Page 1: Installation Manual
MONITOR WITH DVD RECEIVER KVT-536DVD KVT-536DVDM INSTALLATION MANUAL © B54-4752-00/00 (MW/M2W) - Page 2 Accessories KVT-536DVD/KVT-536DVDM ...1 ...1 ...2 ...1 ...4 ...4...
-
Page 3: Installation Procedure
Installation Procedure 1. To prevent a short circuit, remove the key from the ignition and disconnect the - battery. 2. Make the proper input and output wire connections for each unit. 3. Connect the speaker wires of the wiring harness. 4. -
Page 4: Connecting Wires To Terminals
Connect to the terminal that is grounded when either the telephone rings or during conversation. To connect the Kenwood navigation system, consult your navigation manual. Depending on what antenna you are using, connect either to the control terminal of the motor antenna, or to the power terminal for the booster amplifier of the film-type or short pole type antenna. - Page 5 Wiring harness (Accessory 1) REVERSE ILLUMI STEERING WHEEL REMOTE CONT REMOTE INPUT MUTE ANT CONT P. CONT Cooling fan FM/AM antenna input Wiring harness AV IN (Accessory 2) REAR VIEW CAMERA AV OUT REAR/SUB WOOFER FRONT White/Black To front left speaker White Gray/Black To front right speaker...
-
Page 6: Optional Accessory Connection
USB terminal To KCA-BT200 (Optional Accessory) TV Tuner (Optional Accessory) UNIT MONITOR Connection cable (Included in the TV tuner) KVT-536DVD/KVT-536DVDM Audio Input Resistance-free stereo type mini plug (3.5Ф) Visual Input (Yellow) Resistance-free mini plug (3.5Ф) USB terminal INPUT ANTENNA ⁄... -
Page 7: Installation/Removing The Unit
Installation/Removing the Unit Installation Make sure that the unit is installed securely in place. If the unit is unstable, it may malfunction (eg, the sound may skip). Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. English... -
Page 8: Removing The Unit
• The frame can be removed from the top side in the same manner. 2. When the lower level is removed, remove the upper two locations. KVT-536DVD/KVT-536DVDM Removing the Unit 1. Remove the hard rubber frame by referring to the removal procedure in the section <Removing the Hard Rubber Frame>. -
Page 9: Installing In Japanese-Made Cars
Installing in Japanese-made Cars Installation on Toyota, Nissan or Mitsubishi Car using Brackets at Holes shown by "●" Accessory 5 (M5x6mm) or Accessory 6 (M5x7mm) Screws (included in audio unit package) ⁄ • Do not use your own screws. Use only the screws provided. If you use the wrong screws, you could damage the unit. - Page 10 Accessory 5 (M5x6mm) Screws (included in audio unit package) 2. Bend each end of case to fix the bracket. KVT-536DVD/KVT-536DVDM Car Bracket Use a flat-blade screwdriver or pliers, and bend each case tab into the hole of installation bracket to fix the bracket.
