Crestron TPMC-4SMD Operations & Installation Manual

4.3” designer touch screen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Crestron TPMC-4SMD
4.3" Designer Touch Screen
Operations & Installation Guide

Advertisement

Table of Contents
loading

Related Manuals for Crestron TPMC-4SMD

Summary of Contents for Crestron TPMC-4SMD

  • Page 1 Crestron TPMC-4SMD 4.3” Designer Touch Screen Operations & Installation Guide...
  • Page 2 Microsoft Corporation in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.

  • Page 3: Table Of Contents

    Crestron TPMC-4SMD 4.3” Designer Touch Screen Contents 4.3” Designer Touch Screen: TPMC-4SMD Introduction ..........................1 Features and Functions ....................1 Applications......................... 5 Specifications ......................6 Physical Description ....................8 Setup ............................11 Network Wiring ......................11 Identity Code ......................11 Configuring the Touch Screen ...................

  • Page 5: Designer Touch Screen: Tpmc-4Smd

    An incredibly thin profile and small footprint allow the TPMC-4SMD to be installed in places other touch screens just cannot go, providing the choice of mounting to a standard electrical box or to virtually any flat surface, even glass, granite or marble.
  • Page 6 Available with black or white smooth finish Advanced Touch Screen Control A Crestron touch screen offers an ideal user interface for controlling all the technology in a home, boardroom, classroom, courtroom or command center. Touch screens do away with piles of remote controls, cluttered wall switches and cryptic computer screens, simplifying and enhancing the technology.

  • Page 7: Proximity Sensor

    Single Wire Connectivity A simple Ethernet LAN connection is all that is required to wire the TPMC-4SMD, containing all control, video, intercom and power signals in a single wire. Power over Ethernet Using PoE technology, the TPMC-4SMD gets its operating power right through the LAN wiring.
  • Page 8 Crestron TPMC-4SMD Occupancy Sensing Crestron GLS series room occupancy sensors can be connected directly to the TPMC-4SMD to allow automation of the room’s lighting, climate control and other devices. Simple, Versatile Mounting The TPMC-4SMD installs easily on virtually any mounting surface. As standard, it...

  • Page 9: Applications

    Crestron TPMC-4SMD 4.3” Designer Touch Screen Applications The following diagram shows a TPMC-4SMD in a typical application. TPMC-4SMD in a Typical Application 4.3” Designer Touch Screen: TPMC-4SMD • 5 Operations & Installation Guide – DOC. 7027E...

  • Page 10: Specifications

    4.3” Designer Touch Screen Crestron TPMC-4SMD Specifications Specifications for the TPMC-4SMD are listed in the following table. TPMC-4SMD Specifications SPECIFICATION DETAILS Touch Screen Display Display Type TFT active matrix color LCD Size 4.3 inch (109 mm) diagonal Aspect Ratio 16:9 WVGA...
  • Page 11 TouchPoint Virtual Mouse & Keyboard ® Software for Windows 1. Wakes the touch screen and backlight. 2. Refer to “Identity Code” on page 11 for details. 4.3” Designer Touch Screen: TPMC-4SMD • 7 Operations & Installation Guide – DOC. 7027E...

  • Page 12: Physical Description

    4.3” Designer Touch Screen Crestron TPMC-4SMD Physical Description This section provides information on the connections, controls and indicators available on the TPMC-4SMD. TPMC-4SMD Physical View 8 • 4.3” Designer Touch Screen: TPMC-4SMD Operations & Installation Guide – DOC. 7027E...
  • Page 13 Crestron TPMC-4SMD 4.3” Designer Touch Screen TPMC-4SMD Overall Dimensions (Front, Bottom and Rear Views) 3.47 in (89 mm) 6.20 in (158 mm) 0.75 in (19 mm) 1.21 in (31 mm) 0.46 in (12 mm) 1.70 in (44 mm) 2.36 in (60 mm) 2.00 in...
  • Page 14 Crestron GLS Series occupancy sensors The pin out table indicates signal connections. dc power applied by Ethernet power sourcing equipment (PSE) can connect to either signal pins or N/C pins. 10 • 4.3” Designer Touch Screen: TPMC-4SMD Operations & Installation Guide – DOC. 7027E...

  • Page 15: Setup

    The IP ID is set within the TPMC-4SMD’s IP table using Crestron Toolbox™. For information on setting an IP table, refer to the Crestron Toolbox help file. The IP IDs of multiple TPMC-4SMD devices in the same system must be unique.

  • Page 16: Ethernet Setup

    Connection, MAC and IP addresses and to access the Control System Settings and IP Address Settings buttons and their respective submenus. Touch Back to return to the “Panel Setup Options” menu. 12 • 4.3” Designer Touch Screen: TPMC-4SMD Operations & Installation Guide – DOC. 7027E...
  • Page 17 To add an IP entry to a blank slot, first touch Add IP. The “Edit Control System Settings” screen is displayed, as shown in the illustration below. “Edit Control System Settings” Screen 4.3” Designer Touch Screen: TPMC-4SMD • 13 Operations & Installation Guide – DOC. 7027E...
  • Page 18 (refer to the middle illustration on page 13). Removing an entry displays a message saying Please Confirm IP Table Entry Removal By Pressing the OK Button, as shown in the illustration below. 14 • 4.3” Designer Touch Screen: TPMC-4SMD Operations & Installation Guide – DOC. 7027E...
  • Page 19 13). From the “Control System Interface” menu, touch Back to return to the “Ethernet Setup” menu. On the TPMC-4SMD, DHCP is enabled by default. To switch to a static IP address, touch IP Address Settings on the “Ethernet Setup” menu, to access the “Edit IP Address Settings”...

  • Page 20: Display Settings

    LCD Wake Options screens. Touch Back to return to the “Panel Setup Options” menu. Touch Key LED Options to enter the “Key LED Options” screen, shown in the illustration below. 16 • 4.3” Designer Touch Screen: TPMC-4SMD Operations & Installation Guide – DOC. 7027E...

  • Page 21: Audio Setup

    “Panel Setup Options” menu. Audio Setup On the “Panel Setup Options” menu, touch Audio Setup to display the “Audio Settings” screen, shown in the illustration below. 4.3” Designer Touch Screen: TPMC-4SMD • 17 Operations & Installation Guide – DOC. 7027E...

  • Page 22: Standby Setup

    120 minutes. Touch Back to return to the “Panel Setup Options” menu. Diagnostics On the “Panel Setup Options” menu, touch Diagnostics to display the “Diagnostics” menu, shown in the illustration below. 18 • 4.3” Designer Touch Screen: TPMC-4SMD Operations & Installation Guide – DOC. 7027E...
  • Page 23 From the main “Diagnostics” menu, the Touch Test button displays the following screen, with a Calibrate button to initiate touch screen calibration. The Calibrate Touch button on the “Diagnostics” menu also initiates touch screen calibration. 4.3” Designer Touch Screen: TPMC-4SMD • 19 Operations & Installation Guide – DOC. 7027E...
  • Page 24 Inactive to Active as appropriate for each sensor’s activity. Similarly, the TPMC-4SMD’s own proximity sensor’s indicator changes from Inactive to Active when the TPMC-4SMD senses motion in front of the unit. Use the Sensor Strength controls to adjust proximity sensor sensitivity. Touch Back to return to the “Diagnostics”...
  • Page 25 4.3” Designer Touch Screen Mic Test In Progress Screen Speak into the microphone on the front of the TPMC-4SMD and the recording is played back to confirm the microphone is functioning. After playback, the button reverts to its original Mic Test label.

  • Page 26: Changing The Button Inserts

    Crestron TPMC-4SMD Changing the Button Inserts The TPMC-4SMD ships with 10 “hard key” push buttons for quick access to commonly used functions. For a clean appearance, either column of buttons may be removed and covered using the no-button covers provided.

  • Page 27: Installation

    The TPMC-4SMD is supplied with screws for installation into an electrical box. Mounting in a US Electrical Box NOTE: When mounting the TPMC-4SMD into an electrical box, the box must be installed horizontally. To mount the TPMC-4SMD into an electrical box, use the following procedure: Insert a small slot head screwdriver into the hole shown in the following illustration and gently separate the back of the TPMC-4SMD.
  • Page 28 NOTE: Use the left and right screw holes for attachment to the electrical box. Mounting the TPMC-4SMD into an Electrical Box Carefully position the front of the TPMC-4SMD over the back panel and gently snap it into place, as shown in the following illustration.
  • Page 29 Crestron TPMC-4SMD 4.3” Designer Touch Screen Use two of the included #04-40 x 1/4” screws to secure the TPMC-4SMD, as shown in the following illustration: For standard applications, use the Phillips screws (2007152 or 2007160). For secure applications, use the security type Torx screws (2025311 or 2025312) along with the included Torx screwdriver bit (2025915).
  • Page 30 Insert a small slot head screwdriver into the hole shown in the illustration at the top of page 21 and gently separate the back of the TPMC-4SMD. Use the two included #4B x 3/4” screws (2019088) to attach the back panel to the electrical box, as shown in the following illustration.

  • Page 31: Hardware Hookup

    Make the necessary connections as called out in the illustration that follows this paragraph. Apply power after all connections have been made. When making connections to the TPMC-4SMD, use Crestron power supplies for Crestron equipment. Hardware Connections for the TPMC-4SMD...

  • Page 32: Uploading And Upgrading

    Finally, program checks can be performed (such as changing the device ID or creating an IP table) to ensure proper functioning. NOTE: Crestron software and any files on the Web site are for authorized Crestron dealers and Crestron Service Providers (CSPs) only. New users must register to obtain access to certain areas of the site (including the FTP site).

  • Page 33: Programs, Projects And Firmware

    Crestron Toolbox. For details on uploading and upgrading, refer to the Crestron Studio help file, SIMPL Windows help file, VT Pro-e help file or the Crestron Toolbox help file.

  • Page 34: Problem Solving

    4.3” Designer Touch Screen Crestron TPMC-4SMD Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPMC-4SMD Troubleshooting TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION Device does not...

  • Page 35: Further Inquiries

    Crestron worldwide offices on the Crestron Web site (www.crestron.com/offices) for assistance within a particular geographic region. To post a question about Crestron products, log onto the Online Help section of the Crestron Web site (www.crestron.com/onlinehelp). First-time users must establish a user account to fully benefit from all available features.
  • Page 36 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 7027E 15 Volvo Drive Rockleigh, NJ 07647 (2028205) Tel: 888.CRESTRON 02.15 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
