup menu allows you to configure the output image to the specifications of your glasses and emitter. - Page 55 • Sync Delay: You can increase or decrease the sync delay. The scale goes from –10 000 µs to +10 000 µs with a step of 100 µs. R5913251 /00 FS-FL40 MKII series...
- Page 56 R5913251 /00 FS-FL40 MKII series...
-
Page 57: Upgrade Projector Firmware
Upgrade projector firmware Upgrade procedure........................58 R5913251 /00 FS-FL40 MKII series... -
Page 58: Upgrade Procedure
The LCD display will show the progression and status of the upgrade during the process. Update • Go to www.barco.com and select your product. All available firmware downloads are filed under the Technical Downloads tab. • Download the firmware. Extract and save the file to a USB stick with FAT file system. Use the eject function on your PC to safely remove the device from the computer. -
Page 59: User Maintenance - Cleaning The Projector
User maintenance — Cleaning the projector Projector lenses..........................60 Projector cabinet ..........................60 Filters ............................60 R5913251 /00 FS-FL40 MKII series... -
Page 60: Projector Lenses
This equipment is intended to operate in a “normal” environment, without any exposure to extreme amounts of dust or moisture. and by that also shipped without any kind filters for the air intake. There are filters for extreme environments available, contact your dealer for more info. R5913251 /00 FS-FL40 MKII series... -
Page 61: Index
Disposal Information 12 LAN/Ethernet 42 LCD 21 LCD functionality in Ready Mode 24 LCD information mode. 22 Enable / Disable Remote Control 29 LCD Panel 21 Lens lock 36 Lenses 33 local keypad 25 Filters 60 R5913251 /00 FS-FL40 MKII series... - Page 62 39 power up 39 Projector address 30 Controlling 30 Projector source and control connections 40 RCU 26 Battery Installation 26 Functionality overview 28 Protocol setup 27 RCU on/off 28 Replace a lens 34 RS-232 42 R5913251 /00 FS-FL40 MKII series...
- Page 64 R5913251 /00 | 2020-08-26 Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com...
