“RUSSIAN SET”
When this is set to ON, the following character
strings are displayed in Russian. (Folder name/ File
name/ Song title/ Artist name/ Album name)
OFF/ON
“P-OFF WAIT”
Setting the timer to turn this unit’s power OFF
automatically when Standby mode continues. Using
this setting can save the vehicle’s battery power.
– – –: Power OFF Timer function is OFF.
20M: Turns the power OFF after 20 minutes.
40M: Turns the power OFF after 40 minutes.
60M: Turns the power OFF after 60 minutes.
“BUILT-IN AUX”
When this is set to ON, AUX source can be selected.
(“BUILTIN AUX”)
ON1: Outputs the sound of external unit connected
to the AUX terminal when switched to AUX
source.
ON2: Activates the attenuator function when
turning on the power with AUX source
selected. Cancel the attenuator function
by turning the volume knob clockwise
when listening to the audio of the external
equipment.
OFF: Disables the selection of AUX source. Set to
OFF when not using the AUX terminal.
“CD READ”
Sets the method for reading CD.
1: Automatically distinguishes between audio file
disc and music CD when playing disc.
2: Forces playing as music CD.
“SWITCH PREOUT”
Switches the preout between rear output (“REAR”)
(“SWITCH PRE”)
and subwoofer output (“SUB-W”)
REAR/SUB-W
“SP SELECT”
Fine-tuning so that the System Q value is optimal
when setting the speaker type as follows;
SP OFF: OFF
SP 5/4: For 5 & 4 in. speaker
SP 6*9/6: For 6 & 6x9 in. speaker
SP OEM: For the OEM speaker
“F/W UP”
Display the firmware version and update the
firmware.
MEDIA USB: Select a USB device.
MEDIA CD: Select CD.
(With the KDC-BT30, CD is selected.)
For how to update the firmware, access our web
site.
http://www.kenwood.com/cs/ce/
(Factory setting: Underlined)
4
Make a setting
Turn the [VOL] knob and press it when the
desired item is displayed.
5
Exit Function Setting mode
Press the [
] button for at least 1 second.

Removing the Faceplate

The faceplate of the unit can be detached and taken
with you, helping to deter theft.
Detach the faceplate
Press the Release button.
Reattaching the Faceplate
Refer to the following diagram when
reattaching the faceplate.
¤
• After pressing the Release button, detach the faceplate
immediately. If the faceplate is left attached, it can fall
due to vibration and so on.
• The faceplate is a precision piece of equipment and can
be damaged by shocks or jolts.
• Keep the faceplate in its faceplate case while detached.
• Do not place the faceplate (and the faceplate case)
in areas exposed to direct sunlight, excessive heat or
humidity. Also avoid places with too much dust or the
possibility of water splashing.

How to Reset Your Unit

If the unit fails to operate properly, press the Reset
button. The unit returns to factory settings when
the Reset button is pressed.
1
Release the faceplate lock so that it can be
removed.
Refer to <Removing the Faceplate> (page 19).
2
Press the Reset button and reattaching the
faceplate.
Reset button
Page 19
