- Page 1 Altitude™ 4521 Series Access Point Installation Guide Extreme Networks, Inc. 3585 Monroe Street Santa Clara, California 95051 (888) 257-3000 (408) 579-2800 http://www.extremenetworks.com Published: October 2012 Part number: 120790-00 Rev 02...
- Page 2 Purple Extreme Solution, ExtremeXOS ScreenPlay, ReachNXT, Sentriant, ServiceWatch, Summit, SummitStack, Triumph, Unified Access Architecture, Unified Access RF Manager, UniStack, the Extreme Networks logo, the Alpine logo, the BlackDiamond logo, the Extreme Turbodrive logo, the Summit logos, and the Powered by ExtremeXOS logo are trademarks or registered trademarks of Extreme Networks, Inc.
-
Page 3: Table Of Contents
Table of Contents Chapter 1: Introduction....................5 Document Conventions....................... 6 Warnings............................. 7 Site Preparation .......................... 7 Package Contents ........................7 Features............................8 Chapter 2: Hardware Installation ..................9 Installation Instructions ....................... 9 Precautions ..........................10 Access Point Placement ......................10 Antenna Options ........................ 11 Power Injector System....................... - Page 4 Table of Contents Safety in Hospitals......................51 RF Exposure Guidelines ......................52 Safety Information ......................52 International ..........................52 EU ............................. 52 US and Canada ........................53 Power Supply..........................53 Radio Frequency Interference Requirements – FCC..............54 Radio Frequency Interference Requirements – Canada ............54 Radio Transmitters ......................
-
Page 5: Chapter 1: Introduction
Point is an enterprise class 802.11n Access Point, installed in minutes anywhere a CAT-5e (or better) cable is located. An Altitude 4521 Series Access Point utilizes a setup wizard to define its operational mode as either a Dependent mode AP, Standalone AP or Virtual Controller AP. -
Page 6: Document Conventions
The Altitude 4521 Series Access Point is approved under MODEL: NCAP-500. Extreme Networks recommends the Access Point receive power and transfer data through the same CAT-5e (or better) Ethernet cable using an Extreme Networks approved Power Injector. The Power Injector (Part No. AP-PSBIAS-2P2-AFR) is an 802.3af PoE injector. For information, see “Power Injector System”... -
Page 7: Warnings
Prepare Ethernet port connections. ● Verify cabling is within the maximum 100 meter allowable length. ● Package Contents The Access Point ships with the following: One Altitude 4521 Series Access Point ● Installation Guide (This Guide) ● Rubber Wall Mount Spacers (4) ●... -
Page 8: Features
DC power connector ● An Altitude 4521 Series Access Point has one RJ-45 connector supporting an 10/100/1000 Ethernet port connection and requires 802.3af compliant power from an external source. The Access Point contains runtime firmware which enables the unit to boot after either a power up or a watchdog reset. -
Page 9: Chapter 2: Hardware Installation
C H A P T E R Installation Instructions An Altitude 4521 Series Access Point can attach to a wall, mount under a suspended T-Bar or mount above a ceiling. Selecting a mounting option based on the physical environment of the coverage area. Do not mount the Access Point in a location that has not been approved in a site survey. -
Page 10: Precautions
Chapter 2: Hardware Installation 4 Determine whether the Access Point is powered using a Power Injector system, combining data and power to the Access Point’s GE1/PoE port, or is powered from a conventional power adapter providing power only to the Access Point’s DC-48V connector. -
Page 11: Antenna Options
Access Point. Antenna Options Extreme Networks supports various antennas for the single radio, dual-band Altitude 4521 Series Access Point. These antennas support the 2.4 GHz band, the 5 GHz band, or both. Select an antenna best suited to the intended operational environment of your Access Point. -
Page 12: Power Injector System
Chapter 2: Hardware Installation For a more exhaustive overview of the antennas supported by the Extreme Networks Access Point family, refer to the Enterprise Wireless LAN Antenna Specification Guide and Enterprise Wireless LAN Antenna Specification Guide Addendum documents available from http://www.extremenetworks.com/go/documentation... - Page 13 Access Point Placement The following guidelines should be adhered to before cabling the Power Injector to an Ethernet source and an Access Point: Do not block or cover airflow to the Power Injector. ● Keep the Power Injector away from excessive heat, humidity, vibration and dust. ●...
-
Page 14: Wall Mount Installation
Chapter 2: Hardware Installation CAUTION To avoid problematic performance and restarts, disable PoE from a wired controller port connected to an Access Point if mid-span power sourcing equipment (PSE) is used between the two, regardless of the manufacturer. CAUTION Ensure AC power is supplied to the Power Injector using an AC cable with an appropriate ground connection approved for the country of operation. - Page 15 Wall Mount Installation 3 At each point, drill a hole in the wall, insert an anchor, screw into the anchor the wall mounting screw and stop when there is 1mm between the screw head and the wall. If pre-drilling a hole, the recommended hole size is 2.8mm (0.11in.) if the screws are going directly into the wall and 6mm (0.23in.) if wall anchors are being used.
-
Page 16: Suspended Ceiling T-Bar Installation
Chapter 2: Hardware Installation 9 Verify the behavior of the Access Point LEDs. For more information, see “LED Indicator” on page 10 The Access Point is ready to configure. For information on basic Access Point device configuration, see “Defining a Basic Configuration” on page Suspended Ceiling T-Bar Installation A suspended ceiling mount requires holding the Access Point up against the T-bar of a suspended ceiling grid and twisting the Access Point chassis onto the T-bar. - Page 17 Suspended Ceiling T-Bar Installation CAUTION Do not connect to the power source until the cabling of the Access Point is complete. Ensure PoE is not connected to the Access Point’s console connector or risk rendering the console connector permanently inoperable. 5 Verify the behavior of the Access Point LEDs.
-
Page 18: Above The Ceiling (Plenum) Installation
UL approved and certification of UL2043 compliance would be void in that case. CAUTION Extreme Networks does not recommend mounting the Access Point directly to suspended ceiling tile with a thickness less than 12.7mm (0.5in.) or a suspended ceiling tile with an unsupported span greater than 660mm (26in.). - Page 19 Above the Ceiling (Plenum) Installation CAUTION Extreme Networks recommends care be taken not to damage the finished surface of the ceiling tile when creating the light pipe hole and installing the light pipe. 6 Remove the light pipe’s rubber stopper (from the Access Point) before installing the light pipe.
-
Page 20: Led Indicator
15 The Access Point is ready to configure. For information on basic Access Point device configuration, see “Using the Initial Setup Wizard” on page LED Indicator An Altitude 4521 Series Access Point has a single LED activity indicator on the front of the unit. Altitude™ 4521 Series Access Point Installation Guide... - Page 21 LED Indicator The LED provides a status display indicating error conditions, transmission, and network activity for the 5 GHz 802.11a/n (amber) radio or the 2.4 GHz 802.11b/g/n (green) radio. Task 5 GHz Activity LED (Amber) 2.4 GHz Activity LED (Green) Unadopted Blinking 5 times per second Normal...
- Page 22 Chapter 2: Hardware Installation Altitude™ 4521 Series Access Point Installation Guide...
-
Page 23: Chapter 3: Defining A Basic Configuration
Configuration C H A P T E R An Altitude 4521 Series Access Point can utilize an initial setup wizard to streamline the process of initially accessing the wireless network. The wizard defines the Access Point’s operational mode, deployment location, basic security, network and WLAN settings. - Page 24 Chapter 3: Defining a Basic Configuration 2 Point the Web browser to the Access Point’s IP address. The following login screen displays: 3 Enter the default username admin in the Username field. 4 Enter the default password admin123 in the Password field. 5 Click the Login button to load the management interface.
- Page 25 Using the Initial Setup Wizard 6 If this is the first time the management interface has been accessed, a dialogue displays to start the wizard. Select Start Wizard to run the initial setup wizard. Altitude™ 4521 Series Access Point Installation Guide...
- Page 26 Chapter 3: Defining a Basic Configuration The first page of the Initial AP Setup Wizard displays the Navigation Panel and Introduction for the configuration activities comprising the Access Point's initial setup A green checkmark to the left of an item in the Navigation Panel defines the listed task as having its minimum required configuration parameters set correctly.
- Page 27 Using the Initial Setup Wizard The Introduction screen displays a list of the basic configuration activities supported by the Initial Setup Wizard. 7 Select Save/Commit within each page to save the updates made to that page's configuration. Select Next to proceed to the next page listed in the Navigation Panel. Select Back to revert to the previous screen in the Navigation Panel without saving your updates.
- Page 28 Chapter 3: Defining a Basic Configuration 8 Select Next. The Initial AP Setup Wizard displays the Access Point Type screen to define the Access Point's Standalone versus Virtual Controller AP functionality and the way the Access Point is adopted to a controller. Altitude™...
- Page 29 Summit WM3000 Series Controller. NOTE If designating the Access Point as a Standalone AP, Extreme Networks recommends the Access Point’s UI be used exclusively to define its device configuration, and not the CLI. The CLI provides the ability to define more than one profile and the UI does not. Consequently, the two interfaces cannot be used collectively to manage profiles without an administrator encountering problems.
- Page 30 Chapter 3: Defining a Basic Configuration Select the Automatic controller discovery option to enable the Access Point to be discovered and adopted using layer 2 settings. If preferring layer 3 adoption, select the Static Controller Configuration option, and define the addresses of the preferred controllers.
- Page 31 Using the Initial Setup Wizard 10 Select Next. The Initial AP Setup Wizard displays the Access Point Mode screen to define the Access Point's routing or bridging mode functionality. Altitude™ 4521 Series Access Point Installation Guide...
- Page 32 Chapter 3: Defining a Basic Configuration 11 Select an Access Point Mode from the available options. Router Mode - In Router Mode, the Access Point routes traffic between the local ● network (LAN) and the Internet or external network (WAN). Router mode is recommended in a deployment supported by just a single Access Point.
- Page 33 Using the Initial Setup Wizard 12 Select Next. The Initial AP Setup Wizard displays the LAN Configuration screen to set the Access Point's LAN interface configuration. Altitude™ 4521 Series Access Point Installation Guide...
- Page 34 Use DHCP - Select the checkbox to enable an automatic network address ● configuration using the Access Point’s DHCP server. An Altitude 4521 Series Access Point does not have an onboard DHCP server and an external DHCP server must be utilized.
- Page 35 Using the Initial Setup Wizard 14 Select Next. The Initial AP Setup Wizard displays the WAN Configuration screen to set the Access Point's WAN interface configuration. Altitude™ 4521 Series Access Point Installation Guide...
- Page 36 16 Select Next. The Initial AP Setup Wizard displays the Radio Configuration screen to define support for the 2.4GHz radio band, 5GHz radio band or to set the radio's functionality as a dedicated sensor. An Altitude 4521 Series Access Point supports a single dual-band radio.
- Page 37 Using the Initial Setup Wizard NOTE The ADSP Sensor Support field displays at the bottom of the screen only if a radio has been dedicated as a sensor. 17 Set the following parameters for the radio: Configure as a Data Radio - Select this option to dedicate this radio for WLAN client ●...
- Page 38 Chapter 3: Defining a Basic Configuration NOTE If configuring an Altitude 4521 Series Access Point as a sensor, the Access Point will require a reboot before its sensor functionality is invoked. The reboot can take place at the completion of the Initial AP Setup Wizard.
- Page 39 Using the Initial Setup Wizard 18 Select Next. The Initial AP Setup Wizard displays the Wireless LAN Setting screen to define network address and security settings for two WLAN configurations available to the Access Point as part of the Initial AP Setup Wizard. Once the Access Point has an initial configuration defined, numerous additional WLAN configurations can be set.
- Page 40 Chapter 3: Defining a Basic Configuration 19 Set the following parameters for each of the two WLAN configurations available as part of this Initial AP Setup Wizard: SSID - Enter or modify the Services Set Identification (SSID) associated with the ●...
- Page 41 Using the Initial Setup Wizard NOTE If using the Access Point’s onboard RADIUS server, an additional RADIUS Server Configuration screen displays within the Navigation Panel on the left-hand side of the screen. Use this screen to create user accounts validated when the Access Point authenticates client connection requests to the onboard RADIUS server.
- Page 42 Chapter 3: Defining a Basic Configuration 21 Refer to the Username, Password, Description and Actions columns to review credentials of existing RADIUS Server user accounts. Add new accounts or edit the properties of existing accounts as updates are required. 22 Refer to the Add On-Board RADIUS Server Users field to set the following parameters for a user account: Username - If adding a new user account, create a username up to X characters in ●...
- Page 43 Using the Initial Setup Wizard 24 Select Next. The Initial AP Setup Wizard displays the Country/Date/Time screen to set device deployment, administrative contact and system time information. The system time can either be set manually or be supplied by a dedicated Network Time Protocol (NTP) resource.
- Page 44 Location - Define the location of the Access Point. The Location parameter acts as a ● reminder of where the AP can be located within the Extreme Networks managed wireless network. Contact - Specify the contact information for the administrator. The credentials ●...
- Page 45 Using the Initial Setup Wizard There's no user intervention or additional settings required within this screen. Its an additional means of validating the configuration before its deployed. However, if a screen displays settings not intended as part of the initial configuration, the screen can be selected from within the Navigation Panel and its settings modified accordingly.
- Page 46 Chapter 3: Defining a Basic Configuration Altitude™ 4521 Series Access Point Installation Guide...
-
Page 47: Chapter 4: Specifications
Specifications C H A P T E R Electrical Characteristics An Altitude 4521 Series Access Point has the following electrical characteristics: Max DC Power Consumption 12.95W (270mA@48V) Physical Characteristics An Altitude 4521 Series Access Points has the following physical characteristics: Dimensions 6.0 (Length) x 5.5 (Width) x 1.63 (Tall) - Inches... -
Page 48: Radio Characteristics
Electrostatic +/-15kV Air and +/-8kV Contact @ 50% Relative Humidity Discharge Radio Characteristics An Altitude 4521 Series Access Points has the following radio characteristics: Radio Characteristic Altitude 4521 Series Access Point High Power Operating Channel (2.4 GHz) Channel 1 to 13 (2412 to 2472 MHz) -
Page 49: Chapter 5: Regulatory Information
This guide applies to Part Numbers AP4521i-US, AP4521i-ROW, AP4521e-US and AP4521e-ROW. Altitude 4521 Series Access Points are approved under MODEL: NCAP-500. All Extreme Networks devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. -
Page 50: Country Selection - Note For Ap & Wireless Controller
Wireless Device Country Approvals Please refer to the Declaration of Conformity (DoC) for details of other country markings. This http://www.extremenetworks.com/go/rfcertification.htm. is available at Note: For 2.4GHz or 5GHz Products: Europe includes, Austria, Belgium, Bulgaria, Czech Republic, Cyprus, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland and the United Kingdom. -
Page 51: Health And Safety Recommendations
Health and Safety Recommendations Health and Safety Recommendations Warnings for the use of Wireless Devices Please observe all warning notices with regard to the usage of wireless devices Potentially Hazardous Atmospheres – Fixed Installations You are reminded of the need to observe restrictions on the use of radio devices in fuel depots, chemical plants etc. -
Page 52: Rf Exposure Guidelines
International The device complies with internationally recognized standards covering human exposure to electromagnetic fields from radio devices. For information on “International” human exposure to eletromagnic fields refer to the Extreme Networks Declaration of Conformity http://www.extremenetworks.com/go/rfcertification.htm. (DoC) at Remote and Standalone Antenna Configurations... -
Page 53: Us And Canada
US and Canada US and Canada Co-located statement To comply with FCC RF exposure compliance requirements, the antennas used with this transmitter must not be co-located, or operating in conjunction, with any other transmitter/ antenna except those already approved in this filling. Remote and Standalone Antenna Configurations To comply with FCC RF exposure requirements, antennas that are mounted externally at remote locations or operating near users at stand-alone desktop of similar configurations... -
Page 54: Radio Frequency Interference Requirements - Fcc
Radio Frequency Interference Requirements – FCC Radio Frequency Interference Requirements – This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 55: Radio Transmitters
Italy requires a user license for outside usage. ● Statement of Compliance Extreme Networks hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A Declaration of http://www.extremenetworks.com/go/rfcertification.htm. Conformity may be obtained from... -
Page 56: Waste Electrical And Electronic Equipment (Weee)
Waste Electrical and Electronic Equipment (WEEE) Waste Electrical and Electronic Equipment (WEEE) English: For EU Customers: All products at the end of their life must be returned to Extreme Networks for recycling. For information on how to return product, please go to: http://www.extremenetworks.com/go/eu-weee. - Page 57 Suomi: Asiakkaat Euroopan unionin alueella: Kaikki tuotteet on palautettava kierrätettäväksi Extreme Networks-yhtiöön, kun tuotetta ei enää käytetä. Lisätietoja tuotteen palauttamisesta on osoitteessa http://www.extremenetworks.com/go/eu-weee. Dansk: Til kunder i EU: Alle produkter skal returneres til Extreme Networks til recirkulering, når de er udtjent. Læs oplysningerne om returnering af produkter på: http://www.extremenetworks.com/go/eu-weee.
-
Page 58: Japan (Vcci) - Voluntary Control Council For Interference Class B Ite
Japan (VCCI) - Voluntary Control Council for Interference Class B ITE Japan (VCCI) - Voluntary Control Council for Interference Class B ITE の 装 置 は 、 情 報 処 理 装 置 等 電 波 障 害 自 主 規 制 協 議 会 （ Ｖ Ｃ Ｃ Ｉ ） の 基 準 に 基 づ く ク ラ... -
Page 59: Other Countries
Brazil Regulatory declarations for - BRAZIL Note: The certification mark applied to the Altitude 4521 Series Access Point is for Restrict Radiation Equipment. This equipment operates on a secondary basis and does not have the right for protection against harmful interference from other users including same equipment types. -
Page 60: Taiwan
Other Countries Taiwan NOTICE! According to: Administrative Regulations on Low Power Radio Waves Radiated Devices Article 12 Without permission granted by the DGT, any company, enterprise, or user is not allowed to change frequency, enhance transmitting power or alter original characteristic as well as performance to an approved low power radio-frequency devices. -
Page 61: Korea
Other Countries Korea For radio equipment using 2400~2483.5MHz or 5725~5825MHz, the following expressions should be displayed: 1 “This radio equipment can be interfered with during operation.” 당 해 무 선 설 비 는 운 용 중 전 파 혼 신 가 능 성 이 있 음 2 “This radio equipment cannot provide a service relevant to human life safety, as it can be crossed”... -
Page 62: Chapter 6: Customer Support
C H A P T E R NOTE Services can be purchased from Extreme Networks or through one of its channel partners. If you are an end-user who has purchased service through an Extreme Networks channel partner, please contact your partner first for support. -
Page 63: Documentation
Chapter 6: Customer Support Documentation Check for the latest versions of documentation on the Extreme Networks documentation website at: http://www.extremenetworks.com/go/documentation Altitude™ 4521 Series Access Point Installation Guide...
